- Page 1 054-7150-2 1/3 SHEET SANDER INSTRUCTION IMPORTANT: Read and understand this instruction manual thoroughly MANUAL before using the product.
-
Page 2: Table Of Contents
headline bars TABLE OF CONTENTS Technical Specifications Safety Guidelines Key Parts Diagram Operating Instructions continuation tabs Maintenance Troubleshooting Parts List Warranty notes warnings NOTE: If any parts are missing or damaged, or if you have any questions, please call our toll-free helpline at 1-800-689-9928. SAVE THESE INSTRUCTIONS •... -
Page 3: Technical Specifications
054-7150-2 | contact us 1-800-689-9928 SAFETY GUIDELINES TECHNICAL SPECIFICATIONS WARNING! Rated voltage 120V~, 60 Hz Safety symbols in this instruction manual are used to flag possible dangers. The safety Rated power input symbols and their explanations require your full understanding. The safety warnings do not,... - Page 4 054-7150-2 | contact us 1-800-689-9928 ELECTRICAL SAFETY • Do not use the power tool if the switch does not turn it on and off. Any power tool that cannot be controlled with the switch is dangerous and must be repaired.
-
Page 5: Key Parts Diagram
054-7150-2 | contact us 1-800-689-9928 PACKAGE CONTENTS: • The label on your tool may include the following symbols. The symbols and their definitions are as follows: 1/3 sheet sander, 1pc sanding paper, dust box, punch plate and instruction manual. -
Page 6: Operating Instructions
054-7150-2 | contact us 1-800-689-9928 USING THE DUST BOX (fig 2) OPERATING INSTRUCTIONS fig 2 Before attempting to use this sander, familiarize yourself with all its operating features and safety To install: Press dust box port down to the slot of the requirements. -
Page 7: Maintenance
054-7150-2 | contact us 1-800-689-9928 MAINTENANCE TROUBLESHOOTING Before cleaning or performing any maintenance, make sure that the sander has been disconnected Problem Possible Causes Solution from the power supply. Keep all ventilation openings clean. Avoid using solvents when cleaning plastic Cooling vents may be obstructed by Clean, clear vents. - Page 8 054-7150-2 | contact us 1-800-689-9928 EXPLODED VIEW Part No. Description Part No. Description 3128074000 Left housing 2751036000 Rotor 4960273000 Carbon brush 5660029000 E ring 2740098000 Stator 5650187000 Washer 3120309000 Switch actuator 3128080000 Dust fan...
-
Page 9: Warranty
This Mastercraft product is guaranteed for a period of 3 years from the date of original retail Notice to Consumer...
