FOR ARCHITECTS & DESIGNERS
TC30
SERIES D
5056.9030-A TC30
Dimensions | Clearances | Venting
IMPORTANT
This booklet is intended as a basic specifi cation
guide for architects, designers and builders.
Please refer to the Instruction Manual supplied
with the fi replace for detailed information regarding
installation and operation.
Product installation manuals can also be viewed at:
www.townandcountryfi replaces.com
040216-12

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TC30 and is the answer not in the manual?

Questions and answers

Related Manuals for Town & Country Fireplaces TC30

Summary of Contents for Town & Country Fireplaces TC30

  • Page 1 This booklet is intended as a basic specifi cation guide for architects, designers and builders. Please refer to the Instruction Manual supplied with the fi replace for detailed information regarding installation and operation. Product installation manuals can also be viewed at: www.townandcountryfi replaces.com 5056.9030-A TC30 040216-12...

  • Page 2: Fireplace Dimensions

    28 3/8" 27 3/4 32 1/2" 27 3/4" Must allow for minimum 1/2 inch gap for non-combustible board and facing. TC30.D Cad Drawing Available at www.townandcountry replaces.com FRAME LINTEL Examples of Common Locations FOR REFERENCE ONLY. CONSULT MANUAL BEFORE INSTALLATION 5056.9030-A_TC30.D...

  • Page 3: Mantel Clearance Chart

    Mantel Clearance Chart NON-COMBUSTIBLE ZONE. COMBUSTIBLE FRAMING AND DO NOT INSTALL ANY COMBUSTIBLE FINISH WALL ABOVE STANDOFFS MATERIAL, ELECTRICAL WIRING OR GAS STEEL FRAMING PLUMBING IN THIS AREA. MAY USE COMBUSTIBLE STANDOFFS FACING MATERIAL IN THIS MANTEL CLEARANCE AREA CHART NON-COMBUSTBLE * MANTEL CLEARANCE FINISH MATERIAL...

  • Page 4: Non-Combustible Board

    Steel Stud Framing Kit Dimensions Kit Framing kit is supplied Non-combustible with unit with Fireplace Board Detail All other framing can be done with conventional lumber NON-COMBUSTIBLE BOARD 47 3/8” 12” 5 7/8” 40 3/8” NON-COMBUSTIBLE materials must extend 12” above and 5 7/8” to the sides of the framing edges.

  • Page 5: Hearth Extension

    Proflame 2 Control System Town and Country D Series fireplaces use the SIT Proflame 2 control system. This includes an elegant hand-held remote control transmitter with an easy to read LCD display. The fireplace also comes with a wall-mounted control switch which allows for simple ON/OFF operation, or Up to 40 Feet can be linked with the hand-held remote control unit.
  • Page 6 Direct Vent Wall Installation Direct Vent Roof Installation HORIZONTAL 14 1/2" FRAMED TERMINAL OPENING WALL SHIELD THIMBLE MIN 24" VENT PIPE ELBOW * 52 7/16 MIN 12" VENT PIPE * Minimum height 52 7/16 from the floor to center of the opening with a maximum horizontal run of 34 5/16"...

  • Page 7: Wall Termination Venting Chart

    90° elbow, or an equal combination of elbows, reduce horizontal vent run by 2 feet. Ensure vent pipe is properly supported. A minimum of 1 support every 4’ must be used. TC30.D Cad Drawing Available at www.townandcountry replaces.com FOR REFERENCE ONLY.

  • Page 8: Roof Termination Venting Chart

    2 feet. Ensure vent pipe is properly supported. A minimum of 1 support every 4’ must be used. TC30.D Cad Drawing Available at www.townandcountry replaces.com FOR REFERENCE ONLY. CONSULT MANUAL BEFORE INSTALLATION 5056.9030-A_TC30.D...

  • Page 9: Vent Terminal Minimum Clearances

    Vent Terminal Clearance Minimum clearances to the vent terminal must be maintained as shown (See illustration to right & below). Measure VENT TERMINAL MINIMUM CLEARANCES clearances to the nearest edge of termination hood. TO ADJACENT STRUCTURES (See pitch table below). NOTE: Vent terminal must not be recessed 36"...
  • Page 10 fi replace. Up to 110 feet of run plus six 90º elbows The premium Power Vent fan runs quietly outside, at the exterior terminal. TC30.D Cad Drawing Up to 3 feet below unit Available at www.townandcountry replaces.com Power Vent Terminals...
  • Page 11 FOR REFERENCE ONLY. CONSULT MANUAL BEFORE INSTALLATION 5056.9030-A_TC30.D 040216-12...
  • Page 12 © 2016 Copyright Paci c Energy Fireplace Products LTD Reproduction, adaptation, or translation without prior written permission is prohibited, except as allowed under the copyright laws. For personal service pertaining to specific projects, contact: Town & Country Architect Resource Planner architects@townandcountryfireplaces.com www.townandcountryfireplaces.com Phone: (250) 748-1184...
