Read this manual carefully before operating this vehicle.
OWNER'S MANUAL
XJR1300C
2PN-28199-EG

Advertisement

Table of Contents
loading

Related Manuals for Yamaha XJR1300C

Summary of Contents for Yamaha XJR1300C

  • Page 1 Read this manual carefully before operating this vehicle. OWNER’S MANUAL XJR1300C 2PN-28199-EG...
  • Page 2 EAU70220 Read this manual carefully before operating this vehicle. This manual should stay with this vehicle if it is sold. YAMAHA MOTOR ELECTRONICS CO., LTD. 1450-6, Mori, Mori-machi, Shuchi-gun, Shizuoka-ken, 437-0292 Japan DECLARATION of CONFORMITY Product: IMMOBILIZER Model: 5WM-10 Supplied by...
  • Page 3 Yamaha a reputation for dependability. Please take the time to read this manual thoroughly, so as to enjoy all advantages of your XJR1300C. The Owner’s Manual does not only instruct you in how to operate, inspect and maintain your motorcycle, but also in how to safeguard yourself and others from trouble and injury.

  • Page 4: Important Manual Information

    IMPORTANT MANUAL INFORMATION EAU10134 Particularly important information is distinguished in this manual by the following notations: This is the safety alert symbol. It is used to alert you to potential personal injury hazards. Obey all safety messages that follow this symbol to avoid possible injury or death.
  • Page 5 IMPORTANT MANUAL INFORMATION EAU10201 XJR1300C OWNER’S MANUAL ©2015 by Yamaha Motor Co., Ltd. 1st edition, April 2015 All rights reserved. Any reprinting or unauthorized use without the written permission of Yamaha Motor Co., Ltd. is expressly prohibited. Printed in Japan.

  • Page 6: Table Of Contents

    TABLE OF CONTENTS SAFETY INFORMATION ....1-1 EXUP system ........3-21 Tires ..........6-15 Sidestand ........3-21 Cast wheels ........6-18 DESCRIPTION ........2-1 Ignition circuit cut-off system ..3-22 Clutch lever........6-18 Left view ......... 2-1 Checking the brake lever free Right view........2-2 FOR YOUR SAFETY –...
  • Page 7 TABLE OF CONTENTS Replacing the fuses.......6-29 Replacing the headlight bulb..6-30 Replacing the auxiliary light bulb ..........6-32 Tail/brake light.......6-33 Replacing a turn signal light bulb ..........6-33 Replacing a license plate light bulb ..........6-34 Supporting the motorcycle....6-35 Front wheel........6-36 Rear wheel........6-37 Troubleshooting ......6-39 Troubleshooting chart ....6-40 MOTORCYCLE CARE AND STORAGE ..........7-1...

  • Page 8: Safety Information

    SAFETY INFORMATION  Never operate a motorcycle with- pears to be very effective in reduc- EAU1028B out proper training or instruction. ing the chance of this type of Take a training course. Beginners accident. Be a Responsible Owner should receive training from a cer- Therefore: As the vehicle’s owner, you are re- tified instructor.
  • Page 9 SAFETY INFORMATION  Many accidents involve inexperi- • Always signal before turning or Protective Apparel enced operators. In fact, many op- changing lanes. Make sure that The majority of fatalities from motorcy- erators who have been involved in other motorists can see you. cle accidents are the result of head in- ...
  • Page 10 SAFETY INFORMATION  Do not run engine outdoors where Avoid Carbon Monoxide Poisoning When loading within this weight limit, All engine exhaust contains carbon engine exhaust can be drawn into keep the following in mind:  Cargo and accessory weight monoxide, a deadly gas.
  • Page 11 Yamaha accessories, which are avail- performed to your vehicle that change lightweight as possible and able only from a Yamaha dealer, have any of the vehicle’s design or operation should be kept to a minimum. been designed, tested, and approved characteristics can put you and others •...

  • Page 12: Specifications

    SAFETY INFORMATION  Check that the fuel cock (if operator and may limit control ability, therefore, such accesso- equipped) is in the “OFF” position ries are not recommended. and that there are no fuel leaks.  Use caution when adding electri- ...

