- Page 1 OPERATION MANUAL OFFICE PRO 12 / OFFICE PRO 18 / OFFICE PRO 24 SERIAL NUMBER FROM APRIL 2007 (0407) TO DECEMBER 2007 (1207) READ THIS MANUAL CAREFULLY FOR INSTRUCTIONS ON CORRECT INSTALLATION AND USAGE AND READ ALL SAFEGUARDS SECCIÓN EN ESPAÑOL SECTION EN FRANÇAIS...
- Page 2 All rights reserved. This book may not be reproduced or copied, in whole or in part, without the written permission of the publisher. DENSO SALES CALIFORNIA, INC. reserves the right to make changes without prior notice. MovinCool is a registered trademark of DENSO Corporation.
-
Page 3: Operation Manual
OPERATION MANUAL OFFICE PRO 12 / OFFICE PRO 18 / OFFICE PRO 24... -
Page 4: Table Of Contents
Table of Contents FOREWORD....................... 5 Definition of Terms....................5 GENERAL WARNINGS & CAUTIONS .............. 6 INVENTORY ....................... 7 INSTALLATION....................8 Choosing an Installation Site ................8 Moving the Unit ....................9 Plugging in the Unit ..................10 Warning Signal Connection ................11 Fire Alarm Control Panel Connection ............12 LCDI Power Cord Instruction .................13 FEATURES....................... -
Page 5: Foreword
FOREWORD Congratulations on purchasing the MovinCool portable air conditioner. This manual explains how to install and operate the MovinCool Office Pro 12, Office Pro 18, and Office Pro 24 portable air conditioning units. Please read this operation manual thoroughly to familiarize yourself with the features of the unit and to ensure years of reliable operation. -
Page 6: General Warnings & Cautions
12, and 115V, 20A for Office Pro 18 and 230V, 20A for Office Pro 24 or equivalent. 4. The Office Pro 12 and Office Pro 18 are equipped with a ten (10) foot (3 meter) UL approved LCDI power cords. The Office Pro 24 is equipped with a six (6) foot (1.8 meter) UL approved LCDI power cord. -
Page 7: Inventory
After unpacking your MovinCool unit, please check to make sure you have the following items: 1. Office Pro 12 or Office Pro 18 or Office Pro 24 MovinCool Unit (1) 2. Operation Manual/Product Registration (1) Note: If any of these items were not included in the box or appear damaged, please contact your MovinCool reseller for replacement. -
Page 8: Installation
INSTALLATION Choosing an Installation Site CAUTION: Following are some precautions to consider before choosing your installation site. Please review carefully as improper installation may result in personal injury or damage to the unit. 1. Do not use the unit in areas where leakage of flammable gas may occur. 2. -
Page 9: Moving The Unit
INSTALLATION (cont.) Moving the Unit Unlock the casters and push the MovinCool unit using the side handles to a flat, level surface and set the casters back to the LOCKED position. Right Side Handle Left Side Handle UNLOCKED LOCKED... -
Page 10: Plugging In The Unit
1. Make sure the AC outlet is free of dirt, dust, oil, water, or any other foreign matter. 2. The Office Pro 12 is equipped with a UL approved LCDI cord and an approved NEMA plug configuration (5-15). The appropriate outlet must be used for this plug type. -
Page 11: Warning Signal Connection
3. Use recommended warning signal wire size from 16AWG to 26AWG for a solid wire, or 16AWG to 22AWG for a stranded wire with ring terminal for #6 stud size. 4. Connect warning device to terminal L+ and L- according to its polarities. *This function is not available in Office Pro 12. -
Page 12: Fire Alarm Control Panel Connection
16AWG to 22AWG for a stranded wire with ring terminal for #6 stud size. 4. Connect warning device to terminal E+ and E- according to its polarities. *This function is not available in Office Pro 12. Input Signal... -
Page 13: Lcdi Power Cord Instruction
INSTALLATION (cont.) LCDI Power Cord Instruction WARNING The LCDI device is non-serviceable device. Attempting to open the device may expose the user to hazardous of electric shock, and could void warranties of this product. Manufacturer’s reliability is limited to the replacement of the device. CAUTION 1. -
Page 14: Features
9. A programmable clock/timer function. This function allows the user to program a specific time and day at which the unit begins to operate/start and turn off (Automatic Operation). *This function is not available in Office Pro 12. -
Page 15: Operation
