4.8 Turn the wheel of the print head module to ensure the
ribbon is tightly wound.
4.9 Press down the print head module firmly on both sides till
you hear a snap.
Wheel
Print Head Module
Note:
1. Compact-series ribbons
coating). Outside-coating ribbon is not acceptable.
2. Optional ribbon core adapter is available once ribbon
width is less than 4'' width.
are wound face (inside
11

5. Loading the Media

Compact-Series printers can be operated in three different
options: standard, peel-off, or with a cutter.
- Standard mode allows you to collect each label freely.
- In peel-off mode, the backing material is being peeled away
from the label as it is printed. After the former label is
removed, the next one will be printed.
- In cutter mode, the printer automatically cuts the label after
it is printed.
