Purview PV-A-300 Appliance
Installation Guide
Published September 2015
9034791

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Purview PV-A-300 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Extreme Networks Purview PV-A-300

Summary of Contents for Extreme Networks Purview PV-A-300

  • Page 1 Purview PV-A-300 Appliance Installation Guide Published September 2015 9034791...

  • Page 2: Legal Notices

    Copyright © 2015 Extreme Networks, Inc. All Rights Reserved. Legal Notices Extreme Networks, Inc., on behalf of or through its wholly-owned subsidiary, Enterasys Networks, Inc., reserves the right to make changes in specifications and other information contained in this document and its website without prior notice. The reader should in all cases consult representatives of Extreme Networks to determine whether any such changes have been made.

  • Page 3: Table Of Contents

    Contents About This Guide.......................2 Who Should Use This Guide ............................2 Related Documents ................................2 Typographical Conventions ............................2 Getting Help ..................................3 Appliance Overview and Setup ................4 Kit Contents ..................................4 Specifications ..................................5 Front Panel Features ................................7 Hard Drive LED Indicator Patterns ..........................8 Back Panel Features ................................

  • Page 4: About This Guide

    Calls the reader’s attention to any item of information that may be of special importance. Contains information essential to avoid damage to the equipment. Precaución: Contiene información esencial para prevenir dañar el equipo. Achtung: Verweißt auf wichtige Informationen zum Schutz gegen Beschädigungen. Purview PV-A-300 Appliance Installation Guide...

  • Page 5: Getting Help

    Address Extreme Networks 145 Rio Robles San Jose, CA 95134 (USA) Before contacting Extreme Networks for technical support, have the following data ready: • Your Extreme Networks service contract number • A description of the failure • A description of any action(s) already taken to resolve the problem (for example, changing mode switches or rebooting the unit) •...

  • Page 6: Appliance Overview And Setup

    • Front bezel label • A rack mounting kit • Two AC power cables • Two rack handles and appropriate screws • AC power cord bracket and cable clamp kit • One USB flash drive Purview PV-A-300 Appliance Installation Guide...

  • Page 7: Specifications

    AC power supply (per power supply) Redundant Power Supply Wattage 750 watts Input Voltage 100 - 127 V at 50/60 Hz 8.2 A 200 - 240 V at 50/60 Hz 4.4 A Output Voltage 62.0A at 12 V 2.1A at 12 VSB Purview PV-A-300 Appliance Installation Guide...
  • Page 8 (40 lbs to < 80 lbs) Shock, Packaged Non-palletized free fall in height 24 inches (40 lbs to < 80 lbs) +/-12 KV except I/O port +/- 8 KV per Intel ® Environmental test specification Estimated Thermal Dissipation 1550 BTU/Hr Purview PV-A-300 Appliance Installation Guide...

  • Page 9: Front Panel Features

    A System ID Button w/Integrated LED System Status LED NMI Button (recessed, tool required for Power Button w/Integrated LED use) Mgmt Port Activity LED Hard Drive Activity LED Not used Not used System Cold Reset Button Not used Purview PV-A-300 Appliance Installation Guide...

  • Page 10: Hard Drive Led Indicator Patterns

    Not used eth0, Mgmt Port, 1 GbE RJ45 USB 2.0 Ports eth1 Not used eth2 Not used (Used if PV-A-300-10G-UG is installed) eth3 Not used Table 6 describes the LEDs for the RJ45 management port. Purview PV-A-300 Appliance Installation Guide...

  • Page 11: Power Supply Status Indicator Patterns

    Power supply warning events where PS continues to operate — high 1Hz Blinking temp, high power, high current, slow fan Amber Power supply critical event causing a shutdown, failure, OCP, OVP, fan Amber fail Power supply firmware updating 2Hz Blinking Green Purview PV-A-300 Appliance Installation Guide...

