Remote Control Features

Your boat may be equipped with one of the Mercury Precision or
Quicksilver remote controls shown. If not, consult your dealer for
a description of the functions and operations of the remote
control.
c
f
a
d
e
a - Control handle – forward, neutral, reverse
b - Neutral release lever
c - Trim/tilt switch (if equipped) – Refer to Features and
Controls – Power Trim and Tilt
d - Lanyard stop switch – Refer to General Information –
Lanyard Stop Switch
e - Lanyard – Refer to General Information – Lanyard Stop
Switch
f - Throttle friction adjustment – Console controls require
cover removal for adjustment
g - Ignition key switch – "OFF," "ON," START"
h - Fast idle lever – Refer to Operation – Starting the Engine
i - Throttle only button – Refer to Operation – Starting the
Engine

FEATURES AND CONTROLS

c
a
h
b
g
d
e
c
a
b
i
i
g
f
56
