Chapter 4: System Management

Overview

The N5200PRO provides an easily accessible Web Administration Interface.
With it, you can configure and monitor the N5200PRO anywhere on the network.

Web Administration Interface

Make sure your network is connected to the Internet. To access the N5200PRO
Web Administration Interface:
1. Type the N5200PRO's IP address into your browser. (Default IP address is
http://192.168.1.100)
NOTE
2. Login to the system using the administrator user name and password. The
factory defaults are:
User Name: admin
Password: admin
If you changed your password in the setup wizard, use the new password.
Once you are logged in as an administrator, you will see the Web
Administration Interface. From here, you can configure and monitor virtually
every aspect of the N5200PRO from anywhere on the network.

Menu Bar

The Menu Bar is where you will find all of the information screens and system
settings of the N5200PRO. The various settings are placed in the following groups
on the menu bar:
Menu Bar
Item
Status
Storage
Your computer's network IP address must be on the same subnet as the N5200PRO.
If the N5200PRO has default IP address of 192.168.1.100, your managing PC IP
address must be 192.168.1.x, where x is a number between 1 and 254, but not
Description
Current system status of the N5200PRO.
Information and settings for storage devices installed into the
