US ENVIRONMENTAL
PROTECTION AGENCY
PHASE II CERTIFIED
WOOD STOVE
Printed in Canada
ENERZONE WOOD STOVE MANUAL
Solution 2.9
STOVE BUILDER INTERNATIONAL INC.
250, rue de Copenhague,
Saint-Augustin-de-Desmaures
After-sale service: 418-908-8002
E-mail: tech@sbi-international.com
www.enerzone-intl.com
READ AND KEEP THIS MANUAL FOR REFERENCE
This manual is available for free download on the manufacturer's web site. It is a copyrighted
document. Resale is strictly prohibited. The manufacturer may update this manual from time to
time and cannot be responsible for problems, injuries, or damages arising out of the use of
information contained in any manual obtained from unauthorized sources.
(EB00004 model)
Fabriqué par :
(Quebec) G3A 2H3
Verified and tested
following ULC S627
and UL 1482 Standards
by an accredited
laboratory
45863A
18-05-2016

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Solution 2.9 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Enerzone Solution 2.9

Summary of Contents for Enerzone Solution 2.9

  • Page 1 ENERZONE WOOD STOVE MANUAL Solution 2.9 (EB00004 model) Fabriqué par : Verified and tested US ENVIRONMENTAL STOVE BUILDER INTERNATIONAL INC. following ULC S627 250, rue de Copenhague, PROTECTION AGENCY and UL 1482 Standards Saint-Augustin-de-Desmaures PHASE II CERTIFIED by an accredited...
  • Page 3 INTRODUCTION Stove Builder International, one of the most important wood stoves and fireplace manufacturers in North America, congratulates you on your purchase and wishes to help you get maximum satisfaction from your wood stove. In the pages that follow, we will give you advice on wood heating and controlled combustion as well as technical specifications regarding installation, operation and maintenance of the model you have chosen.

  • Page 4: Table Of Contents

    TABLE OF CONTENTS SOLUTION 2.9 SPECIFICATIONS ....................... 4 INSTALLATION .............................. 7 GENERAL INSTALLATION ........................7 2.1.1 Pedestal or leg kit assembly ..........................8 2.1.2 Installation of the decorative u-shaped inserts ....................9 2.1.3 Door overlay installation ............................ 9 2.1.4 Optional air mate installation ..........................10 POSITIONING THE STOVE ........................

  • Page 5: Solution 2.9 Specifications

    1. SOLUTION 2.9 SPECIFICATIONS Fuel Type Cordwood Test Standards ULC S627 & UL 1482 residential. Recommended surface: 750 to 2300 sq. ft. Heating capacity* – BTU/hr., EPA test wood: 29,400 BTU/h. Heating capacity* – BTU/hr., seasoned cordwood: 85,000 BTU/h. Optimum efficiency: 76% *Why is the BTU indicated on the EPA label smaller than the one advertised? You will notice a difference between the BTU output as indicated on the unit’s white EPA label affixed to the glass...
  • Page 7 622mm...

  • Page 8: Installation

    2. INSTALLATION When installed and operated as described in these instructions, the Enerzone wood stove is suitable for use as a freestanding wood stove in residential installations. The Enerzone wood stove is not intended for installation in a bedroom. In Canada, the CSA B365 Installation Code for Solid Fuel Burning Appliances and Equipment and the CSA C22.1 Canadian National Electrical Code are to be followed in the absence of local...

  • Page 9: Pedestal Or Leg Kit Assembly

    2.1.1 Pedestal or leg kit assembly We suggest assembling the leg kit or pedestal before positioning the stove. See table below: 1- Unscrew the 4 bolts in order to remove the 2 steel supports. Dispose of the two steel supports. They are no longer required. Note: Parts may vary slightly from one model to another but the assembly procedure remains the same.

  • Page 10: Installation Of The Decorative U-Shaped Inserts

    Table 2.1.2 Installation of the decorative u-shaped inserts 2.1.3 Door overlay installation In order to complete the assembly of your freestanding Enerzone wood stove, you need to install the door overlay. See table 2.1.3 below for installation instructions: 1- Position the overlay on the door frame and fix it in place from behind using the 4 screws.

  • Page 11: Optional Air Mate Installation

    2.1.4 Optional air mate installation Most freestanding Enerzone wood stoves can be equipped with an optional air mate. This device accumulates heat and increases the airflow. See below for installation instructions: Remove the 3 screws holding the rear eat shield deflector.

