Lexus LX 570 2016 Service Manual
Hide thumbs Also See for LX 570 2016:
Table of Contents

Advertisement

For safety
1
and security
2
Operation of
3
each component
4
5
Maintenance
6
and care
When trouble
7
arises
Vehicle
8
specifications
9
LX570_OM_OM60N01U_(U)
Search by illustration
Make sure to read through them
How to read the gauges and meters, the variety of
Warning Lights and indicators, etc.
Opening and closing the doors and windows,
adjustment before driving, etc.
Operations and advice which are necessary for driving
Usage of the interior features, etc.
Caring for your vehicle and maintenance procedures
What to do in case of malfunction or emergency
Vehicle Specifications, customizable features, etc.
and SRS airbag instructions for Canadian owners
Search by symptom
Search alphabetically

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LX 570 2016 and is the answer not in the manual?

Questions and answers

Summary of Contents for Lexus LX 570 2016

  • Page 1 Pictorial index Search by illustration For safety Make sure to read through them and security How to read the gauges and meters, the variety of Instrument cluster warning lights and indicators, etc. Operation of Opening and closing the doors and windows, each component adjustment before driving, etc.
  • Page 2: Table Of Contents

    TABLE OF CONTENTS For your information........8 Operation of each Reading this manual........12 component How to search ..........13 3-1. Key information Pictorial index..........14 Keys ............110 For safety and security 3-2. Opening, closing and locking the doors Side doors........115 1-1. For safe use Back door ........122 Before driving.........
  • Page 3 4-5. Using the driving support Driving systems Lexus Safety System+ ....242 4-1. Before driving PCS (Pre-Collision System) ........250 Driving the vehicle .......174 LDA (Lane Departure Cargo and luggage....182 Alert)..........263 Vehicle load limits....... 186 Dynamic radar cruise Trailer towing .........187 control with full-speed Dinghy towing......204...
  • Page 4: Table Of Contents

    5-1. Remote Touch screen • Overhead console....424 Remote Touch/12.3-inch • Cup holders......425 display.......... 394 • Bottle holders......426 5-2. Lexus Climate Concierge • Card holder ......426 Lexus Climate Concierge..400 • Auxiliary boxes ......427 5-3. Using the air conditioning Luggage compartment system and defogger features ........
  • Page 5 Maintenance and care When trouble arises 6-1. Maintenance and care 7-1. Essential information Cleaning and protecting Emergency flashers ....514 the vehicle exterior ....458 If your vehicle has to be Cleaning and protecting stopped in an emergency..515 the vehicle interior....461 7-2. Steps to take in an emergency 6-2.
  • Page 6: Table Of Contents

    TABLE OF CONTENTS Vehicle specifications Index 8-1. Specifications What to do if... (Troubleshooting) .........612 Maintenance data (fuel, oil level, etc.) ....562 Alphabetical index ........616 Fuel information......571 Tire information......574 8-2. Customization Customizable features ....585 8-3. Initialization Items to initialize......598 For owners Reporting safety defects for U.S.
  • Page 7 LX570_OM_OM60N01U_(U)
  • Page 8 Lexus vehicle. This vehicle should not be modified with non-genuine Lexus products. Modification with non-genuine Lexus products could affect its performance, safety or durability, and may even violate governmental regulations.
  • Page 9 ● land only) If your Lexus has Safety Connect or Lexus Enform and if you have subscribed to those services, please refer to the Safety Connect / Lexus Enform Telematics Subscription Service Agreement for information on data collected and its usage.
  • Page 10: Event Data Recorder

    EDR. Disclosure of the EDR data ● Lexus will not disclose the data recorded in an EDR to a third party except when: • An agreement from the vehicle’ s owner (or the lessee for a leased vehicle) is obtained •...
  • Page 11 Scrapping of your Lexus The SRS airbag and seat belt pretensioner devices in your Lexus contain explosive chemicals. If the vehicle is scrapped with the airbags and seat belt pretensioners left as they are, this may cause an accident such as fire. Be sure to have the systems of the SRS airbag and seat belt pretensioner removed and disposed of by a qualified service shop or by your Lexus dealer before you scrap your vehicle.
  • Page 12 Reading this manual WARNING: Explains something that, if not obeyed, could cause death or serious injury to people. NOTICE: Explains something that, if not obeyed, could cause damage to or a mal- function in the vehicle or its equipment. Indicates operating or working procedures. Follow the steps in numerical order.
  • Page 13 How to search Searching by name ■ • Alphabetical index....P. 616 Searching by installation position ■ • Pictorial index ......P. 14 Searching by symptom or sound ■ • What to do if... (Troubleshooting)....P. 612 Searching by title ■ • Table of contents......P. 2 LX570_OM_OM60N01U_(U)
  • Page 14 Pictorial index Pictorial index ■ Exterior Side doors............. P. 115 Locking/unlocking .
  • Page 15 Pictorial index Windshield wipers ........... P. 231 Precautions against winter season .
  • Page 16: Instrument Panel

    Pictorial index ■ Instrument panel Engine switch ............P. 205 Starting the engine/changing the modes .
  • Page 17 Pictorial index Multi-information display ..........P. 91 Display .
  • Page 18 Pictorial index ■ Switches Outside rear view mirror switches ........P. 162 Window lock switch .
  • Page 19 Pictorial index Tire pressure warning reset switch........P. 487 PCS (Pre-Collision System) switch .
  • Page 20 Pictorial index Audio remote control switches Talk switch Telephone switches Meter control switches..........P. 93 Vehicle-to-vehicle distance button .
  • Page 21 Pictorial index Crawl Control switches/Multi-terrain Select mode selector dial........... . P. 309, 314 VSC OFF switch.
  • Page 22 Pictorial index ■ Interior SRS airbags ............P. 38 Floor mats.
  • Page 23 Pictorial index Inside rear view mirror ..........P. 160 Sun visors .
  • Page 24 Pictorial index LX570_OM_OM60N01U_(U)
  • Page 25: And Security

    For safety and security 1-1. For safe use Before driving......... 26 For safety drive.......28 Seat belts ..........30 SRS airbags ........38 Front passenger occupant classification system....51 Safety information for children .......... 57 Child restraint systems ....58 Installing child restraints.....63 Exhaust gas precautions.... 75 1-2.
  • Page 26: Driving

    1-1. For safe use Before driving Floor mat Use only floor mats designed specifically for vehicles of the same model and model year as your vehicle. Fix them securely in place onto the carpet. Insert the retaining hooks (clips) into the floor mat eyelets.
  • Page 27 ■ Do not use floor mats designed for other models or different model year vehicles, ● even if they are Lexus Genuine floor mats. Only use floor mats designed for the driver’ s seat. ● Always install the floor mat securely using the retaining hooks (clips) provided.
  • Page 28 1-1. For safe use For safety drive For safe driving, adjust the seat and mirror to an appropriate position before driving. Correct driving posture Adjust the angle of the seatback so that you are sitting straight up and so that you do not have to lean forward to steer.
  • Page 29: Adjusting The Mirrors

    1-1. For safe use Adjusting the mirrors Make sure that you can see backward clearly by adjusting the inside and outside rear view mirrors properly. (P. 160, 162) WARNING Observe the following precautions. Failure to do so may result in death or serious injury. Do not adjust the position of the driver’...
  • Page 30 1-1. For safe use Seat belts Make sure that all occupants are wearing their seat belts before driving the vehicle. Correct use of the seat belts Extend the shoulder belt so that it ● comes fully over the shoulder, but does not come into contact with the neck or slide off the shoulder.
  • Page 31 1-1. For safe use Fastening and releasing the third center seat belt Pull out the tab. Tab B Tab A Push tab B into buckle B until a click- ing sound is heard. Tab B Buckle B Push tab A into buckle A until a clicking sound is heard.
  • Page 32 1-1. For safe use Releasing and stowing the third center seat belt Push the release button on buckle A. Buckle A Push either the mechanical key or tab A into buckle B. Buckle B When releasing and storing the seat belt, hold the belt while winding it back gently.
  • Page 33 1-1. For safe use Adjusting the seat belt shoulder anchor height (front and second out- board seats) Push the seat belt shoulder anchor down while pressing the release but- ton. Push the seat belt shoulder anchor Move the height adjuster up and down as needed until you hear a click.
  • Page 34 Seat belt extender ■ If your seat belts cannot be fastened securely because they are not long enough, a personal- ized seat belt extender is available from your Lexus dealer free of charge. LX570_OM_OM60N01U_(U)
  • Page 35 Each seat belt should be used by one person only. Do not use a seat belt for more ● than one person at once, including children. Lexus recommends that children be seated in the rear seat and always use a seat belt ● and/or an appropriate child restraint system.
  • Page 36 If the pretensioner has activated, the SRS warning light will come on. In that case, the ● seat belt cannot be used again and must be replaced at your Lexus dealer. Adjustable shoulder anchor ■...
  • Page 37 1-1. For safe use WARNING Using a seat belt extender ■ Do not wear the seat belt extender if you can fasten the seat belt without the extender. ● Do not use the seat belt extender when installing a child restraint system because the ●...
  • Page 38 1-1. For safe use SRS airbags The SRS airbags inflate when the vehicle is subjected to certain types of severe impacts that may cause significant injury to the occupants. They work together with the seat belts to help reduce the risk of death or serious injury. ◆...
  • Page 39 1-1. For safe use ◆ SRS side and curtain shield airbags SRS front side airbags Can help protect the torso of the front seat occupants SRS rear side airbags Can help protect the torso of occupants in the second outboard seats SRS curtain shield airbags Can help protect primarily the head of occupants in the outboard seats LX570_OM_OM60N01U_(U)
  • Page 40 1-1. For safe use SRS airbag system components Knee airbags Airbag sensor assembly Curtain shield airbags Front impact sensors Front passenger airbag Seat belt pretensioners and force limiters (front seats) Side impact sensors (front door) Driver’ s seat position sensor Front side airbags “RSCA OFF”...
  • Page 41 1-1. For safe use Your vehicle is equipped with ADVANCED AIRBAGS designed based on the US motor vehicle safety standards (FMVSS208). The airbag sensor assembly (ECU) controls airbag deployment based on information obtained from the sen- sors etc. shown in the system components diagram above. This information includes crash severity and occupant information.
  • Page 42 An infant or child who is too small to use a seat belt should be properly secured using a child restraint system. Lexus strongly recom- mends that all infants and children be placed in the rear seats of the vehicle and prop- erly restrained.
  • Page 43 1-1. For safe use WARNING SRS airbag precautions ■ Do not lean against the door, the roof side rail ● or the front, side and rear pillars. Do not allow anyone to kneel on the passen- ● ger seats toward the door or put their head or hands outside the vehicle.
  • Page 44 If the areas where the SRS airbags are stored, such as the steering wheel pad and ● front, side and rear pillar garnishes, are damaged or cracked, have them replaced by your Lexus dealer. Do not place anything, such as a cushion, on the front passenger’ s seat. Doing so will ●...
  • Page 45 The airbag itself may also be hot. The windshield may crack. ● For Lexus Enform Safety Connect subscribers, if the SRS airbags deploy or in the event ● of a severe rear-end collision, the system is designed to send an emergency call to the response center, notifying them of the vehicle’...
  • Page 46 1-1. For safe use SRS airbag deployment conditions (SRS front airbags) ■ The SRS front airbags will deploy in the event of an impact that exceeds the set thresh- ● old level (the level of force corresponding to an approximately 12 - 18 mph [20 - 30 km/h] frontal collision with a fixed wall that does not move or deform).
  • Page 47 1-1. For safe use Types of collisions that may not deploy the SRS airbags (SRS front airbags) ■ The SRS front airbags do not generally inflate if the vehicle is involved in a side or rear collision, if it rolls over, or if it is involved in a low-speed frontal collision. But, whenever a collision of any type causes sufficient forward deceleration of the vehicle, deployment of the SRS front airbags may occur.
  • Page 48 1-1. For safe use Types of collisions that may not deploy the SRS airbags ■ (SRS side and curtain shield airbags) The SRS side and curtain shield airbags may not activate if the vehicle is subjected to a collision from the side at certain angles, or a collision to the side of the vehicle body other than the passenger compartment.
  • Page 49 1-1. For safe use When to contact your Lexus dealer ■ In the following cases, the vehicle will require inspection and/or repair. Contact your Lexus dealer as soon as possible. Any of the SRS airbags have been inflated. ● The front of the vehicle is damaged or ●...
  • Page 50 1-1. For safe use Deactivating the curtain shield airbags in a vehicle rollover ON/OFF (hold for a few seconds) The “RSCA OFF” indicator turns on (only when the engine switch is in IGNI- TION ON mode.) The roll sensing function for the curtain shield airbags and seat belt pretension- ers will turn back on automatically each time the engine switch is turned to...
  • Page 51 1-1. For safe use Front passenger occupant classification system Your vehicle is equipped with a front passenger occupant classification sys- tem. This system detects the conditions of the front passenger seat and acti- vates or deactivates the devices for the front passenger. SRS warning light “AIR BAG OFF”...
  • Page 52 1-1. For safe use Condition and operation in the front passenger occupant classification system Adult ■ “AIR BAG ON” and “AIR BAG OFF” “AIR BAG ON” indicator lights Indicator/ SRS warning light warning light Front passenger’ s seat belt reminder light or flashing Front passenger airbag Side airbag...
  • Page 53 1-1. For safe use Unoccupied ■ “AIR BAG ON” and “AIR BAG OFF” Not illuminated indicator lights Indicator/ SRS warning light warning light Front passenger’ s seat belt reminder light Front passenger airbag Deactivated Side airbag on the front passenger seat Activated Curtain shield airbag Devices...
  • Page 54 1-1. For safe use : The system judges a person of adult size as an adult. When a smaller adult sits in the front passenger seat, the system may recognize him/her as a child depending on his/her physique and posture. : In the event the front passenger is wearing a seat belt.
  • Page 55 1-1. For safe use WARNING Front passenger occupant classification system precautions ■ Observe the following precautions regarding the front passenger occupant classifica- tion system. Failure to do so may cause death or serious injury. Wear the seat belt properly. ● Make sure the front passenger’...
  • Page 56 ● SRS warning light may come on to indicate a malfunction of the front passenger occupant classification system. In this case, contact your Lexus dealer immediately. Child restraint systems installed on the second seat should not contact the front seat- ●...
  • Page 57 1-1. For safe use Safety information for children Observe the following precautions when children are in the vehicle. Use a child restraint system appropriate for the child, until the child becomes large enough to properly wear the vehicle’s seat belt. It is recommended that children sit in the rear seats to avoid accidental con- ●...
  • Page 58 1-1. For safe use Child restraint systems A child restraint system for a small child or baby must itself be properly restrained on the seat with the LATCH anchors or the lap portion of the lap/ shoulder belt. The laws of all 50 states of the U.S.A. and Canada now require the use of child restraint systems.
  • Page 59 1-1. For safe use Types of child restraints Child restraint systems are classified into the following 3 types according to the age and size of the child: Rear facing  Infant seat/convert- Forward facing  Convertible   ible seat seat Booster seat ...
  • Page 60 1-1. For safe use When installing a child restraint system on the front passenger seat ■ When you have to use a child restraint system on the front passenger seat, adjust the fol- lowing: The seatback to the most upright position ●...
  • Page 61 In an accident, the child can be crushed against the windshield, or between you and the vehicle’ s interior. Lexus strongly urges the use of a proper child restraint system that conforms to the ● size of the child, installed on the rear seat. According to accident statistics, the child is safer when properly restrained in the rear seat than in the front seat.
  • Page 62 1-1. For safe use WARNING When children are in the vehicle ■ Do not allow children to play with the seat belt. If the seat belt becomes twisted around a child’ s neck, it may lead to choking or other serious injuries that could result in death. If this occurs and the buckle cannot be unfastened, scissors should be used to cut the belt.
  • Page 63 1-1. For safe use Installing child restraints Follow the child restraint system manufacturer’s instructions. Firmly secure the child restraints to the outboard second seats using the LATCH anchors or a seat belt. Attach the top tether strap when installing a child restraint. The lap/shoulder belt can be used if your child restraint system is not compati- ble with the LATCH (Lower Anchors and Tethers for Children) system.
  • Page 64 1-1. For safe use Installation with LATCH system Fold the seatback forward and then adjust it as upright as possible. Take off the covers between the seat cushion and seatback, then confirm the position of the LATCH anchors below the symbol in the seatback. LX570_OM_OM60N01U_(U)
  • Page 65: For Owners

    1-1. For safe use Type A  Latch the hooks of the lower straps onto the LATCH anchors. If the child restraint has a top tether strap, the top tether strap should be latched onto the top tether strap anchor. For owners in Canada: The symbol on a child restraint system indicates the presence of a lower con-...
  • Page 66 1-1. For safe use Installing child restraints using a seat belt (child restraint lock function belt) Rear-facing Infant seat/Convertible seat ■ Fold the seatback while pulling the seatback angle lever. Return the seatback and secure it at the first lock position. (P. 142) Place the child restraint system on the second seat facing the rear of the vehicle.
  • Page 67 1-1. For safe use Fully extend the shoulder belt and then allow it to retract slightly in order to activate the ALR lock mode. Lock mode allows the seat belt to retract only. While pushing the child restraint system down into the second seat, allow the shoulder belt to retract until the child restraint sys- tem is securely in place.
  • Page 68 1-1. For safe use Forward-facing Convertible seat ■ Fold the seatback while pulling the seatback angle lever. Return the seatback and secure it at the first lock position. (P. 142) Place the child restraint system on the seat facing the front of the vehicle.
  • Page 69 1-1. For safe use Fully extend the shoulder strap and then allow it to retract slightly into the ALR lock mode. Lock mode allows the seat belt to retract only. While pushing the child restraint system into the second seat, allow the shoulder belt to retract until the child restraint system is securely in place.
  • Page 70 1-1. For safe use Booster seat ■ Fold the seatback while pulling the seatback angle lever. Return the seatback and secure it at the first lock position. (P. 142) Place the child restraint system on the seat facing the front of the vehicle.
  • Page 71 1-1. For safe use Removing a child restraint system installed with a seat belt Push the buckle release button and fully retract the seat belt. Child restraint systems with a top tether strap Second outboard seats  Secure the child restraint system using a seat belt or LATCH anchors, and move the head restraint in place at the upmost position.
  • Page 72 1-1. For safe use Adjust the head restraint to the downmost position. Second center seat  Secure the child restraint system using a seat belt and remove the head restraint. Open the anchor bracket cover, latch the hook onto the anchor bracket and tighten the top tether strap.
  • Page 73 1-1. For safe use WARNING When installing a booster seat ■ To prevent the belt from going into ALR lock mode, do not fully extend the shoulder belt. ALR mode causes the belt to tighten only. This could cause injury or discomfort to the child.
  • Page 74 1-1. For safe use WARNING When installing a child restraint system ■ When a booster seat is installed, always ensure that the shoulder belt is positioned ● across the center of the child’ s shoulder. The belt should be kept away from the child’ s neck, but not so that it could fall off the child’...
  • Page 75 ● If you smell exhaust gases in the vehicle even when the back door is closed, open the ● windows and have the vehicle inspected at your Lexus dealer as soon as possible. When parking ■ If the vehicle is in a poorly ventilated area or a closed area, such as a garage, stop the ●...
  • Page 76 1-2. Theft deterrent system Engine immobilizer system The vehicle’s keys have built-in transponder chips that prevent the engine from starting if a key has not been previously registered in the vehicle’s on- board computer. Never leave the keys inside the vehicle when you leave the vehicle. This system is designed to help prevent vehicle theft but does not guarantee absolute security against all vehicle thefts.
  • Page 77 1-2. Theft deterrent system Certifications for the engine immobilizer system ■ For vehicles sold in the U.S.A., Hawaii, Guam and Puerto Rico  For vehicles sold in Canada  WARNING Certifications for the engine immobilizer system ■ Changes or modifications not expressly approved by the party responsible for compli- ance could void the user’...
  • Page 78 1-2. Theft deterrent system Alarm The alarm The alarm uses light and sound to give an alert when an intrusion is detected. The alarm is triggered in the following situations when the alarm is set: A locked door is unlocked or opened in any way other than using the entry ●...
  • Page 79: Moon Roof

