Read this manual carefully before operating this vehicle.
OWNER'S MANUAL
XJR1300C
2PN-28199-E1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the XJR1300 and is the answer not in the manual?

Questions and answers

Related Manuals for Yamaha XJR1300

Summary of Contents for Yamaha XJR1300

  • Page 1 Read this manual carefully before operating this vehicle. OWNER’S MANUAL XJR1300C 2PN-28199-E1...
  • Page 2 EAU70220 Read this manual carefully before operating this vehicle. This manual should stay with this vehicle if it is sold. YAMAHA MOTOR ELECTRONICS CO., LTD. 1450-6, Mori, Mori-machi, Shuchi-gun, Shizuoka-ken, 437-0292 Japan DECLARATION of CONFORMITY Product: IMMOBILIZER Model: 5WM-10 Supplied by...
  • Page 3 EAU10103 Welcome to the Yamaha world of motorcycling! As the owner of the XJR1300C, you are benefiting from Yamaha’s vast experience and newest technology regarding the design and manufacture of high-quality products, which have earned Yamaha a reputation for dependability.

  • Page 4: Important Manual Information

    Important manual information EAU10134 Particularly important information is distinguished in this manual by the following notations: This is the safety alert symbol. It is used to alert you to potential personal injury hazards. Obey all safety messages that follow this symbol to avoid possible injury or death.
  • Page 5 Important manual information EAU10201 XJR1300C OWNER’S MANUAL ©2015 by Yamaha Motor Co., Ltd. 1st edition, December 2015 All rights reserved. Any reprinting or unauthorized use without the written permission of Yamaha Motor Co., Ltd. is expressly prohibited. Printed in Japan.

  • Page 6: Table Of Contents

    Table of contents Safety information......1-1 Sidestand ........3-21 Cast wheels ........6-18 Ignition circuit cut-off system ..3-22 Clutch lever........6-18 Description ........2-1 Checking the brake lever free Left view ......... 2-1 For your safety – pre-operation play..........6-18 Right view........2-2 checks ..........4-1 Brake light switches .....
  • Page 7 Table of contents Replacing the headlight bulb..6-30 Replacing the auxiliary light bulb ..........6-31 Brake/tail light .......6-32 Replacing a turn signal light bulb ..........6-33 Replacing a license plate light bulb ..........6-33 Supporting the motorcycle....6-35 Front wheel........6-35 Rear wheel........6-37 Troubleshooting ......6-38 Troubleshooting chart ....6-40 Motorcycle care and storage ..7-1 Matte color caution ......7-1 Care ..........7-1...

  • Page 8: Safety Information

    Safety information  Never operate a motorcycle with- pears to be very effective in reduc- EAU1028B out proper training or instruction. ing the chance of this type of Take a training course. Beginners accident. Be a Responsible Owner should receive training from a cer- Therefore: As the vehicle’s owner, you are re- tified instructor.
  • Page 9 Safety information  Many accidents involve inexperi- • Always signal before turning or Protective Apparel enced operators. In fact, many op- changing lanes. Make sure that The majority of fatalities from motorcy- erators who have been involved in other motorists can see you. cle accidents are the result of head in- ...
  • Page 10 Safety information  Do not run engine outdoors where Avoid Carbon Monoxide Poisoning When loading within this weight limit, All engine exhaust contains carbon engine exhaust can be drawn into keep the following in mind:  Cargo and accessory weight monoxide, a deadly gas.
  • Page 11 Yamaha accessories, which are avail- performed to your vehicle that change lightweight as possible and able only from a Yamaha dealer, have any of the vehicle’s design or operation should be kept to a minimum. been designed, tested, and approved characteristics can put you and others •...

  • Page 12: Specifications

    Safety information  Check that the fuel cock (if operator and may limit control ability, therefore, such accesso- equipped) is in the “OFF” position ries are not recommended. and that there are no fuel leaks.  Use caution when adding electri- ...

