  • Page 1 DNP5320E HIGH RESOLUTION PoE DUAL-CODEC PROFESSIONAL OUTDOOR DAy/ NIGHT NETwORk CAmERA...
  • Page 2: Package Contents

    DNP5320E High Resolution PoE Dual-Codec Professional Outdoor Day/ Night Network Camera on your network. For all other aspects of using the product, please refer to the user manual available at www.digimerge.com or on the Installation CD included with this product.
  • Page 3: Hardware Connections

    HARDWARE CONNECTIONS Hardware installation: A. PoE Enabled Install B. AC Powered Install C. Optional Connections OPTION 1 Hardware Installation - PoE Enabled Install This camera is PoE enabled (built-in). The Ethernet Cable provides both Network Connectivity and Power if you use this installation option (PoE equipment will be needed.
  • Page 4 HARDWARE CONNECTIONS Continued OPTION 2 Hardware Installation - AC Powered Install The Hardware installation (using 12V DC Power) consists of removing the back plate and installing cables to the Camera. 1. Remove the Back Plate: Once the plate is removed, access to additional ports and AC power becomes available: A.
  • Page 5 HARDWARE CONNECTIONS Continued Hardware Installation - Optional Connections The Optional Connection includes the use of the GPIO Connector Cable for Alarm and/or PTZ Control. 1. Connect the GPIO Connector Cable to the GPIO Port located to the left of the Ethernet Cable Connection.
  • Page 6: Software Installation

    CD included with your package, and provides you with the following: 1. Web links to various resources and documentation 2. Discovery of all the Digimerge IP devices on the network 3. Provides Network configuration of IP Devices 4. Installs DigiConsole and...
  • Page 7: Software Setup

    3rd party software support links. Find Devices: Locates all available Digimerge IP devices on your network and displays a snapshot of the results. Click on any available device to display image on the right side screen display.
  • Page 8 SOFTWARE SET-UP Continued OPTIONAL Edit Network Parameters: The Network Parameters are automatically assigned to the Device by the network router (by using DHCP). These settings can be manually changed if desired. 1. Select the IP device you would like to edit by clicking on its icon. 2.
  • Page 9: Open Device In Browser

    SOFTWARE SET-UP Continued Open Device in Browser: Once user names and passwords are set Opens up the DigiViewer Video Browser up by the administrator, the users (except using your default web browser (e.g. for a VIEWER level user) are required to Internet Explorer).
  • Page 10 SOFTWARE SET-UP Continued 3 Levels of User Access: • Administrator (current user) • Operator (general user) Default User Name: guest Password: <leave blank> • Viewer (anonymous guest) Creating Current User Account: 1. Click SETTINGS 2. Select ACCOUNTS 3. Fill in a user name and password in the assigned fields 4.
  • Page 11 This page is intentionally left blank. w w w d i g i m e r g e c o m DNP530E_Quick Installation Guide_En_R1 Page 11...
  • Page 12 Opens up a window to search your computer for downloaded firmware (with .bin extension). NOTE: This product will not auto- matically check for firmware updates. Please visit the Digimerge website to download the most current firmware for your product. Register: Provides you with information on the device warranty and/or free DDNS service.
  • Page 13 The application is optional as we offer software solution compatibility with some of the premier IP software developers in the industry. Visit the Digimerge website for the most up to date information on compatible software solutions. Application Installation: When you install the Digiconsole...
  • Page 14 DDNS SET-UP AND REGISTRATION Port forwarding on your router and the creation of a DDNS account with Digimerge is required in order for you to have remote internet access. Open your Web Browser. Select the Create Account Enter http://ddns.digimerge.net Option http://ddns.digimerge.net...
  • Page 15 Router: Refer to your for DDNS, click on the ‘register with DDNS Router’s manual for specific service’ link. This will bring up the Digimerge instructions on port forwarding DDNS Account login screen. Log in using or check DNP5320E product...
  • Page 16: Power Over Ethernet (Poe)

    Lower Costs IP Camera (non-PoE) • Eliminate the need to run A/C power wires Digimerge IP Devices are certified for use with Microsemi PoE hardware solutions. Visit www.microsemi. • Utilize existing IT infrastructure investments com/PowerDsine for details on all available PoE hardware solutions.
  • Page 17 DIGIMERGE IP CAMERA LINE-UP • Full Range of High Resolution (520TVL+) Cameras • Dual Codec (MPEG4/MJPEG) • Hardware Solutions to Fit Most Common CCTV • Full D1 Resolution (@ up to 30fps) Applications (Day/Night/PTZ/ WDR/ Weatherproof/ • Complete Software Solution Included...
  • Page 18 For additional information or troubleshooting help, refer to your owners manual for assistance. You can also call or email for further support. Toll Free Technical Support: 1--3- or +05-- Email Support: tech@digimerge.com Website: www.digimerge.com w w w d i g i m e r g e...