  • Page 13: Description

    DESCRIPTION EAU10411 Left view 4 5 6 1. Front fork compression damping force adjusting screw (page 3-16) 8. Shock absorber assembly rebound damping force adjusting knob (page 3-18) 2. Front fork spring preload adjusting bolt (page 3-16) 9. Shock absorber assembly spring preload adjusting ring (page 3-18) 3.

  • Page 14: Right View

    DESCRIPTION EAU10421 Right view 1. Owner’s tool kit (page 6-2) 9. Engine oil level check window (page 6-10) 2. Rear brake fluid reservoir (page 6-20) 10.Brake pedal (page 3-12) 3. Battery (page 6-28) 11.Rear brake light switch (page 6-19) 4. Air filter element (page 6-13) 5.

  • Page 15: Controls And Instruments

    DESCRIPTION EAU10431 Controls and instruments 1. Clutch lever (page 3-10) 9. Brake lever (page 3-11) 2. Left handlebar switches (page 3-9) 10.Throttle grip (page 6-15) 3. Clutch fluid reservoir (page 6-20) 11.Main switch/steering lock (page 3-2) 4. Speedometer (page 3-5) 5.

  • Page 16: Instrument And Control Functions

     Do not expose any key to exces- cess, take the vehicle along with all three keys to a Yamaha dealer to have sively high temperatures.  Do not place any key close to them re-registered. Do not use the key with the red bow for driving.

  • Page 17: Main Switch/Steering Lock

    INSTRUMENT AND CONTROL FUNCTIONS  Keep other immobilizer system EAU10474 EAU38531 Main switch/steering lock keys away from the main switch All electrical circuits are supplied with as they may cause signal inter- power; the meter lighting, taillight, li- ference. cense plate light and auxiliary light come on, and the engine can be start- ed.
  • Page 18 INSTRUMENT AND CONTROL FUNCTIONS To unlock the steering EAU10693 ECA11021 LOCK NOTICE The steering is locked, and all electrical Do not use the parking position for systems are off. The key can be re- an extended length of time, other- moved.

  • Page 19: Indicator Lights And Warning Lights

    1 2 3 4 5 6 circuit monitoring the engine. If this oc- This warning light comes on if the en- curs, have a Yamaha dealer check the 1. Left turn signal indicator light “ ” gine oil level is low.

  • Page 20: Speedometer

    “ON”, ECA10032 NOTICE or if the indicator light remains on, have a Yamaha dealer check the electrical Do not operate the engine in the ta- circuit. chometer red zone. The self-diagnosis device also detects...

  • Page 21: Multi-Function Display

    INSTRUMENT AND CONTROL FUNCTIONS  two tripmeters (which show the Odometer and tripmeter modes EAU65401 Multi-function display distance traveled since they were last set to zero)  a fuel reserve tripmeter (which shows the distance traveled on the fuel reserve) ...
  • Page 22 3. Reset button proximately 3 seconds. If this occurs, Fuel meter have a Yamaha dealer check the elec- The clock uses a 12-hour time system. trical circuit. To set the clock 1. Turn the key to “ON”.
  • Page 23 If a problem is detected in the immobi- key and both standard keys to a lizer system circuits, the immobilizer Yamaha dealer and have the stan- system indicator light will flash and the dard keys re-registered. display will indicate an error code.

  • Page 24: Handlebar Switches

    INSTRUMENT AND CONTROL FUNCTIONS This function allows you to adjust the Right EAU1234H Handlebar switches brightness of the multi-function dis- play, speedometer, and tachometer to Left suit the outside lighting conditions. To adjust the brightness 1. Turn the key to “OFF”. 2.

  • Page 25: Clutch Lever

    INSTRUMENT AND CONTROL FUNCTIONS ter position. To cancel the turn signal EAU12735 EAU12831 Hazard switch “ ” Clutch lever lights, push the switch in after it has re- With the key in the “ON” or “ ” posi- turned to the center position. tion, use this switch to turn on the haz- ard lights (simultaneous flashing of all EAU12501...

  • Page 26: Shift Pedal

    INSTRUMENT AND CONTROL FUNCTIONS EAU12872 EAU26825 Shift pedal Brake lever 1. Clutch lever position adjusting dial 2. Arrow mark 1. Shift pedal 1. Brake lever The clutch lever is equipped with a The shift pedal is located on the left The brake lever is located on the right clutch lever position adjusting dial.

