X-2 Technical Service Manual
1

1.1 Purpose

The purpose of this manual is to provide a technical description, details and
drawings about the X-2 transceiver for the technician to understand the:
•
•
•
•
•

1.2 How this manual is organised

The X-2 Technical Service Manual is organised as follows:
Chapter 1
Chapter 2
Chapter 3
Chapter 4
Chapter 5
Chapter 6
Chapter 7
Chapter 8
Publication No: 15-02047
function
technical operation
fault diagnosis
dismantling and assembly
setup and adjustment procedures
An overview of the features of the X-2 transceiver
including specifications.
A brief description of the X-2 transceiver with a general
description of the major circuit functions for the control,
reception and transmission of signals.
Operating instructions for the X-2 transceiver.
A more detailed technical description of the operation
and circuit function of the X-2 transceiver. Read this
with the associated technical drawings found in the
appendices.
Maintenance, general cautions and warnings, fault
diagnosis procedures associated with the maintenance of
the X-2 transceiver.
Programming procedures for channel additions.
Adjustments, checks and alignments to the X-2
Transceiver detailing required test equipment.
Comprises four appendices. Connector tables, parts lists,
engineering drawings and glossaries.

Introduction

1-1
