  • Page 1 Meridian Communications Adapter M3902 M3903 M3904 M3905 User Guide Enterprise Voice Solutions Customer Documentation...
  • Page 2 While you are away from your desk: Call Forward...

  • Page 3: Table Of Contents

    Contents Introduction About the document ... 1 Before you use the MCA ... 1 Use the MCA to make data calls ... 2 Dialing methods Switching between keyboard and AT dialing ... 3 Make a data call Keyboard dialing ... 4 AT dialing ...
  • Page 4 Contents ATOn (on-line, where n = 0, 1) ... 19 ATQn (result code, where n = 0, 1) ... 19 ATV n (verbal result, where n = 0, 1) ... 19 ATXn (result code selection, where n = 0–4) ... 19 ATZn (soft reset, where n = 0, 1) ...
  • Page 5 Contents S66 (AT/KBD autobaud interpretation; range = 0, 1) ... 24 S51 (delay until modem pool activation; range = 0–255) ... 24 Dial modifier ... 25 Introduction to Keypad dialing Keypad dialing ... 26 MCA Data Parameters for Keypad dialing commands ... 29 Keypad dialing commands ...
  • Page 6 Contents...

  • Page 7: Introduction

    This guide displays information pertaining to synchronous operation in italic type. The Meridian Communications Adapter (MCA) passes synchronous and asynchronous data through Nortel Networks systems by using the M3900 Series Meridian Digital Telephone. The MCA supports Data Terminal Equipment; there is no way to configure the MCA for Data Communications Equipment, but a “null...

  • Page 8: Use The Mca To Make Data Calls

    Introduction M3900 series telephone.Once the ACM is installed, the MCA cartridge accessory is inserted into the ACM to provide an interface to data functions. To install the ACM refer to the Accessory Connection Module Installation Guide packaged with the ACM. Use the following procedures to install the MCA to the telephone: •...

  • Page 9: Dialing Methods

    Dialing methods The MCA provides three methods for making data calls through the Nortel Networks PBX: keyboard dialing, AT dialing, and keypad dialing. You use Keyboard and AT dialing by entering commands at a terminal or on a PC running software to make it emulate a terminal.

  • Page 10: Make A Data Call

    Make a data call Make a data call The procedures in this section describes how to make basic data calls. There are three methods used to make a data call; keyboard dialing, AT dialing and keypad dialing. Note: Throughout this guide, Keyboard dialing <CR>...

  • Page 11: Keypad Dialing

    Keypad dialing Keypad dialing is accessed through the Options. Press the Options Key and use the Navigation Keys to scroll to MCA data parameters. Once you are familiar with your MCA option number, you can press the Options key and dial the MCA data parameters option number, followed by the parameter number.

  • Page 12: Release A Data Call

    Make a data call Release a data call To release a call while in asynchronous mode, use any of the following methods: Break Break Break Options • Release a synchronous call using one of these methods: Options • Press the Key(s) on your PC Break keyboard for 1.6 seconds or longer.

  • Page 13: Default Parameters For Asynchronous And Synchronous

    Default parameters for Asynchronous and Synchronous The MCA is configured in asynchronous mode when it is shipped from the factory. The MCA defaults to synchronous or asynchronous mode from the telephone. The mode is determined prior to resetting the parameters. Listed here are the default parameters.
  • Page 14 Make a data call Script File Menu L — LEARN SCRIPT D — DELETE SCRIPT SELECT: Modify Menu A — AUTO NUMBER S — SPEED NUMBER R — REMOTE LOOPBACK SELECT: Learn Script Menu A — LEARN AUTO DIAL SCRIPT S —...

  • Page 15: Keyboard Dialing

    Keyboard dialing This chapter explains the keyboard dialing commands and how to use them. You can enhance your data call dialing by using features such as Speed Call and file scripting. Keyboard dialing is menu-driven. See Figure 1 for menus. Use them as a reference when following procedures.

  • Page 16: Speed Call

    Keyboard dialing A A A A <CR> XX <CR> Speed Call To use Speed Call: <CR> XX <CR> To define (change): <CR> <CR> XX <CR> XXXX <CR> Terminal displays Modify menu. 3. Select (Auto Number) and press the Carriage Return. AUTO DIAL NO.

  • Page 17: Script File

    Script File To use Script File: script name <CR> To define the Script File: <CR> <CR> <CR> <CR> <CR> XX <CR> <CR> Keyboard dialing Enter script name and press the Return. The MCA will connect to the far end data device and the script will be executed automatically.

  • Page 18: Script File Directory

    Keyboard dialing Name <CR> <CR> <CR> E E E E s s s s c c c c E E E E s s s s c c c c E E E E s s s s c c c c Script File directory To view a list of your script files: <CR>...

  • Page 19: Delete Script File

    SCRIPT FILE DIRECTORY ACCESS SCRIPT CODE NAME EMAIL MAINFRAME DBASE Delete Script File <CR> <CR> <CR> <CR> <CR> <CR> Keyboard dialing LENGTH (BYTES) 1. Select (Modify) and press the Carriage Return. Terminal displays Modify menu. 2. Select (Script File) and press the Carriage Return.