  • Page 27: Brake Pedal

    INSTRUMENT AND CONTROL FUNCTIONS The brake lever is equipped with a EAU12944 EAU13075 Brake pedal Fuel tank cap brake lever position adjusting dial. To adjust the distance between the brake lever and the throttle grip, turn the ad- justing dial while holding the lever pushed away from the throttle grip.

  • Page 28: Fuel

    INSTRUMENT AND CONTROL FUNCTIONS EAU13213 Fuel The fuel tank cap cannot be closed un- Make sure there is sufficient gasoline in less the key is in the lock. In addition, the tank. the key cannot be removed if the cap is EWA10882 WARNING not properly closed and locked.

  • Page 29: Fuel Tank Breather Hose And Overflow Hose

    Your Yamaha engine has been de- signed to use premium unleaded gas- oline with a research octane number of 95 or higher. If knocking (or pinging)

  • Page 30: Catalytic Converters

    INSTRUMENT AND CONTROL FUNCTIONS EAU13446 ECA10702 EAU13941 Catalytic converters Seat NOTICE This vehicle is equipped with catalytic Use only unleaded gasoline. The use converters in the exhaust system. To remove the seat of leaded gasoline will cause unre- 1. Insert the key into the seat lock, EWA10863 pairable damage to the catalytic WARNING...

  • Page 31: Adjusting The Front Fork

    INSTRUMENT AND CONTROL FUNCTIONS EAU14744 Adjusting the front fork EWA10181 WARNING Always adjust both fork legs equally, otherwise poor handling and loss of stability may result. This front fork is equipped with spring preload adjusting bolts, rebound damping force adjusting screws and 1.
  • Page 32 INSTRUMENT AND CONTROL FUNCTIONS Spring preload setting: Rebound damping setting: Minimum (soft): Minimum (soft): 10 click(s) in direction (b)* Standard: Standard: 5 click(s) in direction (b)* Maximum (hard): Maximum (hard): 1 click(s) in direction (b)* * With the adjusting screw fully turned in direction (a) Rebound damping force To increase the rebound damping...

  • Page 33: Adjusting The Shock Absorber Assembly

    INSTRUMENT AND CONTROL FUNCTIONS justment, it would be advisable to 2. To increase the spring preload EAU43257 Adjusting the shock absorber check the number of clicks of each and thereby harden the suspen- assembly damping force adjusting mechanism sion, turn the adjusting ring in di- EWA10211 and to modify the specifications as rection (a).
  • Page 34 INSTRUMENT AND CONTROL FUNCTIONS Spring preload setting: Minimum (soft): Distance A = 0 mm (0 in) Standard: Distance A = 17 mm (0.67 in) Maximum (hard): Distance A = 28 mm (1.10 in) 3. Tighten the lock screw to the specified torque.
  • Page 35 To obtain a precise adjustment, it is sembly yourself. Take the shock advisable to check the actual total absorber assembly to a Yamaha number of clicks or turns of each dealer for any service. damping force adjusting mechanism.

  • Page 36: Luggage Strap Holders

    EAU15283 EAU15306 Luggage strap holders EXUP system Sidestand This model is equipped with Yamaha’s The sidestand is located on the left EXUP (EXhaust Ultimate Power valve) side of the frame. Raise the sidestand system. This system boosts engine or lower it with your foot while holding power by means of a valve that regu- the vehicle upright.

  • Page 37: Ignition Circuit Cut-Off System

    INSTRUMENT AND CONTROL FUNCTIONS this system regularly and have a EAU44893 Ignition circuit cut-off system Yamaha dealer repair it if it does not The ignition circuit cut-off system function properly. (comprising the sidestand switch, clutch switch and neutral switch) has the following functions.
  • Page 38 INSTRUMENT AND CONTROL FUNCTIONS WARNING With the engine turned off: 1. Move the sidestand down. If a malfunction is noted, have a Yamaha 2. Make sure that the engine stop switch is set to “ ”. dealer check the system before riding.

  • Page 39: For Your Safety - Pre-Operation Checks

    • If necessary, add recommended oil to specified level. 6-10 • Check vehicle for oil leakage. • Check operation. • If soft or spongy, have Yamaha dealer bleed hydraulic system. • Check brake pads for wear. Front brake • Replace if necessary.
  • Page 40 • Make sure that operation is smooth. • Check throttle grip free play. Throttle grip 6-15, 6-24 • If necessary, have Yamaha dealer adjust throttle grip free play and lubricate ca- ble and grip housing. • Make sure that operation is smooth. Control cables 6-24 •...
  • Page 41 • Tighten if necessary. Instruments, lights, signals • Check operation. — and switches • Correct if necessary. • Check operation of ignition circuit cut-off system. Sidestand switch 3-21 • If system is not working correctly, have Yamaha dealer check vehicle.

