Specification

Product:
Type:
Capacity:
Loading:
Thermostat:
Thermal cut-out: Manually re-settable set to 85+/-3ºC
Water vessel:
Safety Features: Expansion relief valve set to 6 bar (supplied)
Approvals:
Models:
Performance:
4
5/11/08
Zip Aquapoint III
Direct unvented multipoint
10 litre, 15 litre
2.0kW
Adjustable 7ºC to 75ºC
Glass enamelled steel tested to 12 bar. Maximum working
pressure 6 bar
Manually re-settable over temperature safety cut-out
Provision to fit Pressure and Temperature relief valve
(available as an optional accessory)
Sacrificial anode to provide anti-corrosion protection for the
vessel and element.
Zip Aquapoint III complies with LVD and EMC directives and
is CE endorsed.
Zip Aquapoint III has been examåined, tested and found,
when correctly fitted, to comply with the requirements
of the United Kingdom Water Regulations/Byelaws
(Scotland). The product, therefore, is listed under the
WRAS (Water Regulations Advisory Scheme) Water
Fitting and Materials Directory.
Underbasin
5 litre AP3/05
10 litre AP3/10
15 litre AP3/15
Model Heat up time Re-heat time Heat Loss
(15° to 65ºC)
AP3/05 (OB) 11 mins
AP3/10 (OB) 18 mins
AP3/15 (OB) 32 mins
AP3/05, AP3/10, AP3/15 Installation Instructions
15:51 Page 3
Overbasin
AP3/05/OB
AP3/10/OB
AP3/15/OB
(70% vol.) (kW/24 hrs)
7 mins 0.25
12 mins 0.33
18 mins 0.44
