- Page 1 SB-E-2-362 ISS.05 Operation Manual GTi – Pressure Feed Spraygun P 1 - 8...
-
Page 2: Ec Declaration Of Conformity
Read and follow all instructions and Safety Precautions before using this equipment Description The GTi Pressure Feed Spraygun Kit is approved to ATEX regulations 94/9/EC, protection II 2 G X, Suitable for use in Zones 1 and 2 level; Important: These Sprayguns are suitable for use with both waterbased and solvent based coating materials. -
Page 3: Personal Protective Equipment
SAFETY WARNINGS Always wear eye protection when Fire and explosion spraying or cleaning the spraygun Solvents and coating materials Gloves must worn when can be highly flammable or spraying cleaning combustible when sprayed. ALWAYS equipment refer to the coating material suppliers Training –... -
Page 4: Parts List
Parts List Ref. No Description Part Number Air Cap/Retaining ring GTI-407-* Spring Clip JGA-156-K5 Nozzle SEE CHART Baffle & Seal GTI-425-K Baffle Seal - Kit of 5 GTI-33-K5 Spring Adjusted Needle Packing Gti-445-K2 Spreader Valve GTI-405-K Stud and Screw GTI-408-K5... -
Page 5: Specification
Specification Air supply connection - Universa l BSP and NPS Fluid Supply Connection - Universal BSP and NPS Maximum static Air inlet pressure - = 9 bar (130 psi) Maximum static Fluid inlet pressure - = 14 bar (200 psi) Nominal gun Air inlet pressure with gun triggered 2 bar (29 psi) Maximum Service temperature - 40°C... -
Page 6: Installation
Installation Important: To ensure that this equipment bore. The hose must be conductive reaches you in first class condition, electrical bond from protective coatings have been use. Flush spraygun to earth should be checked the equipment through with a suitable with an ohmeter. -
Page 7: Replacement Of Parts
Spanner – order SPN-5 Cleaning Brush – order 4900-5-1-K3 Service Kit – For sizes 16 to 22 order GTI-416 and nozzle size as required (i.e GTI-416-18) For sizes 085 to 15 order GTI-426 and nozzle as required size as required (i.e GTI-426-14) - Page 8 ITW Finishing Systems and Products Ringwood Road, Bournemouth, BH11 9LH, England. Tel. No. (01202) 571111 ITW Oberflächentechnik GmbH & Co. KG Telefax No. (01202) 581940, Justus-von-Liebig-Straße 31 Website address http://www.itweuropeanfinishing.com 63128 Dietzenbach Tel (060 74) 403-1 Telefax: (060 74) 403300 ITW Automotive Finishing UK Website address http://www.itw-finishing.de Anchorbrook Industrial Estate...