  • Page 42: Operation And Important Riding Points

     a lean angle sensor to stop the en-  The transmission is in the neutral understand, ask your Yamaha dealer. gine in case of a turnover. In this EWA10272 position.

  • Page 43: Shifting

    The neutral indi- with the engine off, and do not cator light should come on. If not, tow the motorcycle for long dis- ask a Yamaha dealer to check the tances. The transmission is electrical circuit. properly lubricated only when 3.

  • Page 44: Tips For Reducing Fuel Consumption

    Yamaha dealer check the vehi- to the correct operating clearances. gine. cle. During this period, prolonged full-throt- ...

  • Page 45: Parking

    OPERATION AND IMPORTANT RIDING POINTS EAU17214 Parking When parking, stop the engine, and then remove the key from the main switch. EWA10312 WARNING  Since the engine and exhaust system can become very hot, park in a place where pedestri- ans or children are not likely to touch them and be burned.

  • Page 46: Periodic Maintenance And Adjustment

    To avoid possible burns, let tivities incorrectly may increase brake components cool before your risk of injury or death during touching them. service or while using the vehicle. If you are not familiar with vehicle ser- vice, have a Yamaha dealer perform service.

  • Page 47: Owner's Tool Kit

    If you do not have the tools or experi- ence required for a particular job, have a Yamaha dealer perform it for you.

  • Page 48: Periodic Maintenance Chart For The Emission Control System

     From 50000 km (30000 mi), repeat the maintenance intervals starting from 10000 km (6000 mi).  Items marked with an asterisk should be performed by a Yamaha dealer as they require special tools, data and tech- nical skills.

  • Page 49: General Maintenance And Lubrication Chart

    PERIODIC MAINTENANCE AND ADJUSTMENT EAU1770K General maintenance and lubrication chart ODOMETER READING ANNUAL ITEM CHECK OR MAINTENANCE JOB 1000 km 10000 km 20000 km 30000 km 40000 km CHECK (600 mi) (6000 mi) (12000 mi) (18000 mi) (24000 mi) √ Air filter element •...
  • Page 50 PERIODIC MAINTENANCE AND ADJUSTMENT ODOMETER READING ANNUAL ITEM CHECK OR MAINTENANCE JOB 1000 km 10000 km 20000 km 30000 km 40000 km CHECK (600 mi) (6000 mi) (12000 mi) (18000 mi) (24000 mi) • Check operation and for exces- √ √...
  • Page 51 PERIODIC MAINTENANCE AND ADJUSTMENT ODOMETER READING ANNUAL ITEM CHECK OR MAINTENANCE JOB 1000 km 10000 km 20000 km 30000 km 40000 km CHECK (600 mi) (6000 mi) (12000 mi) (18000 mi) (24000 mi) • Check operation and for oil leak- √...
  • Page 52 PERIODIC MAINTENANCE AND ADJUSTMENT  Hydraulic brake and clutch service • Regularly check and, if necessary, correct the brake fluid and clutch fluid levels. • Every two years replace the internal components of the brake master cylinders and calipers as well as clutch master and release cylinders, and change the brake and clutch fluids.

  • Page 53: Removing And Installing Panels

    PERIODIC MAINTENANCE AND ADJUSTMENT EAU18773 Removing and installing pan- The panels shown need to be removed to perform some of the maintenance jobs described in this chapter. Refer to this section each time a panel needs to be removed and installed. 1.

  • Page 54: Checking The Spark Plugs

    1/2 turn past finger tight. However, the Yamaha dealer. Since heat and depos- with a wire thickness gauge and, if spark plug should be tightened to the its will cause any spark plug to slowly necessary, adjusted to specification.