  • Page 12: Clearances To Combustibles And Floor Protector

    2.3 CLEARANCES TO COMBUSTIBLES AND FLOOR PROTECTOR To install your appliance correctly, it is extremely important to respect all clearances to any combustibles as indicated on your stove’s certification label. See figure 2.3 to match each letter to a clearance. APPLIANCE CLEARANCES APPLIANCE CLEARANCES (INSTALLATION WITH SINGLE...
  • Page 13 FIGURE 2.3 Clearances to combustible materials and floor protection...
  • Page 14 Floor protector If the stove is to be installed on top of a combustible floor, it must be guarded by a non combustible material as shown on figure 2.3 (see the dotted line area). FLOOR PROTECTOR* CANADA (203 mm) – Note 1 N/A (Canada only) "...
  • Page 15 Reducing Wall and Ceiling Clearances Safely It is often desirable to reduce the minimum installation clearances by placing the stove closer to walls so the installation takes up less floor space. You can safely reduce the minimum clearances by permanently installing a shield between the stove and combustible material.
  • Page 16 Clearances for shield construction...
  • Page 17 Table of Clearance Reduction Percentages Clearances may be reduced by these percentages Sides Top % Type of shield and rear % (ceiling) Can/USA Can/USA min. min. Sheet metal, a minimum of 24 gauge (0.61 mm) in thickness , spaced out at 12 in 18 in least 25 mm (1 in)* by non-...

  • Page 18: Chimney (Flue System)

    3. CHIMNEY (FLUE SYSTEM) 3.1 DEFINITIONS For clarity, the following definitions should be used with respect to these instructions:  A chimney system consists of a connector off the top of the stove, and a chimne , which attaches to the connector and terminates outside the house. ...
  • Page 19 Your wood stove may be hooked up with a factory built or masonry chimney. If you are using a factory built chimney, it must comply with UL 103 (USA) or ULCS629 (Canada) standards. It must therefore be a 6” (152 mm) HT Type (2100°F) chimney. It is extremely important that it be installed according to the manufacturer's specifications.

  • Page 20: Step By Step Installation Of Your Factory-Built Chimney

     If an exterior chimney is used, the best results will be obtained by using a connector vertically off the unit to the highest possible point before elbowing off horizontally to the exterior chimney. For efficiency and safety reasons the stove must not be installed with an insulated chimney connected directly to the appliance.
  • Page 21 Typical installation through the wall Wall support system If your chimney must rise along an outside wall, you need to connect it to your stove through an adjacent wall. For this type of installation, the following items are normally required: Chimney ...
  • Page 22 Typical installation through the ceiling Ceiling support system If your chimney must rise inside the house and go through the ceiling, you need to connect it to your stove at the ceiling level. For this type of installation, the following items are normally required: Chimney ...

  • Page 23: Typical Installation Through An Existing Masonry Chimney

    3.2.2 Typical installation through an existing masonry chimney You can also install your stove using your existing masonry chimney. To do so, follow the guidelines below. You may want to use a factory-built thimble, on construct your own brick thimble. If you are using a masonry chimney, it is important that it be built in compliance with the specifications of the Building Code in your region.
  • Page 24 FIGURE 3.2.2 (B) Factory Built Thimble FIGURE 3.2.2 (C) Brick Thimble...

  • Page 25: Chimney Connector

    3.3 CHIMNEY CONNECTOR Your chimney connector (commonly called stove pipe) and chimney must have the same diameter as the stove’s exhaust outlet. The stove pipe must be made of aluminized or cold roll steel with a minimum 24-gauge thickness (0.021" or 0.53 mm). It is strictly forbidden to use galvanized steel.
  • Page 26 FIGURE 3.3 (B) Minimum Slope  The assembly should be as short and direct as possible between the stove and chimney (See figure 3.4 (A)). The use of two 45 degree elbows (See figure 3.4 (C)) is often preferable to a single 90 degree elbow (See figure 3.4 (B)) because less turbulence is created in the exhaust flow and they result in less horizontal run.

  • Page 27: Draft

    3.4 DRAFT Your Enerzone stove’s performance will be optimized if it is installed with a chimney (flue) system that provides an adequate draft. The draft is the force that moves air from the appliance up through the chimney and is predominantly affected by the height and diameter of the chimney, as well as the stack temperatures of the stove.

  • Page 28: The Advantage Of Installing A Blower

    3.6 THE ADVANTAGE OF INSTALLING A BLOWER A blower can be installed at the back of your Enerzone stove. This option is necessary if you wish to redistribute into a room the heat trapped at the back of your stove. By forcing hot air toward the front, the blower enables you to extend the radiation and convection power of your stove.

