INSTRUCTION MANUAL
Cordless Rotary Hammer
BHR200
003091
IMPORTANT: Read Before Using.
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BHR200 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Makita BHR200

Summary of Contents for Makita BHR200

  • Page 1 INSTRUCTION MANUAL Cordless Rotary Hammer BHR200 003091 IMPORTANT: Read Before Using.

  • Page 2: Specifications

    ENGLISH (Original instructions) SPECIFICATIONS Model BHR200 Concrete 20 mm Capacities Steel 13 mm Wood 27 mm No load speed (min 0 - 1,100 Blows per minute 0 - 4,700 Overall length 316 mm Net weight 3.8 kg Rated voltage D.C. 24 V •...
  • Page 3 Do not use any Makita Corporation responsible adapter plugs with earthed (grounded) power manufacturer declare that the following Makita tools. Unmodified plugs and matching outlets will machine(s): reduce risk of electric shock. Designation of Machine:...

  • Page 4: Cordless Rotary Hammer Safety Warnings

    away from moving parts. Loose clothes, terminal another. Shorting the battery jewellery or long hair can be caught in moving terminals together may cause burns or a fire. parts. 27. Under abusive conditions, liquid may be 16. If devices are provided for the connection of ejected from the battery;...

  • Page 5: Functional Description

    exceed 50 ﾟ C (122 ﾟ F). Do not leave the tool running. Operate the tool only when hand-held. Do not incinerate the battery cartridge even if 12. Do not point the tool at any one in the area it is severely damaged or is completely worn when operating.
  • Page 6 the tool, causing injury to you or someone around Selecting the action mode you. Rotation with hammering Do not use force when inserting the battery • cartridge. If the cartridge does not slide in easily, it 1. Rotation with is not being inserted correctly. hammering 2.
  • Page 7 CAUTION: Torque limiter Always use the side grip to ensure operating safety The torque limiter will actuate when a certain torque level • when drilling in concrete, masonry, etc. is reached. The motor will disengage from the output The side grip swings around to either side, allowing easy shaft.

  • Page 8: Operation

    Bit angle (when chipping, scaling or Dust cup demolishing) 1. Dust cup 1. Change lever 2. O symbol 001300 Use the dust cup to prevent dust from falling over the tool 003170 and on yourself when performing overhead drilling 1. Change lever operations.

  • Page 9: Maintenance

    repeating this several times, the hole will be cleaned out Use the optional drill chuck assembly. When installing it, and normal drilling may be resumed. refer to "Installing or removing the bit" described on the previous page. CAUTION: Set the change lever so that the pointer points to There is a tremendous and sudden twisting force symbol.
  • Page 10 Only use accessory or attachment for its stated purpose. If you need any assistance for more details regarding these accessories, ask your local Makita Service Center. SDS-Plus Carbide-tipped bits • Bull point • Cold chisel •...
  • Page 12 Makita Corporation Anjo, Aichi, Japan www.makita.com 884305F220...
