- Page 1 ™ ExtremeWireless Appliance C5215 Installation Guide 9035111 Published November 2017...
- Page 2 Copyright © 2017 Extreme Networks, Inc. All rights reserved. Legal Notice Extreme Networks, Inc. reserves the right to make changes in specifications and other information contained in this document and its website without prior notice. The reader should in all cases consult representatives of Extreme Networks to determine whether any such changes have been made.
-
Page 3: Table Of Contents
Table of Contents Preface............................4 Text Conventions...................................4 Platform-Dependent Conventions..........................4 Providing Feedback to Us..............................5 Getting Help.....................................5 Extreme Networks Documentation..........................6 Chapter 1: Overview........................7 Features..................................... 7 Hard Drive LED Indicator Patterns..........................7 Chapter 2: Installation Process....................8 Verifying the Box Contents.............................. 8 Connecting to a Power Source............................ -
Page 4: Preface
Preface Text Conventions The following tables list text conventions that are used throughout this guide. Table 1: Notice Icons Icon Notice Type Alerts you to... General Notice Helpful tips and notices for using the product. Note Important features or instructions. Caution Risk of personal injury, system damage, or loss of data. -
Page 5: Providing Feedback To Us
Ideas for improvements to our documentation so you can find the information you need faster. • Broken links or usability issues. If you would like to provide feedback to the Extreme Networks Information Development team about this document, please contact us using our short online feedback form. -
Page 6: Extreme Networks Documentation
Preface Extreme Networks Documentation To find Extreme Networks product guides, visit our documentation pages at: Current Product Documentation www.extremenetworks.com/documentation/ Archived Documentation (for earlier www.extremenetworks.com/support/documentation-archives/ versions and legacy products) Release Notes www.extremenetworks.com/support/release-notes Open Source Declarations Some software files have been licensed under certain open source licenses. More information is available at: www.extremenetworks.com/support/policies/software-licensing. -
Page 7: Chapter 1: Overview
Overview Features Hard Drive LED Indicator Patterns The C5215 is a new server platform from ExtremeWireless ™ that helps manage up to 1000 APs in standalone mode in mid-to-high capacity deployment areas, such as stadiums, healthcare campus, and higher-education. The C5215 controller supports mixed mode deployments of 802.11ac, 802.11n, and 802.11a/b/g APs along with the ability to seasmlessly transition between wireless appliances and access points, providing scability and ease of deployment. -
Page 8: Chapter 2: Installation Process
Installation Process Verifying the Box Contents Connecting to a Power Source Attaching the Front Bezel Installing a Power Supply Module Removing a Power Supply Module Replacing a Power Supply Warning Only qualified personnel should perform installation procedures. Caution An antistatic wrist strap is required to perform the following procedures to minimize ESD damage to the devices involved. -
Page 9: Connecting To A Power Source
Installation Process Table 5: C5215 Box Contents (continued) Quantity Item Rack mounting kit Front panel bezel Note The power cord needs to be purchased separately for the respective deployment country. They can be ordered at http://www.extremenetworks.com/product/powercords/ 2 Perform a visual inspection of the controller for any signs of physical damage. Contact Extreme Networks if there are any signs of damage. - Page 10 Installation Process Port Number Description Power Supply Module #1 Power Supply Module #2 Mgmt Port, 1 GbE RJ45 (eth0) Port 4 (not used, plugged) Video Connector RJ45 Serial-A Port USB 2.0/3.0 Ports RMM4 NIC Port (not used, plugged) Data Port 1, 1GbE RJ45(esa0) Data Port 2, 1GbE RJ45(esa0) Data Port 3, 1/10GbE SFP+(esa2) Data Port 4, 1/10GbE SFP+(esa3)
-
Page 11: Attaching The Front Bezel
Installation Process Figure 3: C5215 Front Control Panel Marking Description System ID Button w/ Integrated LED NMI Button Mgmt Port Activity LED Not Used System Cold Reset Button Drive Activity LED System Status LED Power Button w/ Integrated LED Attaching the Front Bezel The appliance comes with an optional front panel bezel, which can be attached to the front of the chassis by snapping it on the rack handles. -
Page 12: Installing A Power Supply Module
Installation Process 2 Rotate the front bezel clockwise until the left end clicks into place (see letter “B” below). Figure 4: Attaching the Optional Bezel 3 Lock the bezel if needed. Installing a Power Supply Module Follow this procedure to install a power supply module to a C5215 controller: If an Insert is installed, remove it from the chassis power supply bay. -
Page 13: Removing A Power Supply Module
Installation Process 2 Insert the power supply module into the power supply bay. Figure 6: Installing a Power Supply Module 3 Push the power supply module into the power supply bay until it locks into place. Removing a Power Supply Module Follow this procedure to remove a power supply module from the C5215 controller: Caution You can hot-swap the power supply without turning the system down only if the system is... -
Page 14: Replacing A Power Supply
Installation Process 2 Using the handle in the bottom of the power supply module, pull the power supply from the system while pushing the green latch in the direction indicated in the image. Figure 7: Removing a Power Supply Module Replacing a Power Supply The appliance has two power supplies, supplying hot-pluggable power redundancy. - Page 15 Installation Process Table 6: Power Supply Status LED Indicator Patterns (continued) LED Pattern Power Supply Condition Amber Power supply critical event causing a shutdown, failure, OCP, OVP, fan fail 2Hz Blinking Green Power supply firmware updating ExtremeWireless™ Appliance C5215 Installation Guide...
