  • Page 2 Congratulations Congratulations on your purchase of this electronic keyboard! This keyboard is easy-to-use, with advanced functions especially suitable for self-learning beginners. No matter you are adult or children, you will enjoy playing the keyboard as it provides amazing styles for accompaniment, expressive tones, and real time record. Other features such as numbered musical notation display chord dictionary, variety of songs will help you better master the playing skill.
  • Page 3 Important Notes Your keyboard will give you years of playing pleasure if you follow the simple rules given below: Location Cleaning Do not expose the unit to the following Clean the unit with a soft dry cloth. A slightly dampened cloth may remove con dit ion s to avo i d defo rmat i on, stubborn grime and dirt.
  • Page 4 Main Features KEYBOARD 61-key touch keyboard OPERATION Use numeric keypad and [+/YES] [-/NO] to select voice, style and song Function including Transpose, ， Octave, Beat, Split point, MIDI Accomp volume, Bank select ， 。 VOICE 157 voices in total, including 128 GM Voices, 6 Percussion Voices, and Synth Voices. STYLE 100 styles in total, including 10 PIANO styles.

  • Page 5: Table Of Contents

    Contents General Guide......Record............ ＊Start Record............. ＊Front Panel..........＊Stop Record............＊Rear Panel........... ＊Playback Record..........＊LCD Display........... Function Menu........ 22-23 Preparation........＊Transpose............. ＊Power Supply........... ＊Octave............＊Setting the Music Stand......... ＊Beat..........＊Split Point............. ＊MIDI IN............Connections........＊MIDI OUT..........＊Headphones Jack........＊Accomp Volume..........＊Sustain Jack.........

  • Page 6: General Guide

    General Guide Front Panel 100 SONGS 100 S TYLES 157 VOICES 2 DEMOS 001-014 CLASSIC 001-015 BEAT POP 071-080 LATIN 001-008 PIANO 049-056 STRING ENSEMBLE 097-104 EFFECTS LITTER BROWN JUG 015-040 FAVORITE 016-028 ROCK 081-090 T RADITIONAL 009-016 MALLET 057-064 BRASS 105-112 ETHNIC 002 CHA CHA 041-066 FOLK...

  • Page 7: Preparation

    Preparation Power Supply This electronic keyboard can be powered by the current of a standard household wall outlet (using the specified AC adaptor) or by batteries. Using the AC Adaptor Make sure that only the AC adaptor specified for this electronic keyboard is used.

  • Page 8: Setting The Music Stand

    Preparation Setting Music Stand Please set up the music stand as the instruction below: Connections Headphones Jack If you prefer to play with headphones for high quality personal monitoring, plug a set of stereo headphones into the rear panel PHONES jack. Plug a set of headphones into the PHONES jack and the speakers will be disabled automatically.

  • Page 9: Sustain Jack

    Connections Sustain Jack An optional footswitch can be plugged into the SUSTAIN jack for sustain control. The footswitch functions like the damper pedal of a piano. Press for sustain, release for normal sound. USB Jack Connect PC or other USB host devices that support USB Audio.

  • Page 10: Basic Operation

    Basic Operation Power Switch First, please ensure the correct connection has been made based on the previous instruction. POWER Turn the [POWER] switch on. The LCD display lights NOTE: If the LCD display does not light up after you turned on the keyboard, please check the power supply.

  • Page 11: Voices And Effects

    Voices and Effects There are 157 voices in total (See appendix), including 128 GM voices, 6 percussion voices, and synth voices. Select a Voice STYLE VOICE Press the [VOICE] button to enter the voice mode. The default VOICE 1 is NO:01; LCD will display VOICE 1 DEMO and its number.

  • Page 12: Sustain

    Voices and Effects Press [+/YES] / [-/NO] button or numeric keypad to select your desired voice. The default DUAL VOICE number is NO.50 Strings2. Press [DUAL] button again to turn off the DUAL VOICE. VOICE 2 will be disabled, the notes you play will return to the single voice of VOICE 1.

