Chapter 10 Maintenance
Printhead Replacement, cont.
3
Remove any media and transfer ribbon.
5
Disconnect the printhead bracket from the print
mechanism as indicated by the arrows and pull
out the printhead as far as the cables allow.
56
4
Pull the printhead bracket away from the
6
Disconnect the cables from the printhead. Note
the snap-lock on the inner connector. Pull at the
Intermec EasyCoder F4 – Installation & Operation IPL Version, Ed. 1
magnet in the pressure arm.
connectors–not the cables!
Snap-lock
