Sony CDP-M7 Service Manual page 26

BD
DISPLAY
Ref. No. Part No. Description
R116 1-216-061-00 METAL CHIP
R117 1-216-069-00 METAL CHIP
R118 1-216-049-91 METAL GLAZE
R119 1-216-089-91 METAL GLAZE
R120 1-216-089-91 METAL GLAZE
R121 1-216-114-00 METAL GLAZE
R122 1-216-097-91 METAL GLAZE
R123 1-216-099-00 METAL CHIP
R124 1-216-091-00 METAL CHIP
R125 1-216-069-00 METAL CHIP
R126 1-216-063-91 METAL GLAZE
R127 1-216-089-91 METAL GLAZE
R128 1-216-105-91 METAL GLAZE
R129 1-216-049-91 METAL GLAZE
R130 1-216-079-00 METAL CHIP
R131 1-216-079-00 METAL CHIP
R132 1-216-061-00 METAL CHIP
R133 1-216-061-00 METAL CHIP
R134 1-216-065-00 METAL CHIP
R135 1-216-065-00 METAL CHIP
R136 1-216-073-00 METAL CHIP
R137 1-216-065-00 METAL CHIP
R138 1-216-049-91 METAL GLAZE
R139 1-216-033-00 METAL CHIP
R140 1-216-081-00 METAL CHIP
R141 1-216-061-00 METAL CHIP
R142 1-216-061-00 METAL CHIP
R143 1-216-121-91 METAL GLAZE
R144 1-216-073-00 METAL CHIP
R145 1-216-097-91 METAL GLAZE
R146 1-216-097-91 METAL GLAZE
R147 1-216-049-91 METAL GLAZE
R148 1-216-049-91 METAL GLAZE
R149 1-216-049-91 METAL GLAZE
R150 1-216-037-00 METAL CHIP
R151 1-216-037-00 METAL CHIP
R152 1-216-037-00 METAL CHIP
R153 1-216-082-00 METAL GLAZE
R154 1-216-065-00 METAL CHIP
R156 1-216-085-00 METAL CHIP
R157 1-216-069-00 METAL CHIP
R158 1-216-001-00 METAL CHIP
< VARIABLE RESISTOR >
RV101 1-241-396-11 RES, ADJ, METAL GLAZE 22K
RV102 1-241-396-11 RES, ADJ, METAL GLAZE 22K
RV103 1-241-396-11 RES, ADJ, METAL GLAZE 22K
< SWITCH >
S101 1-572-085-11 SWITCH, LEAF (LIMIT)
Ref. No.
Remark
3.3K 5% 1/10W
6.8K 5% 1/10W
1K 5% 1/10W
47K 5% 1/10W
************************************************************
47K 5% 1/10W
510K 5% 1/10W
*
100K 5% 1/10W
120K 5% 1/10W
*
56K 5% 1/10W
6.8K 5% 1/10W
*
3.9K 5% 1/10W
*
47K 5% 1/10W
220K 5% 1/10W
1K 5% 1/10W
18K 5% 1/10W
18K 5% 1/10W
3.3K 5% 1/10W
3.3K 5% 1/10W
4.7K 5% 1/10W
4.7K 5% 1/10W
10K 5% 1/10W
4.7K 5% 1/10W
1K 5% 1/10W
220 5% 1/10W
22K 5% 1/10W
3.3K 5% 1/10W
* CN501
3.3K 5% 1/10W
* CN502
1M 5% 1/10W
10K 5% 1/10W
100K 5% 1/10W
100K 5% 1/10W
1K 5% 1/10W
1K 5% 1/10W
1K 5% 1/10W
330 5% 1/10W
330 5% 1/10W
330 5% 1/10W
24K 5% 1/10W
4.7K 5% 1/10W
33K 5% 1/10W
6.8K 5% 1/10W
10 5% 1/10W
— 40 —
Part No. Description
< VIBRATOR >
X101 1-579-280-11 VIBRATOR, CRYSTAL (16.9344MHz)
A-4673-994-A DISPLAY BOARD, COMPLETE (SP,HK,JE)
***********************************
A-4673-998-A DISPLAY BOARD, COMPLETE (US,CND)
*********************************
4-955-901-01 CUSHION (FL)
4-977-695-01 HOLDER (FL)
< CAPACITOR >
C501 1-164-159-11 CERAMIC
C502 1-162-302-11 CERAMIC
C503 1-162-292-31 CERAMIC
C504 1-162-294-31 CERAMIC
C505 1-162-294-31 CERAMIC
C506 1-164-159-11 CERAMIC
C507 1-164-159-11 CERAMIC
C508 1-164-159-11 CERAMIC
C509 1-164-159-11 CERAMIC
C511 1-126-177-11 ELECT
< CONNECTOR >
1-568-845-11 SOCKET, CONNECTOR 31P
1-568-832-11 SOCKET, CONNECTOR 13P
< FILTER >
FL501 1-517-462-11 INDICATOR TUBE, FLUORESCENT
< IC >
IC501 8-759-377-67 IC uPD780205GF-016-3BA
< TRANSISTOR >
Q502 8-729-900-80 TRANSISTOR DTC114ES
Q503 8-729-900-80 TRANSISTOR DTC114ES
< RESISTOR >
R502 1-249-413-11 CARBON
R503 1-249-415-11 CARBON
R504 1-249-417-11 CARBON
R505 1-247-807-31 CARBON
R506 1-247-807-31 CARBON
R507 1-247-807-31 CARBON
R508 1-247-807-31 CARBON
R509 1-247-807-31 CARBON
R510 1-247-807-31 CARBON
R512 1-249-413-11 CARBON
R513 1-249-415-11 CARBON
Remark
0.1uF 50V
0.0022uF 30% 16V
680PF 10% 50V
0.001uF 10% 50V
0.001uF 10% 50V
0.1uF 50V
0.1uF 50V
0.1uF 50V
0.1uF 50V
100uF 20% 10V
470 5% 1/4W F
680 5% 1/4W F
1K 5% 1/4W F
100 5% 1/4W
100 5% 1/4W
100 5% 1/4W
100 5% 1/4W
100 5% 1/4W
100 5% 1/4W
470 5% 1/4W F
680 5% 1/4W F