  • Page 13: Metronome

    Voices and Effects Metronome Press [METRO] button to enable to the metronome. METRO PIANO DUAL TOUCH SUSTAIN Press [METRO] button again to disable it. Metronome could not be played in SONG/CHORD DICT LESSON 1 RIGHT mode. LESSON 2 LEFT DUAL LESSON 3 NOTE: A.B.C.

  • Page 14: Style Control

    Style Control The keyboard has a total of 100 styles, from 01 to 100, including 10 piano styles. Select a Style STYLE VOICE Press the [STYLE] button to set the keyboard to the style mode. The default STYLE 1 is NO:01; DEMO LCD will display the STYLE flag and its number.

  • Page 15: Start A Style

    Style Control Start a Style 1. Start immediately: STYLE START/STOP SYNC INTRO/END MAIN/FILL A.B.C. Press [START/STOP] button to start the style, the drum beats of the style will be played at once. The beats will be shown on the LCD alternately. 2.

  • Page 16: Main/Fill

    Style Control Intro Start: STYLE START/STOP SYNC INTRO/END MAIN/FILL A.B.C. Press [INTRO/END] button when the style is not playing, NOR or VAR flag will flash on the LCD, indicating the intro section is ready to play. Length of the intro varies Flashing in different styles.

  • Page 17: Stop A Style

    Style Control Stop a Style Stop immediately STYLE START/STOP SYNC INTRO/END MAIN/FILL A.B.C. The accompaniment can be stopped at any time by pressing the [START/STOP] button. Ending stop Press the [INTRO/END] button to complete the style STYLE START/STOP SYNC INTRO/END MAIN/FILL A.B.C.

  • Page 18: Chord Recognize

    Style Control Chord Recognize "A.B.C." is disabled during the default setting. STYLE START/STOP SYNC INTRO/END MAIN/FILL A.B.C. Press [A.B.C.] button to turn on this "auto bass chord" function; the A.B.C. flag on the LCD is lightened. The left section of the keyboard is known as the "chord area", RIGHT LESSON 1 while playing the chord, both the bass and the chord...
  • Page 19 Style Control Chord Basics Three or more notes played together constitute a chord " ". The most basic chord type is the "triad" consisting three notes: the root, third, and fifth degrees of the corresponding scale. A "C major triad", for example, is made up of the notes C (the root), E(the third note of the C major scale),and G (the fifth note of the C major scale).

  • Page 20: Memory

    Memory There are 4 memories for storage. ONE TOUCH SETTING STORE O.T.S. Press and hold [STORE], press [M1](or [M2]-[M4]) meanwhile. The data will be stored into M1 (M2-M4). LESSON 1 RIGHT The data which can be stored into the memory are as LEFT LESSON 2 follows:...

  • Page 21: Record

    Record Start Recording METRO PIANO DUAL TOUCH SUSTAIN Press the [RECORD] button, the four-beat on the LCD will flash simultaneity, indicating the record waiting " status . " Flash simultaneously A voice, style and memory can be selected in this status. The ACCOMP track and MELODY track can be recorded LESSON 1 RIGHT...

  • Page 22: Function Menu

    Function Menu Press [FUNCTION] key to enter the menu of function. Option LCD Display Range Default The default option of the menu is TRANSPOSE . " " TRANSPOSE XPS 00 -6...6 Everytime when you enter the menu, it will return to OCTAVEOCT OCT 00 -1...1...

  • Page 23: Split Point

    Function Menu Split Point L & R Press the [FUNCTION] button to enter SPLIT POINT CHORD DICT. sub-menu. The LCD displays the current split point FUNCTION value. Use [+/YES] / [-/NO] to select the beat value. The keyboard can be also used to change the split point. LESSON The key of the split point is the part of the left area.

  • Page 24: Song

    Song There are total 100 songs in this keyboard STYLE VOICE (see Appendix). Each song can be practised in the MELODY OFF mode. START/STOP the song Press [SONG] button to enter the song mode , the " " SONG song flag on the LCD will show up. All songs will be played in a loop.