    1-2. Theft deterrent system System maintenance ■ The vehicle has a maintenance-free type alarm system. Items to check before locking the vehicle ■ To prevent unexpected triggering of the alarm and vehicle theft, make sure of the follow- ing. Nobody is in the vehicle. ●...
  • Page 80 1-2. Theft deterrent system Alarm-operated door lock ■ In the following cases, depending on the situation, the door may automatically lock to prevent improper entry into the vehicle: When a person remaining in the vehicle unlocks the door and the alarm is activated. ●...
  • Page 81: Lights

    Instrument cluster Instrument cluster Warning and indicators lights ..........82 Gauges and meters .....88 Multi-information display ... 91 Head-up display ......100 Fuel consumption information .........105 LX570_OM_OM60N01U_(U)
  • Page 82 2. Instrument cluster Warning and indicators lights The warning and indicators lights on the instrument cluster and center panel inform the driver of the status of the vehicle’s various systems. For the purpose of explanation, the following illustration display all warning lights and indicators illuminated.
  • Page 83 2. Instrument cluster Warning lights Warning lights inform the driver of malfunctions in any of the vehicle’ s systems. Automatic headlight Brake system warning light leveling system warning (P. 524) light (P. 525) (U.S.A.) Low speed four-wheel Brake system warning light drive indicator light (P.
  • Page 84 There may be a malfunction in a system if the lights do not turn on, or turn off. Have the vehicle inspected by your Lexus dealer. : The light flashes to indicate a malfunction.
  • Page 85 2. Instrument cluster Indicators The indicators inform the driver of the operating state of the vehicle’ s various sys- tems. Turn signal indicator “LDA” (Lane Departure (P. 216) Alert) indicator (P. 263) (if equipped) 1, 2 Headlight indicator Slip indicator (P. 380) (P.
  • Page 86 There may be a malfunction in a system if the lights do not turn on, or turn off. Have the vehicle inspected by your Lexus dealer. : The light flashes to indicate that the system is operating.
  • Page 87 Have the vehicle inspected by your Lexus dealer immediately if this occurs. LX570_OM_OM60N01U_(U)
  • Page 88: Gauges And Meters

    2. Instrument cluster Gauges and meters The units used on the speedometer may differ depending on the target region. Engine oil pressure gauge Displays the engine oil pressure Tachometer Displays the engine speed in revolutions per minute Speedometer Displays the vehicle speed Voltmeter Displays the charge state Fuel gauge...
  • Page 89 2. Instrument cluster Odometer and trip meter display Odometer: Displays the total distance the vehicle has been driven Trip meter: Displays the distance the vehicle has been driven since the meter was last reset. Trip meters A and B can be used to record and display different distances independently. Shift position and shift range display Displays the selected shift position or selected shift range (P.
  • Page 90: Multi-Information Display

    When the oil pressure drops even though the engine oil amount has not decreased, or if the oil pressure does not increase when engine oil is added, contact your Lexus dealer, as there may be a problem with the lubrication system.
  • Page 91 2. Instrument cluster Multi-information display Display contents The following information will be dis- played when a menu icon is selected. (P. 93) Some of the information may be dis- played automatically depending on the situation. Drive information Select to display various drive data. (P. 94) Vehicle information display (if equipped) Select to display the vehicle information.
  • Page 92 2. Instrument cluster Driving assist system information (if equipped) Select to display the operational status of the following systems: • Dynamic radar cruise control with full-speed range (P. 271) When the vehicle is in constant speed control mode (P. 279), the menu icon will change to •...
  • Page 93 2. Instrument cluster Operating the meter control switches The multi-information display is operated using the meter control switches. : Switch menu : Change displayed con- tent, scroll up/down the screen and move the cursor up/down Press: Enter/Set Press and hold: Reset Return to the previous screen Press: Displays the screen registered to When no screen has been registered, the drive information screen will be dis-...
  • Page 94: Drive Information

    2. Instrument cluster Drive information Drive information ■ 4 of the following items can be registered and displayed as the drive informa- tion 1 and the drive information 2 (2 items on each screen). Refer to P. 96 for the registration method of the drive information 1 and the drive information 2.
  • Page 95 2. Instrument cluster Eco Indicator (Eco Driving Indicator Zone Display) ■ P. 98 Speed ■ Displays the vehicle speed. Outside temperature ■ Displays the outside temperature within the range of -40F (-40C) to 122F (50C). Sway warning (if equipped) ■ Detects the sway of the vehicle within a lane, which is often associated with a decrease in the driver’...
  • Page 96: Head-Up Display

    2. Instrument cluster Settings display The settings of some features can be changed by using the meter control switches. Setting procedure ■ For functions that can be enabled or disabled, the function switches between on and off each time is pressed. Setting items ■...
  • Page 97 2. Instrument cluster Meter settings ● Select to set the following items. • Language Select to change the language on the display. • Units Select to change the unit for measure of the fuel consumption. • Eco Driving Indicator Light (if equipped) Select to activate/deactivate the Eco Driving Indicator Light.
  • Page 98 2. Instrument cluster Eco Driving Indicator ■ Eco Driving Indicator Light (P. 87) Eco Driving Indicator Zone Display Suggests the Zone of Eco driving with current Eco driving ratio based on acceleration. Eco driving ratio based on acceleration If the acceleration exceeds Zone of Eco driv- ing, the right side of Eco Driving Indicator Zone Display will illuminate.
  • Page 99 2. Instrument cluster WARNING Caution for use while driving ■ For safety, avoid operating the meter control switch while driving as much as possible, and do not look continuously at the multi-information display while driving. Stop the vehicle and operate the meter control switch. Failure to do so may cause a steering wheel operation error, resulting in an unexpected accident.
  • Page 100 2. Instrument cluster  Head-up display Summary of functions The head-up display is linked to the meters and navigation system (if equipped) and projects a variety of information in front of the driver, such as the current vehicle speed and route guidance to a set destination. Navigation system-linked display area (if equipped) (P.
  • Page 101 2. Instrument cluster Driving assist system status display area (if equipped) Select to display the operational status of the following systems: • Dynamic radar cruise control (P. 271) • LDA (Lane Departure Alert) (P. 263) • Intuitive parking assist (P. 289) Displayed content is the same as that displayed on the multi-information display.
  • Page 102 2. Instrument cluster Warning and information icons Displays the following multi-information display linked icons: : Master warning icon Displayed when a warning message is displayed on the multi-information display. (P. 532) : Information icon Displayed when a suggestion/advice pop-up display is displayed on the multi-information display.
  • Page 103 2. Instrument cluster Head-up display ■ The head-up display may seem dark or hard to see when viewed through sunglasses, especially polarized sunglasses. Adjust the brightness of the head-up display or remove your sunglasses. When the battery is disconnected ■ The customize settings of the head-up display will be reset.
  • Page 104 2. Instrument cluster NOTICE To prevent damage to components ■ Do not place any drinks near the head-up dis- ● play projector. If the projector gets wet, elec- trical malfunctions may result. Do not place anything on or put stickers onto ●...
  • Page 105: Fuel Consumption Information

    2. Instrument cluster Fuel consumption information Fuel consumption information can be displayed on the Remote Touch screen. The fuel consumption information can be displayed and operated on the side display. Remote Touch screen Remote Touch knob (P. 394) “MENU” button “ENTER”...
  • Page 106 2. Instrument cluster Fuel consumption Press the “MENU” button on the Remote Touch, then select “Info” on the “Menu” screen, and then select “Fuel Consumption”. Trip information ■ If the “Past Record” screen is displayed, select “Trip Information”. Resetting the consumption data Fuel consumption in the past 15 minutes Current fuel consumption...
  • Page 107 2. Instrument cluster Past record ■ If the “Trip Information” screen is displayed, select “Past Record”. Resetting the past record data Best recorded fuel consumption Average fuel consumption Previous fuel consumption record Updating the average fuel con- sumption data The average fuel consumption his- tory is divided by color into past averages and the average fuel con- sumption since the last reset.
  • Page 108 2. Instrument cluster Using the side display Vehicle information can be displayed on the side display (P. 399), then select to select the desired screen. Fuel consumption  Displays the average fuel consumption for the past 10 minutes in 1 minute inter- vals, as well as the cruising range.
  • Page 109 Operation of each component 3-1. Key information Keys ............110 3-2. Opening, closing and locking the doors Side doors........115 Back door........122 Smart access system with push-button start...... 132 3-3. Adjusting the seats Front seats........140 Rear seats........142 Driving position memory...151 Head restraints ......155 3-4.
  • Page 110 Locks the doors (P. 115) Unlocks the doors (P. 115) Opens the windows and moon roof (P. 115) Opens/closes the power back door (P. 122) Sounds the alarm (P. 111) : This setting must be customized at your Lexus dealer. LX570_OM_OM60N01U_(U)
  • Page 111 3-1. Key information Using the mechanical key To take out the mechanical key, push the release button and take the key out. The mechanical key can only be inserted in one direction, as the key only has grooves on one side. If the key can- not be inserted in a lock cylinder, turn it over and re-attempt to insert it.
  • Page 112 If you lose your mechanical keys ■ New genuine mechanical keys can be made by your Lexus dealer using another mechanical key and the key number stamped on your key number plate. Keep the plate in a safe place such as your wallet, not in the vehicle.
  • Page 113 Replacing the key battery ■ P. 503 Confirmation of the registered key number ■ The number of keys already registered to the vehicle can be confirmed. Ask your Lexus dealer. NOTICE To prevent key damage ■ Do not drop the keys, subject them to strong shocks or bend them.
  • Page 114 When an electronic key is lost ■ If the electronic key remains lost, the risk of vehicle theft increases significantly. Visit your Lexus dealer immediately with all remaining electronic keys and the card key that were provided with your vehicle. LX570_OM_OM60N01U_(U)
  • Page 115 Unlocks all the doors Pressing the button unlocks the driver’ s door. Pressing the button again unlocks the other doors. Press and hold to open the windows and moon roof. : These settings must be customized at your Lexus dealer. LX570_OM_OM60N01U_(U)
  • Page 116 3-2. Opening, closing and locking the doors Operation signals ■ Doors: A buzzer sounds and the emergency flashers flash to indicate that the doors have been locked/unlocked. (Locked: once; Unlocked: twice) Windows and moon roof: A buzzer sounds to indicate that the windows and moon roof are operating.
  • Page 117 3-2. Opening, closing and locking the doors Locking and unlocking the doors from the inside ◆ Door lock switches Locks all the doors Unlocks all the doors ◆ Inside lock buttons Locks the door Unlocks the door The front doors can be opened by pulling the inside handles even if the lock buttons are in the lock position.
  • Page 118 3-2. Opening, closing and locking the doors Locking the driver’s door from the outside without a key Move the inside lock button to the lock position. Close the door. The door cannot be locked if the engine switch is in ACCESSORY or IGNI- TION ON mode, or the electronic key is left inside the vehicle.
  • Page 119 3-2. Opening, closing and locking the doors Automatic door locking and unlocking systems The following functions can be set or canceled: For instructions on customizing, refer to P. 585. Function Operation Shift position linked door lock- Shifting the shift lever out of P locks all the doors. ing function Shift position linked door Shifting the shift lever to P unlocks all the doors.
  • Page 120 3-2. Opening, closing and locking the doors Changing the door unlock function setting ■ It is possible to set which doors the entry function unlocks using the wireless remote con- trol. Turn the engine switch off. When the indicator light on the key surface is not on, press and hold approximately 5 seconds while pressing and holding The setting changes each time an operation is performed, as shown below.
  • Page 121 3-2. Opening, closing and locking the doors Impact detection door lock release system ■ In the event that the vehicle is subject to a strong impact, all the doors are unlocked. Depending on the force of the impact or the type of accident, however, the system may not operate.
  • Page 122 3-2. Opening, closing and locking the doors Back door The back door can be locked/unlocked and opened by the following proce- dures. Locking and unlocking the back door ◆ Smart access system with push-button start Carry the electronic key to enable this function. Locks all the doors Check that the door is securely locked.
  • Page 123 3-2. Opening, closing and locking the doors Opening/closing the back door from the inside The power back door can be opened/ closed using the power back door switch or wireless remote control. (P. 110) Push and hold the switch to close or open.
  • Page 124 3-2. Opening, closing and locking the doors Canceling the power back door system Turn the main switch to disable the power back door system. Inoperative Operative The back door cannot be operated even with the wireless remote control or power back door switch. When closing the back door Make sure that the lower side of the ●...
  • Page 125 3-2. Opening, closing and locking the doors Rear step bumper The rear step bumper is for rear end protection and easier step-up loading. Power back door operating conditions ■ The back door can be opened automatically when the power back door main switch is on, and the following conditions are met.
  • Page 126 3-2. Opening, closing and locking the doors Jam protection function ■ If anything obstructs the power back door while it is closing/opening, the back door will ● automatically operate in the opposite direction. If the lower back door is opened while the upper back door is in a closing operation, it ●...
  • Page 127 3-2. Opening, closing and locking the doors WARNING While driving ■ Keep the back door closed while driving. ● If the back door is left open, it may hit near-by objects while driving or luggage may be unexpectedly thrown out, causing an accident. In addition, exhaust gases may enter the vehicle, causing death or a serious health hazard.
  • Page 128 3-2. Opening, closing and locking the doors WARNING Operating the back door ■ Observe the following precautions. Failure to do so may cause parts of the body to be caught, resulting in death or serious injury. Remove any heavy loads, such as snow and ice, from the back door before opening it. ●...
  • Page 129 ● denly shut again after being opened, causing someone’ s hands, head or neck to be caught and injured. When installing an accessory part to the back door, using a genu- ine Lexus part is recommended. Back door closer ■...
  • Page 130 When installing an accessory part to the back door, using a genu- ine Lexus part is recommended. Jam protection function ■...
  • Page 131 Do not touch the damper stay rod with gloves ● or other fabric items. Do not attach any accessories other than ● genuine Lexus parts to the back door. Damper stay Do not place your hand on the damper stay or ● apply lateral forces to it.
  • Page 132 3-2. Opening, closing and locking the doors Smart access system with push-button start The following operations can be performed simply by carrying the electronic key on your person, for example in your pocket. The driver should always carry the electronic key. Locks and unlocks the side doors (P.
  • Page 133 3-2. Opening, closing and locking the doors Effective range (areas within which the electronic key is detected) ■ When locking or unlocking the doors The system can be operated when the elec- tronic key is within about 2.3 ft. (0.7 m) of either of the outside front door handle.
  • Page 134 3-2. Opening, closing and locking the doors Battery-saving function ■ The battery-saving function will be activated in order to prevent the electronic key bat- tery and the battery from being discharged while the vehicle is not in operation for a long time.
  • Page 135 3-2. Opening, closing and locking the doors When carrying the electronic key together with the following devices that emit radio ● waves • Another vehicle’ s electronic key or a wireless key that emits radio waves • Personal computers or personal digital assistants (PDAs) •...
  • Page 136 3-2. Opening, closing and locking the doors If the electronic key is inside the vehicle and a door handle becomes wet during a car ● wash, a message may be shown on the multi-information display and a buzzer will sound outside the vehicle. To turn off the alarm, lock all the doors. The lock sensor may not work properly if it comes into contact with ice, snow, mud, etc.
  • Page 137 3-2. Opening, closing and locking the doors Certification for the smart access system with push-button start ■ For vehicles sold in the U.S.A., Hawaii, Guam and Puerto Rico  LX570_OM_OM60N01U_(U)
  • Page 138 3-2. Opening, closing and locking the doors For vehicles sold in Canada  LX570_OM_OM60N01U_(U)
  • Page 139 The radio waves may affect the operation of such devices. If necessary, the entry function can be disabled. Ask your Lexus dealer for details, such as the frequency of radio waves and timing of the emitted radio waves. Then, consult your doctor to see if you should disable the entry function.
  • Page 140 3-3. Adjusting the seats Front seats Adjustment procedure Seat position adjustment switch Seatback angle adjustment switch Seat cushion (front) angle adjustment switch Vertical height adjustment switch Lumber support adjustment switch Seat cushion length adjustment switch (driver’ s side only) Active head restraints When the occupant’...
  • Page 141 3-3. Adjusting the seats Power easy access system ■ The driver’ s seat and steering wheel move in accordance with engine switch mode and the driver’ s seat belt condition. (P. 151) Active head restraints ■ Even small forces applied to the seatback may cause the head restraint to move. Pushing up a locked head restraint forcibly may appear the head restraint inner structure.
  • Page 142 3-3. Adjusting the seats Rear seats Adjustment procedure Second seats  Seatback angle adjustment lever Seat position adjustment switch Third seats  Seatback angle adjustment lever LX570_OM_OM60N01U_(U)
  • Page 143 3-3. Adjusting the seats Tumbling the second seats and third seat entry For easy access to the third seat, perform in “Tumbling the second seats” (P. 144). Before tumbling the second seats ■ Stow the seat belt buckles and lower the head restraints to the lowest position.
  • Page 144 3-3. Adjusting the seats Tumbling the second seats ■ Fold down the seatback while pulling the seatback angle adjust- ment lever, and swing the whole seat up and forward. Hook the holding strap to the assist grip and secure the seat by pulling its free end.
  • Page 145 3-3. Adjusting the seats Folding the third seats Before folding the third seats ■ Stow the seat belts buckles. Stow the center head restraint in the seatback. (P. 157) Pass the outer seat belts through the seat belt hangers and secure the seat belt plates.
  • Page 146 3-3. Adjusting the seats The seat will automatically fold when the switch is pressed. LX570_OM_OM60N01U_(U)
  • Page 147 3-3. Adjusting the seats Folding up the third seats ■ Perform following steps in “Before folding the third seats”. (P. 145) If the switch is pressed and held, the seat will automatically fold and lift sideward. (The buzzer sounds twice when the seat is about to lift.) If the switch is released while the seat is lifting sideward, operation will stop...
  • Page 148 3-3. Adjusting the seats If the switch is held down the seat will automatically return to the folding position. (Buzzer sounds twice) If the switch is released while return- ing to the folding position, operation will stop and a buzzer will sound con- tinuously.
  • Page 149 Automatic tumbling or return operation Have the system checked stopped because of a sys- by your Lexus dealer. tem problem. Buzzer sounds for 10 sec- Check something onds Indicator light...
  • Page 150 3-3. Adjusting the seats WARNING Seat adjustment ■ To reduce the risk of sliding under the lap belt during a collision, do not recline the seat more than necessary. If the seat is too reclined, the lap belt may slide past the hips and apply restraint forces directly to the abdomen, or your neck may contact the shoulder belt, increasing the risk of death or serious injury in the event of an accident.
  • Page 151 3-3. Adjusting the seats Driving position memory This feature automatically adjusts the driver’s seats, steering wheel and out- side rear view mirrors to make entering and exiting the vehicle easier or to suit your preferences. Power easy access system The seat and steering wheel are automatically adjusted to allow the driver to enter and exit the vehicle easily.
  • Page 152 3-3. Adjusting the seats Driving position memory Your preferred driving position (the position of the driver’ s seat, steering wheel and outside rear view mirrors) can be entered into the computer’ s memory and recalled with the touch of a button. It is also possible to set this function to acti- vate automatically when the doors are unlocked.
  • Page 153 3-3. Adjusting the seats To stop the position recall operation part-way through ■ Perform any of the following: Press the “SET” button. ● Press button “1”, “2” or “3”. ● Operate any of the seat adjustment switches (only cancels seat position recall). ●...
  • Page 154 3-3. Adjusting the seats Recall procedure ■ Carry the electronic key that has been registered to the driving position, and then unlock and open the driver’ s door using the smart access system with push-button start or wireless remote control. The driving position will move to the recorded position (not including the steering wheel).
  • Page 155 3-3. Adjusting the seats Head restraints Head restraints are provided for all seats. Front seats Vertical adjustment Pull the head restraints up. Down Push the head restraint down while pushing the lock release button. Lock release button Angle adjustment (if equipped) Second seats Pull the head restraints up.
  • Page 156 3-3. Adjusting the seats Third outboard seats To fold the head restraints, pull the head restraint angle lever Adjusting the height of the head restraints ■ Make sure that the head restraints are adjusted so that the center of the head restraint is closest to the top of your ears.
  • Page 157 3-3. Adjusting the seats Third center seat  Pull the head restraint up while pressing the lock release button. Lock release button Third outboard seats  The head restraint cannot be removed. Installing the head restraints (except for the third outboard seats) ■...
  • Page 158 3-4. Adjusting the steering wheel and mirrors Steering wheel Adjustment procedure Operating the switch moves the steer- ing wheel in the following directions: Down Toward the driver Away from the driver Horn To sound the horn, press on or close to mark.
  • Page 159 3-4. Adjusting the steering wheel and mirrors The steering wheel can be adjusted when ■ The engine switch is in ACCESSORY or IGNITION ON mode : If the driver’ s seat belt is fastened, the steering wheel can be adjusted regardless of engine switch mode.
  • Page 160 3-4. Adjusting the steering wheel and mirrors Inside rear view mirror The rear view mirror’s position can be adjusted to enable sufficient confirma- tion of the rear view. Adjusting the height of rear view mirror The height of the rear view mirror can be adjusted to suit your driving posture. Adjust the height of the rear view mir- ror by moving it up and down.
  • Page 161 3-4. Adjusting the steering wheel and mirrors WARNING Do not adjust the position of the mirror while driving. Doing so may lead to mishandling of the vehicle and an accident, resulting in death or serious injury. LX570_OM_OM60N01U_(U)
  • Page 162 3-4. Adjusting the steering wheel and mirrors Outside rear view mirrors Adjustment procedure To select a mirror to adjust, press the switch. Left Right Pressing the same switch again will put the switch in neutral. To adjust the mirror, press the switch. Right Down Left...
  • Page 163 3-4. Adjusting the steering wheel and mirrors Setting automatic mode ■ Automatic mode allows the folding or extending of the mirrors to be linked to locking/unlocking of the doors. Press the “AUTO” switch to set auto- matic mode. The indicator will come on. Pressing the switch once more will return to manual mode.
  • Page 164 3-4. Adjusting the steering wheel and mirrors Using automatic mode in cold weather ■ When automatic mode is used in cold weather, the door mirror could freeze up and automatic stowing and return may not be possible. In this event, remove any ice and snow from the door mirror, then either operate the mirror using manual mode or move the mir- ror by hand.
  • Page 165 3-5. Opening, closing the windows and moon roof Power windows Opening and closing procedures The power windows can be opened and closed using the switches. Operating the switch moves the windows as follows: Closing One-touch closing Opening One-touch opening : To stop the window partway, operate the switch in the opposite direction.
  • Page 166 The power windows can be opened using the wireless remote control. (P. 115) ● : These settings must be customized at your Lexus dealer. Power windows open warning buzzer ■ The buzzer sounds and a message is shown on the multi-information display in the instru- ment cluster when the engine switch is turned off and the driver’...
  • Page 167 3-5. Opening, closing the windows and moon roof WARNING Observe the following precautions. Failing to do so may result in death or serious injury. Closing the windows ■ The driver is responsible for all the power window operations, including the operation ●...
  • Page 168 3-5. Opening, closing the windows and moon roof Moon roof Use the overhead switches to open and close the moon roof and tilt it up and down. Opening and closing Opens the moon roof The moon roof stops slightly before the fully open position to reduce wind noise.
  • Page 169 ● The moon roof can be opened using the wireless remote control . (P. 115) ● : These settings must be customized at your Lexus dealer. If the moon roof cannot be closed automatically ■ Keep the switch depressed. When the moon roof does not close normally ■...
  • Page 170 Check to make sure that the moon roof is completely closed and then release the switch. If the moon roof does not fully close even after performing the above procedure cor- rectly, have the vehicle inspected by your Lexus dealer. Moon roof open warning buzzer ■...
  • Page 171 3-5. Opening, closing the windows and moon roof WARNING Observe the following precautions. Failing to do so may cause death or serious injury. Opening the moon roof ■ Do not allow any passengers to put their hands or heads outside the vehicle while it is ●...
  • Page 172 3-5. Opening, closing the windows and moon roof LX570_OM_OM60N01U_(U)
  • Page 173: Winter Driving Tips

