- Page 2 Congratulations Congratulations on your purchase of this electronic keyboard! This keyboard is easy-to-use, with advanced functions especially suitable for self-learning beginners. No matter you are adult or children, you will enjoy playing the keyboard as it provides amazing styles for accompaniment, expressive tones, and real time record. Other features such as numbered musical notation display chord dictionary, variety of songs will help you better master the playing skill.
- Page 3 Important Notes Your keyboard will give you years of playing pleasure if you follow the simple rules given below: Location Cleaning Do not expose the unit to the following Clean the unit with a soft dry cloth. A slightly dampened cloth may remove conditions to avoid deformation, stubborn grime and dirt.
- Page 4 Main Features KEYBOARD 61-key touch keyboard OPERATION Use numeric keypad and [+/YES] [-/NO] to select voice, style and song，Function including Transpose, Octave, Beat, Split point, MIDI，Accomp volume, Bank select。 VOICE 157 voices in total, including 128 GM Voices, 6 Percussion Voices, and Synth Voices. STYLE 100 styles in total, including 10 PIANO styles.
-
Page 5: Table Of Contents
Contents General Guide......Record............ ＊Start Record............. ＊Front Panel..........＊Stop Record............＊Rear Panel........... ＊Playback Record..........＊LCD Display........... Function Menu........ 22-23 Preparation........＊Transpose............. ＊Power Supply........... ＊Octave............＊Setting the Music Stand......... ＊Beat..........＊Split Point............. ＊MIDI IN............Connections........＊MIDI OUT..........＊Headphones Jack........＊Accomp Volume..........＊Sustain Jack......... -
Page 6: Front/Rear Panel Overview
General Guide Front Panel 100 SONGS 100 STYLES 157 VOICES 2 DEMOS 001-014 CLASSIC 001-015 BEAT POP 071-080 LATIN 001-008 PIANO 049-056 STRING ENSEMBLE 097-104 EFFECTS 001 POP 015-040 FAVORITE 016-028 ROCK 081-090 TRADITIONAL 009-016 MALLET 057-064 BRASS 105-112 ETHNIC 002 CHA CHA 041-066 FOLK 029-038 DANCE... -
Page 7: Preparation
Preparation Power Supply This electronic keyboard can be powered by the current of a standard household wall outlet (using the specified AC adaptor) or by batteries. Using the AC Adaptor PHONES SUSTAIN Make sure that only the AC adaptor specified for this electronic keyboard is used. -
Page 8: Setting The Music Stand
Preparation Setting Music Stand Please set up the music stand as the instruction below: Connections Headphones Jack If you prefer to play with headphones for high quality personal monitoring, plug a set of stereo headphones into the rear panel PHONES jack. PHONES SUSTAIN Plug a set of headphones into the PHONES jack and... -
Page 9: Sustain Jack
Connections Sustain Jack An optional footswitch can be plugged into the SUSTAIN jack for sustain control. The footswitch functions like the damper pedal of a PHONES SUSTAIN piano. Press for sustain, release for normal sound. USB Jack Connect PC or other USB host devices that support USB Audio. -
Page 10: Basic Operation
Basic Operation Power Switch First, please ensure the correct connection has been made based on the previous instruction. POWER Turn the [POWER] switch on. The LCD display lights NOTE: If the LCD display does not light up after you turned on the keyboard, please check the power supply. -
Page 11: Voices And Effects
Voices and Effects There are 157 voices in total (See appendix), including 128 GM voices, 6 percussion voices, and synth voices. Select a Voice STYLE VOICE Press the [VOICE] button to enter the voice mode. The default VOICE 1 is NO:01; LCD will display VOICE 1 DEMO and its number. -