  • Page 25: Lesson 1

    Song Lesson 1-Practice an timing L & R CHORD Press [LESSON] button to enter the LESSON 1 mode, DICT. the lesson 1 flag is lightened on the LCD. Evaluation is based on the accuracy of the time value, and the accuracy of note playing will not be graded. LESSON Press [START/STOP] to begin.

  • Page 26: Lesson 3

    Song Lesson 3-Melody off L & R CHORD DICT. Press [LESSON] button in LESSON 2 to enter the LESSON 3 mode. In this mode, evaluation is based on the correctiveness LESSON of both the time value and notes. Press [START/STOP ] button to begin. STYLE START/STOP SYNC...

  • Page 27: Chord Dictionary

    Chord Dictionary Chord Dictionary is essentially a built-in chord book " " showing you the individual notes of the chords. It is ideal for you to learn the name of certain chords and to learn how to play them instantly. Press [CHORD DICT./R] button to enter the DICT mode.

  • Page 28: Midi Function

    MIDI Function What is MIDI MIDI stands for Musical Instrument Digital Interface " ", that is the standard interface between a PC and other electronic instrument(s). USB connection can be used for midi data transference with a computer or other USB host devices that support NOTE: USB audio devices.

  • Page 29: Specifications

    Specifications LCD display Multi-functional LCD Keys 61 keys with Touch Response Polyphony 32-note polyphony(max) 157 Voices Voice Style 100 Styles 100 Songs; 2 Demos Demo Song Master Volume Tempo +/-, R / Chord Dictionary, L , Lesson, Voice, ， Style, Song, O.T.S. , M1-M4, Store, Start/Stop, Sync, Intro/Ending, Control button Main/Fill, A.B.C.

  • Page 30: Appendix

    Appendix 1- Voice List SYNTH VOICE Name STRING ENSEMBLE EFFECTS PIANO Strings 1 70elep Rain Strings 2 G rand Piano Fzpiano SoundTrk Synth Strings 1 B right Piano Crystal Synth Strings 2 El Gr d Piano Atmosphr Choir Aahs Honky-To nk P iano Bright Voice Ooh Elec Piano 1...

  • Page 31: Appendix 2- Style List

    Appendix 2- Style List 8/16BEAT SOUL & FUNK TRADITIONAL 8 Beat 1 Funky Pop Marc h 1 8 Beat 2 Jaz z Funk Marc h 2 8 Beat 3 Cool Funk y German March Soul 1 8 Beat 4 6/8 March Soul 2 60's 8 Beat Polka...

  • Page 32: Appendix 3- Song List

    Appendix 3- Song List 01~1 4 C L ASSIC AL My Bonni e Cannon Yankee Doodle Thais Meditation Red River Valley Old France Auld Lang Syne Minuet When The Saint s Go Marching In Ode To Joy Twi nkle Twi nkle Little Star Wiegenlied Happ y Birt hday To You "...

  • Page 33: Appendix 4- Demo List

    Appendix 4- Demo List Number Name Little Brown Jug Cha Cha Appendix 5- Chord List Chord Name/[Abbreviation] Normal Voicing Ch ord( C) DISPLAY Major [M] 1-3 -5 1-( 3)-5 -6 Sixth [6] Major seventh[M7] 1-3 -(5) -7 Major add ninth [M(9)] CM(9) CM (9) 1-2 -3-5...

  • Page 34: Appendix 6- Midi List

    Appendix 6- MIDI List Function Remarks Transmitted Recog nized Basic Default Channel Changed 1-16ch 1-16ch De fault Mode Messages *********** Alt ered Note 18-114 0...127 Number True voice *********** 0...127 Velocity : Note on O 9nH,V=1-127 O 9nH,V=1-127 Noteoff (9nH,V=0) X (9nH,V=0;...
  • Page 35 M10_G04...