  • Page 13: Description

    Description EAU10411 Left view 4 5 6 1. Front fork compression damping force adjusting screw (page 3-16) 8. Shock absorber assembly rebound damping force adjusting knob (pa- ge 3-18) 2. Front fork spring preload adjusting bolt (page 3-16) 9. Shock absorber assembly spring preload adjusting ring (page 3-18) 3.

  • Page 14: Right View

    Description EAU10421 Right view 1. Owner’s tool kit (page 6-2) 9. Engine oil level check window (page 6-10) 2. Rear brake fluid reservoir (page 6-20) 10.Brake pedal (page 3-12) 3. Battery (page 6-28) 11.Rear brake light switch (page 6-19) 4. Air filter element (page 6-13) 5.

  • Page 15: Controls And Instruments

    Description EAU10431 Controls and instruments 1. Clutch lever (page 3-10) 9. Brake lever (page 3-11) 2. Left handlebar switches (page 3-9) 10.Throttle grip (page 6-15) 3. Clutch fluid reservoir (page 6-20) 11.Main switch/steering lock (page 3-2) 4. Speedometer (page 3-5) 5.

  • Page 16: Instrument And Control Functions

     Do not expose any key to exces- cess, take the vehicle along with all three keys to a Yamaha dealer to have sively high temperatures.  Do not place any key close to them re-registered. Do not use the key with the red bow for driving.

  • Page 17: Main Switch/Steering Lock

    Instrument and control functions  Keep other immobilizer system EAU10474 EAU38531 Main switch/steering lock keys away from the main switch All electrical circuits are supplied with as they may cause signal inter- power; the meter lighting, taillight, li- ference. cense plate light and auxiliary light come on, and the engine can be start- ed.
  • Page 18 Instrument and control functions The steering must be locked before the EAU10696 LOCK key can be turned to “ ”. The steering is locked and all electrical If the steering will not lock, try turning ECA11021 systems are off. The key can be re- the handlebars back to the right or left NOTICE moved.

  • Page 19: Indicator Lights And Warning Lights

    1 2 3 4 5 6 circuit monitoring the engine. If this oc- This warning light comes on if the en- curs, have a Yamaha dealer check the 1. Left turn signal indicator light “ ” gine oil level is low.

  • Page 20: Speedometer

    “ON”, ECA10032 NOTICE or if the indicator light remains on, have a Yamaha dealer check the electrical Do not operate the engine in the ta- circuit. chometer red zone. The self-diagnosis device also detects...

  • Page 21: Multi-Function Display

    Instrument and control functions  fuel reserve tripmeter The fuel reserve tripmeter shows the EAU4324C Multi-function display  fuel meter distance traveled on the fuel reserve.  clock  self-diagnosis device  The odometer will lock at 999999.  brightness control mode ...
  • Page 22 If this occurs, have a and traveling 5 km (3 mi). 5. Use the reset button to set the mi- Yamaha dealer check the electrical cir- nutes. cuit. Fuel meter 6. Push the select button and then release it to start the clock.
  • Page 23 2. If the engine starts, turn it off and Brightness control mode note the code number, and then have try starting the engine with the a Yamaha dealer check the vehicle. standard keys. The self-diagnosis device also detects 3. If one or both of the standard keys...

  • Page 24: Handlebar Switches

    Instrument and control functions Right EAU1234K EAU12461 Handlebar switches Turn signal switch “ ” To signal a right-hand turn, push this Left switch to “ ”. To signal a left-hand turn, push this switch to “ ”. When released, the switch returns to the cen- ter position.

  • Page 25: Clutch Lever

    Instrument and control functions EAU41701 EAU12832 The engine trouble warning light will Clutch lever come on when the key is turned to “ON” and the start switch is pushed, but this does not indicate a malfunc- tion. EAU12735 Hazard switch “ ” With the key in the “ON”...

  • Page 26: Shift Pedal

    Instrument and control functions The brake lever is equipped with a EAU12872 EAU26825 Shift pedal Brake lever brake lever position adjusting dial. To adjust the distance between the brake lever and the throttle grip, turn the ad- justing dial while holding the lever pushed away from the throttle grip.