  • Page 29: Operation

    4. OPERATION Keep these instructions for future reference. WARNING:  ANY MODIFICATION OF THE APPLIANCE THAT HAS NOT BEEN APPROVED IN WRITING BY THE CSA B365 ( ANSI NFPA TESTING AUTHORITY IS CONSIDERED AS BREACHING CANADA 211 (USA).  DO NOT USE FLAMMABLE LIQUIDS OR AEROSOLS TO START OR REKINDLE THE FIRE ...

  • Page 30: Safety Information

    4.1 SAFETY INFORMATION  These stoves are designed for the safe operation . Altering or WHEN BURNING WOOD ONLY modifying the unit or installation without proper authorization will void the certification, warranty, and safety listing, and may result in a safety hazard. ...

  • Page 31: Fuel

    Fuel for the stove must not be stored closer than the required clearances to combustible (heat- sensitive materials). NEVER STORE WOOD IN THE ASH PAN COMPARTMENT. Your Enerzone stove is designed to burn . Do not burn coal, charcoal, or trash in the WOOD ONLY unit.

  • Page 32: The Use Of Manufactured Logs

    Decorative fireplaces generally have larger, cooler, and less air-tight fireboxes. Your Enerzone stove, on the other hand, has a smaller, completely sealed firebox which attains much higher temperatures. It is therefore not designed to support excessive heat caused by the addition of chemicals in manufactured logs.

  • Page 33: Simple Wood Moisture Test

    4.2.2 Simple Wood Moisture Test Add one large piece of wood to the top of an established fire. If it starts to burn on three sides within one minute, it is dry and seasoned and right for burning. If it turns black and starts to burn in about three minutes or more, it is damp.

  • Page 34: Maintaining The Fire

    Closing the draft control down too soon will lower combustion efficiency, and may result in creosote build-up in the chimney (which could lead to a future chimney fire). AUTION DJUSTMENT ANGE HOULD LTERED NCREASED IRING EASON DAMPER OPERATION OPENED CLOSED Figure 4.4 4.5 MAINTAINING THE FIRE Once the wood has been consumed (or partially consumed) and you have obtained a good bed of...

  • Page 35: Blower Operation

    Your Enerzone stove will work best if a thick bed of hot embers is maintained in the bottom of the firebox and a minimum of two large pieces of seasoned fuel is added. Combustion efficiency is largely related to establishing a hot ember bed, and hot firebox temperatures. The quicker the stove and chimney (flue) get up to normal operating temperatures, the better.

  • Page 36: Maintenance

    5. MAINTENANCE 5.1 CLEANING AND PAINTING YOUR STOVE Clean the stove frequently so that soot, ash, and creosote do not accumulate. Do not attempt to clean the stove when the unit is hot. Special care must be taken with plated surfaces in order to maintain the finish at its original brilliance.

  • Page 37: Gasketing

    Carefully clean the gasket groove, apply a high temperature silicone sold for this purpose, and install the new gasket. Use only the genuine Enerzone gasket. You may light up your stove again approximately 24 hours after having completed this operation.

  • Page 38: Chimney (Flue) Cleaning

    If creosote has accumulated, it should be removed to reduce the risk of a chimney fire. Call a professional chimney sweep, or go to your local Enerzone dealer, purchase a chimney brush, and have the chimney cleaned.

  • Page 39: Baffle Installation

    5.6 BAFFLE INSTALLATION All firebrick and ceramic wool baffles must be properly in place for correct burning operation. Have any damaged firebricks replaced. Check the firebricks annually for damage and replace if they are broken or damaged. See figure 6.6.2 (B) for the firebrick layout. WOOL WEIGHT CERAMIC WOOL VERMICULITE BAFFLE...

  • Page 40: Secondary Air Tube Replacement

    Note that any tube can be replaced without disturbing the baffle. Important Notes: Figure 5.7 – Secondary air tube replacement The air tubes are identified for placement as follows: Model Type of tube All tubes ► 65 holes of 7/64" Solution 2.9...

  • Page 41: Enerzone Limited Lifetime Warranty

    Labour costs and repair work to the account of the manufacturer are based on a predetermined rate schedule and must not exceed the wholesale price of the replacement part. Shall your unit or a component be defective, contact immediately your ENERZONE dealer. To accelerate processing of your warranty claim, make sure to have on hand the following information when calling: ...