  • Page 55: Engine Oil And Oil Filter Element

    PERIODIC MAINTENANCE AND ADJUSTMENT 4. Remove the engine oil filler cap, EAU65421 Engine oil and oil filter ele- the engine oil drain bolt and its ment gasket to drain the oil from the The engine oil level should be checked crankcase.
  • Page 56 PERIODIC MAINTENANCE AND ADJUSTMENT 1. Drive sprocket cover 1. Oil filter element drain screw 1. O-ring 2. Bolt 2. Gasket 2. Oil filter element cover bolt 3. Oil filter element cover bolt 3. Oil filter element cover 6. Remove the oil filter element drain 4.
  • Page 57 PERIODIC MAINTENANCE AND ADJUSTMENT 13. Install the engine oil filter element Tightening torque: cover (together with the spring, Oil filter element drain screw: Be sure to wipe off spilled oil on any washer and oil filter element) by 7 Nm (0.7 m·kgf, 5.1 ft·lbf) parts after the engine and exhaust sys- aligning the projection on the cov- tem have cooled down.

  • Page 58: Replacing The Air Filter Element And Cleaning The Check Hose

    In addition, correct, immediately turn the engine 1. Bolt off and have a Yamaha dealer check the air filter check hose must be fre- 2. Right side cover the vehicle.
  • Page 59 PERIODIC MAINTENANCE AND ADJUSTMENT 2. If dirt or water is visible, remove the hose, clean it, and then install 1. Air filter element 8. Install the panel. 5. Insert a new air filter element into the air filter case. NOTICE: Make To clean the air filter check hose 1.

  • Page 60: Checking The Throttle Grip Free Play

    Therefore, it must be adjusted by a Yamaha dealer is essential to maintain the tires in good at the intervals specified in the periodic condition at all times and replace them maintenance and lubrication chart.
  • Page 61 250 kPa (2.50 kgf/cm², 36 psi) or glass fragments in it, or if the side- surface must first be “broken Rear: wall is cracked, have a Yamaha dealer in” for it to develop its optimal 290 kPa (2.90 kgf/cm², 42 psi) replace the tire immediately.
  • Page 62 2. Tire air valve core ed below have been approved for this surfaces until they have been 3. Tire air valve cap with seal model by Yamaha. “broken in”. Therefore, it is ad- This model is equipped with tubeless visable before doing any high- Front tire: tires and tire air valves.

  • Page 63: Cast Wheels

    1. No brake lever free play formed or cracked wheel must be is air in the hydraulic system, have a replaced. Yamaha dealer bleed the system be- There should be no free play at the  The wheel should be balanced fore operating the motorcycle.

  • Page 64: Brake Light Switches

    If necessary, adjust the rear brake light switch as follows, but the front brake light switch should be adjusted by a Yamaha dealer. Turn the rear brake light switch adjust- ing nut while holding the rear brake light switch in place. To make the brake light come on earlier, turn the ad- justing nut in direction (a).

  • Page 65: Checking The Brake And Clutch Fluid Levels

    1. Minimum level mark has almost disappeared, have a Clutch Yamaha dealer replace the brake pads as a set. 1. Minimum level mark 1. Minimum level mark The rear brake fluid reservoir is located behind panel A.

  • Page 66: Changing The Brake And Clutch Fluids

    Specified brake and clutch fluid: Changing the brake and ing point of the fluid and may re- DOT 4 brake fluid clutch fluids sult in vapor lock. Have a Yamaha dealer change the EWA16001 ECA17641 WARNING brake and clutch fluids at the intervals NOTICE...

  • Page 67: Drive Chain Slack

    EAU34318 2. Shift the transmission into the To adjust the drive chain slack neutral position. Consult a Yamaha dealer before ad- 3. Measure the drive chain slack as justing the drive chain slack. shown. 1. Loosen the axle nut and the lock- nut on each side of the swingarm.

  • Page 68: Cleaning And Lubricating The Drive Chain

    PERIODIC MAINTENANCE AND ADJUSTMENT 3. Tighten the axle nut, then the lock- may contain substances that EAU23026 Cleaning and lubricating the nuts to their specified torques. could damage O-rings. drive chain [ECA11112] The drive chain must be cleaned and Tightening torques: Axle nut: lubricated at the intervals specified in 150 Nm (15 m·kgf, 108 ft·lbf)

  • Page 69: Checking And Lubricating The Cables

    Yamaha dealer at the intervals bricated if necessary. cated if necessary. If a cable is specified in the periodic maintenance...