    Driving the vehicle.......174 Opening the fuel tank cap ..239 Cargo and luggage....182 4-5. Using the driving support systems Vehicle load limits .......186 Lexus Safety System+ ....242 Trailer towing......... 187 PCS (Pre-Collision Dinghy towing......204 system) ........250 4-2. Driving procedures LDA (Lane Departure Engine (ignition) switch ..
  • Page 174 4-1. Before driving Driving the vehicle The following procedures should be observed to ensure safe driving: Starting the engine P. 205 Driving With the brake pedal depressed, shift the shift lever to D. (P. 210) Release the parking brake. (P. 218) If the parking brake is in automatic mode, the parking brake is released automatically when shifting the shift lever to any position other than P.
  • Page 175 ● operating. If a warning message is shown on the multi-information display, read the message and follow the instructions. Breaking in your new Lexus ■ To extend the life of the vehicle, observing the following precautions is recommended: For the first 200 miles (300 km): ●...
  • Page 176 Your vehicle has a drum-in-disc type parking brake system. This type of brake system needs bedding-down of the brake shoes periodically or when- ever the parking brake shoes and/or drum are replaced. Have your Lexus dealer, perform the bedding-down operation. Operating your vehicle in a foreign country ■...
  • Page 177 4-1. Before driving WARNING Observe the following precautions. Failure to do so may result in death or serious injury. When starting the vehicle ■ Always keep your foot on the brake pedal while stopped with the engine running. This prevents the vehicle from creeping. When driving the vehicle ■...
  • Page 178 If you hear a squealing or scraping noise (brake pad wear limit indicators) ■ Have the brake pads checked and replaced by your Lexus dealer as soon as possible. Rotor damage may result if the pads are not replaced when needed.
  • Page 179: Glove Box

    4-1. Before driving WARNING Observe the following precautions. Failure to do so may result in death or serious injury. When the vehicle is stopped ■ Do not race the engine. ● If the vehicle is in any gear other than P or N, the vehicle may accelerate suddenly and unexpectedly, causing an accident.
  • Page 180 4-1. Before driving WARNING Observe the following precautions. Failure to do so may result in death or serious injury. When the vehicle is parked ■ If the shift lever is moved before the low speed four-wheel drive indicator turns on/off, ●...
  • Page 181 Engine damage caused by water immersion ● In the event that you drive on a flooded road and the vehicle is flooded, be sure to have your Lexus dealer check the following: Brake function ● Changes in quantity and quality of oil and fluid used for the engine, transmission, ●...
  • Page 182 4-1. Before driving Cargo and luggage Take notice of the following information about storage precautions, cargo capacity and load: Capacity and distribution Cargo capacity depends on the total weight of the occupants. (Cargo capacity) = (Total load capacity)  (Total weight of occupants) Steps for Determining Correct Load Limit ...
  • Page 183 4-1. Before driving Calculation formula for your vehicle Cargo capacity Total load capacity (vehicle capacity weight) (P. 562) When 2 people with the combined weight of A lb. (kg) are riding in your vehicle, which has a total load capacity (vehicle capacity weight) of B lb. (kg), the avail- able amount of cargo and luggage load capacity will be C lb.
  • Page 184 4-1. Before driving WARNING Things that must not be carried in the luggage compartment ■ The following things may cause a fire if loaded in the luggage compartment: Receptacles containing gasoline ● Aerosol cans ● Storage precautions ■ Observe the following precautions. Failure to do so may prevent the pedals from being depressed properly, may block the driver’...
  • Page 185 ■ To use the roof rails as a roof luggage carrier, you must fit the roof rails with two or more genuine Lexus cross rails or their equivalent. When you load cargo on the roof luggage carrier, observe the following: Place the cargo so that its weight is distributed evenly between the front and rear ●...
  • Page 186 4-1. Before driving Vehicle load limits Vehicle load limits include total load capacity, seating capacity, TWR (Trailer Weight Rating) and cargo capacity. ◆ Total load capacity (vehicle capacity weight): P. 562 Total load capacity means the combined weight of occupants, cargo and lug- gage.
  • Page 187 To tow a trailer safely, use extreme care and drive the vehicle in accordance with your trailer’s characteristics and operating conditions. Lexus warranties do not apply to damage or malfunction caused by towing a trailer for commercial purposes. Contact your Lexus dealer for further information about additional require- ments such as towing kits, etc.
  • Page 188 4-1. Before driving Towing related terms GCWR (Gross Combination Weight Rating) ■ The maximum allowable gross com- bination weight. The gross combina- tion weight is the sum of the total vehicle weight (including the occu- pants, cargo and any optional equip- ment installed on the vehicle) and the weight of the trailer being towed (including the cargo in the trailer).
  • Page 189 4-1. Before driving GAWR (Gross Axle Weight Rating) ■ The maximum allowable gross axle Front GAWR weight. The gross axle weight is the load placed on each axle (front and rear). Rear GAWR TWR (Trailer Weight Rating) ■ The maximum allowable gross trailer (With brakes) weight.
  • Page 190 4-1. Before driving Unbraked TWR (Unbraked Trailer Weight Rating) ■ The trailer weight rating for towing a (Without brakes) trailer without a trailer service brake system. Tongue Weight ■ The load placed on the trailer hitch ball. (P. 192) LX570_OM_OM60N01U_(U)
  • Page 191 4-1. Before driving Weight limits The gross trailer weight must never exceed 7000 lb. (3175 kg). ● The gross combination weight must never exceed 13400 lb. (6078 kg). ● The gross vehicle weight must never ● exceed the GVWR indicated on the Certification Label.
  • Page 192 4-1. Before driving Trailer Tongue Weight A recommended tongue weight varies in accordance with the types of trailers ● or towing as described below. To ensure the recommended values shown below, the trailer must be loaded ● by referring to the following instructions. •...
  • Page 193 4-1. Before driving Hitch Trailer hitch assemblies have different weight capacities. Lexus recommends the use of Lexus hitch/bracket for your vehicle. For details, contact your Lexus dealer. If you wish to install a trailer hitch, contact your Lexus dealer. ●...
  • Page 194 4-1. Before driving Selecting trailer ball Use the correct trailer ball for your application. Trailer ball load rating Matches or exceeds the gross trailer weight rating of the trailer. Ball diameter Matches the size of the trailer coupler. Most couplers are stamped with the required trailer ball size.
  • Page 195 4-1. Before driving Positions for towing hitch receiver Hitch receiver pin hole position: 45.3 in. (1151 mm) Connecting trailer lights Use the wire harness stored in the rear end under the vehicle body. Please consult your dealer when installing trailer lights, as incorrect installation may cause damage to the vehicle’...
  • Page 196 4-1. Before driving Connecting and disconnecting a trailer Stop your vehicle and a trailer in line and perform the following: Connecting a trailer ● Put the 4-Wheel AHC in the “LO” (low) mode. Turn off the engine switch or the 4-Wheel AHC. Connect a trailer.
  • Page 197 Speed limits for towing a trailer vary by state or province. Do not exceed the ● posted towing speed limit. Lexus recommends that the vehicle-trailer speed limit is 65 mph (104 km/h) ● on a flat, straight, dry road. Do not exceed this limit, the posted towing speed limit or the speed limit for your trailer as set forth in your trailer owner’...
  • Page 198 4-1. Before driving Avoid jerky starts or sudden acceleration. ● Avoid jerky steering and sharp turns, and slow down before making a turn. ● Note that when making a turn, the trailer wheels will be closer than the vehicle ● wheels to the inside of the turn.
  • Page 199 4-1. Before driving Always place wheel blocks under both the vehicle’ s and the trailer’ s wheels ● when parking. Apply the parking brake firmly, and put the transmission in P. Avoid parking on a slope, but if unavoidable, do so only after performing the following: Apply the brakes and keep them applied.
  • Page 200 4-1. Before driving Matching trailer ball height to trailer coupler height ■ No matter which class of tow hitch applies, for a more safe trailer hookup, the trailer ball setup must be the proper height for the coupler on the trailer.
  • Page 201 If your vehicle is new or equipped with any new power train components (such as an engine, transmission, differential or wheel bearing), Lexus recommends that you do not tow a trailer until the vehicle has been driven for over 500 miles (800 km).
  • Page 202 4-1. Before driving WARNING Trailer towing precautions ■ To tow a trailer safely, use extreme care and drive the vehicle in accordance with the ● trailer’ s characteristics and operating conditions. Failure to do so could cause an acci- dent resulting in death or serious injury. Vehicle stability and braking performance are affected by trailer stability, brake setting and performance, and the hitch.
  • Page 203 NOTICE When installing a trailer hitch ■ Use only the position recommended by your Lexus dealer. Do not install the trailer hitch on the bumper; this may cause body damage. Do not directly splice trailer lights ■...
  • Page 204 4-1. Before driving Dinghy towing Your vehicle is not designed to be dinghy towed (with 4 wheels on the ground) behind a motor home. NOTICE To avoid serious damage to your vehicle ■ Do not tow your vehicle with four wheels on the ground. LX570_OM_OM60N01U_(U)
  • Page 205 4-2. Driving procedures Engine (ignition) switch Performing the following operations when carrying the electronic key on your person starts the engine or changes engine switch modes. Starting the engine Pull the parking brake switch to check that the parking brake is set. (P. 217) Parking brake indicator will come on.
  • Page 206 4-2. Driving procedures Stopping the engine Stop the vehicle. Shift the shift lever to P. Set the parking brake. (P. 218) If the parking brake is in automatic mode, the parking brake is set automatically when shifting the shift lever to P. (P. 217) Press the engine switch.
  • Page 207 ■ The engine immobilizer system may not have been deactivated. (P. 76) ● Contact your Lexus dealer. Check that the shift lever is securely set in P. The engine may not start if the shift lever is ● displaced out of P.
  • Page 208 When “Smart Access System Malfunction See Owner’s Manual” is displayed on the ■ multi-information display The system may be malfunctioning. Have the vehicle inspected by your Lexus dealer, immediately. If the electronic key battery is depleted ■ P. 503 If the smart access system with push-button start has been deactivated in a customized ■...
  • Page 209 Lexus dealer immediately. Symptoms indicating a malfunction with the engine switch ■ If the engine switch seems to be operating somewhat differently than usual, such as the switch sticking slightly, there may be a malfunction. Contact your Lexus dealer immedi- ately. LX570_OM_OM60N01U_(U)
  • Page 210 4-2. Driving procedures Automatic transmission Shifting the shift lever While the engine switch is in IGNITION ON mode, move the shift lever with the brake pedal depressed. When shifting the shift lever between P and D, make sure that the vehicle is completely stopped.
  • Page 211 4-2. Driving procedures Selecting the second start mode Use second start mode for accelerating and driving on slippery road surfaces such as snow. Press the button to use second start mode. Press the button again to cancel second start mode. LX570_OM_OM60N01U_(U)
  • Page 212 4-2. Driving procedures Changing shift range in D position (vehicles with paddle shift switches) To drive using temporary shift range selection, operate the “-” or “+” paddle shift switch. When the “-” paddle shift switch is operated, the shift range will be downshifted to a range that enables engine braking force that is suitable to driving conditions.
  • Page 213 4-2. Driving procedures Changing shift ranges in S mode When the shift lever is in the S position, the shift lever or paddle shift switches can be operated as follows: Upshifting Downshifting The selected shift range, from 1 to 8, will be displayed in the meter.
  • Page 214 If the “S” indicator does not come on even after shifting the shift lever to S ■ This may indicate a malfunction in the automatic transmission system. Have the vehicle inspected by your Lexus dealer immediately. (In this situation, the transmission will operate in the same manner as when the shift lever is in D.) Downshift restriction warning buzzer ■...
  • Page 215 4-2. Driving procedures WARNING When driving on slippery road surfaces ■ Do not accelerate or shift gears suddenly. Sudden changes in engine braking may cause the vehicle to spin or skid, resulting in an accident. LX570_OM_OM60N01U_(U)
  • Page 216: Operating Instructions