  • Page 27: Brake Pedal

    Instrument and control functions EAU12944 EAU13075 Brake pedal Fuel tank cap The fuel tank cap cannot be closed un- less the key is in the lock. In addition, the key cannot be removed if the cap is not properly closed and locked. EWA11092 WARNING Make sure that the fuel tank cap is...

  • Page 28: Fuel

    Gasoline is poisonous and can cau- fuel expands when it heats up, Your Yamaha engine has been de- se injury or death. Handle gasoline heat from the engine or the sun signed to use premium unleaded gas- with care.

  • Page 29: Fuel Tank Breather Hose And Overflow Hose

    10% (E10). Gas-  Do not park the vehicle near ohol containing methanol is not possible fire hazards such as recommended by Yamaha because it grass or other materials that can cause damage to the fuel system easily burn.

  • Page 30: Seat

    Instrument and control functions ECA10702 EAU13941 Seat NOTICE Use only unleaded gasoline. The use To remove the seat of leaded gasoline will cause unre- 1. Insert the key into the seat lock, pairable damage to the catalytic and then turn it clockwise. converter.

  • Page 31: Adjusting The Front Fork

    Instrument and control functions EAU14744 Spring preload setting: Adjusting the front fork Minimum (soft): EWA10181 WARNING Standard: Always adjust both fork legs equally, Maximum (hard): otherwise poor handling and loss of stability may result. This front fork is equipped with spring Rebound damping force preload adjusting...
  • Page 32 Instrument and control functions justment, it would be advisable to Rebound damping setting: check the number of clicks of each Minimum (soft): damping force adjusting mechanism 10 click(s) in direction (b)* Standard: and to modify the specifications as 5 click(s) in direction (b)* necessary.

  • Page 33: Adjusting The Shock Absorber Assembly

    Instrument and control functions 2. To increase the spring preload EAU43257 Adjusting the shock absorber and thereby harden the suspen- assembly sion, turn the adjusting ring in di- EWA10211 rection (a). To decrease the spring WARNING preload and thereby soften the Always adjust both shock absorber suspension, turn the adjusting ring assemblies equally, otherwise poor...
  • Page 34 Instrument and control functions Spring preload setting: Minimum (soft): Distance A = 0 mm (0 in) Standard: Distance A = 17 mm (0.67 in) Maximum (hard): Distance A = 28 mm (1.10 in) 3. Tighten the lock screw to the specified torque.

  • Page 35: Luggage Strap Holders

    To obtain a precise adjustment, it is sembly yourself. Take the shock advisable to check the actual total absorber assembly to a Yamaha number of clicks or turns of each dealer for any service. damping force adjusting mechanism.

  • Page 36: Exup System

    EAU15283 EAU15306 EXUP system Sidestand Yamaha dealer repair it if it does not This model is equipped with Yamaha’s The sidestand is located on the left function properly. EXUP (EXhaust Ultimate Power valve) side of the frame. Raise the sidestand system.

  • Page 37: Ignition Circuit Cut-Off System

    Instrument and control functions EAU44893 Ignition circuit cut-off system The ignition circuit cut-off system (comprising the sidestand switch, clutch switch and neutral switch) has the following functions.  It prevents starting when the transmission is in gear and the sidestand is up, but the clutch le- ver is not pulled.
  • Page 38 Instrument and control functions WARNING With the engine turned off: 1. Move the sidestand down. If a malfunction is noted, have a Yamaha 2. Make sure that the engine stop switch is set to “ ”. dealer check the system before riding.

  • Page 39: For Your Safety - Pre-Operation Checks

    • If necessary, add recommended oil to specified level. 6-10 • Check vehicle for oil leakage. • Check operation. • If soft or spongy, have Yamaha dealer bleed hydraulic system. • Check brake pads for wear. Front brake • Replace if necessary.
  • Page 40 • Make sure that operation is smooth. • Check throttle grip free play. Throttle grip 6-15, 6-24 • If necessary, have Yamaha dealer adjust throttle grip free play and lubricate ca- ble and grip housing. • Make sure that operation is smooth. Control cables 6-24 •...
  • Page 41 • Tighten if necessary. Instruments, lights, signals • Check operation. — and switches • Correct if necessary. • Check operation of ignition circuit cut-off system. Sidestand switch 3-21 • If system is not working correctly, have Yamaha dealer check vehicle.