Page 12: Sustain
Voices and Effects Press [+/YES] / [-/NO] button or numeric keypad to select your desired voice. The default DUAL VOICE number is NO.50 Strings2. Press [DUAL] button again to turn off the DUAL VOICE. VOICE 2 will be disabled, the notes you play will return to the single voice of VOICE 1. -
Page 13: Metronome
Voices and Effects Metronome Press [METRO] button to enable to the metronome. METRO PIANO DUAL TOUCH SUSTAIN Press [METRO] button again to disable it. Metronome could not be played in SONG/CHORD DICT RIGHT LESSON 1 mode. LESSON 2 LEFT LESSON 3 DUAL NOTE: A.B.C. -
Page 14: Style Control
Style Control The keyboard has a total of 100 styles, from 01 to 100, including 10 piano styles. Select a Style STYLE VOICE Press the [STYLE] button to set the keyboard to the style mode. The default STYLE 1 is NO:01; DEMO LCD will display the STYLE flag and its number. -
Page 15: Start A Style
Style Control Start a Style 1. Start immediately: STYLE START/STOP SYNC INTRO/END MAIN/FILL A.B.C. Press [START/STOP] button to start the style, the drum beats of the style will be played at once. The beats will be shown on the LCD alternately. 2. -
Page 16: Main/Fill
Style Control Intro Start: STYLE START/STOP SYNC INTRO/END MAIN/FILL A.B.C. Press [INTRO/END] button when the style is not playing, NOR or VAR flag will flash on the LCD, indicating the intro section is ready to play. Length of the intro varies Flashing in different styles. -
Page 17: Stop A Style
Style Control Stop a Style Stop immediately STYLE START/STOP SYNC INTRO/END MAIN/FILL A.B.C. The accompaniment can be stopped at any time by pressing the [START/STOP] button. Ending stop STYLE START/STOP SYNC INTRO/END MAIN/FILL A.B.C. Press the [INTRO/END] button to complete the style with an ending section. -
Page 18: Chord Recognize
Style Control Chord Recognize STYLE START/STOP SYNC INTRO/END MAIN/FILL A.B.C. "A.B.C." is disabled during the default setting. Press [A.B.C.] button to turn on this "auto bass chord" function; the A.B.C. flag on the LCD is lightened. The left section of the keyboard is known as the "chord area", RIGHT LESSON 1 while playing the chord, both the bass and the chord... - Page 19 Style Control Chord Basics Three or more notes played together constitute a " chord ". The most basic chord type is the "triad" consisting three notes: the root, third, and fifth degrees of the corresponding scale. A "C major triad", for example, is made up of the notes C (the root), E(the third note of the C major scale),and G (the fifth note of the C major scale).
-
Page 20: Memory
Memory There are 4 memories for storage. ONE TOUCH SETTING STORE O.T.S. Press and hold [STORE], press [M1](or [M2]-[M4]) meanwhile. The data will be stored into M1 (M2-M4). LESSON 1 RIGHT LEFT The data which can be stored into the memory are as LESSON 2 LESSON 3 DUAL... -
Page 21: Record
Record Start Recording METRO PIANO DUAL TOUCH SUSTAIN Press the [RECORD] button, the four-beat on the LCD will flash simultaneity, indicating the " record waiting status " . Flash simultaneously A voice, style and memory can be selected in this status. LESSON 1 RIGHT The ACCOMP track and MELODY track can be recorded... -
Page 22: Function Menu
Function Menu Press [FUNCTION] key to enter the menu of function. Option LCD Display Range Default The default option of the menu is " TRANSPOSE " . TRANSPOSE XPS 00 -6...6 Everytime when you enter the menu, it will return to OCTAVEOCT OCT 00 -1...1... -
Page 23: Split Point