OPERATION Control Panel Before operating the unit, it is important to familiarize yourself with the basic controls located on the control panel. 1. COOL Mode Button Activates/deactivates the COOL mode/turns the unit off. 2. FAN Mode Button Activates/deactivates the high, low, and off fan speed. -
Page 16: Lcd Indicators
OPERATION (cont.) (cont.) Control Panel LCD Indicators 9. MO...SU Illuminates to indicate selected day of the week. 10. °C or °F Temperature displayed in either Fahrenheit or Celsius (see Note). 11. AM/PM Illuminates to indicate AM or PM time of day. 12. -
Page 17: Set Clock
OPERATION (cont.) Set Clock Prior to operating the Office Pro 12, Office Pro 18, or Office Pro 24 users should set the clock of the controller to the correct time as shown in the following steps: 1. Press and hold the SET CLOCK button for 3 seconds or until beep. -
Page 18: Operating In Fan Only Mode
OPERATION (cont.) Operating in FAN ONLY Mode 1. The unit can also be operated in FAN ONLY mode by pressing FAN HI/LO button (LCD indicates “FAN HI/LO” and “COOL OFF”). 2. The unit can then be turned off by pressing the FAN HI/LO button until fan turns off (FAN ONLY mode speed sequences are HI→LO→OFF). -
Page 19: How To Set A Program
OPERATION (cont.) How to Set a Program SET START TIME 1. Press and hold the SET PROG button for 3 seconds or until beep. 2. Press SET TEMP buttons to select day of the week. 3. Press ENTER button. Step 1 & 18 4. -
Page 20: How To View And Delete Program
OPERATION (cont.) How to View and Delete Program 1. Press and hold the SET PROG button for 3 seconds or until beep. 2. To view edited program - While pressing and holding the SET PROG button, press SET TEMP ( ) to scroll program sequence. -
Page 21: Operating Modes
OPERATION (cont.) Operating Modes The Office Pro 12, Office Pro 18, and Office Pro 24 can be operated in two modes, FAN ONLY and COOL. When in FAN ONLY mode, the unit circulates the surrounding air. When in COOL mode, the compressor is operational and cool air is circulated. -
Page 22: Empty The Drain Tank
Note: If you want to empty the drain tank, while the unit is in operation, press the COOL ON/OFF button to turn the unit off. *This function is not available in Office Pro 12. 1. Open the drain tank door. -
Page 23: Drain Pump Kit (Optional)
Note: The compressor does not operate while the drain pump is discharging the water for the Office Pro 12 and Office Pro 18. When the water level drops below level (B), the drain pump stops, and the compressor restarts. -
Page 24: Self-Diagnostic Codes
LCD displays “AS”. Once drain pump is fixed and unit has been RESET, the unit returns to normal operation. Contact your MovinCool reseller if problem persists. < Office Pro 24 ONLY > When high pressure switch is activated, display shows “HP” if high pressure switch is activated 3 times in 24 hours, unit displays blinking “HP”... -
Page 25: Daily Inspection & Maintenance
DAILY INSPECTION & MAINTENANCE Empty the Drain Tank To empty the drain tank, refer to instructions on page 22. Clean the Air Filters Clean the air filters once a week. If the unit is used in a dusty environment, more frequent cleaning may be required. -
Page 26: Filter Cleaning Method
2. Check the power cord, plug and prongs for damage or excess play. If any damage or excess play is found, contact your MovinCool reseller for repair. 3. Check the air filters and drain tank. -
Page 27: Troubleshooting
Insufficient cooling. 2. Air inlet/outlet blocked. Clean air inlet/outlet. 3. Improper temperature setting. Adjust temperature setting. If symptoms persist after the above actions have been taken, turn the unit off, disconnect the power cord plug and contact your MovinCool reseller. -
Page 28: Technical Specificatons
TECHNICAL SPECIFICATONS ITEMS/FEATURES Office Pro 12 Office Pro 18 Office Pro 24 Rating Conditions Dry bulb 95°F(35°C) 95°F(35°C) 95°F(35°C) Wet bulb 83°F(28.2°C) 83°F(28.2°C) 83°F(28.2°C) Humidity (60%) (60%) (60%) Specifications Power frequency 60Hz 60Hz 60Hz Line voltage Single Phase 115V Single Phase 115V... -
Page 29: Limited Warranty
LIMITED WARRANTY DENSO SALES CALIFORNIA, INC. (“DENSO”) warrants its MOVINCOOL Products only to the extent stated in its official written warranties. Unless otherwise specifically provided in writing by DENSO, DENSO warrants to end-user that the Products shall be free of defects in materials or workmanship and will function in accordance with DENSO’s published specifications under... - Page 30 DENSO SALES CALIFORNIA, INC. Long Beach, CA 90810 www.movincool.com P/N: 484007- 2112EN Third Issue: July 2011...