  • Page 42: Operation And Important Riding Points

     a lean angle sensor to stop the en-  The transmission is in the neutral understand, ask your Yamaha dealer. gine in case of a turnover. In this EWA10272 position.

  • Page 43: Shifting

    The neutral indi- with the engine off, and do not cator light should come on. If not, tow the motorcycle for long dis- ask a Yamaha dealer to check the tances. The transmission is electrical circuit. properly lubricated only when 3.

  • Page 44: Tips For Reducing Fuel Consumption

    Yamaha dealer check the vehi- to the correct operating clearances. gine. cle. During this period, prolonged full-throt- ...

  • Page 45: Parking

    Operation and important riding points EAU17214 Parking When parking, stop the engine, and then remove the key from the main switch. EWA10312 WARNING  Since the engine and exhaust system can become very hot, park in a place where pedestri- ans or children are not likely to touch them and be burned.

  • Page 46: Periodic Maintenance And Adjustment

    To avoid possible burns, let tivities incorrectly may increase brake components cool before your risk of injury or death during touching them. service or while using the vehicle. If you are not familiar with vehicle ser- vice, have a Yamaha dealer perform service.

  • Page 47: Owner's Tool Kit

    If you do not have the tools or experi- ence required for a particular job, have a Yamaha dealer perform it for you.

  • Page 48: Periodic Maintenance Chart For The Emission Control System

     From 50000 km (30000 mi), repeat the maintenance intervals starting from 10000 km (6000 mi).  Items marked with an asterisk should be performed by a Yamaha dealer as they require special tools, data and tech- nical skills.

  • Page 49: General Maintenance And Lubrication Chart

    Periodic maintenance and adjustment EAU1770M General maintenance and lubrication chart ODOMETER READING ANNUAL ITEM CHECK OR MAINTENANCE JOB 1000 km 10000 km 20000 km 30000 km 40000 km CHECK (600 mi) (6000 mi) (12000 mi) (18000 mi) (24000 mi) √ Air filter element •...
  • Page 50 Periodic maintenance and adjustment ODOMETER READING ANNUAL ITEM CHECK OR MAINTENANCE JOB 1000 km 10000 km 20000 km 30000 km 40000 km CHECK (600 mi) (6000 mi) (12000 mi) (18000 mi) (24000 mi) • Check operation and for exces- √ √...
  • Page 51 Periodic maintenance and adjustment ODOMETER READING ANNUAL ITEM CHECK OR MAINTENANCE JOB 1000 km 10000 km 20000 km 30000 km 40000 km CHECK (600 mi) (6000 mi) (12000 mi) (18000 mi) (24000 mi) • Check operation and for oil leak- √...
  • Page 52 Periodic maintenance and adjustment  Hydraulic brake and clutch service • Regularly check and, if necessary, correct the brake fluid and clutch fluid levels. • Every two years replace the internal components of the brake master cylinders and calipers as well as clutch master and release cylinders, and change the brake and clutch fluids.

  • Page 53: Removing And Installing Panels

    Periodic maintenance and adjustment EAU18773 Removing and installing pan- The panels shown need to be removed to perform some of the maintenance jobs described in this chapter. Refer to this section each time a panel needs to be removed and installed. 1.

  • Page 54: Checking The Spark Plugs

    1/2 turn past finger tight. However, the Yamaha dealer. Since heat and depos- with a wire thickness gauge and, if spark plug should be tightened to the its will cause any spark plug to slowly necessary, adjusted to specification.