    4-2. Driving procedures Turn signal lever Operating instructions The turn signal lever can be used to show the following intentions of the driver: Right turn Lane change to the right (move the lever partway and then release it) The right hand signals will flash 3 times. Lane change to the left (move the lever partway and then release it) The left hand signals will flash 3 times.
  • Page 217 4-2. Driving procedures Parking brake A selections can be made as desired from the following modes. Automatic mode The parking brake is set or released automatically according to shift lever opera- tion. Even when in automatic mode, the parking brake can be set and released manu- ally.
  • Page 218 4-2. Driving procedures Manual mode Sets the parking brake The parking brake indicator light will come on. (P. 218) U.S.A. Canada Pull and hold the parking brake switch if an emergency occurs and it is necessary to operate the parking brake while driv- ing.
  • Page 219 When the parking brake cannot be released due to a malfunction ■ Driving the vehicle with the parking brake set will lead to brake components overheat- ing, which may affect braking performance and increase brake wear. Have the vehicle inspected by your Lexus dealer immediately if this occurs. LX570_OM_OM60N01U_(U)
  • Page 220 4-3. Operating the lights and wipers Headlight switch The headlights can be operated manually or automatically. Operating instructions Turning the end of the lever turns on the lights as follows: Type A  The daytime running lights turn off. The side marker, parking, tail, license plate and instru- ment panel lights turn on.
  • Page 221 4-3. Operating the lights and wipers Type B  The daytime running lights turn on. (P. 222) The side marker, parking tail, license plate and instru- ment panel lights turn on. The headlights and all lights listed above (except day- time running lights) turn on.
  • Page 222 4-3. Operating the lights and wipers Daytime running light system ■ To make your vehicle more visible to other drivers during daytime driving, the daytime ● running lights turn on automatically whenever the engine is started and the parking brake is released. (Illuminate brighter than the parking lights.) Daytime running lights are not designed for use at night.
  • Page 223 If the automatic headlight leveling system warning light flashes ■ It may indicate a malfunction in the system. Contact your Lexus dealer. Light reminder buzzer ■ A buzzer sounds when the engine switch is turned off or turned to ACCESSORY mode and the driver’...
  • Page 224 Do not modify the vehicle. ● Do not replace windshield with non-genuine windshield. ● Contact your Lexus dealer. Do not replace headlights with non-genuine headlights. ● Contact your Lexus dealer. Vehicles with PCS (Pre-Collision System): P. 246 ...
  • Page 225 4-3. Operating the lights and wipers Activating the Automatic High Beam system Push the lever away from you with the headlight switch in the position. Press the Automatic High Beam switch. The Automatic High Beam indicator will come on when the headlights are turned on automatically to indicate that the sys- tem is active.
  • Page 226 4-3. Operating the lights and wipers Turning the high beam on/off manually Switching to low beam ■ Pull the lever to the original position. The Automatic High Beam indicator will turn off. Push the lever away from you to acti- vate the Automatic High Beam sys- tem again.
  • Page 227 4-3. Operating the lights and wipers Camera sensor detection information ■ The high beam may not be automatically turned off in the following situations: ● • When oncoming vehicles suddenly appear from a curve • When the vehicle is cut in front of by another vehicle •...
  • Page 228 4-3. Operating the lights and wipers Temporary lowering sensor sensitivity ■ The sensitivity of the sensor can be temporarily lowered. Vehicles without PCS (Pre-Collision System):  To lower the sensitivity, push and hold on the inside rear view mirror for 15 to 20 sec- onds, and release.
  • Page 229 4-3. Operating the lights and wipers Fog light switch The fog lights assist visibility in difficult driving conditions, such as in rain or fog. Type A  Turns the fog lights off Turns the fog lights on LX570_OM_OM60N01U_(U)
  • Page 230 4-3. Operating the lights and wipers Type B  Turns the fog lights off Turns the fog lights on Fog lights can be used when ■ The headlights are on in low beam. NOTICE To prevent battery discharge ■ Do not leave the lights on longer than necessary when the engine is not running. LX570_OM_OM60N01U_(U)
  • Page 231 4-3. Operating the lights and wipers Windshield wipers and washer Operating the wiper lever The wiper operation is selected by moving the lever as follows. Type A  Temporary operation Rain-sensing operation (“AUTO”) Low speed operation High speed operation When “AUTO” is selected, the wipers will operate automatically when the sen- sor detects falling rain.
  • Page 232 4-3. Operating the lights and wipers Washer/wiper dual operation The wipers operate automatically. (After operating several times, the wipers operate one more time after a short delay to prevent dripping.) Type B  Temporary operation Rain-sensing operation (“AUTO”) Low speed operation High speed operation When “AUTO”...
  • Page 233 4-3. Operating the lights and wipers The sensor sensitivity can be adjusted when “AUTO” is selected. Increases the sensitivity Decreases the sensitivity Washer/wiper dual operation The wipers operate automatically. (After operating several times, the wipers operate one more time after a short delay to prevent dripping.) The windshield wipers and washer can be operated when ■...
  • Page 234 4-3. Operating the lights and wipers Effects of vehicle speed on wiper operation ■ With the settings other than “AUTO” also, the time until drip prevention wiper sweep occurs is changed depending on vehicle speed. Type A  With selected, wiper operation will be switched from low speed to intermittent wiper operation only when the vehicle is stationary.
  • Page 235 4-3. Operating the lights and wipers Rear window wiper and washer The wiper operation is selected by moving the lever as follows: Type A  Intermittent window wiper operation Normal window wiper operation Washer/wiper dual operation LX570_OM_OM60N01U_(U)
  • Page 236 4-3. Operating the lights and wipers Type B  Intermittent window wiper operation Normal window wiper operation Washer/wiper dual operation LX570_OM_OM60N01U_(U)
  • Page 237 4-3. Operating the lights and wipers The rear window wiper and washer can be operated when ■ The engine switch is in IGNITION ON mode. If no washer fluid sprays ■ Check that the washer nozzles are not blocked if there is washer fluid in the washer fluid reservoir.
  • Page 238 4-3. Operating the lights and wipers  Headlight cleaner switch Washer fluid can be sprayed on the headlights. Press the switch to clean the headlights. The headlight cleaners can be operated when ■ The engine switch is in IGNITION ON mode and the headlight switch is turned on. NOTICE When the washer fluid tank is empty ■...
  • Page 239 Fuel types ■ P. 571 Fuel tank opening for unleaded gasoline ■ To help prevent incorrect fueling, your Lexus has a fuel tank opening that only accommo- dates the special nozzle on unleaded fuel pumps. WARNING When refueling the vehicle ■...
  • Page 240 4-4. Refueling NOTICE Refueling ■ Do not spill fuel during refueling. Doing so may damage the vehicle, such as causing the emission control systems to operate abnormally or damaging fuel system components or the vehicle’ s painted sur- face. Opening the fuel tank cap Pull the lever.
  • Page 241 When replacing the fuel tank cap ■ Do not use anything but a genuine Lexus fuel tank cap designed for your vehicle. Doing so may cause a fire or other incident which may result in death or serious injury. LX570_OM_OM60N01U_(U)
  • Page 242 Lexus Safety System+ ■ The Lexus Safety System+ is designed to operate under the assumption that the driver will drive safely, and is designed to help reduce the impact to the occupants and the vehicle in the case of a collision or assist the driver in normal driving conditions.
  • Page 243 Data usage ● Lexus may use the data recorded in this computer to diagnose malfunctions, conduct research and development, and improve quality. Lexus will not disclose the recorded data to a third party except: • With the consent of the vehicle owner or with the consent of the lessee if the vehicle is leased •...
  • Page 244 4-5. Using the driving support systems Sensors Two types of sensors, located behind the front grille and windshield, detect infor- mation necessary to operate the drive assist systems. Radar sensor Camera sensor LX570_OM_OM60N01U_(U)
  • Page 245 Do not subject the radar sensor or surrounding area to a strong impact. ● If the radar sensor, front grille, or front bumper has been subjected to a strong impact, have the vehicle inspected by your Lexus dealer. Do not disassemble the radar sensor. ●...
  • Page 246 ● of the camera sensor by the windshield wipers, replace the wiper insert or wiper blade. If the wiper inserts or wiper blades need to be replaced, contact your Lexus dealer. Do not attach window tinting to the windshield. ●...
  • Page 247 Do not attach any accessories that may obstruct the camera sensor to the hood, front ● grille or front bumper. Contact your Lexus dealer for details. If a surfboard or other long object is to be mounted on the roof, make sure that it will ●...
  • Page 248 4-5. Using the driving support systems Certification ■ LX570_OM_OM60N01U_(U)
  • Page 249 4-5. Using the driving support systems LX570_OM_OM60N01U_(U)
  • Page 250 (P. 254) : Depending on the region in which the vehicle was sold, the pedestrian detection function may not be available. Contact your Lexus dealer for details. : Depending on the region in which the vehicle was sold, the pre-collision braking function (automatic braking function) may not be available.
  • Page 251 4-5. Using the driving support systems ◆ Pre-collision braking When the system determines that the possibility of a frontal collision is high, the system warns the driver. If the system determines that the possibility of a collision is extremely high, the brakes are automatically applied to help avoid the collision or reduce the collision speed.
  • Page 252 4-5. Using the driving support systems WARNING Limitations of the pre-collision system ■ The driver is solely responsible for safe driving. Always drive safely, taking care to ● observe your surroundings. Do not use the pre-collision system instead of normal braking operations under any circumstances.
  • Page 253 4-5. Using the driving support systems WARNING When to disable the pre-collision system ■ In the following situations, disable the system, as it may not operate properly, possibly leading to an accident resulting in death or serious injury: When the vehicle is being towed ●...
  • Page 254 4-5. Using the driving support systems Changing settings of the pre-collision system Enabling/disabling the pre-collision system ■ Press the PCS switch for 3 seconds or more. The system is automatically enabled each time the engine switch is turned to IGNI- TION ON mode.
  • Page 255 4-5. Using the driving support systems Operational conditions ■ For vehicles sold in regions where the pedestrian detection function and pre-collision  braking function are available The pre-collision system is enabled and the system determines that the possibility of a frontal collision with a vehicle or pedestrian is high.
  • Page 256 4-5. Using the driving support systems For vehicles sold in regions where the pedestrian detection function is not available  and the pre-collision braking function is available The pre-collision system is enabled and the system determines that the possibility of a frontal collision with a vehicle is high.
  • Page 257 4-5. Using the driving support systems Pedestrian detection function ■ The pre-collision system detects pedestrians based on the size, profile, and motion of a detected object. However, a pedestrian may not be detected depending on the surrounding brightness and the motion, posture, and angle of the detected object, preventing the system from operating properly.
  • Page 258 4-5. Using the driving support systems • When driving on a road where relative location to vehicle ahead in an adjacent lane may change, such as on a winding road • When a preceding vehicle suddenly decelerates • If the front of the vehicle is raised or lowered, such as when the road surface is uneven or undulating •...
  • Page 259 4-5. Using the driving support systems • When passing under an object (billboard, etc.) at the top of an uphill road • When rapidly closing on an electric toll gate barrier, parking area barrier, or other barrier that opens and closes •...
  • Page 260 4-5. Using the driving support systems • If a vehicle ahead is carrying a load which protrudes past its rear bumper • If a vehicle ahead has extremely high ground clearance • If a vehicle ahead is irregularly shaped, such as a tractor or side car •...
  • Page 261 4-5. Using the driving support systems In some situations such as the following, sufficient braking force may not be obtained, ● preventing the system from performing properly: • If the braking functions cannot operate to their full extent, such as when the brake parts are extremely cold, extremely hot, or wet •...
  • Page 262 If the PCS warning light continues to flash or the warning message does not disappear, ● the system may be malfunctioning. Have the vehicle inspected by your Lexus dealer immediately. If VSC is disabled ■...
  • Page 263 4-5. Using the driving support systems  LDA (Lane Departure Alert) Summary of functions When driving on highways and freeways with white (yellow) lines, this function alerts the driver when the vehicle might depart from its lane. The LDA system recognizes visible white (yellow) lines with the camera sensor on the upper portion of the front windshield.
  • Page 264 4-5. Using the driving support systems ◆ Vehicle sway warning When the vehicle is swaying or appears as if it may depart from its lane multiple times, the warning buzzer sounds and a message is dis- played on the multi-information dis- play to alert the driver.
  • Page 265 Do not install or place anything on the hood or grille. Also, do not install a grille guard ● (bull bars, kangaroo bar, etc.). If your windshield needs repairs, contact your Lexus dealer. ● Turning LDA system on Press the LDA switch to turn the LDA system on.
  • Page 266 4-5. Using the driving support systems Indications on multi-information display Lane departure alert function display Displayed when the multi-informa- tion display is switched to the driving assist system information screen. Inside of displayed white lines is Inside of displayed white lines is ...
  • Page 267 4-5. Using the driving support systems Operation conditions of each function ■ Lane departure alert function ● This function operates when all of the following conditions are met. • LDA is turned on. • Vehicle speed is approximately 32 mph (50 km/h) or more. •...
  • Page 268 4-5. Using the driving support systems Conditions in which functions may not operate properly ■ In the following situations, the camera sensor may not detect white (yellow) lines and var- ious functions may not operate normally. There are shadows on the road that run parallel with, or cover, the white (yellow) lines. ●...
  • Page 269 Warning message Details/Actions “Lane Departure The system may not be operating properly. Alert  Have the vehicle inspected at your Lexus Malfunction dealer. Visit Your Dealer” Dirt, rain, condensation, ice, snow, etc., are present on the windshield in front of the cam- “Forward Camera...
  • Page 270 4-5. Using the driving support systems Customization ■ The following settings can be changed. Function Setting details Adjust alert sensitivity Lane departure alert Adjust alert type (if equipped) Turn function on and off Vehicle sway warning Adjust alert sensitivity For how to change settings, refer to P. 585. LX570_OM_OM60N01U_(U)
  • Page 271 4-5. Using the driving support systems Dynamic radar cruise controlwith full-speed  range Summary of functions In vehicle-to-vehicle distance control mode, the vehicle automatically acceler- ates, decelerates and stops to match the speed changes of the preceding vehicle even if the accelerator pedal is not depressed. In constant speed control mode, the vehicle runs at a fixed speed.
  • Page 272 4-5. Using the driving support systems WARNING Before using dynamic radar cruise control with full-speed range ■ Driving safely is the sole responsibility of the driver. Do not rely solely on the system, and drive safely by always paying careful attention to your surroundings. The dynamic radar cruise control with full-speed range provides driving assistance to reduce the driver’...
  • Page 273 4-5. Using the driving support systems WARNING Situations unsuitable for dynamic radar cruise control with full-speed range ■ Do not use dynamic radar cruise control with full-speed range in any of the following situations. Doing so may result in inappropriate speed control and could cause an accident result- ing in death or serious injury.
  • Page 274 4-5. Using the driving support systems Driving in vehicle-to-vehicle distance control mode This mode employs a radar sensor to detect the presence of vehicles up to approximately 400 ft. (120 m) ahead, determines the current vehicle-to-vehicle following distance, and operates to maintain a suitable following distance from the vehicle ahead.
  • Page 275 4-5. Using the driving support systems Setting the vehicle speed (vehicle-to-vehicle distance control mode) Press the “ON/OFF” button to acti- vate the cruise control. Radar cruise control indicator will come on and a message will be displayed on the multi-information display. Press the button again to deactivate the cruise control.
  • Page 276 4-5. Using the driving support systems Adjusting the set speed To change the set speed, operate the lever until the desired set speed is dis- played. Increases the speed (Except when the vehicle has been stopped by system control in vehicle-to- vehicle distance control mode) Decreases the speed Fine adjustment: Momentarily move...
  • Page 277 4-5. Using the driving support systems Changing the vehicle-to-vehicle distance (vehicle-to-vehicle distance control mode) Pressing the button changes the vehi- Preceding cle-to-vehicle distance as follows: vehicle mark Long Medium Short The vehicle-to-vehicle distance is set automatically to long mode when the engine switch is turned to IGNITION ON mode.
  • Page 278 4-5. Using the driving support systems Canceling and resuming the speed control Pulling the lever toward you cancels the speed control. The speed control is also canceled when the brake pedal is depressed. (When the vehicle has been stopped by system control, depressing the brake pedal does not cancel the setting.) Pushing the lever up resumes the...
  • Page 279 4-5. Using the driving support systems Selecting constant speed control mode When constant speed control mode is selected, your vehicle will maintain a set speed without controlling the vehicle-to-vehicle distance. Select this mode only when vehicle-to-vehicle distance control mode does not function correctly due to a dirty radar sensor, etc.
  • Page 280 • The vehicle has been stopped for about 3 minutes If vehicle-to-vehicle distance control mode is automatically canceled for any other rea- son, there may be a malfunction in the system. Contact your Lexus dealer. Automatic cancelation of constant speed control mode ■...
  • Page 281 4-5. Using the driving support systems Warning messages and buzzers for dynamic radar cruise control with full-speed range ■ Warning messages and buzzers are used to indicate a system malfunction or to inform the driver of the need for caution while driving. If a warning message is shown on the multi-information display, read the message and follow the instructions.
  • Page 282 4-5. Using the driving support systems Conditions under which the vehicle-to-vehicle distance control mode may not function ■ correctly In the case of the following conditions, operate the brake pedal (or accelerator pedal, depending on the situation) as necessary. As the sensor may not be able to correctly detect vehicles ahead, the system may not operate properly.
  • Page 283 4-5. Using the driving support systems  Cruise control Summary of functions Use the cruise control to maintain a set speed without depressing the accelera- tor pedal. Indicators Cruise control switch Setting the vehicle speed Press the “ON/OFF” button to acti- vate the cruise control.
  • Page 284 4-5. Using the driving support systems Adjusting the set speed To change the set speed, operate the lever until the desired set speed is obtained. Increases the speed Decreases the speed Fine adjustment: Momentarily move the lever in the desired direction. Large adjustment: Hold the lever in the desired direction.
  • Page 285 If the cruise control speed cannot be set or if the cruise control cancels immediately after being activated, there may be a malfunction in the cruise control system. Have the vehi- cle inspected by your Lexus dealer. WARNING To avoid operating the cruise control by mistake ■...
  • Page 286 4-5. Using the driving support systems Driving mode select switch The driving modes can be selected to suit driving condition. Normal mode/Customized mode Normal mode and customized mode are selected by pressing the driving mode select switch. Each time the switch is pressed, the driving mode changes between normal mode and customized mode.
  • Page 287 4-5. Using the driving support systems Function Setting Normal Powertrain Power Normal Chassis Sport Normal Air conditioning system Comfort mode By controlling the suspension, riding comfort is further enhanced. Suitable for city driving. When not in comfort mode and the driving mode select switch is turned to the left, the “COMFORT”...
  • Page 288 4-5. Using the driving support systems Operation of the air conditioning system in Eco drive mode ■ Eco drive mode controls the heating/cooling operations and fan speed of the air condi- tioning system to enhance fuel efficiency. To improve air conditioning performance, adjust the fan speed or turn off eco mode of the air conditioning system.
  • Page 289 4-5. Using the driving support systems Intuitive parking assist The distance from your vehicle to nearby obstacles when parallel parking or maneuvering into a garage is measured by the sensors and communicated via the multi-information display, the remote touch screen, and a buzzer. Always check the surrounding area when using this system.
  • Page 290 4-5. Using the driving support systems Display When the sensors detect an obstacle, a graphic is shown on the multi-informa- tion display and the remote touch screen depending on the position and distance to the obstacle. Multi-information display  Front corner sensor operation Front center sensor operation Rear corner sensor operation Rear center sensor operation...
  • Page 291 4-5. Using the driving support systems Sensor detection display, obstacle distance Distance display ■ Sensors that detect an obstacle will illuminate continuously or blink. Approximate distance to obstacle Multi-information Remote touch Corner sensor/ display screen Rear center sensor front center sensor Front center sensor: 4.
  • Page 292 4-5. Using the driving support systems Buzzer operation and distance to an obstacle ■ A buzzer sounds when the sensors are operating. The buzzer sounds faster as the vehicle approaches an obstacle. ● When the vehicle comes within the following distance of the obstacle, the buzzer sounds continuously.
  • Page 293 Setting up intuitive parking assist You can change the buzzer sound volume and the screen operating conditions. Press the “SETUP” button. Select “Vehicle”, and then select “LEXUS Park Assist”/“LEXUS Park Assist Settings” on the screen. Select the desired item. The buzzer sound volume can be adjusted.
  • Page 294 Intuitive parking assist display ■ When an obstacle is detected while the rear view monitor system, Lexus parking assist monitor or Multi-terrain Monitor is in use, the warning indicator will appear in the upper corner of the screen even if the display setting has been set to off.
  • Page 295 If “Parking Assist Malfunction” is displayed on the multi-information display ■ Depending on the malfunction of the sensor, the device may not be working normally. Have the vehicle inspected by your Lexus dealer. Certification for the intuitive parking assist (Canada only) ■...
  • Page 296 ■ In the following situations, the system may not function correctly due to a sensor mal- function etc. Have the vehicle checked by your Lexus dealer. A buzzer does not sound when you turn the intuitive parking assist on. ●...
  • Page 297 4-5. Using the driving support systems 4-Wheel AHC (Active Height Control Suspension) The 4-Wheel AHC adjusts the vehicle height in accordance with driving con- ditions. There are 3 selectable modes, “HI” (high), “N” (normal), and “LO” (low). Easy access mode switch Height control OFF switch Height select switch Selecting vehicle height...
  • Page 298 4-5. Using the driving support systems Display Current mode The vehicle is in the N (normal) height mode in the illustration. show directions in which it is possible to adjust the vehicle height. Height up Height down Height control “OFF” indicator When the height control “OFF”...
  • Page 299 4-5. Using the driving support systems Conditions for changing the vehicle height mode Some modes may not be selectable depending on the vehicle speed when the four-wheel drive control switch is in the H4 position. Refer to the following table. Low mode Normal mode High mode...
  • Page 300 4-5. Using the driving support systems Disabling the height control When the height control OFF switch is pressed with the vehicle stopped. The height control “OFF” indicator will appear on the multi-information display, and the vehicle height will be fixed in the current mode.
  • Page 301 4-5. Using the driving support systems Extra high mode ■ If the vehicle becomes stuck or the Crawl Control system requests the vehicle height be raised, extra high mode may be automatically selected when the vehicle height is in high mode with the four-wheel drive control switch in the L4 position.
  • Page 302 Stop the engine and start it again. If the warning message turns off, the system is operat- ing correctly. If the warning message continues to be displayed, have the vehicle checked at your Lexus dealer as soon as possible. LX570_OM_OM60N01U_(U)
  • Page 303 4-5. Using the driving support systems WARNING When switching the vehicle height mode ■ Before lowering the vehicle height, check that there are no people under or around the vehicle, and check for obstacles. If you do not do this, body parts may be caught in the vehicle, possibly leading to an accident.
  • Page 304 4-5. Using the driving support systems NOTICE When parking in areas with limited overhead height ■ After leaving the vehicle or unloading the luggage, the vehicle height may be slightly higher than normal. Take care when overhead height is limited. To avoid damage to the vehicle ■...
  • Page 305 4-5. Using the driving support systems Four-wheel drive system Use the four-wheel drive control switch and center differential lock/unlock switch to select the following transfer and center differential modes. Four-wheel drive control switch H4 (high speed position) Normal driving on all types of roads. L4 (low speed position) Driving requiring maximum power and traction such as climbing or descending...
  • Page 306 4-5. Using the driving support systems Center differential lock/unlock switch Lock the center differential when your vehicle’ s wheels get stuck in a ditch or when driving on a slippery or bumpy surface. The center differential lock indicator will come on. Unlock the center differential after the wheels have been freed, or after moving to a flat, non-slippery surface.
  • Page 307 In this case, you may not be able to shift between H4 and L4, and the center differential lock may not be operable. Have the vehicle inspected by your Lexus dealer immediately. LX570_OM_OM60N01U_(U)
  • Page 308 4-5. Using the driving support systems WARNING While driving ■ Never move the four-wheel drive control switch if the wheels have lost traction. Doing so may cause an accident resulting in death or serious injury. When the vehicle is parked ■...
  • Page 309 4-5. Using the driving support systems Crawl Control (with Turn Assist function) Allows travel on extremely rough off-road surfaces at a fixed low speed with- out pressing the accelerator or brake pedal. Minimizes loss of traction or vehicle slip when driving on slippery road surfaces, allowing for stable driving. Crawl Control switches ON/OFF switch Speed selection switch...
  • Page 310 4-5. Using the driving support systems Speed modes The following table shows some typical terrains and the recommended speed modes. Mode Road condition Rock, mogul (downhill) and gravel (down- hill) Lo-Med Mogul (uphill) Med-Hi Snow, mud, gravel (uphill), sand, dirt, mogul (uphill) and grass Turn Assist function This function assists cornering performance in accordance with steering opera-...
  • Page 311 4-5. Using the driving support systems When the system is turned off Crawl Control  Press the ON/OFF switch while Crawl Control is operating. If the switch is turned off, the slip indicator and the Turn Assist indicator will go off (if the Turn Assist function is in use), the Crawl Control indicator will flash until the system has turned off completely, and a message stating that Crawl Control has been turned off will be displayed on the multi-information display for several seconds.
  • Page 312 4-5. Using the driving support systems Automatic system cancelation ■ Crawl Control  In the following situations, the buzzer will sound intermittently and Crawl Control will be canceled automatically. In this event, the Crawl Control indicator will flash and then go off, the Turn Assist indicator will go off (if the Turn Assist function is in use), and a message stating that Crawl Control has been turned off will be displayed on the multi-information display for several seconds.
  • Page 313 4-5. Using the driving support systems Sounds and vibrations caused by the Crawl Control system ■ A sound may be heard from the engine compartment when the engine is started or just ● after the vehicle begins to move. This sound does not indicate that a malfunction has occurred in Crawl Control system.
  • Page 314 4-5. Using the driving support systems Multi-terrain Select Multi-terrain Select is a system that helps drivability in off-road situations. When the Crawl Control is turned off  Select a mode that most closely matches the type of terrain on which you are driving from among 5 modes.
  • Page 315 4-5. Using the driving support systems Selectable modes When the Crawl Control is turned off, a mode which matches the road condi- tions can be selected from among the following 5 modes. MUD & SAND LOOSE ROCK MOGUL ROCK & DIRT ROCK Mode Road Conditions...
  • Page 316 After a short time, the TRAC OFF indicator will go off, and you will be able to use Multi- terrain Select. When there is a malfunction in the system ■ The slip indicator light will come on. Have the vehicle inspected by your Lexus dealer immediately. LX570_OM_OM60N01U_(U)
  • Page 317 4-5. Using the driving support systems WARNING When using the Multi-terrain Select ■ Observe the following precautions to avoid an accident that could result in death or serious injuries: There is a chance that the selected mode may not be the most appropriate in terms of ●...
  • Page 318 4-5. Using the driving support systems Multi-terrain Monitor The Multi-terrain Monitor helps the driver to check the vehicle surroundings. It assists in determining the conditions around the driver in a variety of situa- tions, such as when judging conditions during off-road driving or checking for obstacles when parking.
  • Page 319 4-5. Using the driving support systems Screens when the four-wheel drive control switch is in L4 ■ When checking the area to the front and sides of the vehicle ● Front view & dual side view Front view & dual side view (front ...
  • Page 320 4-5. Using the driving support systems When checking the area to the rear of the vehicle ● Rear view & dual side view Wide rear view   P. 333 P. 333 Screens when the four-wheel drive control switch is in H4 ■...
  • Page 321 4-5. Using the driving support systems When checking the area to the rear of the vehicle ● Panoramic view & rear view Wide rear view   P. 340 P. 340 When checking the area to the sides, front and rear of the vehicle (with out- ●...
  • Page 322 4-5. Using the driving support systems Using the Multi-terrain Monitor screen Displaying the Multi-terrain Monitor screen ■ The Multi-terrain Monitor screen will be displayed when the VIEW switch is pressed while the engine switch is in IGNITION ON mode. When the vehicle speed exceeds a certain value for a specific amount of time, the display returns to the navigation or information display screen.
  • Page 323 4-5. Using the driving support systems Switch operations ■ On some screens, the display mode or display settings can be changed using the switches. Automatic display mode switch ● When automatic display mode is turned on, the Multi-terrain Monitor screen is displayed in the following conditions, even if the VIEW switch has not been operated.
  • Page 324 4-5. Using the driving support systems Changing the Multi-terrain Monitor screen The screen display can be switched by operating the switches as follows while the Multi-terrain Monitor screen is displayed. (Screens that can be displayed will vary depending on the positions of the shift lever and four-wheel drive control switch) Screens when the four-wheel drive control switch is in L4 ■...
  • Page 325 4-5. Using the driving support systems Front view & dual side view: Under vehicle terrain view & dual P. 327 side view (front magnified): P. 331 Under vehicle terrain view & dual side view: P. 331 Rear view & dual side view: P.
  • Page 326 4-5. Using the driving support systems Screens when the four-wheel drive control switch is in H4 ■ : Press : Select : Operate the shift lever Navigation screen, information set- Panoramic view & rear view: P. 340 tings screen, etc. Dual side view: P.
  • Page 327 4-5. Using the driving support systems Multi-terrain Monitor screen display ■ The amount of time that the Multi-terrain Monitor screen is displayed changes as follows according to the vehicle speed at the time the VIEW switch was pressed. The Multi-terrain Monitor screen is displayed if the vehicle speed is approximately 7 mph (12 km/h) or less when the camera switch is pressed.
  • Page 328 4-5. Using the driving support systems Screen description ● Under vehicle terrain view selection 6 ft. (2 m) distance guide line switch (blue) Switches between front view and under Items indicate the estimated vehicle terrain view display each time distance from the front end of the vehi- the switch is selected.
  • Page 329 4-5. Using the driving support systems Front view rotating display function ● This function operates when the four-wheel drive control switch is in L4. The front view image is automatically adjusted to be parallel and assist the driver to check road surface conditions regardless of the vehicle inclina- tion.
  • Page 330 Pop-up display of the Lexus parking assist-sensor Displayed if an obstacle is detected while the Lexus parking assist-sensor is turned on. Pop-up display of the RCTA Displayed if a vehicle approaching from right or left rear of the vehicle is detected while the RCTA is turned on.
  • Page 331 4-5. Using the driving support systems Under vehicle terrain view & dual side view ■ Lines indicating current vehicle and tire position are displayed in a composite view on an image taken approximately 10 ft. (3 m) behind the current vehicle position and assists the driver to check conditions underneath the vehicle or determine the position of the front tires.
  • Page 332 4-5. Using the driving support systems Under vehicle terrain view & dual side view ■ The screen can be displayed when the shift lever is in D or N. ● While the under vehicle terrain view is displayed, if the vehicle speed reaches or ●...
  • Page 333 4-5. Using the driving support systems Rear view & dual side view/wide rear view ■ Guide lines are displayed in a composite view on an image of the area to the rear of the vehicle to use as a reference when deciding a course of movement and assist the driver to check the safety of the area to the rear of the vehicle or to park the vehicle.
  • Page 334 Guide lines ■ If the back door is not closed, guide lines will not be displayed. If the guide lines do not display even when the back door is closed, have the vehicle inspected at your Lexus dealer. WARNING Guide lines ■...
  • Page 335 4-5. Using the driving support systems Panoramic view & wide front view ■ The image looking down at the vehicle from above and the image from the front camera are displayed simultaneously and assist the driver to check con- ditions in front, and to the right and left, of the vehicle at intersections or T- junctions with poor visibility.
  • Page 336 4-5. Using the driving support systems Switching to automatic display mode ●  P. 323 Switching guide line display modes ● The mode switches and the switch display changes each time the guide line display selection switch is selected. Distance guide line display Projected course line display Selected mode mode...
  • Page 337 4-5. Using the driving support systems Dual side view ■ The image from the both side cameras is displayed and assists the driver to check conditions on the sides of the vehicle or to confirm the safety of narrow roads. Screen description ●...
  • Page 338 4-5. Using the driving support systems Using the vehicle width lines ● The relative distance of obstacles from the vehicle width lines can be con- firmed. Example 1: When there is an obstacle in front of the vehicle Operate the steering wheel so that the vehicle width line and the obstacle do not overlap.
  • Page 339 4-5. Using the driving support systems Dual side view ■ The screen can be displayed when the shift lever is in P, D or N. ● When the outside rear view mirrors are retracted, the displayed area changes (the area ●...
  • Page 340 4-5. Using the driving support systems Panoramic view & rear view/wide rear view ■ • Panoramic view & rear view: The image looking down at the vehicle from above and the image from the rear camera are displayed simultaneously and assist the driver to check the safety of the area when parking.
  • Page 341 4-5. Using the driving support systems Switching modes ● The display mode switches and the icon display changes each time the guide line display selection switch is selected. Projected course Parking assist guide Distance guide line Selected mode line display mode line display mode display mode Icon display...
  • Page 342 4-5. Using the driving support systems Distance guide line display mode  Front distance guide line (blue) Indicates a distance approximately 3 ft. (1 m) from the front end of the vehicle. Rear vehicle width extension guide lines Indicate the estimated course of the vehicle when backing up straight. •...
  • Page 343 4-5. Using the driving support systems Parking operation (using the estimated curse line) ● When parking in a space which is in the reverse direction to the space described in the procedure below, the steering directions will be reversed. Shift the shift lever to the R position. Turn the steering wheel so that the estimated course lines are within the parking space, and...
  • Page 344 4-5. Using the driving support systems Once the vehicle width extension guide lines and the parking space lines are parallel, straighten the steering wheel and back up slowly until the vehi- cle has completely entered the parking space. Stop the vehicle in an appropriate place, and finish parking. Parking operation (using the parking assist guide line) ●...
  • Page 345 Guide lines ■ If the back door is not closed, guide lines will not be displayed. If the guide lines do not display even when the back door is closed, have the vehicle inspected at your Lexus dealer. WARNING Guide lines ■...
  • Page 346 4-5. Using the driving support systems Display when the outside rear view mirrors are retracted (side view and ■ dual side view) When the outside rear view mirrors are retracted, one of the following screens is displayed and assists the driver to confirm the safety of the area around the vehicle, or park alongside and close to another object.
  • Page 347 4-5. Using the driving support systems Using the vehicle width lines ● The relative distance of obstacles from the vehicle width lines can be con- firmed. • Approach the shoulder, but do not allow the vehicle width line to overlap the curb or other obstacles.
  • Page 348 4-5. Using the driving support systems Intuitive parking assist and RCTA cooperative display ■ When either the intuitive parking assist (P. 289) or Blind Spot Mon- itor (P. 365) is turned on, an icon warns the driver when an obstacle is detected.
  • Page 349 4-5. Using the driving support systems When using the Multi-terrain Monitor Observe the following precautions. Failure to do so may result in an unexpected accident. Also, when driving, make sure to directly confirm the safety of your sur- roundings and the area to the rear of the vehicle. WARNING Conditions under which the Multi-terrain Monitor should not be used ■...
  • Page 350 4-5. Using the driving support systems NOTICE Panoramic view ■ In the panoramic view, the system combines images taken from the front, back, left ● and right side cameras into a single image. There are limits to the range and content that can be displayed.
  • Page 351 4-5. Using the driving support systems Display range ■ Panoramic view ● Not displayed. Not displayed. (Displayed in black around the vehicle icon.) Wide front view ● Masking Parts of the vehicle (such as the bumper or grille) are displayed on the screen. Camera visibility range Object detectable by camera Object not detectable by camera...
  • Page 352 4-5. Using the driving support systems Dual side view ● The side of the vehicle is displayed on the screen. Camera visibility range Object detectable by camera Side view ● The side of the vehicle is displayed on the screen. Camera visibility range Object detectable by camera LX570_OM_OM60N01U_(U)
  • Page 353 4-5. Using the driving support systems Rear view ● The corners of the bumper are not seen on the screen. Wide rear view ● The corners of the bumper are not seen on the screen. LX570_OM_OM60N01U_(U)
  • Page 354 4-5. Using the driving support systems Panoramic view display range ■ In the panoramic view, the system processes and displays images acquired form the 4 ● cameras under the assumption that the vehicle is on a flat road surface. Therefore, the display may appear as follows.
  • Page 355 If the camera or surrounding area has received a strong impact, the camera posi- tion, installation angle, etc., may deviate. If the camera is accidentally subjected to an impact, have the vehicle inspected at your Lexus dealer. • Do not remove, disassemble or modify the camera or surrounding parts Doing so may result in the camera malfunctioning.
  • Page 356 4-5. Using the driving support systems Differences between the panoramic view screen and the actual road ■ The distance guide lines, the combined panoramic view image, guide lines, etc., indicate estimated distances on a flat road surface. In the following situa- tions, actual distances and vehicle course will differ from the guide lines on the screen.
  • Page 357 4-5. Using the driving support systems When the ground behind the vehicle slopes down sharply ● The distance guide lines are displayed further away than the actual dis- tance. Therefore, obstacles on a downward slope appear closer than the actually are. In the same way, the actual course of the vehicle will differ from the course indicated by the guide lines.
  • Page 358 4-5. Using the driving support systems Differences between the panoramic view display and actual three-dimen- ■ sional objects Be aware of the following points when three-dimensional objects higher than the surface of the road (such as a vehicle bumper) are nearby. Panoramic view display ●...
  • Page 359 4-5. Using the driving support systems Projected course lines ● Projected course lines are displayed under the assumption that the vehicle is on a flat road surface. Therefore, the position of three-dimensional objects higher than the road surface (such as a vehicle bumper) cannot be determined.
  • Page 360 4-5. Using the driving support systems Differences between the rear view or wide rear view and actual roads ■ The guide lines on the screen are intended for flat surfaces (such as the road). Be aware of the following points when three-dimensional objects with protru- sions (obstacles such as the cargo bed of a truck) are nearby.
  • Page 361 4-5. Using the driving support systems Differences between the panoramic view, rear view and wide rear view and ■ actual roads Distance guide lines ● Guide lines are displayed in reference to the road surface and cannot be used to determine the distance of three-dimensional objects from the vehi- cle.
  • Page 362 4-5. Using the driving support systems Using under vehicle terrain view ■ The images displayed were previously taken approximately 10 ft. (3 m) behind the cur- ● rent vehicle position. Therefore, actual conditions may differ from those shown on the screen in the following situations.
  • Page 363  The image is out of alignment The camera or surrounding area has Have the vehicle inspected by your Lexus received a strong impact dealer.  The guide lines are very far out of alignment...
  • Page 364 • The camera can be damaged by flying rocks and other debris. Do not expose the camera to strong impact as this could cause a malfunction. If this ● happens, have the vehicle inspected by your Lexus dealer as soon as possible. LX570_OM_OM60N01U_(U)
  • Page 365 4-5. Using the driving support systems  BSM (Blind Spot Monitor) Summary of the Blind Spot Monitor The Blind Spot Monitor is a system that has 2 functions: The BSM (Blind Spot Monitor) function ● Assists the driver in making a decision when changing lanes RCTA (Rear Cross Traffic Alert) function ●...
  • Page 366 4-5. Using the driving support systems Multi-information display Turning the BSM function/RCTA function on/off. (P. 367) Outside rear view mirror indicators BSM function: When a vehicle is detected in a blind spot of the outside rear view mirrors or approaching rapidly from behind into a blind spot, the outside rear view mirror indica- tor on the detected side will illuminate.
  • Page 367 When “Blind Spot Monitor System Malfunction” is shown on the multi-information dis- ■ play There may be a sensor malfunction or voltage abnormality. Have the vehicle inspected at your Lexus dealer. Certification for the Blind Spot Monitor ■ For vehicles sold in the U.S.A., Hawaii, Guam, Puerto Rico and American Samoa ...
  • Page 368 Do not attach stickers to the sensor or surrounding area on the rear bumper. ● Do not modify the sensor or surrounding area on the rear bumper. ● Do not paint the rear bumper any color other than an official Lexus color. ● LX570_OM_OM60N01U_(U)
  • Page 369 4-5. Using the driving support systems BSM function The BSM function uses radar sensors to detect the following vehicles traveling in adjacent lanes and advises the driver of the presence of such vehicles via the indicators on the outside rear view mirrors. Vehicles that are traveling in areas that are not visible using the outside rear view mirrors (the blind spots) Vehicles that are approaching rapidly from behind in areas that are not visible...
  • Page 370 4-5. Using the driving support systems BSM function detection areas The areas that vehicles can be detected in are outlined below. The range of each detection area is: Approximately 1.6 ft. (0.5 m) to 11.5 ft. (3.5 m) from either side of the vehicle : The area between the side of the vehicle and 1.6 ft.
  • Page 371 4-5. Using the driving support systems The BSM function is operational when ■ The BSM function is operational when all of the following conditions are met: The BSM function is on. ● The shift lever is in a position other than R. ●...
  • Page 372 4-5. Using the driving support systems Conditions under which the BSM function may not function correctly ■ The BSM function may not detect vehicles correctly in the following situations: ● • When the sensor is misaligned due to a strong impact to the sensor or its surround- ing area •...
  • Page 373 4-5. Using the driving support systems RCTA function The RCTA function uses radar sensors to detect vehicles approaching from the right or left at the rear of the vehicle and alerts the driver of the presence of such vehicles by flashing the outside rear view mirror indicators and sounding a buzzer.
  • Page 374 4-5. Using the driving support systems RCTA icon display ■ When a vehicle approaching from the right or left at the rear of the vehicle is detected, the following will be displayed on the monitor screen Display Content A vehicle is approaching from the left at the rear of the vehicle A vehicle is approaching from the right at the rear of the vehicle Vehicles are approaching from both sides of the vehicle The RCTA function is malfunctioning (P.
  • Page 375 4-5. Using the driving support systems RCTA function detection areas The areas that vehicles can be detected in are outlined below. The buzzer can alert the driver of faster vehicles approaching from farther away. Example: Approximate Approaching vehicle Speed alert distance Fast 18 mph (28 km/h) 65 ft.
  • Page 376 4-5. Using the driving support systems Conditions under which the Rear Cross Traffic Alert function will not detect a vehicle ■ The Rear Cross Traffic Alert function is not designed to detect the following types of vehicles and/or objects: Vehicles approaching from directly behind ●...
  • Page 377 4-5. Using the driving support systems Conditions under which the Rear Cross Traffic Alert function may not function cor- ■ rectly The Rear Cross Traffic Alert function may not detect vehicles correctly in the following ● situations: • When the sensor is misaligned due to a strong impact to the sensor or its surround- ing area •...
  • Page 378 4-5. Using the driving support systems Instances of the Rear Cross Traffic Alert function unnecessarily detecting a vehicle ● and/or object may increase in the following situations: • When a vehicle passes by the side of your vehicle • When the parking space faces a street and vehicles are being driven on the street •...
  • Page 379 4-5. Using the driving support systems Driving assist systems To help enhance driving safety and performance, the following systems oper- ate automatically in response to various driving situations. Be aware, however, that these systems are supplementary and should not be relied upon too heavily when operating the vehicle.
  • Page 380 4-5. Using the driving support systems When the VSC/Trailer Sway Control/Active TRAC/hill-start assist control systems are operating The slip indicator light flashes to indi- cate that the VSC/Trailer Sway Con- trol/Active TRAC/hill-start assist control systems have been engaged. The stop lights and high mounted stop- light turn on when the hill-start assist control system or Trailer Sway Control is operating.
  • Page 381 4-5. Using the driving support systems Automatic Active TRAC reactivation ■ If only the Active TRAC system is turned off, the Active TRAC system will turn on when vehicle speed increases. Automatic Active TRAC, VSC and Trailer Sway Control reactivation ■...
  • Page 382 4-5. Using the driving support systems WARNING Any of the following conditions may result in an accident which could cause death or seri- ous injury: The Multi Terrain ABS does not operate effectively when ■ The limits of tire gripping performance have been exceeded (such as excessively ●...
  • Page 383 The Multi Terrain ABS, Active TRAC, VSC and Trailer Sway Control will not function correctly if different tires are fitted on the vehicle. Contact your Lexus dealer for further information when replacing tires or wheels. Handling of tires and suspension ■...
  • Page 384 4-6. Driving tips Winter driving tips Carry out the necessary preparations and inspections before driving the vehi- cle in winter. Always drive the vehicle in a manner appropriate to the prevail- ing weather conditions. Pre-winter preparations Use fluids that are appropriate to the prevailing outside temperatures. ●...
  • Page 385 4-6. Driving tips When driving the vehicle Accelerate the vehicle slowly, keep a safe distance between you and the vehicle ahead, and drive at a reduced speed suitable to road conditions. When parking the vehicle Park the vehicle and move the shift lever to P without setting the parking brake. The parking brake may freeze up, preventing it from being released.
  • Page 386 NOTICE Repairing or replacing snow tires ■ Request repairs or replacement of snow tires from Lexus dealers or legitimate tire retailers. This is because the removal and attachment of snow tires affects the operation of the tire pressure warning valves and transmitters.
  • Page 387 4-6. Driving tips Off-road precautions This vehicle belongs to the utility vehicle class, which has higher ground clear- ance and narrower tread in relation to the height of its center of gravity to make it capable of performing in a wide variety of off-road applications. Off-road vehicle features Specific design characteristics give it a higher center of gravity than ordinary ●...
  • Page 388 4-6. Driving tips WARNING Off-road vehicle precautions ■ Always observe the following precautions to minimize the risk of death, serious injury or damage to your vehicle: In a rollover crash, an unbelted person is significantly more likely to die than a person ●...
  • Page 389 4-6. Driving tips Off-road driving When driving your vehicle off-road, please observe the following precautions to ensure your driving enjoyment and to help prevent the closure of areas to off- road vehicles: Drive your vehicle only in areas where off-road vehicles are permitted to ●...
  • Page 390 4-6. Driving tips WARNING Off-road driving precautions ■ Always observe the following precautions to minimize the risk of death, serious injury or damage to your vehicle: Drive carefully when off the road. Do not take unnecessary risks by driving in danger- ●...
  • Page 391 4-6. Driving tips NOTICE To prevent the water damage ■ Take all necessary safety measures to ensure that water damage to the engine or other components does not occur. Water entering the engine air intake will cause severe engine damage. ●...
  • Page 392 4-6. Driving tips LX570_OM_OM60N01U_(U)
  • Page 393: Power Outlets

