Duplicating drives

Duplicate a drive

Warning! Any data saved on the destination drive will be overwritten during the
duplication process.
Note: The destination drive must be the same size or larger than the source drive.
1. Disconnect the USB cable from a host computer or the USB 3.0 port on the
SATDOCK2REU3.
2. Insert the 2.5 in. or 3.5 in. drive that you would like to duplicate into the HDD 1
Source slot on the dock.
3. Insert the 2.5 in. or 3.5 in. drive that you would like to overwrite into the HDD 2
Destination slot on the dock.
4. Press and hold the Clone button for several seconds until the LEDs on the front of
the dock blink amber. When all of the LED progress indicators on the front of the
dock are illuminated, including 100% complete, the duplication process is finished.
If you want to check the drive, remove the source drive from the dock. Reconnect the
dock to your computer, install the source drive in the dock, and turn on the dock.

About the duplication LED indicators

The SATDOCK2REU3 features four LED indicators. The following table describes the
behavior of the LED indicators when you use the SATDOCK2REU3 to duplicate drives.
Situation
Duplication in
process
Duplication
complete
Duplication can't
start
Duplication failed
Instruction manual
Link LED Power LED
25%
complete
Amber (running back and forth)
As the duplication progresses, the completion indicators will
be solidly illuminated to indicate the state of completion.
Blinking
amber
Not
illuminated illuminated
Not
illuminated illuminated
LED indicators
activity LED
50%
complete
complete
Blinking Blinking
amber
Not
illuminated
Not
illuminated
7
HDD 1 HDD 2
activity LED
75% 100%
complete
Blinking
amber amber
Not Blinking red
Not Illuminated
red