Function Menu Split Point L & R Press the [FUNCTION] button to enter SPLIT POINT CHORD DICT. sub-menu. The LCD displays the current split point FUNCTION value. Use [+/YES] / [-/NO] to select the beat value. The LESSON keyboard can be also used to change the split point. The key of the split point is the part of the left area. -
Page 24: Song
Song There are total 100 songs in this keyboard VOICE STYLE (see Appendix). Each song can be practised in the MELODY OFF mode. START/STOP the song Press [SONG] button to enter the " song mode " , the SONG song flag on the LCD will show up. All songs will be played in a loop. -
Page 25: Lesson 1
Song Lesson 1-Practice an timing L & R CHORD DICT. Press [LESSON] button to enter the LESSON 1 mode, the lesson 1 flag is lightened on the LCD. Evaluation is based on the accuracy of the time value, and the accuracy of note playing will not be graded. LESSON Press [START/STOP] to begin. -
Page 26: Lesson 3
Song Lesson 3-Melody off L & R CHORD DICT. Press [LESSON] button in LESSON 2 to enter the LESSON 3 mode. In this mode, evaluation is based on the correctiveness LESSON of both the time value and notes. Press [START/STOP ] button to begin. STYLE START/STOP SYNC... -
Page 27: Chord Dictionary
Chord Dictionary Chord Dictionary is essentially a built-in "chord book" showing you the individual notes of the chords. It is ideal for you to learn the name of certain chords and to learn how to play them instantly. Press [CHORD DICT./R] button to enter the DICT mode. L &... -
Page 28: Midi Function
MIDI Function What is MIDI MIDI stands for Musical Instrument Digital Interface " ", that is the standard interface between a PC and other electronic instrument(s). USB connection can be used for midi data transference with a computer or other USB host devices that support NOTE: USB audio devices. -
Page 29: Specifications
Specifications LCD display Multi-functional LCD Keys 61 keys with Touch Response Polyphony 32-note polyphony(max) Voice 157 Voices Style 100 Styles 100 Songs; 2 Demos Demo Song Master Volume，Tempo +/-, R / Chord Dictionary, L , Lesson, Voice, Style, Song, O.T.S. , M1-M4, Store, Start/Stop, Sync, Intro/Ending, Control button Main/Fill, A.B.C. -
Page 30: Appendix
Appendix 1- Voice List SYNTH VOICE Name STRING ENSEMBLE EFFECTS PIA NO Strings 1 70elep Rain Grand Piano Strings 2 Fzpiano SoundTrk Bright Piano Synth Strings 1 Crystal Synth Strings 2 El Grd Piano Atmosphr Choir Aahs Honky-Tonk Piano Bright Voice Ooh Elec Piano 1 Harppian... -
Page 31: Appendix 2- Style List
Appendix 2- Style List 8/16BEAT SOUL & FUNK TRADIT IO NAL 8 Beat 1 Funky Pop Marc h 1 8 Beat 2 Jazz Funk Marc h 2 8 Beat 3 Cool Funky Germ an Marc h 8 Beat 4 Soul 1 6/8 Marc h 60's 8 Beat Soul 2... -
Page 32: Appendix 3- Song List
Appendix 3- Song List 01~14 CL ASSICAL My Bonnie Cannon Yankee Doodle Thais Meditation Red River Valley Old France Auld Lang Syne Minuet When The Saints Go Marching In Ode To Joy Twinkle Twinkle Little Star Wiegenlied Happy Birthday To You "The Surprise "... -
Page 33: Appendix 4- Demo List
Appendix 4- Demo List Number Name CHA CHA Appendix 5- Chord List Chord Name/[Abbreviation] Normal Voicing Chord(C) DISPLAY Major [M] 1-3-5 1-(3)-5-6 Sixth [6] Major seventh[M7] 1-3-(5)-7 Major add ninth [M(9)] CM(9) CM (9) 1-2-3-5 Augmented [aug] Caug Caug 1-3-#5 Minor [m] 1-b3-5 Minor sixth [m6]... -
Page 34: Appendix 6- Midi List
Appendix 6- MIDI List Function Transmitted Recognized Remarks Basic Default Channel Changed 1-16ch 1-16ch Default Mode Messages Altered *********** Note 18-114 0...127 *********** 0...127 Number True voice Velocity : Note on O 9nH,V=1-127 O 9nH,V=1-127 Noteoff (9nH,V=0) X (9nH,V=0; 8nH,V=0-127 After Keys Touch... - Page 35 M10_G08...