    Remote Touch/12.3-inch Interior lights list ......419 display ..........394 • Interior lights......420 • Personal lights ......421 5-2. Lexus Climate Concierge 5-5. Using the storage features Lexus Climate Concierge..400 List of storage features .... 422 5-3. Using the air conditioning •...
  • Page 394 5-1. Remote Touch screen Remote Touch/12.3-inch display The Remote Touch can be used to operate the Remote Touch screens. Owners of models equipped with a navigation system should refer to the “NAVIGATION SYSTEM OWNER’S MANUAL”. Remote Touch operation “MAP” button Press this button to display the vehicle’...
  • Page 395 5-1. Remote Touch screen Remote Touch operation Select: Move the Remote Touch knob in the desired direction. Enter: Press the Remote Touch knob or “ENTER” button. Screen display during low temperatures ■ When the ambient temperature is extremely low, screen response may be delayed even if the Remote Touch is operated.
  • Page 396 Select to display the radio control screen. Select to display the media control screen. Select to display the hands-free operation screen. Select to display the “LEXUS App Suite” screen. Select to display the “Information” screen. Select to display the air conditioning control screen. (P. 401) Select to display the “Setup”...
  • Page 397 5-1. Remote Touch screen Switch Function Select to adjust the contrast and brightness of the screens, turn the “Display” screen off, etc. : Refer to the “NAVIGATION SYSTEM OWNER’S MANUAL”. 12.3-inch display operation Full screen display ■ The following functions can be displayed full screen: Initial screen ●...
  • Page 398 5-1. Remote Touch screen Split-screen display ■ Different information can be displayed on the left and right of the screen. For example, air conditioning system or audio screens can be displayed and oper- ated while the fuel consumption information screen is being displayed. The large screen on the left of the display is called the main display, and the small screen to the right is called the side display.
  • Page 399 5-1. Remote Touch screen Split-screen display operation Main Display ■ For details about the functions and operation of the main display, refer to the respective section and “NAVIGATION SYSTEM OWNER’S MANUAL”. Side Display ■ Basic screens  To change the screen displayed on the side display, use the screen buttons on the right side of the display.
  • Page 400 The seat heaters, seat ventilators and heated steering wheel are each auto- matically controlled according to the set temperature of the air conditioning system, the outside and cabin temperature, etc. Lexus Climate Concierge allows a comfortable condition to be maintained without adjusting each sys- tem.
  • Page 401 5-3. Using the air conditioning system and defogger Front automatic air conditioning system Air outlets and fan speed are automatically adjusted according to the temper- ature setting. Select the “MENU” button on the Remote Touch, then select to display the air conditioning control screen. (P. 396) The air conditioning system can be displayed and operated on the “Side Dis- play”.
  • Page 402 5-3. Using the air conditioning system and defogger Change the airflow mode ■ To change the air outlets, press The air outlets used are switched each time the button is pressed. Air flows to the upper body. Air flows to the upper body and feet.
  • Page 403 5-3. Using the air conditioning system and defogger Control screen Operation screen “Main display” ■ Left-hand front seat side temperature control Left-hand front seat side air outlet selector Air flows to the feet and the windshield defogger operates Fan speed control Right-hand front seat side air outlet selector Option control screen Right-hand front seat side temperature control...
  • Page 404 5-3. Using the air conditioning system and defogger Changing the air flow mode ■ To adjust settings, select the screen button.  Air flows to the upper body.  Air flows to the upper body and feet.  Air flows to the feet. ...
  • Page 405 5-3. Using the air conditioning system and defogger Air conditioning controls Using the automatic mode ■ Press or select on the control screen. The air conditioning system will begin to operate. Air outlets and fan speed are automatically adjusted according to the temperature setting. Press to switch to automatic air intake mode.
  • Page 406 5-3. Using the air conditioning system and defogger Changing the rear seat settings Using the automatic mode ■ Select on the operation screen “Main display”. Select Select to increase the tem- perature and to decrease the temperature. Adjusting the temperature setting ■...
  • Page 407: Other Functions