  • Page 55: Engine Oil And Oil Filter Element

    Periodic maintenance and adjustment 4. Remove the engine oil filler cap, EAU65421 Engine oil and oil filter ele- the engine oil drain bolt and its ment gasket to drain the oil from the The engine oil level should be checked crankcase.
  • Page 56 Periodic maintenance and adjustment 1. Drive sprocket cover 1. Oil filter element drain screw 1. O-ring 2. Bolt 2. Gasket 2. Oil filter element cover bolt 3. Oil filter element cover bolt 3. Oil filter element cover 6. Remove the oil filter element drain 4.
  • Page 57 Periodic maintenance and adjustment 13. Install the engine oil filter element Tightening torque: cover (together with the spring, Oil filter element drain screw: Be sure to wipe off spilled oil on any washer and oil filter element) by 7 Nm (0.7 m·kgf, 5.1 ft·lbf) parts after the engine and exhaust sys- aligning the projection on the cov- tem have cooled down.

  • Page 58: Replacing The Air Filter Element And Cleaning The Check Hose

    In addition, correct, immediately turn the engine 1. Bolt off and have a Yamaha dealer check the air filter check hose must be fre- 2. Right side cover the vehicle.
  • Page 59 Periodic maintenance and adjustment 2. If dirt or water is visible, remove the hose, clean it, and then install 1. Air filter element 8. Install the panel. 5. Insert a new air filter element into the air filter case. NOTICE: Make To clean the air filter check hose 1.

  • Page 60: Checking The Throttle Grip Free Play

    Therefore, it must be adjusted by a Yamaha dealer is essential to maintain the tires in good at the intervals specified in the periodic condition at all times and replace them maintenance and lubrication chart.
  • Page 61 * Total weight of rider, passenger, car- or glass fragments in it, or if the side- surface must first be “broken go and accessories wall is cracked, have a Yamaha dealer in” for it to develop its optimal replace the tire immediately. characteristics.
  • Page 62 2. Tire air valve core ed below have been approved for this surfaces until they have been 3. Tire air valve cap with seal model by Yamaha. “broken in”. Therefore, it is ad- This model is equipped with tubeless visable before doing any high- Front tire: tires and tire air valves.

  • Page 63: Cast Wheels

    1. No brake lever free play formed or cracked wheel must be is air in the hydraulic system, have a replaced. Yamaha dealer bleed the system be- There should be no free play at the  The wheel should be balanced fore operating the motorcycle.

  • Page 64: Brake Light Switches

    If necessary, adjust the rear brake light switch as follows, but the front brake light switch should be adjusted by a Yamaha dealer. Turn the rear brake light switch adjust- ing nut while holding the rear brake light switch in place. To make the brake light come on earlier, turn the ad- justing nut in direction (a).

  • Page 65: Checking The Brake And Clutch Fluid Levels

    1. Minimum level mark has almost disappeared, have a Clutch Yamaha dealer replace the brake pads as a set. 1. Minimum level mark 1. Minimum level mark The rear brake fluid reservoir is located behind panel A.

  • Page 66: Changing The Brake And Clutch Fluids

    Specified brake and clutch fluid: Changing the brake and ing point of the fluid and may re- DOT 4 brake fluid clutch fluids sult in vapor lock. Have a Yamaha dealer change the EWA16001 ECA17641 WARNING brake and clutch fluids at the intervals NOTICE...

  • Page 67: Drive Chain Slack

    EAU3431A To check the drive chain slack To adjust the drive chain slack 1. Place the motorcycle on the side- Consult a Yamaha dealer before ad- stand. justing the drive chain slack. 1. Loosen the axle nut and the lock- nut on each side of the swingarm.

  • Page 68: Cleaning And Lubricating The Drive Chain

    Periodic maintenance and adjustment 4. Make sure that the drive chain may contain substances that EAU23026 Cleaning and lubricating the pullers are in the same position, could damage O-rings. drive chain the drive chain slack is correct, [ECA11112] The drive chain must be cleaned and drive chain moves...

  • Page 69: Checking And Lubricating The Cables

    Yamaha dealer at the intervals bricated if necessary. cated if necessary. If a cable is specified in the periodic maintenance...