  • Page 70: Checking And Lubricating The Brake And Clutch Levers

    PERIODIC MAINTENANCE AND ADJUSTMENT EAU43602 Recommended lubricant: Recommended lubricant: Checking and lubricating the Lithium-soap-based grease Silicone grease brake and clutch levers The operation of the brake and clutch levers should be checked before each ride, and the lever pivots should be lu- bricated if necessary.

  • Page 71: Checking And Lubricating The Sidestand

    The swingarm pivots must be lubricat- face and hold it in an upright posi- be checked before each ride, and the ed by a Yamaha dealer at the intervals tion. WARNING! To avoid injury, sidestand pivot and metal-to-metal specified in the periodic maintenance...

  • Page 72: Checking The Steering

    If any damage is found or the front the vehicle so there is no danger fork does not operate smoothly, of it falling over. have a Yamaha dealer check or re- [EWA10752] 2. Hold the lower ends of the front pair it.

  • Page 73: Checking The Wheel Bearings

    EWA10761 WARNING To charge the battery  Electrolyte is poisonous and Have a Yamaha dealer charge the bat- dangerous since it contains sul- tery as soon as possible if it seems to furic acid, which causes severe have discharged. Keep in mind that the...

  • Page 74: Replacing The Fuses

    PERIODIC MAINTENANCE AND ADJUSTMENT battery tends to discharge more quick- is turned to “OFF”, then connect EAU43274 Replacing the fuses ly if the vehicle is equipped with op- the positive lead before con- The main fuse is located under the tional electrical accessories.

  • Page 75: Replacing The Headlight Bulb

    4. If the fuse immediately blows If a fuse is blown, replace it as follows. again, have a Yamaha dealer 1. Turn the key to “OFF” and turn off check the electrical system. the electrical circuit in question.
  • Page 76 7. Have a Yamaha dealer adjust the 5. Install the bulb cover, and then headlight beam if necessary. connect the coupler. When installing the headlight bulb cov- er, make sure the “TOP”...

  • Page 77: Replacing The Auxiliary Light Bulb

    PERIODIC MAINTENANCE AND ADJUSTMENT 5. Insert a new bulb into the socket, EAU65440 Replacing the auxiliary light push it in, and then turn it clock- bulb wise until it stops. If the auxiliary light bulb burns out, re- 6. Install the socket (together with place it as follows.

  • Page 78: Tail/Brake Light

    1. Remove the turn signal light lens If the tail/brake light does not come on, by removing the screw. have a Yamaha dealer check it. 1. Turn signal light bulb 3. Insert a new bulb into the socket, push it in, and then turn it clock- wise until it stops.

  • Page 79: Replacing A License Plate Light Bulb

    PERIODIC MAINTENANCE AND ADJUSTMENT 4. Remove the license plate light EAU65451 Replacing a license plate light bulb socket (together with the bulb bulb) by turning it counterclock- 1. Remove the reflector by removing wise, and then pulling it out. the nut. 1.

  • Page 80: Supporting The Motorcycle

    PERIODIC MAINTENANCE AND ADJUSTMENT 7. Install the socket (together with a jack either under each side of the EAU24351 Supporting the motorcycle the bulb) by pushing it in, and then frame in front of the rear wheel or under Since this model is not equipped with a turn it clockwise until it stops.

  • Page 81: Front Wheel

    PERIODIC MAINTENANCE AND ADJUSTMENT 2. Lift the front wheel off the ground To install the front wheel EAU24361 Front wheel according to the procedure in the 1. Lift the wheel up between the fork previous section “Supporting the legs. EAU65460 motorcycle”.

  • Page 82: Rear Wheel

    PERIODIC MAINTENANCE AND ADJUSTMENT EAU25081 Tightening torques: Rear wheel Wheel axle: 72 Nm (7.2 m·kgf, 52 ft·lbf) EAU65470 Front wheel axle pinch bolt: 20 Nm (2.0 m·kgf, 14 ft·lbf) Brake caliper bolt: To remove the rear wheel 40 Nm (4.0 m·kgf, 29 ft·lbf) EWA10822 Brake hose holder bolt: WARNING...
  • Page 83 PERIODIC MAINTENANCE AND ADJUSTMENT 8. Remove the brake caliper bracket 8. Tighten the axle nut, brake caliper and the wheel. bolts and brake torque rod nut to the specified torques. To install the rear wheel Tightening torques: 1. Place the wheel and the brake cal- Axle nut: iper bracket in the original posi- 150 Nm (15 m·kgf, 108 ft·lbf)

  • Page 84: Troubleshooting

    However, should your motorcycle require any repair, take it to a Yamaha dealer, whose skilled technicians have the necessary tools, experience, and know-how to service the motorcycle properly.