  • Page 12: Removing And Installing The Front Bezel

    To install the front bezel: 1 Lock the right end of the front bezel to the rack handle. 2 Rotate the front bezel clockwise till the left end clicks into place. 3 Lock the bezel if needed. Purview PV-A-300 Appliance Installation Guide...

  • Page 13: Installing The Appliance Into A Rack

    1.42 1.57 2 – 56 2.85 3.15 4 – 40 4.75 5.25 6 – 32 8.55 9.45 8 – 32 17.10 18.0 18.90 10 – 32 30.40 32.0 33.60 1/4 – 20 63.65 67.0 70.35 Purview PV-A-300 Appliance Installation Guide...

  • Page 14: Configuration

    (When you purchased NetSight, you received a Licensed Product Entitlement ID. This Entitlement ID allows you to generate a product license. Refer to the instructions included with the Entitlement ID that was sent to you.) Purview PV-A-300 Appliance Installation Guide...

  • Page 15: Configuring The Purview Appliance

    1 Login as root with no password, and then press Enter. The following screen appears. ============================================================================ Extreme Networks - Purview Appliance - Welcome to the Purview Appliance Setup ============================================================================ Please enter the information as it is requested to continue with the configuration.
  • Page 16 Enter the domain name for 10.54.56.141 (Optional): Enable NIS (y/n) [n]? 6 Continue as follows: • For deployment mode 1, go to step • For deployment mode 2, go to step • For deployment mode 3, go to step Purview PV-A-300 Appliance Installation Guide...
  • Page 17 For each line, enter the requested configuration information and press Enter. ============================================================================== Purview Appliance GRE Configuration ============================================================================== Remote mirroring can be configured in Coreflow Switches using GRE tunnels. This requires a specific mirroring configuration enabled on the switches. Purview PV-A-300 Appliance Installation Guide...
  • Page 18 2. Deployment Mode: Dual Interface Tunnel Mirrored 3. Management Interface Configuration (eth0): Address: 10.54.184.88 Netmask: 255.255.255.0 Gateway: 10.54.184.1 Nameserver: 10.54.188.120 Domain name: nac2003.com 4. NIS Server/Domain: Not Configured 5. Mirror Interface Configuration: Name: eth4 Purview PV-A-300 Appliance Installation Guide...
  • Page 19 IP addresses may be entered if NTP is used. ============================================================================ Do you want to use NTP (y/n) [y]? y Please enter a NTP Server IP Address (Required): 144.131.10.120 Would you like to add another server (y/n) [n]? y Purview PV-A-300 Appliance Installation Guide...
  • Page 20 You will now be asked to enter the time zone information for this system. Available time zones are stored in files in the /usr/share/zoneinfo directory Please select from one of the following example time zones: 1. US Eastern 2. US Central Purview PV-A-300 Appliance Installation Guide...

  • Page 21: Launching The Purview Application

    The Purview application software is automatically installed. This could take a few minutes. When the installation is complete, you’ll see the following screen. ============================================================================ Extreme Networks - Purview Appliance - Setup Complete ============================================================================ Setup of the Purview Appliance is now complete. The appliance is now operational and ready to accept remote connections.
  • Page 22 For more information on the NetSight Launch page, access the NetSight Online Help by clicking on Help in the left corner of the NetSight Launch Page banner. In the Online Help Table of Contents, select Installation Guide and then read the section titled Remote Client Launch. Purview PV-A-300 Appliance Installation Guide...

  • Page 23: Adding The Purview Appliance

    • IP address of the eth0 interface • Name of the Purview appliance 4 From the Profile list, select the appropriate SNMP profile. 5 Click OK. 6 Open the drop down menu below Overview and select Enforce Appliance. Purview PV-A-300 Appliance Installation Guide...

  • Page 24: Changing Purview Appliance Settings

    If you have changed the credentials in OneView > Applications view and then install a new appliance that is using the default password, you will not be able to monitor or enforce to the new appliance until you change the password on the appliance using this command. Purview PV-A-300 Appliance Installation Guide...