    5-3. Using the air conditioning system and defogger Other functions Switching between outside air and recirculated air modes ■ Press on the control panel. The mode switches among (recirculated air mode), “AUTO” and (outside air mode) each time is pressed. When the system is switched to automatic mode, it operates automatically.
  • Page 408 5-3. Using the air conditioning system and defogger Air outlets Location of air outlets ■ The air outlets and air volume changes according to the selected air flow mode. Adjusting the position of and opening and closing the air outlets ■...
  • Page 409 5-3. Using the air conditioning system and defogger Using automatic mode ■ Fan speed is adjusted automatically according to the temperature setting and the ambi- ent conditions. Therefore, the fan may stop for a while until warm or cool air is ready to flow immediately after the is pressed or on the control screen is selected.
  • Page 410 5-3. Using the air conditioning system and defogger When the outside temperature is low ■ The dehumidification function may not operate even when is selected. Micro dust and pollen filter ■ In order to prevent the windows from fogging up when the outside air is cold, the fol- ●...
  • Page 411 5-3. Using the air conditioning system and defogger NOTICE To prevent battery discharge ■ Do not leave the air conditioning system on longer than necessary when the engine is not running. LX570_OM_OM60N01U_(U)
  • Page 412 5-3. Using the air conditioning system and defogger Rear air conditioning system Air outlets and fan speed are automatically adjusted according to the temper- ature setting. Adjusting the temperature setting ■ Press to increase the temperature and to decrease the tem- perature.
  • Page 413 5-3. Using the air conditioning system and defogger Air conditioning controls Using the automatic mode ■ Press the Adjust the temperature setting. To stop the operation, press the If the system is operated manually in automatic mode ■ If the fan speed setting or air flow modes are operated, the automatic mode indicator goes off.
  • Page 414 5-3. Using the air conditioning system and defogger NOTICE To prevent battery discharge ■ Do not leave the air conditioning system on longer than necessary when the engine is not running. LX570_OM_OM60N01U_(U)
  • Page 415 5-3. Using the air conditioning system and defogger  Heated steering wheel /seat heaters/seat  ventilators Heated steering wheel and seat heaters heat the side grips of the steering wheel and seats. Seat ventilators maintain good airflow by blowing air from the seats.
  • Page 416 Press the switch to turn the heated steering wheel off and then press the switch again. If the indicator light still flashes, a malfunction may be occurring. Turn the heated steering wheel off and have the vehicle inspected by your Lexus dealer. Customization ■...
  • Page 417 5-3. Using the air conditioning system and defogger Seat heaters and ventilators (if equipped) Front seats Second outboard seats   Seat heater switches The indicator light (yellow) on the switch comes on when the seat heater is operating. Seat ventilator switches (if equipped) The indicator light (green) on the switch comes on when the seat ventilator is operat- ing.
  • Page 418 The engine switch is in IGNITION ON mode. Replacing the air filters ■ Filters are installed in the seat ventilators. For replacement of the filters, contact your Lexus dealer. Customization ■ The automatic mode settings for the seat heaters and ventilators can be changed.
  • Page 419 5-4. Using the interior lights Interior lights list Rear interior lights (P. 420) Footwell lights Rear personal lights (P. 421) Scuff lights (if equipped) Inside door handle light Engine switch light Front interior lights (P. 420) Door courtesy light Front personal lights (P. 421) Luggage compartment light Shift lever light (when the engine Outer foot lights...
  • Page 420 5-4. Using the interior lights Interior lights Front  On/off (touch the light) Door position on/off Rear  On/door position on LX570_OM_OM60N01U_(U)
  • Page 421 5-4. Using the interior lights Personal lights Front Rear   Turns the lights on/off (touch the lights) Turns the lights on/off Illuminated entry system ■ The lights automatically turn on/off according to engine switch mode, the presence of the electronic key, whether the doors are locked/unlocked, and whether the doors are open/closed.
  • Page 422 5-5. Using the storage features List of storage features Auxiliary boxes (P. 427) Console box (if equipped) (P. 423) Card holder (P. 426) Cool box (if equipped) (P. 431) Overhead console (P. 424) Auxiliary box (if equipped) Glove box (P. 423) (P.
  • Page 423 5-5. Using the storage features Glove box Open (push button) Unlock with the mechanical key Lock with the mechanical key Glove box light ■ The glove box light turns on when the tail lights are on. Removing the separate tray ■...
  • Page 424 5-5. Using the storage features Remove the tray. WARNING Keep the console box closed while driving. Injuries may result in the event of sudden braking, sudden swerving or an accident. Overhead console Press the button. WARNING Items unsuitable for storing ■...
  • Page 425 5-5. Using the storage features Cup holders Front  Press down and release the lid. Rear  To open, pull down the armrest, press the button and release the rear cup holder on the armrest. WARNING Items unsuitable for the cup holders ■...
  • Page 426 5-5. Using the storage features Bottle holders Front seats Second seats   Third seats  NOTICE Items that should not be stowed in the bottle holders ■ Put the cap on before stowing a bottle. Do not place open bottles in the bottle holders, or glasses and paper cups containing liquid.
  • Page 427 5-5. Using the storage features Auxiliary boxes Your vehicle is equipped with either a front auxiliary box type B or wireless charger. For vehicles with wireless charger, refer to page 436. Front seats ■ Type A  Press and release the lid. Type B (if equipped) ...
  • Page 428 5-5. Using the storage features Press the button to release the lock. Third seats ■ WARNING While driving ■ Except for the third seats: Do not leave the auxiliary box open while driving. Items stored in it may fall out and cause death or serious injury in case of an accident or sudden stop.
  • Page 429 5-5. Using the storage features Luggage compartment features Cargo hooks Raise the hook to use. The cargo hooks are provided for securing loose items. Cargo net hooks To hang the cargo net, use the cargo net hooks and rear tie-down hooks. The cargo net itself is not included as an original equipment.
  • Page 430 5-5. Using the storage features Warning reflector holder Remove the cover. Hold the warning reflector with the bands. The warning reflector itself is not included as an original equipment. First-aid kit holder Remove the cover. Hold the first-aid kit with a band. The first-aid kit itself is not included as an original equipment.
  • Page 431 5-6. Using the other interior features Other interior features Cool box (if equipped) While the engine is running, the cool box, which is cooled by the air conditioning, can be used. Press the button to open the lid. Turns the cool box on/off When on, the indicator light comes on.
  • Page 432 5-6. Using the other interior features Sun visors Main sun visor  To set the visor in the forward posi- tion, flip it down. To set the visor in the side position, flip down, unhook, and swing it to the side.
  • Page 433 5-6. Using the other interior features Clock The GPS clock’ s time is automatically adjusted by utilizing GPS time informa- tion. For details, refer to “NAVIGA- TION SYSTEM OWNER’S MANUAL”. LX570_OM_OM60N01U_(U)
  • Page 434 5-6. Using the other interior features Power outlets The power outlet can be used for the following components: 12 V DC: Accessories that run on less than 10 A 120 V AC: Accessories that use less than 100 W Center of console ■...
  • Page 435 5-6. Using the other interior features Luggage compartment (120 V AC) ■ The power outlet can be used when ■ 12 V DC: The engine switch is in ACCESSORY or IGNITION ON mode. 120 V AC: The engine switch is in IGNITION ON mode. NOTICE To avoid damaging the power outlet ■...
  • Page 436 5-6. Using the other interior features Wireless charger (if equipped) A portable device can be charged by just placing Qi standard wireless charge compatible portable devices according to the Wireless Power Consortium, such as smart phones and mobile batteries, etc., on the charge area. This function cannot be used with portable devices that are larger than the charging area.
  • Page 437 5-6. Using the other interior features Using the wireless charger ■ Press the lid to open. Press the power supply switch of the wireless charger. Switches on and off with each press of the power supply switch. When turned on, the operation indi- cator light (green) comes on.
  • Page 438 Handle the error based on the following table. Operation indicator light Suspected causes Handling method Flashing repeatedly once Vehicle to charger commu- Contact your Lexus dealer. every second (Orange) nication failure. Remove the foreign sub- A foreign substance is stance from between por-...
  • Page 439 5-6. Using the other interior features When covers and accessories are attached to portable devices ■ Do not charge in situations where cover and accessories not able to handle Qi are attached to the portable device. Depending on the type of cover and accessory, it may not be possible to charge.
  • Page 440 5-6. Using the other interior features LX570_OM_OM60N01U_(U)
  • Page 441 5-6. Using the other interior features WARNING Caution while driving ■ When charging a portable device, for safety reasons, the driver should not operate the main part of the portable device while driving. Caution regarding interference with electronic devices ■ People with implantable cardiac pacemakers, cardiac resynchronization therapy- pacemakers or implantable cardioverter defibrillators, as well as any other electrical medical device, should consult their physician about the usage of the wireless charger.
  • Page 442 In addition, excluding the above-mentioned, when the charger does not perform nor- mally or the operation indicator light is flashing continuously, it is considered that the wireless charger is malfunctioning. Contact your Lexus dealer. To prevent failure or damage to data ■...
  • Page 443 5-6. Using the other interior features Armrest Fold down the armrest for use. NOTICE To prevent damage, do not apply too much load on the armrest. LX570_OM_OM60N01U_(U)
  • Page 444: Coat Hooks

