K-array KMT21 User Manual page 14

KMT21 / KMT21 Mark I
1) CH1 Line Input. XLR line level input with +4 dBu sensitivity.
2) CH2 Mic/Line Input. XLR input, with selectable sensitivity for Mic (-30 dBu) or Line (+4 dBu).
3) Mic/Line switch. Selects CH2 input sensitivity for Mic ( -30 dBu) or Line ( +4 dBu) level.
4) Phantom Power switch. Turns phantom power (48V) on/off on CH2 input.
5) Limiting LEDs. Independent LEDs for the CH1 and CH2 inputs, which blink when the optical limiter
engages to protect the corresponding preamp circuit. Limiter threshold is +5 dBu.
6) CH1 Parallel Line Out. XLR parallel output providing a direct signal from the CH1 Line Input. This
output cannot be processed or controlled via the K-Framework software.
7) DSP Out. Auxiliary XLR balanced output, controlled via the K-Framework software. Users can
select the signal routed to this output and manage its amplitude and EQ individually.
8) DSP Out Power switch. Turns phantom power (48V) on and off on the DSP out. Phantom power
can be engaged to drive additional wireless signal transmitters/receivers.
9) AES/EBU Digital Input. XLR input connector for two-channel AES/EBU digital audio, accepting
sample rates from 32 kHz – 96 kHz.
10) AES/EBU Digital Output. XLR output, providing two-channel digital audio from AES/EBU Input,
at a sample rate of 48 kHz. This output cannot be processed or controlled via the K-Framework
software.
11) REMOTE RS485 Link Input. XLR input for connecting the KMT from another RS485 device in a
K-Framework network. RS485 Link Input can also be used to connect a computer running the
K-Framework software (requires K-USB USB-to-RS485 adapter).
12) REMOTE RS485 Link Output. XLR output for connecting additional RS485 devices in a K-Framework
network.
13) REMOTE USB Input. Connects a computer running the K-Framework software, for remote control
of the KMT. Users can manage an entire network of RS485 devices with one PC connected via
USB.
14) Speaker Out. Powered Speakon output, used to drive passive speakers, like a mid-high module
or a passive subwoofer.
15) Power switch. Turns the KMT system on and off.
16) AC Input. PowerCon input for AC power. See p. 11 for voltage and power requirements.
17) AC Link. PowerCon output for feeding AC mains power to additional K-array components with a
PowerCon AC input socket.
18) Power On LED. Indicates the system is ON.
19) TOUCH SCREEN Control panel. Provides access to the main functions of the DSP on board (see
Section 8).
Ver. 1.3
14