  • Page 25: Upgrading Purview Appliance Software

    7 Change the permissions on the upgrade file by entering the following command: chmod 777 purview_appliance_upgrade_to_<version>.bin 8 Run the install program by entering the following command: ./purview_appliance_upgrade_to_<version>.bin The upgrade automatically begins. You are notified when the upgrade completes. Purview PV-A-300 Appliance Installation Guide...

  • Page 26: Reinstalling Appliance Software

    When the boot is complete, the Appliance Installation screen appears and the installation begins. 9 After the installation completes, reboot the appliance and remove the USB flash drive. 10 Follow the instructions in Chapter Configuration for configuring the PV-A-300 appliance. Purview PV-A-300 Appliance Installation Guide...

  • Page 27: Enabling End-System Distributed Identity Cache

    Secondary NetSight Server on page 26 • Sharing End-System Distributed Cache Within a Single Production NetSight Server page 29 NOTE If you use communication channels between NAC gateways, do not enable the end-system distributed identity cache. Purview PV-A-300 Appliance Installation Guide...

  • Page 28: Sight Server

    1 On the production NetSight server, launch NAC Manager. 2 Navigate to Tools > Options. 3 In the left-hand tree, select NAC Manager > Advanced Settings. 4 Under End-System Mobility, check Enable distributed end-system cache. 5 Click Apply. Purview PV-A-300 Appliance Installation Guide...
  • Page 29 14 Click OK. 15 Enforce the configuration. 16 Restart the Purview appliance services: $ appidctl restart 17 Verify the second NetSight thread is spawned in the appidmgmtserver.log file. 18 Open a web page to http://<Purview appliance IP>:8080. Purview PV-A-300 Appliance Installation Guide...
  • Page 30 Sharing End-System Distributed Cache From a Production NetSight Server with a Secondary 19 Verify that the End System cache has elements and that there is a low amount of time between events. Purview PV-A-300 Appliance Installation Guide...

  • Page 31: Sharing End-System Distributed Cache Within A Single Production Netsight Server

    NOTE While only the enableNacIntegration value is mandatory, the additional FlowServerOptions provide critical value and should be included. 12 Click OK. 13 Enforce the Purview configuration. 14 Restart the Purview appliance services: $ appidctl restart Purview PV-A-300 Appliance Installation Guide...

  • Page 32: Generating An Encrypted Jms Password

    $ appidctl restart 10 Monitor the tail command output after the restart of the Purview application. A log message will include the encrypted password. 11 Remove the entry from the /opt/appid/server/conf/config.properties file: SecondNetSightTest_jmspswd=EnterasysNetSight Purview PV-A-300 Appliance Installation Guide...

  • Page 33: Installing The Pv-A-300-10G-Ug I/O Module

    For complete safety information, refer to the document Intel® Server Products Product Safety and Regulatory Compliance available at the following sites: http://download.intel.com/support/motherboards/server/sb/ • g23122003_safetyregulatory.pdf http://extranet.enterasys.com/downloads/Pages/NMS.aspx • CAUTION Observe normal ESD (ElectroStatic Discharge) procedures to avoid possible damage to system components. Purview PV-A-300 Appliance Installation Guide...

  • Page 34: Installation Procedure

    A non-skid surface or a stop behind the appliance may be needed to prevent the appliance from sliding on your work surface. a Turn off all peripheral devices connected to the appliance. b Turn off the appliance. c Disconnect the power cord. Purview PV-A-300 Appliance Installation Guide...
  • Page 35 Attach the I/O module to the server board connector (see letter “C”). d Secure the I/O module with the three screws as shown (see letter “D”). Figure 3: Placing the I/O Module in the Appliance 4 Install the system cover: Purview PV-A-300 Appliance Installation Guide...
  • Page 36 Lock the right end of the front bezel to the rack handle (see letter “A” in Figure Figure 5: Installing the Front Bezel on the PV-A-300 a Rotate the front bezel clockwise till the left end clicks into place (see letter “B”). b Lock the bezel if needed. Purview PV-A-300 Appliance Installation Guide...
