- Page 1 BA91W LCD TFT Panel Display User Manual...
- Page 2 Please send us a copy of this page if you have any constructive criticism. We would like to thank you in advance for your comments. With kind regards. Your Opinion: Wincor Nixdorf Pte Ltd Research and Development 151 Lorong Chuan New Tech Park #05-01A/B...
- Page 3 BA91W LCD TFT Flat Panel Display User Manual Edition September 2014...
- Page 4 All brand and product names mentioned in this document are trademarks of their respective owners. Copyright © Wincor Nixdorf International GmbH, 2014 The reproduction, transmission or use of this document or its contents is not permitted without express authority. Offenders will be liable for damages.
-
Page 5: Table Of Contents
............8 Preparing the stand ................ 9 Preparing the display ..............9 Installing the stand ............... 10 Connector panel (BA91W /pc-touch) ..........12 Connector panel (BA91W /non-Touch) .......... 13 Connecting the display ..............14 Ergonomic Terminal Workplace ........... 16 On Screen Display (OSD) .............. -
Page 7: Introduction
The low-energy and flicker-free color monitor of the BA91W is a LCD in TFT-technology (Thin Film Transistor). Therefore, it is well suited for multimedia applications as it offers brilliant color representation, an excellent contrast ratio and a high display speed. -
Page 8: Advantages At A Glance
This manual informs you about everything you might need to know for the installation (software and hardware), the operation and the maintenance of your BA91W. Some parts of this book require familiarity and experience in working with operating systems and installation and configuration procedures. -
Page 9: The Flat Panel Display
The TFT LCD flat panel display is an 10.1-inch flat panel display which is ab- solutely flicker-free. It is designed for a resolution of max. 1280X800 pixels. BA91W with standard cable cover BA91W with standard cable cover type 2 (optional) BA91W User Manual... -
Page 10: Operator Panel
Via the menu you can set the brightness, contrast and color. Scrolling The arrows serve for scrolling forwards or backwards in the menu items. LED off Power off green Power on orange Power save mode the LED lights in the standby mode Out of Range BA91W User Manual... -
Page 11: On/Off Button
5 seconds to lock/unlock the OSD function. The power button can be lock/unlock through the OSD Menu. - Software method Using „DDC control“ utility provided by Wincor Nixdorf, OSD function and power button can be lock/unlock remotely through the software command. BA91W User Manual... -
Page 12: Projected Capacitive Touch Screen
With a circular motion of the fingers the element on the dis- play can be rotated. This function must be supported by either the operating system or by the application. BA91W User Manual... -
Page 13: Cleaning Instructions
Use a soft, fine-meshed cloth to clean the surface. Dampen the cloth slightly and then clean the screen. A wrong maintenance may cause damages to the screen, which are not covered by guarantee or warranty. BA91W User Manual... -
Page 14: Lnstalling And Securing
Wincor Nixdorf sales outlet. Transport the device only in its original packaging (to protect it against impact and shock). -
Page 15: Preparing The Stand
2. Lay the display face down on the protection sheet. 3. Tighten the two screws half way through. 4. Remove the cable cover at the bottom of the display. BA91W User Manual... -
Page 16: Installing The Stand
Installing the stand 1. Bring the display to above the stand. 2. Place the screws (that were previously tightened half- way through) to the two U- shaped groove on the frame of the stand. BA91W User Manual... - Page 17 3. Tighten the two screws to secure the display to the stand. 4. Place in the VESA cover. When uninstalling the stand always make sure that all cables are disconnected. BA91W User Manual...
