Summary of Contents for Monogram ZV1050

  • Page 1 Installation Instructions If you have questions, call 800.GE.CARES or visit our website at: www.monogram.com 42" Island Vent Hood Model: ZV1050...
  • Page 2: Design Information

    Design Information BEFORE YOU BEGIN WARNING: TO REDUCE THE RISK OF FIRE, ELECTRICAL Read these instructions completely and carefully. SHOCK OR INJURY TO PERSONS, OBSERVE THE • IMPORTANT – Save these instructions for FOLLOWING: local inspector’s use. A. Use this unit only in the manner intended by the •...
  • Page 3: Table Of Contents

    Order Accessory duct covers for 9 ft. mounted installations. It can be installed over any and 10 ft. ceilings. Monogram cooktop or range, including Professional ZX1059SFSS – For 9 ft. ceiling height models. This kit includes a decorative duct cover and support frame to reach a 9 ft ceiling height.
  • Page 4: Duct Cover Accessories

    ZX1059SFSS be lowered to 25-1/2" over the cooking surface. 9'0" 25-1/2" to 30" ZX1059SFSS • When installing the Island Hood above a Monogram Professional 9'1" 25-1/2" to 30" ZX10510SFSS Range or Cooktop, installation clearance must be at least 30". 9'2"...
  • Page 5: Advance Planning

    Advance Planning POWER SUPPLY TOOLS AND MATERIALS REQUIRED (not supplied) IMPORTANT • Tape measure – Please read carefully. • Knife WARNING: • Spirit level FOR PERSONAL SAFETY, • Wire cutter THIS APPLIANCE MUST BE PROPERLY GROUNDED. • Wire stripper • Wire nuts ATTENTION : POUR DES RAISONS •...
  • Page 6: Duct Fittings

    Advance Planning Total DUCT FITTINGS Equivalent Quantity Equivalent Duct Piece Dimensions Length* Used Length This Hood Must Round, 1 ft. Use 8" Round Duct. straight (per foot It Can Transition to length) 3-1/4" x 12" Duct. 1 ft. 3-1/4" x 12" (per foot Use this chart to compute maximum straight...
  • Page 7: Installation Instructions

    Installation Instructions STEP 1 CONSTRUCT CEILING SUPPORT Ceiling Plan the location Hood Determine the exact location of the vent hood. Ducting Centerline • Use a plumb bob to check location to be sure countertop/cooktop location below the hood will align exactly. •...
  • Page 8 Installation Instructions STEP 1 CONSTRUCT CEILING SUPPORT (cont.) EXAMPLE B 16" Joist 11-1/4" Install Cross-Framing Spacing Symmetrically About Duct/Cooktop Centerline 2x4 Cross Framing 8" Duct 7-1/4" Cooktop Align Duct to Outline Center of Cooktop Front of Hood Top View—Ceiling Joists Run Perpendicular to Front of Hood EXAMPLE C 2x4 Cross 11-1/4"...
  • Page 9 Installation Instructions 2x 4 Min. STEP 1 CONTINUED Cross Framing • Arrange cross framing in the ceiling to suit the existing structure. See examples. – Secure each 2 x 4 block with at least four (4), #10 wood screws, 3" long (not supplied). Use 8 wood screws total for the two supports.
  • Page 10: Step 2, Remove Packaging

    Installation Instructions STEP 2 REMOVE THE PACKAGING The vent hood is packed separately from the decorative duct cover or accessory covers ZX1059SFSS or ZX10510SFSS. • Remove the frame, cover, parts box and packaging. • Remove junction box cover. • Install strain relief onto junction box cover. STEP 3 CHECK INSTALLATION HARDWARE Locate the hardware accessory pack shipped with the hood and check contents.
  • Page 11: Step 4 Mount Template

    Installation Instructions STEP 4 MOUNT TEMPLATE • Align the template with the marks on the ceiling and tape in place. – Be sure the template is oriented correctly, with the front of the hood. • Use a plumb bob to be sure the mounting holes will provide parallel alignment with the countertop below.
  • Page 12: Step 6 Secure Wiring

    Installation Instructions STEP 6 SECURE WIRING STEP 7 SIZE AND INSTALL DUCTWORK • Route house wiring through the ceiling hole and pull a length to reach the hood junction box, Ceiling approximately 6" below the support. Ceiling House Duct Left Side View Required Side...
  • Page 13: Step 8 Install Decorative Duct Covers

    Installation Instructions STEP 8 INSTALL DECORATIVE DUCT COVERS Install Screw on Top Duct Each Side Cover Pretap Bottom Duct Cover 2 Screw Bottom Duct Holes Top Duct Cover (One Cover Each Side) Top Duct Cover Stop Install Stop Screw Screw in Hole of Upper (Inner) Duct Cover •...
  • Page 14: Step 10 Connect Electrical

    Installation Instructions STEP 11 SLIDE DUCT COVER DOWN STEP 10 CONNECT ELECTRICAL Verify that power is turned off at the source. WARNING: If house wiring is not 2-wire with a ground wire, a ground must be provided by the Install installer.
  • Page 15: Step 12 Install Filters, Finalize Installation

    Installation Instructions STEP 12 INSTALL FILTERS, FINALIZE INSTALLATION Filter Slots • Remove protective film on the filters. • Tip the filter into the lower slots at the rear of the opening. Lift the filter and pull the knob forward until the filter rests on the slots. •...
  • Page 16 Note: While performing installations described in this book, safety glasses or goggles should be worn. ® For Monogram local service in your area, call 1.800.444.1845. Note: Product improvement is a continuing endeavor at General Electric. Therefore, materials, appearance and specifications are subject to change without notice.