  • Page 20: Escape Code

    Keyboard dialing Escape code To change Escape code: <CR> <CR> <CR> <CR> <CR> E E E E s s s s c c c c E E E E s s s s c c c c E E E E s s s s c c c c 1.

  • Page 21: Manual Answer (Asynchronous)

    <CR> E E E E s s s s c c c c E E E E s s s s c c c c E E E E s s s s c c c c Manual answer (asynchronous) <CR>...

  • Page 22: Ring Again

    Keyboard dialing Ring Again <CR> <CR> Ring Again (synchronous) Synchronous calls can only be made from the telephone keypad. Remote loopback will be enabled for the next data call only. This feature is useful for diagnostic purposes. When the far end number is busy you receive the prompt: BUSY, RING AGAIN? (Y/N) BUSY, PREVIOUS RING AGAIN ACTIVE,...

  • Page 23: Display Parameters (Asynchronous)

    Display parameters (asynchronous) To list information about MCA configuration from the terminal: <CR> Keyboard dialing Select (display parameters) and press the Carriage Return. The following example shows the items listed with possible values for each. The first three parameters give information on the current version MCA you have (they do not change).

  • Page 24: At Dialing

    AT dialing AT dialing AT dialing is similar to the methods used to make data calls with a Hayes Smartmodem. Some AT commands do not apply to the MCA, and are not supported. Most AT commands begin with the letters AT (not case sensitive). These two letters are followed by a one- or two-character command (sometimes followed by additional parameters) and a carriage return.

  • Page 25: Aton (On-Line, Where N = 0, 1)

    ATOn (on-line, where n = 0, 1) This will put you on-line if you had previously used the escape code (three escape characters) to go off-line. The same result applies to both case n = 0 and n = 1. ATQn (result code, wheren=0,1) Result codes (call progress prompts) are not sent to your terminal when n = 1.

  • Page 26: Atzn (Soft Reset, Where N = 0, 1)

    AT dialing ATZn (soft reset, where n = 0, 1) This returns S0 through S49 registers and AT configurations to their default settings. The same result applies to both case n = 0 and n = 1. Registers S50 through S69 will be reset to their default values only upon power-up.

  • Page 27: Atin (Product Identification Code, Where N = 0, 1, 4)

    AT dialing ATIn (product identification code, where n = 0, 1, 4) When n = 0, the MCA displays the contents of S-registers S52–S54. The default is “960” (Smartmodem V-series 9600 modem). Other possible values are: “122” (Smartmodem 1200) and “240” (Smartmodem 2400). When n = 1, the result is “206.”...

  • Page 28: At&Yn (Recall User Profile On Power-Up, Where N = 0, 1)

    S-registers AT&Yn (recall user profile on power-up, where n = 0, 1) This returns S0 through S49 registers and AT configurations to their default settings. The same result applies to both case n = 0 and n = 1. Off-line mode E E E E s s s s c c c c E E E E s s s s c c c c E E E E s s s s c c c c...

  • Page 29: S1 (Ring Count; Read Only)

    S-registers S1 (ring count; read only) This returns the current number of rings for an incoming data call when read. S2 (escape character; range = 0–255) This holds the ASCII value of the escape character. If the S2 register is set to a value of 128 or greater, then escape character action is disabled.

  • Page 30: S8 (Pause Time For Comma; Range = 0-255)

    S-registers S8 (pause time for comma; range = 0–255) A comma included in the dialing sequence is interpreted as a delay. The default delay time is two seconds. S12 (escape code guard time; range = 0–255) The guard time aids in recognition of the escape sequence, useful since different numbers of escape characters mean different things.

  • Page 31: Dial Modifier

    Dial modifier Dial modifiers are special parameters used to tell the MCA how to dial the data number. Digit for dialing Characters for dialing While dialing, instructs PBX to begin dialing the digits entered to this point. After dialing, this character is outpulsed as tone. After dialing, this character is outpulsed as a tone.

  • Page 32: Introduction To Keypad Dialing

    Introduction to Keypad dialing Introduction to Keypad dialing Keypad dialing can be used in both synchronous and asynchronous mode. The MCA data parameter commands accessed through the Options Key, require a Display on the telephone. Keypad dialing commands are most useful for making simple data calls or for modifying the MCA configuration.
  • Page 33 Options Quit Example: MCA data parameter Keypad dialing command for Ring Again: Options MCA data parameters Select fl› Introduction to Keypad dialing Note 1: When you have given a Keypad command to the MCA, it remains in that mode until you press the Options Key or Quit Key.
  • Page 34 Introduction to Keypad dialing To verify that the call is connected after Ring Again is placed: Options MCA data parameters Select fl› To cancel Ring Again: Options RING AGAIN PLACED Ring Again is automatically placed. 1. Press the Key. Options 2.