-
Page 18: Connector Panel (Ba91W /Pc-Touch)
Connector panel (BA91W /pc-touch) The following sockets are located under the bezel of the display: DC-Power Jack USB-B DVI-I / PLINK2™ （12V） Power Jack Power input for the screen via external power supply (12V) USB-B USB connection to the PC system DVI-I / PLINK2™... -
Page 19: Connector Panel (Ba91W /Non-Touch)
Connector panel (BA91W /non-Touch) The following sockets are located under the bezel of the display: DC-Power Jack DVI-I / PLINK2™ （12V） Power Jack Power input for the screen via external power supply (12V) DVI-I / PLINK2™ DVI-I / PLINK2™ for video/data transfer between the... -
Page 20: Connecting The Display
Before connecting cables switch off the system and disconnect it from the main supply. For display on mounted on a stand 1. Push down the cable cover to release it and slide the cover out of the guide. The connector panel is now accessible. BA91W User Manual... - Page 21 USB A ca- ble and connect the plug. Make sure that cables are not secured by a lock, are loosely inserted into the strain relief. 3. Replace the cable cover. 4. Pull out the cable through the opening. BA91W User Manual...
-
Page 22: Ergonomic Terminal Workplace
Position the screen within a preferred and permit ted 0° range of vision, so that you 40° can look vertically onto the screen. 30° 30° preferred range of vision BA91W User Manual... -
Page 23: On Screen Display (Osd)
There are two ways to exit the OSD menu: via exit or wait for the OSD to time-out (saves changes and exit). The adjustments will be saved in each way. There are a number of parameters that can be set via the OSD menu. BA91W User Manual... -
Page 24: Technical Data
1280 pixel Resolution Vertical 800 pixel Color depth Up to 16.7 Mio. internal LVDS Interface external PLINK2, DVI-I Reading right/left +/- 70° Angle, top/bottom 50°/70° Projected Capacitive 300 cd/ m Brightness Non Touch 310 cd/ m Backlight BA91W User Manual... -
Page 25: Dimensions (Mm)
Dimensions (mm) BA91W BA91W User Manual... -
Page 26: Projected Capacitive Touch Screen
Projected Capacitive Touch Screen Horizontal Resolutions Vertical LCD Technology Projected capacitive Surface Anti-glare Data transfer Power Consumption BA91W Max. 5.60W Typ./Factory Settings 4.60W Standby <=0.5W Soft off <=0.5W BA91W User Manual... -
Page 27: Manufacturer's Declaration And Approval
Modifications not authorized by the manufacturer may void users authori- ty to operate this device. This class A digital apparatus complies with Canadian ICES-003. Cet appareil numerique de la classe A est conforme à la norme NMB-003 du Canada. BA91W User Manual... -
Page 28: Tested Safety
Tested Safety The BA91W has been awarded the cUL- and UL- sym- bol. Energy Star The BA91W has been awarded the ENERGY STAR symbol. User Information Repair work on the devices should only be carried out by authorized and specially trained personnel. Improper repairs will lead to the loss of any guarantee and liability claims. - Page 29 BEETLE or PC should be removed, and the Wincor Nixdorf customer service should be contacted. If the LCD display element is broken and the liquid crystal solution leaks out of the display and onto your hands, clothing etc., wash your hands or clothing immediately with soap or...
-
Page 30: Instructions For Maintenance
Also switch your display off when you take a longer break or finish your work. There are still some parts that are not reusable. Wincor Nixdorf guarantees the environmentally safe disposal of these parts in a Recycling Center, which is certified pursuant to ISO 9001 and ISO 14001. - Page 31 Please contact your competent branch or the Recycling Center Paderborn (for European countries) for information on how to return and re-use de- vices and disposable materials under the following mail address: Email: info@wincor-nixdorf.com We look forward to your mail. BA91W User Manual...
-
Page 32: Abbreviation Index
Low Voltage Differential Signal On Screen Display SVGA Super Video Graphics Array Thin Film Transistor Technology (LCD Technology) Universal Serial Bus Underwriters Laboratory (standards) Verband Deutscher Elektrotechniker (German Electricians Association) VESA Video Electronics Standard Association Video Graphics Array BA91W User Manual... - Page 33 Wincor Nixdorf Pte Ltd 151 Lorong Chuan New Tech Park #05-01A/B Singapore 556741 Order No.: 01750266947A...
