Extreme Networks Universal Compute
Platform Appliance 3160C
Installation Guide: Setup, Configuration, and
Compliance
9039099-00 Rev AA
February 2025

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 3160C and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Extreme Networks 3160C

  • Page 1 Extreme Networks Universal Compute Platform Appliance 3160C Installation Guide: Setup, Configuration, and Compliance 9039099-00 Rev AA February 2025...
  • Page 2: Legal Notice

    Extreme Networks, Inc. reserves the right to make changes in specifications and other information contained in this document and its website without prior notice. The reader should in all cases consult representatives of Extreme Networks to determine whether any such changes have been made.
  • Page 3: Table Of Contents

    Industry Canada, Class A................................24 Conformitè Europëenne (CE) Notice..........................25 Japan (VCCI) - Voluntary Control Council for Interference Class A ITE........... 25 European Waste Electrical and Electronic Equipment (WEEE) Notice..........25 Hazardous Substances.................................25 Extreme Networks Universal Compute Platform Appliance 3160C...
  • Page 4 Table of Contents Supplement to Product Instructions..........................26 CCC Statement - China................................27 BSMI Statement - Taiwan................................27 EMC Statement - Korea................................28 Index..............................29 Extreme Networks Universal Compute Platform Appliance 3160C...
  • Page 5: Abstract

    The Universal Compute Platform Appliance 3160C Installation Guide by Extreme Networks Inc., released in February 2025, offers comprehensive instructions for the setup, configuration, and compliance of the 3160C appliance. This guide includes an overview of the appliance's specifications, detailed installation steps, and configuration instructions for the management interface.
  • Page 6: Preface

    When a feature, function, or operation pertains to a specific hardware product, the product name is used. When features, functions, and operations are the same across an entire product family, such as Extreme Networks switches or SLX routers, the product is the switch or the router .
  • Page 7: Documentation And Training

    When a backslash separates two lines of a command input, enter the entire command at the prompt without the backslash. Documentation and Training Find Extreme Networks product information at the following locations: Extreme Networks Universal Compute Platform Appliance 3160C...
  • Page 8: Open Source Declarations

    Some software files have been licensed under certain open source licenses. Information is available on the Open Source Declaration page. Training Extreme Networks offers product training courses, both online and in person, as well as specialized certifications. For details, visit the Extreme Networks Training page. Help and Support...
  • Page 9: Subscribe To Product Announcements

    You can modify your product selections or unsubscribe at any time. Send Feedback The User Enablement team at Extreme Networks has made every effort to ensure that this document is accurate, complete, and easy to use. We strive to improve our documentation to help you in your work, so we want to hear from you.
  • Page 10: Overview

    Power Supply Unit LED on page 12 The Extreme Networks 3160C appliance is an Universal Compute Platform cloud-based network appliance for large deployments, such as businesses, clinics, or schools. It fits a 19-inch rack and features four data ports, four USB ports, and two Inter-Cluster-Connect (ICC) ports.
  • Page 11: Leds

    Two USB 3.2 ports • Two 25 Gb SFP28 Ethernet ports • Two 100 Gb QSFP28 Ethernet ports LEDs The 3160C has the following status LEDs on the front of the chassis: • Information LED • ICC2 LED • ICC1 LED •...
  • Page 12: Power Supply Unit Led

    Data port 1 and 2, 1/10/25 GbE SFP28 Data port 3 and 4, 10/25/50/100 GbE QSFP28 The 3160C has the following hardware features located on the back panel. Figure 2: The 3160C Back Panel Table 5: The 3160C Back Panel...
  • Page 13 Power supply warning events where power supply 1Hz Blinking Amber continues to operate — high temp, high power, high current, or slow fan. Power supply critical event causing a shutdown, Amber failure, OCP, OVP, or fan fail. Extreme Networks Universal Compute Platform Appliance 3160C...
  • Page 14: Installation

    16 Connect to a Power Source on page 17 Use the information in the following sections to install the 3160C appliance. Installation Workflow The following table lists the installation tasks. Use this information as a guide when you install the 3160C.
  • Page 15: Verify The Box Contents