-
Page 16: Chapter 3: Configuring The C5215 Controller
192.168.10.0/24 subnet. 3 Launch your web browser and type https://192.168.10.1:5825. (192.168.10.1 is the default IP address on the appliance’s management port). The Extreme Networks Wireless Assistant logon screen is displayed. 4 Type admin as the User Name and abc123 as the Password. -
Page 17: Configuring The C5215 System
16 Disconnect your laptop from the appliance’s management port. 17 Connect the appliance’s management port to the enterprise Ethernet LAN. 18 Log on to the Extreme Networks Wireless Assistant. The system is now visible to the enterprise network. Configuring the C5215 System Before you begin configuration: •... - Page 18 Configuring the C5215 Controller 3 Verify that a link exists by checking that the Activity Link LED is on (solid green or blinking green). If the Activity Link LED is off, perform the following steps until it is on: a Verify that the cabling being used is Category 5 or better with an impedance between 85 and 111 ohms with a maximum length of 100 meters (328 feet).
- Page 19 Configuring the C5215 Controller Table 7: RJ45 Port LEDs (Management Port) LED Type LED Pattern Status Indication Network Speed (Right) 10 Mbps Amber 100 Mbps Green 1000 Mbps Link Activity (Left) No link Solid Green Active link Blinking Green Data traffic activity Table 8: Port LEDs (Data Ports 1 and 2) LED Type LED Pattern...
-
Page 20: Chapter 4: Specifications
Specifications This section lists the specifications for the ExtremeWireless™ Appliance C5215 Controller. Table 10: Specifications for the C5215 contoller Item Specification AP Part Number: 30136 WS-C5215 WLAN CONTROLLER Enclosure material AP enclosure is not plenum rated. Power source The controller is powered through two 750W Redundant Power Supplies. -
Page 21: Chapter 5: Regulatory Information
Regulatory Information United States Canada CE Notice VCCI Notice BSMI EMC Statement — Taiwan Other Country Specific Compliance Standards, Approvals, and Declarations Hazardous Substances European Waste Electrical and Electronic Equipment (WEEE) Notice For complete regulatory compliance and safety information, refer to the document Intel® Server Products Product Safety and Regulatory Compliance, available at the following links: http:// download.intel.com/support/motherboards/server/sb/ g23122003_safetyregulatory.pdf... -
Page 22: Canada
Regulatory Information Phone: 1-800-628-8686 Canada CE Notice This product has been determined to be in compliance with 2006/95/EC (Low Voltage Directive), 2004/108/EC (EMC Directive). VCCI Notice This is a class A product based on the standard of the Voluntary Control Council for Interference by Information Technology Equipment (VCCI). -
Page 23: Other Country Specific Compliance Standards, Approvals, And Declarations
Regulatory Information Other Country Specific Compliance Standards, Approvals, and Declarations ExtremeWireless™ Appliance C5215 Installation Guide... -
Page 24: Hazardous Substances
Regulatory Information Hazardous Substances This product complies with the requirements of Directive 2011/65/EU of the European Parliament and of the Council of 8 June 2011 on the restriction of the use of certain hazardous substances in electrical and electronic equipment. European Waste Electrical and Electronic Equipment (WEEE) Notice In accordance with Directive 2012/19/EU of the European Parliament on waste electrical and electronic...
