Related parameters: Pr.03.00(Multi-function Output Relay (RA1, RB1, RC1)) and
Pr.03.01(Multi-function Output Terminal MO1)
setting 2
master freq. attained
(output signal)
setting 9/23
desir ed freq. attai ned
setting 03 z ero s peed indication
setting 19 z ero s peed indication
NOTE
When the output frequency reaches the setting frequency, the detection ranges for the multi-function
output terminals are: ± 2Hz (from OFF to ON) and ± 4Hz (from ON to OFF). The detection range for
the output frequency reaches the desired frequency is -2Hz.
03.03

Analog Output Signal (AFM)

Settings
This parameter sets the function of the AFM output 0~+10VDC (ACM is common). Refer to
Pr.03.04 for applications.
Related parameters: Pr.01.00(Maximum Output Frequency (Fmax)) and Pr.03.04(Analog
Output Gain)
03.04

Analog Output Gain

Settings
This parameter sets the voltage range of the analog output signal AFM.
Revision Jan. 2009, 06EE, SW--PW V1.12/CTL V2.12
F requenc y
master
frequency
detec ti on range
desir ed
frequency
waiting time
03.02/03.14
for
frequency
run/stop
OF F
ON
ON
ou tp ut t im ing ch art of m ultip le fu nct io n term inals(Pr.03.00/Pr.03.01)
wh en settin g to fr eq uen cy att ained or zero sp eed in dicatio n
0 Analog Frequency Meter (0 to Maximum Output Frequency)
1 Analog Current Meter (0 to 250% of rated AC motor drive current)
1 to 200%
2Hz
ON
OF F
ON
ON
OF F
OF F
Chapter 4 Parameters|
detec ti on
4Hz
range
detec ti on
-2Hz
range
DC brak e time
during stop
Time
OF F
OF F
OF F
ON
ON
Factory Setting: 0
Factory Setting: 100
Unit: 1
4-75