    5-6. Using the other interior features Rear door sunshades Pull the tab of the rear door sunshade and hook the shade on using the anchor. To retract the rear door sunshade, unhook the shade and retract it slowly. NOTICE To ensure normal operation of the rear door sunshade, observe the following precau- tions.
  • Page 445: Assist Grips

    5-6. Using the other interior features Assist grips An assist grip (Type A) can be used to support your body while sitting on the seat. An assist grip (Type B) can be used when getting in or out of the vehicle and oth- ers.
  • Page 446: Garage Door Opener

    5-6. Using the other interior features Garage door opener The garage door opener can be programmed to operate garage doors, gates, entry doors, door locks, home lighting systems, security systems, and other devices. ® The garage door opener (HomeLink Universal Transceiver) is manufactured under ®...
  • Page 447 5-6. Using the other interior features Press and hold one of the ® HomeLink buttons and the transmitter button. When the ® HomeLink indicator light changes from a slow to a rapid flash, you can release both but- tons. ® If the HomeLink indicator light comes on but does not flash, flashes...
  • Page 448 5-6. Using the other interior features Programming a rolling code system ■ If your device is rolling code equipped, follow the steps under the heading ® “Programming HomeLink ” before proceeding with the steps listed below. Locate the learn button on the ceiling mounted garage door opener motor. The exact location and color of the button may vary by brand of garage door opener motor.
  • Page 449 5-6. Using the other interior features Programming other devices ■ To program other devices such as home security systems, home door locks or lighting, contact your Lexus dealer for assistance. Reprogramming a button ■ ® The individual HomeLink buttons cannot be erased but can be repro- ®...
  • Page 450 5-6. Using the other interior features Before programming ■ Install a new battery in the remote control transmitter. ● The battery side of the remote control transmitter must be pointed away from the ● ® HomeLink button. Certification for the garage door opener ■...
  • Page 451: Lexus Enform Safety Connect

    Telematics Subscription Service Agreement and its Terms and Conditions, as in effect and amended from time to time, a current copy of which is available at Lexus.com. All use of the Safety Connect service is subject to such then- applicable Terms and Conditions.
  • Page 452 After you have signed the Telematics Subscription Service Agreement and are enrolled, you can begin receiving services. A variety of subscription terms is available for purchase. Contact your Lexus dealer, call 1-800-25-LEXUS (1-800-255-3987) or push the “SOS” button in your vehicle for further subscription details.
  • Page 453 The backup battery will need to be replaced if the Automatic Collision Notification oper- ates for 60 seconds or more. For replacement, consult your Lexus dealer. Safety Connect LED light Indicators When the engine switch is turned to IGNITION ON mode, the red indicator light comes on for 2 seconds then turns off.
  • Page 454 For a description of the Roadside Assistance services and their limitations, please see the Safety Connect Terms and Conditions, which are available at Lexus.com. Safety information for Safety Connect Important! Read this information before using Safety Connect.
  • Page 455 5-6. Using the other interior features Certification for Lexus Enform with Safety Connect ■ FCC ID: O6Y-CDMRF101 FCC ID: XOECDMRF101B FCC ID: N7NGTM2 FCC WARNING: This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment and meets the FCC radio frequency (RF) Exposure Guidelines in Supple- ment C to OET65.
  • Page 456 5-6. Using the other interior features LX570_OM_OM60N01U_(U)
  • Page 457: Fuses 505

    Maintenance and care 6-1. Maintenance and care Cleaning and protecting the vehicle exterior....458 Cleaning and protecting the vehicle interior....461 6-2. Maintenance Maintenance requirements......464 General maintenance....466 Emission inspection and maintenance (I/M) programs ........469 6-3. Do-it-yourself maintenance Do-it-yourself service precautions........ 470 Hood ..........472 Engine compartment ....473 Tires..........486...
  • Page 458 6-1. Maintenance and care Cleaning and protecting the vehicle exterior Perform the following to protect the vehicle and maintain it in prime condi- tion: Working from top to bottom, liberally apply water to the vehicle body, wheel ● wells and underside of the vehicle to remove any dirt and dust. Wash the vehicle body using a sponge or soft cloth, such as a chamois.
  • Page 459 Precautions regarding the Blind Spot Monitor (if equipped) ■ If the paint of the rear bumper is chipped or scratched, the system may malfunction. If this occurs, consult your Lexus dealer. LX570_OM_OM60N01U_(U)
  • Page 460 6-1. Maintenance and care NOTICE To prevent paint deterioration and corrosion on the body and components (aluminum ■ wheels etc.) Wash the vehicle immediately in the following cases: ● • After driving near the sea coast • After driving on salted roads •...
  • Page 461 6-1. Maintenance and care Cleaning and protecting the vehicle interior The following procedures will help protect your vehicle’s interior and keep it in top condition: Protecting the vehicle interior Remove dirt and dust using a vacuum cleaner. Wipe dirty surfaces with a cloth dampened with lukewarm water.
  • Page 462 6-1. Maintenance and care Caring for leather areas ■ Lexus recommends cleaning the interior of the vehicle at least twice a year to maintain the quality of the vehicle’ s interior. Shampooing the carpets ■ There are several commercial foaming-type cleaners available. Use a sponge or brush to apply the foam.
  • Page 463 ● may stick to the leather surface if the vehicle interior heats up significantly. When cleaning the inside of the windshield (vehicles with Lexus Safety System +) ■ Do not allow glass cleaner to contact the lens. Also, do not touch the lens. (P. 246) Water on the floor ■...
  • Page 464 You can perform some maintenance procedures by yourself. Please be aware that do-it-yourself maintenance may affect warranty coverage. The use of Lexus repair manuals is recommended. For details about warranty coverage, refer to the separate “Owner’ s Guide”, “War- ranty and Service Guide”, “Owner’ s Manual Supplement” or “Warranty Booklet”.
  • Page 465 It is recommended that genuine Lexus parts be used for repairs to ensure performance of each system. If non-Lexus parts are used in replacement or if a repair shop other than a Lexus dealer performs repairs, confirm the warranty coverage.
  • Page 466 Listed below are the general maintenance items that should be performed at the intervals specified in the “Warranty and Service Guide” or “Owner’s Manual Supplement”. It is recommended that any problem you notice should be brought to the attention of your Lexus dealer or qualified service shop for advice. Engine compartment...
  • Page 467: Vehicle Interior

    6-2. Maintenance Vehicle interior Items Check points • The accelerator pedal should move smoothly Accelerator pedal (without uneven pedal effort or catching). Automatic transmission • When parked on a slope and the shift lever is in P, is “Park” mechanism the vehicle securely stopped? •...
  • Page 468: Vehicle Exterior

    6-2. Maintenance Vehicle exterior Items Check points Doors • Do the doors operate smoothly? Engine hood • Does the engine hood lock system work properly? • There should not be any signs of fluid leakage after Fluid leaks the vehicle has been parked. •...
  • Page 469 The error code in the OBD system will not be cleared unless the vehicle is driven 40 or more times. If your vehicle does not pass the I/M test Contact your Lexus dealer to prepare the vehicle for re-testing. LX570_OM_OM60N01U_(U)
  • Page 470 6-3. Do-it-yourself maintenance Do-it-yourself service precautions If you perform maintenance yourself, be sure to follow the correct procedures as given in these sections. Items Parts and tools • Warm water • Baking soda • Grease Battery condition (P. 482) • Conventional wrench (for terminal clamp bolts) •...
  • Page 471 6-3. Do-it-yourself maintenance WARNING The engine compartment contains many mechanisms and fluids that may move suddenly, become hot, or become electrically energized. To avoid death or serious injury, observe the following precautions: When working on the engine compartment ■ Keep hands, clothing and tools away from the moving fan and engine drive belt. ●...
  • Page 472 6-3. Do-it-yourself maintenance Hood Release the lock from the inside of the vehicle to open the hood. Pull the hood lock release lever. The hood will pop up slightly. Lift the hood catch and lift the hood. WARNING Pre-driving check ■...
  • Page 473 6-3. Do-it-yourself maintenance Engine compartment Power steering fluid reservoir Brake fluid reservoir (P. 479) (P. 481) Fuse box (P. 505) Engine oil level dipstick Washer fluid tank (P. 485) (P. 475) Battery (P. 482) Engine coolant reservoir Cooling fans (P. 478) Condenser (P.
  • Page 474 6-3. Do-it-yourself maintenance Engine compartment cover Removing the engine compartment cover ■ Installing the clips ■ Push up center portion Insert Press NOTICE After installing an engine compartment cover ■ Make sure the cover is securely installed in its original position. LX570_OM_OM60N01U_(U)
  • Page 475 6-3. Do-it-yourself maintenance Engine oil With the engine at operating temperature and turned off, check the oil level on the dipstick. Checking the engine oil ■ Park the vehicle on level ground. After warming up the engine and turning it off, wait more than 5 minutes for the oil to drain back into the bottom of the engine.
  • Page 476 6-3. Do-it-yourself maintenance Adding engine oil ■ If the oil level is below or near the low level mark, add engine oil of the same type as already in the engine. Make sure to check the oil type and prepare the items needed before adding oil.
  • Page 477 Dispose of used oil and filters only in a safe and acceptable manner. Do not dispose of ● used oil and filters in household trash, in sewers or onto the ground. Call your Lexus dealer, service station or auto parts store for information concerning recycling or dis- posal.
  • Page 478 If the coolant level drops within a short time of replenishing ■ Visually check the radiator, hoses, engine coolant reservoir caps, drain cock and water pump. If you cannot find a leak, have your Lexus dealer test the cap and check for leaks in the cooling system. WARNING When the engine is hot ■...
  • Page 479 Check the radiator and condenser and clear any foreign objects. If either of the above parts is extremely dirty or you are not sure of their condi- tion, have your vehicle checked by your Lexus dealer. WARNING When the engine is hot ■...
  • Page 480 6-3. Do-it-yourself maintenance Adding fluid ■ Make sure to check the fluid type and prepare the necessary item. Fluid type FMVSS No.116 DOT 3 or SAE J1703 brake fluid Items Clean funnel Refilling brake fluid ■ Turn the engine switch off. Depress the brake pedal more than 40 times.
  • Page 481 6-3. Do-it-yourself maintenance Power steering fluid Fluid level ■ The fluid level should be within the appropriate range. Full (when cold) Add fluid (when cold) Full (when hot) Add fluid (when hot) Hot: The vehicles has been driven around 50 mph (80 km/h) for 20 min- utes, or slightly longer in frigid temperatures.
  • Page 482 6-3. Do-it-yourself maintenance WARNING When checking the reservoir ■ Take care as the reservoir may be hot. NOTICE When adding fluid ■ Avoid overfilling, or the power steering may be damaged. After replacing the reservoir cap ■ Check the steering box case, vane pump and hose connections for leaks or damage. Battery Check the battery as follows.
  • Page 483 Make sure to turn off the engine before disconnect the battery. Take extra care when connecting the battery if the engine switch mode prior to discharge is unknown. If the engine will not start even after multiple attempts, contact your Lexus dealer. WARNING Chemicals in the battery ■...
  • Page 484 6-3. Do-it-yourself maintenance WARNING How to recharge the battery ■ Only perform a slow charge (5A or less). The battery may explode if charged at a quicker rate. Emergency measures regarding electrolyte ■ If electrolyte gets in your eyes ● Flush your eyes with clean water for at least 15 minutes and get immediate medical attention.
  • Page 485 6-3. Do-it-yourself maintenance Washer fluid If any washer does not work or the warning message appears on the multi- information display, the washer tank may be empty. Add washer fluid. WARNING When adding washer fluid ■ Do not add washer fluid when the engine is hot or running as washer fluid contains alcohol and may catch fire if spilled on the engine etc.
  • Page 486: Checking Tires

