Univex duro 7510 Instruction Manual page 14

BASE AND KNIFE HOUSING ASSEMBLY
ILLUS. NO. PART NO.
1. 7510012
2. 7510015
3. 7510013
4. 7510150
5. 7510001
7512001
6. 7510156
7. 7510002
8. 7510158
9. 7510004
10. 7510154
11. 6509012
12. 6509014
13. 8512240
14. 7510011
7512011
15. 7510009
7512009
16. 7510008
7512008
17. 1012167
18.
19. 7510022
20. 8512206
21. 7510023
22. 7510019
23. 8512208
24. 8512210
25. 6509098
26. 8512214
27. 7510084
28. 8512211
29. 8512209
30. 7120009
31. 7120009
32. 7120011
33. 7120009
34. 7120014
7120041
35. 4400081
36. 7120026
7120126
37. 7510094
38. 7510014
39. 7510021
40. 8512525
41. 7510020
42. 7120130
43. 8512326
44. 4400338
MODEL 7510 - 7512
FIGURE 3
DESCRIPTION
WASHER, KNIFE
KNOB, KNIFE GUARD
NUT KNIFE
LOCK PIN, SHARPENER
BACK KNIFE GUARD (MODEL 7510)
BACK KNIFE GUARD (MODEL 7512)
WASHER, KNIFE SHIM
SHAFT, KNIFE
WASHER, KNIFE SHIM
SPACER
PULLEY, KNIFE
BUSHING, KNIFE
SCREW, BLADE
SCRAPER, BLADE
KNIFE GUARD (MODEL 7510)
KNIFE GUARD (MODEL 7512)
BLADE (MODEL 7510)
BLADE (MODEL 7512)
INSERT, KNIFE 7510
INSERT, KNIFE 7512
BALL BEARING
RESERVED
KNIFE DEFLECTOR
LOCATING PIN
KNIFE DEFLECTOR SCREW
SLICER BODY
GRADUATED KNOB BUSHING
FRONT WHEEL
SET SCREW
SET SCREW
GRADUATED KNOB
REAR WHEEL
RIVET
ON-OFF SWITCH
SWITCH JAM NUT (PART OF SWITCH)
SWITCH GUARD
SWITCH JAM NUT (PART OF SWITCH)
INDICATOR LIGHT 115V
INDICATOR LIGHT 220V
SCREW, DOME DRIVE, NO.6 X 5/16
BOTTOM COVER
BOTTOM COVER, 100 V ONLY
RUBBER SUCTION FEET
KNIFE GUARD SHAFT
WASHER, FLAT
LOCK WASHER, EXTERNAL TOOTH M10
SCREW, HEX SOCKET HD M10-1.25 X 25MM
SPACER 100 V ONLY
STUD 100V ONLY
LABEL, DURO (NOT SHOWN)
PAGE 13
7510/7512
QTY.
1
1
1
1
1
1
AS REQ;
1
AS REQ.
1
1
1
3
4
1
1
1
1
1
1
2
1
1
1
1
1
1
1
2
1
1
2
1
1
1
1
1
1
1
4
1
2
2
2
4
4
1
