MUND CLIMA MUVR-C6 Installation & Owner's Manual

Window air conditione
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
WINDOW AIR CONDITIONER
Before using your air conditioner, please read
this manual carefully and keep it for future reference.
www.mundoclima.com
Installation & Owner's Manual
MUVR-C6 COOL ONLY
GAS
R32
CL20380 to CL20381
TIMER ON
TIMER
O
C
TIMER OFF
SWING
POWER
SWING
AUTO
SLEEP
TEMP
FAN
MODE
HIGH
COOL
MED
LOW
DRY
FAN
English

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MUVR-C6 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for MUND CLIMA MUVR-C6

Summary of Contents for MUND CLIMA MUVR-C6

  • Page 1 WINDOW AIR CONDITIONER Installation & Owner's Manual MUVR-C6 COOL ONLY TIMER ON TIMER TIMER OFF SWING POWER SWING AUTO SLEEP TEMP MODE HIGH COOL Before using your air conditioner, please read CL20380 to CL20381 English this manual carefully and keep it for future reference.
  • Page 2 SOCIABLE REMARK DISPOSAL: Do not dispose this product as unsorted municipal waste. Collection of such waste separately for special treatment is necessary. It is prohibited to dispose of this appliance in domestic household waste. For disposal, there are several possibilities: A) The municipality has established collection systems, where electronic waste can be disposed of at least free of charge to the user.
  • Page 3 Read This Manual Inside you will find many helpful hints on how to use and maintain your air conditioner properly. Just a little preventive care on your part can save you a great deal of time and money over the life of your air conditioner. You'll find many answers to common problems in the chart of troubleshooting tips.

  • Page 4: Table Of Contents

    CONTENTS 1. SAFETY PRECAUTIONS..............2 2. UNIT PARTS IDENTIFICATION............5 3. OPERATING INSTRUCTIONS ............6 4. INSTALLATION INSTRUCTIONS............11 5. TROUBLESHOOTING ...............15 6. OTHER TIPS..................16 7. REMOTE CONTROLLER..............21...

  • Page 5: Safety Precautions

    SAFETY PRECAUTIONS Read Safety Precautions Before Installation Incorrect installation due to ignoring instructions can cause serious damage or injury. The seriousness of potential damage or injuries is classified as either a WARNING or CAUTION. This symbol indicates that ignoring instructions may cause death or serious injury.
  • Page 6 WARNING 6. For all electrical work, follow all local and national wiring standards, regulations, and the Installation Manual. You must use an independent circuit and single outlet to supply power. Do not connect other appliances to the same outlet. Insufficient electrical capacity or defects in electrical work can cause electrical shock or fire.
  • Page 7 SAFETY PRECAUTIONS (prior to operation) Preparing for operation 1. Contact an installation specialist for installation. 2. Plug in the power plug properly. 3. Do not use a damaged or non-standard power cord. 4. Do not share the same outlet with other appliances. 5.

  • Page 8: Unit Parts Identification

    UNIT PARTS IDENTIFICATION 1. Air inlet grille (indoor side) 2. Air filter 3. Frame 4. Cabinet 5. Air inlet grille (outdoor side) 6. Air outlet grille 7. Electronic control keypad 8. Power supply cord 1. Power cord conductors are distinguished according to color as follows (see Fig.1) 2.

  • Page 9: Operating Instructions

    OPERATING INSTRUCTIONS Controls The electronic control keypad will look like one of the following: TIMER ON TIMER TIMER OFF SWING POWER SWING AUTO SLEEP TEMP MODE HIGH COOL TIMER ON TIMER TIMER OFF SWING POWER SWING AUTO SLEEP TEMP MODE HIGH COOL NOTE: The outline of the operation panel is based on typical model, the function is the...
  • Page 10 OPERATING INSTRUCTIONS POWER: Press the POWER keypad to turn the unit on/off. MODE: Press the "MODE" keypad to select the appropriate operating mode. Select the operating mode from AUTO, COOL, FAN and DRY. The green indicator light beside the "MODE" option will illuminate, identifying the mode selected. When using the DRY and AUTO mode, you cannot select a fan speed.
  • Page 11 OPERATING INSTRUCTIONS (continued) The selected time will register in 5 second and the system will automatically revert back to display the previous temperature setting. Turning the unit ON or OFF at any time will cancel the Auto Start/Stop function. DRY: This mode is used to decrease the humidity in the room.
  • Page 12 OPERATING INSTRUCTIONS (continued) Failure Indicator Display: E0: Indoor EEPROM error; E1: Indoor & outdoor communicaiton error; E3: Indoor fan motor speed out of control; E4: Room temperature sensor error; E5: Evaporator temperature sensor error; EC: Refrigerant leakage detection; F0: Current overload protection; F1: Outdoor temperature sensor error;...
  • Page 13 Vertical air flow adjustment (manually) To adjust vertical air flow direction, adjust any one of the horizontal louvre blades. When adjusting the horizontal louver blades up or down, always keep the top or bottom blades horizontal. This can effectively prevent water droplets condensing on the front panel of the unit.

