RADIO CONTROL MODEL Semi Scale – Almost ready to fly MITSUBISHI A6M5 ZERO ASSEMBLY INSTRUCTION .40 - .46 CLASS – 2 CYCLE ENGINE .60 - .70 CLASS – 4 CYCLE ENGINE WARNING: This radio control model is not a toy. If modify or flown carelessly, it could go out of control and cause serious bodily injury or property damage, It is your responsibility to build this kit correctly, to properly install all components and to...
Page 2
REQUIRED FOR OPERATION (Purchase separately) For 40 ~ 46 ( 2 cycle engine) For 60 ~ 70 (4 cycle engine) 10.5x6 ~ 11x6 12x6 ~ 13x7 Extension for aileron servo Silicon tube Minimum 4 channel radio for 40 ~ 46 2 cycle 60 ~ 70 4 cycle airplane (with 4 standard servos) Linkage Stopper...
1- Joining the wing Use epoxy glue to bury the opening ! Make sure to glue securely, If not properly glued, a failure in flight may occur. Trial fit each part before gluing . Be certain that there are no gaps. If the parts will join, but with a gaps, sand or trim the parts a little at a time until the parts meet exactly with no gaps.
Page 4
4- Retract landing gear Installation Right Wing Top-view Left RETRACTED EXTENDED Retract servo Push rod Retract gear Gear cover Retract gear Wheel Aileron servo Push rod 20 - 28mm Wheel Retract Push rod 40mm 170 mm To retract servo 10mm To landing gear RIGHT RETRACT PUSHROD 30mm...
Page 5
5- Main Wing: Fix gear Main gear (left) Gear mount (hard wood) Plastic strap Main gear (right) Plastic strap Gear mount (hard wood) 3x10mm screw..16 Apply Epoxy glue Square plastic (Or use 3x10 screw) Ply gear mount Main gear plate Square plastic Ply gear mount plate 6- Main Wing: Landing gear...
8- Engine: Four-stroke engine 3.1mm ! Engine thrust on balk head is already adjust at factory 4x25mm screw ....4 Washer.....4 Nut....4 3x20mm screw 2.5mm ....4 ! Before installing the engine mounts, place the engine onto the mounts and make four 3.1mm holes A=107 ~ 110mm SIDE VIEW IN CASE OF 4CYCLE ENGINE...
Page 8
12- Vertical/Horizontal Tail ! Securely glue together Cut away only If coming off during fly, the film both side you lose control of your air plane. Cut away only the film both side A’ 13- Tail cover 3mm screw Hatched-in areas: Drill holes using the stated Check during assembly that these Take particular care here...
Page 9
14-Servo/Push rod Rudder push rod Rudder servo Elevator push rod Throttle push rod Throttle push rod Elevator servo Elevator pushrod 3mm set Screw 3mm set Screw Elevator pushrod Rudder pushrod (Or throttle pushrod) Connector 2 mm 2 mm ..3 Connector ..
16- Balance 107 mm Wing center section DO NOT try to fly an out-of-balance model ! 17- Control Surface AILERON STROKE 35 mm 10mm 35 mm 10mm ELEVATOR STROKE RUDDER STROKE...