  • Page 35: Mca Data Parameters For Keypad Dialing Commands

    MCA data parameters Select ‹· Note: In this chapter, feedback from the MCA refers to what you see on the telephone Display. MCA Data Parameters for Keypad dialing commands There are certain steps that are the same for each Keypad dialing command. Use the following steps prior to and after each Keypad dialing command: To enter MCA data session: Options...
  • Page 36 Introduction to Keypad dialing To end MCA data session: Options Quit Example To initiate a Manual Data Call: Options MCA data parameters Select Select Options Quit 4. Press the Key to end the Options session. Press the Quit Key to end session. 1.

  • Page 37: Keypad Dialing Commands

    Keypad dialing commands MCA parameter Command number £ Manual Data Call • Release Data Call ‚fi Language Selection ¤‚ Asynchronous Mode ¤⁄ Synchronous Mode ¤¤ Baud Rate ¤‹ Space Parity ¤› Odd Parity ¤fi Even Parity ¤fl Mark Parity ¤‡ Host Mode ¤°...
  • Page 38 Introduction to Keypad dialing MCA parameter Command number ‹fi Dynamic Carrier Detect Off Dial ‹fi. ‹fl Dynamic Carrier Detect On Dial ‹fl. ‹‡ Remote Loopback Off Again ‹° Remote Loopback On ‹· Cancel Data Ring ›‚ Full Duplex ›‚ Full Duplex ›⁄...
  • Page 39 MCA parameter Command number fi‡ HDLC On fi° Assert RTS Off fi· Assert RTS On fl‚ Auto Dial Programming fl⁄ Auto Dial Call fl¤ Data Parameter Display fl‹ EIA leads Status Display fl› Monitor data call flfi Reset to Default Parameters Introduction to Keypad dialing Keypad dialing notes...

  • Page 40: Additional Asynchronous Features

    Additional asynchronous features MCA parameter Command number flfl Emulation selection fl‡ Lock/unlock data parameters fl° VDN Key Assignment Additional asynchronous features Autobaud Autobaud is enabled each time you release a data call. Each time you press carriage return to activate AT dialing, the MCA times the length of bits received and sets the baud rate accordingly.

  • Page 41: Additional Synchronous Information

    CALL CONNECTED.SESSION STARTS Additional synchronous information Use fifi and fi‡ (HDLC On) for Group IV FAX. Use fifi and fifl (Bisync On) for video. When V.25 fifi) is turned on, the MCA automatically switches to synchronous mode. When in the V.25 mode, auto answer is not available. If an MCA in synchronous mode calls another data module in asynchronous mode, the call is connected.

  • Page 42: Voice Call Origination

    Additional asynchronous features Voice call origination By using a special cable, the MCA can communicate with two DTEs at the same time. The primary channel is the main communication channel offering MCA features. The second channel can respond to Voice Call Origination commands (VCO) only.

  • Page 43: Asynchronous Troubleshooting

    Asynchronous troubleshooting If data is sent in idle mode (when there is no active call), you can not use keypad dialing. You must stop sending the data from the DTE. You must disconnect pin 22, if you are using an RS-232 cable to connect the MCA to an ADM3/5 terminal.
  • Page 44 Asynchronous troubleshooting Symptom Solution The prompt: CALL CONNECTED.SESSION STARTS RELEASED Garbled prompts appear Enter a period ( .) followed by <CR> to perform an autoparity. on your terminal when you type <CR>. You do not get response First, release the call. Turn on Remote Loopback and make the call from the host computer again.
  • Page 45 Symptom Solution MCA does not operate at all. Asynchronous troubleshooting Check the LED in the back of the telephone to see if it is flashing. If the LED is steadily lit, the MCA needs to be configured in your system, or the MCA is not functioning correctly. If the LED is not lit, the MCA requires external power.

  • Page 46: Synchronous Troubleshooting

    Synchronous troubleshooting Synchronous troubleshooting After the call is connected send the data using bit error rate testers (BERT). If there is no transmission, or if there are excessive errors, the MCA is probably defective. Return it for repair.
  • Page 47 abort current command access code answer AT dialing extensions to AT/KBD autobaud interpretation Auto Dial autobaud autoparity backspace character baud rate autobaud break key(s) carriage return 4, 23 carrier detect carrier detect control carrier detect response time clear-to-send options data call Data Terminal Equipment data-set-ready options default configuration...
  • Page 48 Index Main menu manual answer menus (keyboard) Modem Pooling Modify menu mute number of rings incoming numeric result off/forced dtr command off/loopback command off-line off-line mode on-line parameters default display parity autoparity pause time for comma product code response product identification code recall user profile on power-up release data call Remote Loopback...
  • Page 49 While you are away from your desk: Call Forward...
  • Page 50 Nortel Networks. Information contained in this document is subject to change. Nortel Networks reserves the right, without notice, to make changes in equipment design or program components as progress in engineering, manufacturing or technology may warrant.
