4 . 9 . 6 W a k e o n L A
4 . 9 . 6 W a k e o n L A
A PC client on LAN can be woken up by the router it connects. When a user wants to wake up
a specified PC through the router, he/she must type correct MAC address of the specified PC
on this web page of Wake on LAN of this router.
In addition, such PC must have installed a network card supporting WOL function. By the
way, WOL function must be set as "Enable" on the BIOS setting.
Available settings are explained as follows:
Item
Wake by
IP Address
MAC Address
Wake Up
N
N
Description
Two types provide for you to wake up the bound IP. If you
choose Wake by MAC Address, you have to type the correct
MAC address of the host in MAC Address boxes. If you
choose Wake by IP Address, you have to choose the correct IP
address.
The IP addresses that have been configured in Firewall>>Bind
IP to MAC will be shown in this drop down list. Choose the
IP address from the drop down list that you want to wake up.
Type any one of the MAC address of the bound PCs.
Click this button to wake up the selected IP. See the following
figure. The result will be shown on the box.
247
Vigor2920 Series User's Guide