  • Page 85: Troubleshooting Chart

    Remove the spark plugs and check the electrodes. The engine does not start. Have a Yamaha dealer check the vehicle. Check the compression. 4. Compression The engine does not start. There is compression.

  • Page 86: Motorcycle Care And Storage

    Some models are equipped with matte colored finished parts. Be ble. Rust and corrosion can develop Cleaning sure to consult a Yamaha dealer for even if high-quality components are ECA10773 NOTICE advice on what products to use be- used.
  • Page 87 MOTORCYCLE CARE AND STORAGE off any detergent residue using shield. Test the product on a plenty of water, as it is harmful small hidden part of the wind- Salt sprayed on roads in the winter to plastic parts. shield to make sure that it does may remain well into spring.

  • Page 88: Storage

    EWA11132 poorly ventilated room or cover- WARNING ing it with a tarp, while it is still  Consult a Yamaha dealer for ad- Contaminants on the brakes or tires wet, will allow water and humid- can cause loss of control.
  • Page 89 MOTORCYCLE CARE AND STORAGE 2. Fill up the fuel tank and add fuel e. Remove the spark plug caps stabilizer (if available) to prevent from the spark plugs, and then Make any necessary repairs before the fuel tank from rusting and the install the spark plugs and the storing the motorcycle.

  • Page 90: Specifications

    SPECIFICATIONS Dimensions: Engine oil: Fuel reserve amount: 3.1 L (0.82 US gal, 0.68 Imp.gal) Overall length: Recommended brand: Fuel injection: 2190 mm (86.2 in) YAMALUBE Overall width: Type: Throttle body: 820 mm (32.3 in) SAE 10W-30, 10W-40, 10W-50, 15W-40, ID mark: Overall height: 20W-40 or 20W-50 5UXB 10...
  • Page 91 SPECIFICATIONS 5th: Rear: Operation: 1.115 (29/26) 250 kPa (2.50 kgf/cm², 36 psi) Right foot operation Chassis: Loading condition: Specified brake fluid: 90–210 kg (198–463 lb) DOT 4 Frame type: Front: Front suspension: Double cradle 250 kPa (2.50 kgf/cm², 36 psi) Caster angle: Type: Rear:...
  • Page 92 SPECIFICATIONS Tail/brake light: Ignition fuse: 15.0 A Front turn signal light: Fuel injection system fuse: 12 V, 10.0 W × 2 15.0 A Rear turn signal light: Backup fuse: 12 V, 10.0 W × 2 7.5 A Auxiliary light: 12 V, 5.0 W × 1 License plate light: 12 V, 5.0 W ×...

  • Page 93: Consumer Information

    These identification numbers are needed when registering the vehicle with the authorities in your area and when ordering spare parts from a Yamaha dealer. VEHICLE IDENTIFICATION NUMBER: 1. Vehicle identification number 1. Engine serial number The vehicle identification number is The engine serial number is stamped stamped into the steering head pipe.
  • Page 94 CONSUMER INFORMATION The model label is affixed to the frame under the seat. (See page 3-15.) Re- cord the information on this label in the space provided. This information will be needed when ordering spare parts from a Yamaha dealer.

  • Page 95: Index

    INDEX Air filter element and check hose, Front and rear brake pads, checking ... 6-19 Neutral indicator light ......3-4 replacing and cleaning ....... 6-13 Front fork, adjusting ......3-16 Auxiliary light bulb, replacing ....6-32 Front fork, checking ......6-26 Oil level warning light......
  • Page 96 INDEX Tool kit ............6-2 Troubleshooting ........6-39 Troubleshooting chart......6-40 Turn signal indicator lights......3-4 Turn signal light bulb, replacing....6-33 Turn signal switch ........3-9 Valve clearance........6-15 Vehicle identification number ....9-1 Wheel bearings, checking.....6-28 Wheel (front)..........6-36 Wheel (rear)...........6-37 Wheels ..........6-18 10-2...