  • Page 70: Checking And Lubricating The Brake And Clutch Levers

    Periodic maintenance and adjustment EAU43602 Recommended lubricant: Recommended lubricant: Checking and lubricating the Lithium-soap-based grease Silicone grease brake and clutch levers The operation of the brake and clutch levers should be checked before each ride, and the lever pivots should be lu- bricated if necessary.

  • Page 71: Checking And Lubricating The Sidestand

    The swingarm pivots must be lubricat- ce and hold it in an upright posi- be checked before each ride, and the ed by a Yamaha dealer at the intervals tion. WARNING! To avoid injury, sidestand pivot and metal-to-metal specified in the periodic maintenance...

  • Page 72: Checking The Steering

    [EWA10752] the periodic maintenance and lubrica- 2. Hold the lower ends of the front have a Yamaha dealer check or re- tion chart. If there is play in the wheel fork legs and try to move them for- pair it.

  • Page 73: Battery

    To charge the battery  Electrolyte is poisonous and ge it if necessary. Have a Yamaha dealer charge the bat- 3. Fully charge the battery before dangerous since it contains sul- installation. NOTICE: When in-...

  • Page 74: Replacing The Fuses

    Periodic maintenance and adjustment key is turned to “OFF”, then EAU43274 Replacing the fuses 1 2 3 4 5 6 connect the positive lead before The main fuse is located under the connecting the negative lead. seat. (See page 3-15.) [ECA16841] 4.

  • Page 75: Replacing The Headlight Bulb

    4. If the fuse immediately blows again, have a Yamaha dealer check the electrical system. 1. Headlight coupler 2. Headlight bulb cover 1. Do not touch the glass part of the bulb.

  • Page 76: Replacing The Auxiliary Light

    6. Install the headlight unit by install- position, and then secure it with ing the screws. the bulb holder. 7. Have a Yamaha dealer adjust the 5. Install the bulb cover, and then headlight beam if necessary. connect the coupler.

  • Page 77: Brake/Tail Light

    6. Install the socket (together with If the brake/tail light does not come on, the bulb) by pushing it in. have a Yamaha dealer check it. 7. Install the cover in its original posi- tion. 8. Install the headlight unit by install- ing the screws.

  • Page 78: Replacing A Turn Signal Light Bulb

    Periodic maintenance and adjustment EAU24205 EAU65451 Replacing a turn signal light Replacing a license plate light bulb bulb 1. Remove the turn signal light lens 1. Remove the reflector by removing by removing the screw. the nut. 1. Turn signal light bulb 3.
  • Page 79 Periodic maintenance and adjustment 4. Remove the license plate light 7. Install the socket (together with bulb socket (together with the the bulb) by pushing it in, and then bulb) by turning it counterclock- turn it clockwise until it stops. wise, and then pulling it out.

  • Page 80: Supporting The Motorcycle

    Periodic maintenance and adjustment a jack either under each side of the EAU24351 EAU24361 Supporting the motorcycle Front wheel frame in front of the rear wheel or under Since this model is not equipped with a each side of the swingarm. centerstand, follow these precautions EAU65461 when removing the front and rear...
  • Page 81 Periodic maintenance and adjustment 2. Lift the front wheel off the ground To install the front wheel Tightening torques: according to the procedure in the 1. Lift the wheel up between the fork Wheel axle: previous section “Supporting the legs. 72 Nm (7.2 m·kgf, 52 ft·lbf) Front wheel axle pinch bolt: motorcycle”.

  • Page 82: Rear Wheel

    Periodic maintenance and adjustment EAU25081 Rear wheel EAU65470 To remove the rear wheel EWA10822 WARNING To avoid injury, securely support the vehicle so there is no danger of it 1. Brake caliper 1. Wheel axle falling over. 2. Brake caliper bracket 2.

  • Page 83: Troubleshooting

    3. Install the drive chain onto the rear self. However, should your motorcycle sprocket. require any repair, take it to a Yamaha 4. Connect the brake torque rod to dealer, whose skilled technicians have the brake caliper bracket by in- the necessary tools, experience, and stalling the bolt and the nut.
  • Page 84 Periodic maintenance and adjustment heaters or furnaces. Gasoline or gasoline vapors can ignite or ex- plode, causing severe injury or prop- erty damage. 6-39...

