Weights
Bit
04.25

The Analog Input Used by PLC (NOT for VFD*E*C models)

Settings
Display
The equivalent 2-bit is used to display the status(used or not used) of each analog input. The
value for Pr.04.25 to display is the result after converting 2-bit binary into decimal value.
04.26

Display the Status of Multi-function Input Terminal

Settings
Display
Revision Jan. 2009, 06EE, SW--PW V1.12/CTL V2.12
11 10 9 8 7
Read Only
Bit0=1: AVI used by PLC
Bit1=1: ACI/AVI2 used by PLC
Bit2=1: AI1 used by PLC
Bit3=1: AI2 used by PLC
Weights
Bit
3
Read Only
Bit0: MI1 Status
Bit1: MI2 Status
Bit2: MI3 Status
Bit3: MI4 Status
Bit4: MI5 Status
6 5 4 3 2
0=not used
1=used by PLC
2 1 1 0
AVI
ACI/AVI2
AI1 (optional)
AI2 (optional)
Chapter 4 Parameters|
0=not used
1=Used by PLC
1 0
MI1
MI2
MI3
MI4
MI5
MI6
MI7
MI8
MI9
MI10
MI11
MI12
Factory display: 0
Factory display: 63
