Summary of Contents for Audio Authority DuoDrive 9870D
- Page 1 Model 9870D (9871, 9879) Residential Category 5 HDTV Distribution System Installation and User Manual...
- Page 2 ™ Overview The DuoDrive (Model 9870D) allows HDTV signals to be distributed throughout the home from a single source. Component video (YPbPr), analog stereo audio, and digital audio (coaxial) sigals are included in each two-cable Cat 5 pathway. By connecting IR remote control systems to the DuoDrive system, users can easily control the source equipment from other rooms in the house.
- Page 3 Installing the 9871 Driver Mount the (first) 9871 Driver to any flat vertical or horizontal surface using the screws provided. You may wish to leave space to add 9871 Drivers to expand output capacity. Connect component video and all audio connections desired from the source equipment to the inputs of the 9871.
- Page 4 Cat 5, Cat 5e, or Cat 6 Cable In Case of Difficulty If any problems arise that are not covered in this manual, call Audio Authority Technical Support at 800-322-8346, or outside the US and Canada, call 859-233-4599. 18-volt power supply PN 571-014...