    Verify the Box Contents Verify the Box Contents About This Task The 3160C ships with everything needed for a basic installation. Confirm that you have received the following items before you install your appliance. Note The power cord must be purchased separately for the respective country where you are deploying the device.
  • Page 16: Mount The Appliance

    You can also mount the appliance on a tabletop or shelf. Ensure at least 2.5 in. (6 cm) of clearance on all sides of the unit for proper ventilation. Extreme Networks Universal Compute Platform Appliance 3160C...
  • Page 17: Connect To A Power Source

    2. Plug the other end of the cables into grounded electrical outlets or to separate power sources such as an uninterrupted power supply (UPS) or a power distribution unit (PDU). 3. Power on the appliance. The power button is on the front control panel. Extreme Networks Universal Compute Platform Appliance 3160C...
  • Page 18: Configuration

    • Data plane settings About This Task You can configure the 3160C appliance from the appliance console port if you have physical access to it. Configuration is asynchronous, but you can see the boot up process. The console port is on the appliance's front panel. See Front and Back Panel Information.
  • Page 19 The Universal Compute Platform login screen opens. 10. Enter admin and the credentials that were created when setting up the installation wizard. Note An installation wizard is available to help configure the 3160C for new deployments. Extreme Networks Universal Compute Platform Appliance 3160C...
  • Page 20: Configure The Management Interface From The Inter-Cluster-Connect Port

    Use the information in the following tables to interpret the LED patterns. Table 9: RJ45 Port LEDs (Inter-Cluster-Connect 1 and 2) LED type LED pattern Status Network speed (left) 100 Mbps Solid amber 1,000 Mbps (1 Gbps) Solid green 10,000 Mbps (10 Gbps) Extreme Networks Universal Compute Platform Appliance 3160C...
  • Page 21: Install A Transceiver

    Connect Cables to Transceiver Ports About This Task Connect the cables after you have installed the transceiver. Procedure 1. Remove the protective covers from the transceiver and from the connectors on each end of the cable. Extreme Networks Universal Compute Platform Appliance 3160C...
  • Page 22 Fiber-optic transceivers use Class 1 lasers. Do not use optical instruments to view the laser output. The use of optical instruments to view laser output increases eye hazard. When viewing the output optical port, power must be removed from the network adapter. Extreme Networks Universal Compute Platform Appliance 3160C...
  • Page 23: Regulatory Information

    27 EMC Statement - Korea on page 28 The following sections detail the regulatory information for the 3160C appliance. Safety Guidelines Learn about the safety guidelines that are intended to protect your personal safety and prevent damage to the equipment.
  • Page 24: Battery Notice

    “Digital Apparatus,” ICES-003 of the Canadian Department of Communications. Cet appareil numérique respecte les limites bruits radioélectriques applicables aux appareils numériques de Classe A prescrites dans la norme sur le matériel Extreme Networks Universal Compute Platform Appliance 3160C...
  • Page 25: Conformitè Europëenne (Ce) Notice

    For information about the available collection system, please contact Extreme Environmental Compliance at Green@extremenetworks.com. Hazardous Substances This product complies with the requirements of Directive 2011/65/EU and its amendments of the European Parliament and of the Council of 8 June 2011 on the Extreme Networks Universal Compute Platform Appliance 3160C...
  • Page 26: Supplement To Product Instructions

    Supplement to Product Instructions Regulatory Information restriction of the use of certain hazardous substances in electrical and electronic equipment. Supplement to Product Instructions Extreme Networks Universal Compute Platform Appliance 3160C...
  • Page 27: Ccc Statement - China

    This is a class A product. In a domestic environment this product may cause radio interference in which case the user may be required to take adequate measures. Taiwan BSMI : 02-2715-7336 Warning Extreme Networks Universal Compute Platform Appliance 3160C...
  • Page 28: Emc Statement - Korea

    EMC Statement - Korea Regulatory Information Warning EMC Statement - Korea Extreme Networks Universal Compute Platform Appliance 3160C...
  • Page 29: Index

    , see technical support Industry Canada Notice 24 Installation 14 interface technical support configuration 18 contacting 8, 9 console port 18 management interface 18 warnings 6 LEDs power supply unit LED 12 Extreme Networks Universal Compute Platform Appliance 3160C...
