2. An "always-on" connection to the Internet. A high speed DSL or cable internet connection
that maintains constant connection to the internet.

3.8.2 Software Requirements

An IP scan tool is required to locate the ObserverIP on the network.
Important Note: Download ObserverIP tools at the following location:

3.8.3 ObserverIP Connections

Connect the ObserverIP receiver power jack to AC power with the power adapter (included), as shown
in Figure 14, reference 10.
Connect the OberverIP receiver to your router using the Ethernet cable (included), as shown in Figure
14, reference 8.
Place the indoor and outdoor transmitters about 5 to 10 feet from the ObserverIP receiver and wait
several minutes for the remote sensors to synchronize with the receiver. Once synchronized, the
Indoor blue LED (Figure 13, reference 2) and Outdoor blue LED (Figure 13, reference 3) will be
illuminated.
All of the lights will turn on except the server light (until you connect to Weather Underground)>
Ref. LED
1 RF
2 Indoor
3 Outdoor
4 Server
5 ACT
Version 1.1 ©Copyright 2016, Ambient LLC. All Rights Reserved.
www.AmbientWeather.com/observerip.html
On when radio frequency receiver is operating properly
On when indoor sensor received
Flashes when one outdoor sensor received. On when both outdoor
sensors are received.
On when connected to Wunderground.com® internet hosting
service
Flashes when there is internet activity
Description
Page 16