  • Page 14: Installation Instructions

    INSTALLATION INSTRUCTIONS Select the best location AWNING AWNING FENCE FENCE About 3~4 About 3~4 Over 50cm Over 50cm 1. To avoid vibration and noise, make sure the unit is installed securely and firmly. 2. Install the unit where the sunlight does not shine directly on the unit. If the unit receives direct sunlight, build an awning to shade the cabinet.
  • Page 15 Installation of the Housing Step 1 NOTE: UNIT MAY BE SUPPORTED BY A SOLID FRAME FROM BELOW OR Remove the air conditioner from it's packaging, remove fixing BY A HANGER FROM A SOLID screws and slide the air conditioner out of it's housing (Refer OVERHEAD SUPPORT.
  • Page 16 Installation Steps Step 1. Remove the front panel and the air filter 1. Hold the slot under the front panel, then uplift it outwards, and remove the front panel (See Fig.1). 2. Pinch the handle under the air filter and make the air filter arched, remove it from the slot from underside to upside (See Fig.2).
  • Page 17 Step 3. Installation. 1. Grasp the handle on the chassis and carefully slide the air conditioner out of the cabinet (See Fig.5). 2. Remove shipping pad from around compressor before operation and make sure the discharge points to the drain pan are aligned before the chassis is pushed into the cabinet (See Fig.6). 3.

  • Page 18: Troubleshooting

    TROUBLESHOOTING Troubleshooting Tips Save time and money! Review the chart below first and you may not need to call for service. Normal Operation You may hear a pinging noise caused by water being picked up and thrown against the condenser on rainy days or when the humidity is high. This design feature helps remove moisture and improve efficiency.

  • Page 19: Other Tips

    OTHER TIPS (be applicable for R32 refrigerant) 1.Transport of equipment containing flammable refrigerants See transport regulations 2.Marking of equipment using signs See local regulations 3.Disposal of equipment using flammable refrigerants See national regulations. 4.Storage of equipment/appliances The storage of equipment should be in accordance with the manufacturer's instructions. 5.Storage of packed (unsold) equipment Storage package protection should be constructed such that mechanical damage to the equipment inside the package will not cause a leak of the refrigerant charge.
  • Page 20 OTHER TIPS (be applicable for R32 refrigerant) 7)Ventilated area Ensure that the area is in the open or that it is adequately ventilated before breaking into the system or conducting any hot work. A degree of ventilation shall continue during the period that the work is carried out. The ventilation should safely disperse any released refrigerant and preferably expel it externally into the atmosphere.
  • Page 21 OTHER TIPS (be applicable for R32 refrigerant) Ensure that seals or sealing materials have not degraded such that they no longer serve the purpose of preventing the ingress of flammable atmospheres. Replacement parts shall be in accordance with the manufacturer's specifications. NOTE: The use of silicon sealant may inhibit the effectiveness of some types of leak detection equipment.
  • Page 22 OTHER TIPS (be applicable for R32 refrigerant) The refrigerant charge shall be recovered into the correct recovery cylinders. The system shall be flushed with OFN to render the unit safe. This process may need to be repeated several times. Compressed air or oxygen shall not be used for this task.
  • Page 23 OTHER TIPS (be applicable for R32 refrigerant) k) Recovered refrigerant shall not be charged into another refrigeration system unless it has been cleaned and checked. 15.Labelling Equipment shall be labelled stating that it has been de-commissioned and emptied of refrigerant. The label shall be dated and signed.

  • Page 24: Remote Controller

    REMOTE CONTROLLER Remote Controller Specification Model R51M/(C)E, R51M/BG(C)E, RG51M2/(C)E, RG51A/(C)E, RG51M3/(C)E, RG51M3/BG(C)E, RG51M8/(C)E,RG51M9/(C)E. Rated Voltage 3.0V(Alkaline dry batteries LR03 2) Lowest Voltage of CPU 2.0V Emitting Signal 8m (when using 3.0 voltage, Transmission Distance it Gets 11m) Environment -5 C 60 C Performance Features 1.
  • Page 25 TEMP Button Push this button to decrease the indoor temperature setting. TEMP Button Push this button to increase the indoor temperature setting . MODE Selection Button: Each time the button is pressed, the operation mode is shifted in the direction of the arrow: AUTO COOL HEAT...
  • Page 26 TIMER OFF Button: Press this button to initiate the auto-off time sequence. Each press will increase the auto-timed setting in 30 minutes increments. When the setting time displays 10, each press will increase the auto-timed setting 60 minutes increments. To cancel the auto-timed program, simply adjust the auto-off time to 0.0.
  • Page 27 ON/OFF Indicator: This symbol appears when the unit is turned on by the remote controller, and disappear when the unit is turned off. OPERATION MODE Indicator: When press the MODE button, it shows the current operating mode -- AUTO COOL HEAT (Cooling only model without) mode.
  • Page 28 AUTOMATIC OPERATION 1. Use the MODE button to select AUTO. 2. Push the TEMP button to set the desired room temperature . The most comfortable temperature settings are between 21 C to 28 C. 3. Push the ON/OFF button to start the air conditioner. The OPE- RATION lamp on the display panel of the indoor unit lights.
  • Page 29 DRY Operation 1. Push the MODE button to select DRY. 2. Push the TEMP button to set the desired temperature from 17 C to 30 C. 3. Push the ON/OFF button, the OPERATION lamp lights and the air conditioner starts to operate in DRY mode at LOW fan speed.
  • Page 30 3. Set the starting & stopping time 3.1 Push the TIMER ON button, the remote controller will show TIMER ON, the last set time for START operation and the signal "h" will be shown on the DIGITAL display area. You are now ready to readjust the TIMER ON to start the operation.
  • Page 31 Warning 1. Be sure there are no obstacles between the remote controller and the receiver of indoor unit otherwise the air conditioner will not work. 2. Keep the Remote Controller away from any liquids. 3. Protect the remote controller from the high temperatures and exposure to radiation.
  • Page 32 ASK FOR MORE INFORMATION Phone: (+34) 93 446 27 81 eMail: info@mundoclima.com TECHNICAL ASSISTANCE Phone: (+34) 93 652 53 57 www.mundoclima.com...
