THE WORLD MODELS Clipped Wing Cub EP Instruction Manual page 5

3
PB2x8mm Screw
2
1.5mm
Ø1mm pilot holes for World Models
tri-horn are pre-drilled. Please look for
pin-hole marks at under side of control
surfaces.
Apply instant type CA glue to both sides
of each hinge.
4
E139CSXMPO25951108
(Stabilizer)
B B'
(Main Wing)
B=B'
PB2x8mm
Apply instant type CA glue to both sides of each hinge.
P.4
Temporary install the main wing,
adjust leveling of the stabilizer to
make it as parallel to the main wing
as possible.
Completed
Completed
A A
A=A
Balsa
6x7x3mm
C
C
C= C
