Cordless Rotary
Hammer
MODEL BHR200
003091
I N S T R U C T I O N
M A N U A L
WARNING:
For your personal safety, READ and UNDERSTAND before using.
SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE.

Advertisement

Table of Contents
loading

Related Manuals for Makita BHR200

Summary of Contents for Makita BHR200

  • Page 1 Cordless Rotary Hammer MODEL BHR200 003091 I N S T R U C T I O N M A N U A L WARNING: For your personal safety, READ and UNDERSTAND before using. SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE.

  • Page 2: Specifications

    Director It is also suitable for drilling without impact in wood, MAKITA INTERNATIONAL EUROPE LTD. metal, ceramic and plastic. Michigan Drive, Tongwell, Milton Keynes, Bucks MK15 8JD, ENGLAND Responsible manufacturer: Makita Corporation Anjo Aichi Japan...

  • Page 3: General Safety Rules

    GENERAL SAFETY RULES GEA002-3 WARNING: Read all instructions. Failure to follow all instructions listed below may result in electric shock, fire and/or serious injury. The term “power tool” in all of the warnings listed below refers to your mains-operated (corded) power tool or battery- operated (cordless) power tool.

  • Page 4: Specific Safety Rules

    20. Maintain power tools. Check for misalignment or 25. Use power tools only with specifically desig- binding of moving parts, breakage of parts and nated battery packs. Use of any other battery any other condition that may affect the power packs may create a risk of injury and fire.
  • Page 5 SAVE THESE INSTRUCTIONS WARNING: MISUSE or failure to follow the safety rules stated in this instruction manual may cause serious personal injury. IMPORTANT SAFETY INSTRUCTIONS FOR BATTERY CARTRIDGE ENC005-1 (2) Avoid storing battery cartridge in a con- Before using battery cartridge, read all instruc- tions and cautionary markings on (1) battery tainer with other metal objects such as charger, (2) battery, and (3) product using bat-...

  • Page 6: Functional Description

    FUNCTIONAL CAUTION: DESCRIPTION • Always be sure that the tool is switched off and the battery cartridge is removed before adjusting or checking function on the tool. Installing or removing battery cartridge 003103 • Always switch off the tool before insertion or removal of the battery cartridge.
  • Page 7 Selecting the action mode Rotation with hammering 003128 For drilling in concrete, masonry, etc., depress the lock button and rotate the change lever so that the pointer points to the symbol. Use a tungsten-car- bide tipped bit. 1. Rotation with hammering 2.
  • Page 8 Foot 004215 Remove the foot when you use the battery cartridge BH2420. This will help to place the tool steady. 1. Foot 2. Battery cartridge Install the foot when you use the battery cartridge BH2433. 004216 This will help to place the tool steady. 1.
  • Page 9 Insert the bit into the tool. Turn the bit and push it in until it engages. 003157 If the bit cannot be pushed in, remove the bit. Pull the chuck cover down a couple of times. Then insert the bit again. Turn the bit and push it in until it engages.

  • Page 10: Operation

    Depth gauge 003179 The depth gauge is convenient for drilling holes of uniform depth. Loosen the clamp screw and adjust the depth gauge to the desired depth. After adjusting, tighten the clamp screw firmly. NOTE: • The depth gauge cannot be used at the position where the depth gauge strikes against the gear housing/motor housing.

  • Page 11: Maintenance

    Blow-out bulb (optional accessory) 002449 After drilling the hole, use the blow-out bulb to clean the dust out of the hole. 1. Blow-out bulb Chipping/Scaling/Demolition 003203 Set the change lever to the symbol. Hold the tool firmly with both hands. Turn the tool on and apply slight pressure on the tool so that the tool will not bounce around, uncontrolled.
  • Page 12 CAUTION: • These accessories or attachments are recommended for use with your Makita tool specified in this manual. The use of any other accessories or attachments might present a risk of injury to persons. Only use accessory or attachment for its stated purpose.
  • Page 13 Memo...
  • Page 14 Memo...
  • Page 15 Memo...
  • Page 16 Makita Corporation Anjo, Aichi, Japan 884305E220...
