Draytek vigor2920 series User Manual page 219

To set a new profile, please do the steps listed below:
1. Click the Mail Server tab, and click the number (e.g., #1) under Index column for
configuration in details.
2. The configuration page will be shown as follows:
Available settings are explained as follows:
Item
Profile Name
SMTP Server
SMTP Port
Sender Address
Authentication
Sending Interval
Description
Type a name for such mail service profile.
Type the IP address of the mail server.
Type the port number for SMTP server.
Type the e-mail address of the sender.
The mail server must be authenticated with the correct
username and password to have the right of sending
message out. Check the box to enable the function.
Username – Type a name for authentication.
Password – Type a password for authentication.
Define the interval for the system to send the SMS out.
209
Vigor2920 Series User's Guide