  • Page 85: Troubleshooting Chart

    Remove the spark plugs and check the electrodes. The engine does not start. Have a Yamaha dealer check the vehicle. Check the compression. 4. Compression The engine does not start. There is compression.

  • Page 86: Motorcycle Care And Storage

    Some models are equipped with matte colored finished parts. Be ble. Rust and corrosion can develop Cleaning sure to consult a Yamaha dealer for even if high-quality components are ECA10773 NOTICE used. A rusty exhaust pipe may go un-...
  • Page 87 Motorcycle care and storage off any detergent residue using shield. Test the product on a plenty of water, as it is harmful small hidden part of the wind- Salt sprayed on roads in the winter to plastic parts. shield to make sure that it does may remain well into spring.

  • Page 88: Storage

    EWA11132 poorly ventilated room or cover- WARNING ing it with a tarp, while it is still  Consult a Yamaha dealer for ad- Contaminants on the brakes or tires wet, will allow water and humid- can cause loss of control.
  • Page 89 Motorcycle care and storage 2. Fill up the fuel tank and add fuel e. Remove the spark plug caps stabilizer (if available) to prevent from the spark plugs, and then Make any necessary repairs before the fuel tank from rusting and the install the spark plugs and the storing the motorcycle.

  • Page 90: Specifications

    Specifications Dimensions: Engine oil: Clutch: Overall length: Recommended brand: Clutch type: 2190 mm (86.2 in) YAMALUBE Wet, multiple-disc Overall width: Type: Transmission: 820 mm (32.3 in) SAE 10W-40 Primary reduction ratio: Overall height: Recommended engine oil grade: 1.750 (98/56) 1120 mm (44.1 in) API service SG type or higher, JASO Final drive: Seat height:...
  • Page 91 Specifications Front tire: Front wheel: Spring/shock absorber type: Coil spring/gas-oil damper Type: Wheel type: Wheel travel: Tubeless Cast wheel 120 mm (4.7 in) Size: Rim size: Electrical system: 120/70 ZR17M/C (58W) 17M/C x MT3.50 Manufacturer/model: Rear wheel: System voltage: DUNLOP/D252F L 12 V Wheel type: Rear tire:...
  • Page 92 Specifications Neutral indicator light: 12 V, 1.7 W × 1 High beam indicator light: 12 V, 1.7 W × 1 Oil level warning light: 12 V, 1.7 W × 1 Turn signal indicator light: 12 V, 1.7 W × 2 Engine trouble warning light: 12 V, 1.7 W ×...

  • Page 93: Consumer Information

    These identification numbers are needed when registering the vehicle with the authorities in your area and when ordering spare parts from a Yamaha dealer. VEHICLE IDENTIFICATION NUMBER: 1. Vehicle identification number 1. Engine serial number The vehicle identification number is The engine serial number is stamped stamped into the steering head pipe.
  • Page 94 Consumer information The model label is affixed to the frame under the seat. (See page 3-15.) Re- cord the information on this label in the space provided. This information will be needed when ordering spare parts from a Yamaha dealer.

  • Page 95: Index

    Index Air filter element and check hose, Front and rear brake pads, checking ... 6-19 Neutral indicator light ......3-4 replacing and cleaning ....... 6-13 Front fork, adjusting ......3-16 Auxiliary light bulb, replacing ....6-31 Front fork, checking ......6-26 Oil level warning light......
  • Page 96 Index Troubleshooting ........6-38 Troubleshooting chart......6-40 Turn signal indicator lights......3-4 Turn signal light bulb, replacing....6-33 Turn signal switch ........3-9 Valve clearance........6-15 Vehicle identification number ....9-1 Wheel bearings, checking.....6-27 Wheel (front)..........6-35 Wheel (rear)...........6-37 Wheels ..........6-18 10-2...
  • Page 98 Original instructions PRINTED ON RECYCLED PAPER PRINTED IN JAPAN 2016.01-0.3×1 CR...