    Tire rotation Rotate the tires in the order shown. To equalize tire wear and extend tire life, Lexus recommends that tire rotation is carried out at the same interval as tire inspection. Do not fail to initialize the tire pressure Front warning system after rotating the tires.
  • Page 487 6-3. Do-it-yourself maintenance The tire pressure warning system Your Lexus is equipped with a tire pressure warning system that uses tire pres- sure warning valves and transmitters to detect low tire inflation pressure before serious problems arise. If the tire pressure drops below a predetermined level, the driver is warned by ●...
  • Page 488 The tire pressure warning valve and transmitter is equipped with a unique ID code. When replacing a tire pressure warning valve and transmitter, it is nec- essary to register the ID code of tire pressure warning valve and transmitter. Have the ID code registered by your Lexus dealer. LX570_OM_OM60N01U_(U)
  • Page 489 A tire goes flat repeatedly or cannot be properly repaired due to the size or location of ● a cut or other damage If you are not sure, consult with your Lexus dealer. Replacing tires and wheels ■ If the ID code of the tire pressure warning valve and transmitter is not registered, the tire pressure warning system will not work properly.
  • Page 490 In the following cases, the tire pressure warning system may not operate properly. ● • If non-genuine Lexus wheels are used. • A tire has been replaced with a tire that is not an OE (Original Equipment) tire. • A tire has been replaced with a tire that is not of the specified size.
  • Page 491 6-3. Do-it-yourself maintenance Performance may be affected in the following situations. ● • Near a TV tower, electric power plant, gas station, radio station, large display, air- port or other facility that generates strong radio waves or electrical noise • When carrying a portable radio, cellular phone, cordless phone or other wireless communication device If tire position information is not correctly displayed due to the radio wave conditions, the display may be corrected by driving and changing the radio wave conditions.
  • Page 492 If repeated attempts to record tire inflation pressure settings are unsuccessful, have the vehicle inspected by your Lexus dealer. When operating the tire pressure warning reset switch, the tire pressure warning light ●...
  • Page 493 Do not mix tires of different makes, models or tread patterns. ● Also, do not mix tires of remarkably different treadwear. Do not use tire sizes other than those recommended by Lexus. ● Do not mix differently constructed tires (radial, bias-belted or bias-ply tires).
  • Page 494 When a tire is repaired with liquid sealants, the tire pressure warning valve and trans- mitter may not operate properly. If a liquid sealant is used, contact your Lexus dealer or other qualified service shop as soon as possible. Make sure to replace the tire pressure warning valve and transmitter when replacing the tire.
  • Page 495 6-3. Do-it-yourself maintenance Tire inflation pressure Tire inflation pressure The recommended cold tire inflation pressure and tire size are displayed on the tire and loading information label. (P. 569) LX570_OM_OM60N01U_(U)
  • Page 496 6-3. Do-it-yourself maintenance Inspection and adjustment procedure Tire valve Tire pressure gauge Remove the tire valve cap. Press the tip of the tire pressure gauge onto the tire valve. Read the pressure using the gauge gradations. If the tire inflation pressure is not at the recommended level, adjust the pres- sure.
  • Page 497 Reduced safety ● Damage to the drive train ● If a tire needs frequent inflating, have it checked by your Lexus dealer. Instructions for checking tire inflation pressure ■ When checking tire inflation pressure, observe the following: Check only when the tires are cold.
  • Page 498 6-3. Do-it-yourself maintenance WARNING Proper inflation is critical to save tire performance ■ Keep your tires properly inflated. If the tires are not properly inflated, the following conditions may occur which could lead to an accident resulting in death or serious injury: Excessive wear ●...
  • Page 499 ● Bent wheels that have been straightened ● Aluminum wheel precautions Use only Lexus wheel nuts and wrenches designed for use with your alumi- ● num wheels. When rotating, repairing or changing your tires, check that the wheel nuts are ●...
  • Page 500 Because tire repair or replacement may affect the tire pressure warning valves and ● transmitters, make sure to have tires serviced by your Lexus dealer or other qualified service shop. In addition, make sure to purchase your tire pressure warning valves and transmitters at your Lexus dealer.
  • Page 501 6-3. Do-it-yourself maintenance Air conditioning filter The air conditioning filter must be cleaned or changed regularly to maintain air conditioning efficiency. Removal method Turn the engine switch IGNITION ON mode and switch to recirculated air mode, then turn the engine switch off. Open the glove box and remove the separate tray.
  • Page 502 2 min- utes at 72 psi (500 kPa, 5.0 kgf/cm bar). If it is not available, have the filter cleaned by your Lexus dealer. Replacement method Remove the air conditioning filter and replace it with a new one.
  • Page 503 6-3. Do-it-yourself maintenance Electronic key battery Replace the battery with a new one if it is depleted. You will need the following items: Flathead screwdriver ● Lithium battery (CR2032) ● Replacing the battery Take out the mechanical key. Remove the cover. To prevent damage to the key, cover the tip of the flathead screwdriver with a tape.
  • Page 504 ● When the card key battery needs to be replaced ■ The battery for the card key is available only at Lexus dealers. Your Lexus dealer can replace the battery for you. If the electronic key battery is depleted ■...
  • Page 505 6-3. Do-it-yourself maintenance Checking and replacing fuses If any of the electrical components do not operate, a fuse may have blown. If this happens, check and replace the fuses as necessary. Turn the engine switch off. Open the fuse box cover. Engine compartment Driver’...
  • Page 506 Type A and B: Replace the blown fuse with a new fuse of an appropriate amperage rating. The amperage rating can be found on the fuse box lid. Type C and D: Contact your Lexus dealer. Type A Type B ...
  • Page 507 If the lights do not turn on even after the fuse has been replaced, a bulb may need ● replacement. (P. 508) If the replaced fuse blows again, have the vehicle inspected by your Lexus dealer. ● If there is an overload in a circuit ■...
  • Page 508 You may replace the following bulbs yourself. The difficulty level of replace- ment varies depending on the bulb. If necessary bulb replacement seems diffi- cult to perform, contact your Lexus dealer. For more information about replacing other light bulbs, contact your Lexus dealer. Preparing for light bulb replacement Check the wattage of the light bulb being replaced.
  • Page 509 6-3. Do-it-yourself maintenance Replacing light bulbs Back-up lights ■ Open the back door and remove the bolts and the cover. Turn the bulb bases counter- clockwise. Remove the light bulb. When installing, reverse the steps listed. LX570_OM_OM60N01U_(U)
  • Page 510 6-3. Do-it-yourself maintenance Replacing the following bulbs ■ If any of the lights listed below has burnt out, have it replaced by your Lexus dealer. Headlights ● Parking lights/daytime running lights ● Front side marker lights ● Fog lights ●...
  • Page 511 6-3. Do-it-yourself maintenance WARNING Replacing light bulbs ■ Turn off the headlights. Do not attempt to replace the bulb immediately after turning ● off the headlights. The bulbs become very hot and may cause burns. Do not touch the glass portion of the light bulb with bare hands. When it is unavoid- ●...
  • Page 512 6-3. Do-it-yourself maintenance LX570_OM_OM60N01U_(U)
  • Page 513 When trouble arises 7-1. Essential information Emergency flashers ....514 If your vehicle has to be stopped in an emergency..515 7-2. Steps to take in an emergency If your vehicle needs to be towed......... 516 If you think something is wrong...........
  • Page 514 7-1. Essential information Emergency flashers The emergency flashers are used to warn other drivers when the vehicle has to be stopped in the road due to a breakdown, etc. Press the switch. All the turn signal lights will flash. To turn them off, press the switch once again.
  • Page 515 7-1. Essential information If your vehicle has to be stopped in an emergency Only in an emergency, such as if it becomes impossible to stop the vehicle in the normal way, stop the vehicle using the following procedure: Steadily step on the brake pedal with both feet and firmly depress it. Do not pump the brake pedal repeatedly as this will increase the effort required to slow the vehicle.
  • Page 516 If your vehicle needs to be towed If towing is necessary, we recommend having your vehicle towed by your Lexus dealer or commercial towing service, using a wheel-lift type truck or flatbed truck. Use a safety chain system for all towing, and abide by all state/provincial and local laws.
  • Page 517 7-2. Steps to take in an emergency Towing with a sling-type truck Do not tow with a sling-type truck to prevent body damage. Towing with a wheel-lift type truck From the front From the rear   Use a towing dolly under the rear Use a towing dolly under the front wheels.
  • Page 518 7-2. Steps to take in an emergency Using a flatbed truck If your vehicle is transported by a flat- bed truck, it should be tied down at the locations shown in the illustration. If you use chains or cables to tie down your vehicle, the angles shaded in black must be 45.
  • Page 519 7-2. Steps to take in an emergency Emergency towing procedure Securely attach cables or chains to the towing hooks. Take care not to damage the vehicle body. Enter the vehicle being towed and start the engine. If the engine does not start, turn the engine switch to the IGNITION ON mode.
  • Page 520 7-2. Steps to take in an emergency WARNING Observe the following precautions. Failure to do so may result in death or serious injury. When towing the vehicle ■ Be sure to transport the vehicle with all four wheels raised off the ground. If the vehicle is towed with the tires contacting the ground, the drivetrain or related parts may be damaged, the vehicle may fly off the truck.
  • Page 521 7-2. Steps to take in an emergency NOTICE To prevent damage to the vehicle when towing using a wheel-lift type truck ■ Do not tow the vehicle from the rear when the engine switch is off. The steering lock ● mechanism is not strong enough to hold the front wheels straight.
  • Page 522 7-2. Steps to take in an emergency If you think something is wrong If you notice any of the following symptoms, your vehicle probably needs adjustment or repair. Contact your Lexus dealer as soon as possible. Visible symptoms Fluid leaks under the vehicle ●...
  • Page 523 7-2. Steps to take in an emergency Fuel pump shut off system To minimize the risk of fuel leakage when the engine stalls or when an airbag inflates upon collision, the fuel pump shut off system stops the supply of fuel to the engine.
  • Page 524 (U.S.A.) • The brake system is malfunctioning.  Immediately stop the vehicle in a safe place and contact your Lexus dealer. Continuing to drive the vehicle may be dangerous. (Canada) Charging system warning light Indicates a malfunction in the vehicle’ s charging system ...
  • Page 525 The light will flash when any of the above systems other than the Multi-terrain Select are operating.  Have the vehicle inspected by your Lexus dealer immediately. Automatic headlight leveling system warning light Indicates a malfunction in the automatic headlight leveling system ...
  • Page 526 Low speed four-wheel drive indicator light Indicates a malfunction in the four-wheel drive system if the light continues flashing. (P. 305)  Have the vehicle inspected by your Lexus dealer immediately. (Flashes) Center differential lock indicator light Indicates a malfunction in the four-wheel drive system if the light continues flashing.
  • Page 527 • The electronically controlled brake system • The parking brake system  Have the vehicle inspected by your Lexus dealer immediately. : Brake system warning buzzer: The buzzer sounds to indicate that the brake fluid level is low (with the vehicle reached a speed of 3 mph [5 km/h]).
  • Page 528 If it is, tighten it securely. The light will go off after several driving trips. If the light does not go off even after several trips, contact your Lexus dealer as soon as possible. If the low speed four-wheel drive indicator light or the center differential lock indicator ■...
  • Page 529 (P. 487) If the warning light does not turn off even after several minutes have elapsed, have the vehicle inspected by your Lexus dealer immediately. If the tire pressure warning light flashes for 1 minute then stay on ...
  • Page 530 If both the ABS and the brake system warning lights remain on ■ Stop your vehicle in a safe place immediately and contact your Lexus dealer. The vehi- cle will become extremely unstable during braking, and the ABS system may fail, which could cause an accident resulting in death or serious injury.
  • Page 531 7-2. Steps to take in an emergency WARNING Maintenance of the tires ■ Each tire, including the spare (if provided), should be checked monthly when cold and inflated to the inflation pressure recommended by the vehicle manufacturer on the vehicle placard or tire inflation pressure label (tire and load information label). (If your vehicle has tires of a different size than the size indicated on the vehicle placard or tire inflation pressure label [tire and load information label], you should determine the proper tire inflation pressure for those tires.)
  • Page 532 Multi-information display Handling Method Follow the instructions of the message on the multi-information display. If any of the warning messages are shown again after the following actions have been performed, contact your Lexus dealer. LX570_OM_OM60N01U_(U)
  • Page 533 Messages and warnings The warning lights and warning buzzers operate as follows depending on the content of the message. If a message indicates the need for inspection by a dealer, have the vehicle inspected by your Lexus dealer immediately. System Warning...
  • Page 534 When “Headlight System Malfunction Visit Your Dealer” is displayed on the multi- ■ information display The following systems may be malfunctioning. Have the vehicle inspected by your Lexus dealer. The LED headlight system ● The automatic headlight leveling system ●...
  • Page 535 Indicates that the engine oil should be changed. (The indicator will not work properly unless the message has been reset.) Check and change the engine oil, and oil filter by your Lexus dealer. After changing the engine oil, the message should be reset. (P. 475) If “Visit Your Dealer”...
  • Page 536 7-2. Steps to take in an emergency If you have a flat tire Your vehicle is equipped with a spare tire. The flat tire can be replaced with the spare tire. For details about tires: P. 486 WARNING If you have a flat tire ■...
  • Page 537 7-2. Steps to take in an emergency WARNING Using the tire jack ■ Improper use of the tire jack may lead to death or serious injuries due to the vehicle suddenly falling off the jack. Do not use the tire jack for any purpose other than replacing tires or installing and ●...
  • Page 538 7-2. Steps to take in an emergency Taking out the jack Remove the cover. Unhook the rubber band and take out the jack. Loosen Tighten Loosen and remove the jack. Taking out the tool box Remove the cover. Take out the tool box. LX570_OM_OM60N01U_(U)
  • Page 539 7-2. Steps to take in an emergency Taking out the spare tire Assembling the jack handle. Remove the jack handle and the jack extension bar from the tool box and assemble by following these steps. Loosen the screw using a screw- driver.
  • Page 540 7-2. Steps to take in an emergency Lower the spare tire completely to the ground. Pull out the spare tire and remove the holding bracket and spare wheel cover. Replacing a flat tire Chock the tires. Flat tire Wheel chock positions Left-hand side Behind the rear right-hand side tire Front...
  • Page 541 7-2. Steps to take in an emergency 21-inch tires: Pry off the wheel orna- ment, using the beveled end of the wheel ornament remover as shown. Slightly loosen the wheel nuts (one turn). Assembling the jack handle. Remove the jack handle, jack extension bar and jack handle bar from the tool box and assemble by following these steps.
  • Page 542 7-2. Steps to take in an emergency Assemble the jack handle exten- sion bar and the jack handle and tighten the screw. Check that the screw is firmly tight- ened. Position the jack at the jack points as shown. Front Under the chassis frame side rail Rear Under the rear axle housing...
  • Page 543 • If there are any cracks or deformations in the bolt screws, nut threads or bolt holes of the wheel, have the vehicle inspected by your Lexus dealer. • Do not attach a heavily damaged wheel ornament, as it may fly off the wheel while the vehicle is moving.
  • Page 544 7-2. Steps to take in an emergency Installing the spare tire Remove any dirt or foreign matter from the wheel contact surface. If foreign matter is on the wheel contact surface, the wheel nuts may loosen while the vehicle is in motion, and the tire may come off the vehicle.
  • Page 545 7-2. Steps to take in an emergency Reinstall the wheel ornament. 20-inch tires 21-inch tires   Remove the center wheel ornament Make sure to push the center part of from the flat tire by pushing from the the wheel ornament. reverse side, and reinstall it.
  • Page 546 When a tire is repaired with liquid sealants, the tire pressure warning valve and trans- mitter may not operate properly. If a liquid sealant is used, contact your Lexus dealer or other qualified service shop as soon as possible. Make sure to replace the tire pressure warning valve and transmitter when replacing the tire.
  • Page 547 7-2. Steps to take in an emergency If the engine will not start If the engine will not start even though correct starting procedures are being followed (P. 205), consider each of the following points: The engine will not start even when the starter motor operates nor- mally.
  • Page 548 ● There may be a malfunction in the steering lock system. ● Contact your Lexus dealer if the problem cannot be repaired, or if repair procedures are unknown. Emergency start function When the engine does not start, the following steps can be used as an interim measure to start the engine if the engine switch is functioning normally.
  • Page 549 If the shift lever cannot be shifted with your foot on the brake pedal, there may be a problem with the shift lock system (a system to prevent accidental opera- tion of the shift lever). Have the vehicle inspected by your Lexus dealer, imme- diately.
  • Page 550 Unlocks the doors Turning the key rearward unlocks the driver’ s door. Turning the key once again unlocks the other doors. Opens the windows and moon roof (turn and hold) : These settings must be customized at your Lexus dealer. LX570_OM_OM60N01U_(U)
  • Page 551 Press the engine switch. In the event that the engine still cannot be started, contact your Lexus dealer. Stopping the engine ■ Shift the shift lever to P and press the engine switch as you normally do when stopping the engine.
  • Page 552 7-2. Steps to take in an emergency WARNING When using the mechanical key and operating the power windows or moon roof ■ Operate the power window or moon roof after checking to make sure that there is no possibility of any passenger having any of their body parts caught in the window or moon roof.
  • Page 553 The following procedures may be used to start the engine if the vehicle’s bat- tery is discharged. You can also call your Lexus dealer or qualified repair shop. If you have a set of jumper (or booster) cables and a second vehicle with a 12-volt battery, you can jump start your Lexus following the steps below.
  • Page 554 Once the vehicle’ s engine has started, remove the jumper cables in the exact reverse order in which they were connected. Once the engine starts, have the vehicle checked at your Lexus dealer, as soon as possible. Starting the engine when the battery is discharged ■...
  • Page 555 7-2. Steps to take in an emergency WARNING Avoiding battery fires or explosions ■ Observe the following precautions to prevent accidentally igniting the flammable gas that may be emitted from the battery. Make sure the jumper cable is connected to the correct terminal and that it is not ●...
  • Page 556 If you do not see steam: Carefully lift the hood. After the engine has cooled down sufficiently, inspect the hoses and radiator core (radiator) for any leaks. Radiator Cooling fans If a large amount of coolant leaks, immediately contact your Lexus dealer. LX570_OM_OM60N01U_(U)
  • Page 557 If it is difficult to check these, turn the air conditioning system on and off repeatedly. (The fans may not operate in freezing temperatures.) If the fans are not operating: Stop the engine immediately and contact your Lexus dealer. If the fans are operating: Have the vehicle inspected at the nearest Lexus dealer.
  • Page 558 7-2. Steps to take in an emergency WARNING When inspecting under the hood of your vehicle ■ Observe the following precautions. Failure to do so may result in serious injury such as burns. If steam is seen coming from under the hood, do not open the hood until the steam ●...
  • Page 559 7-2. Steps to take in an emergency If the vehicle becomes stuck Carry out the following procedures if the tires spin or the vehicle becomes stuck in mud, dirt, or snow: Stop the engine. Set the parking brake and shift the shift lever to P. Remove the mud, snow or sand from around the rear wheels.
  • Page 560 7-2. Steps to take in an emergency WARNING When attempting to free a stuck vehicle ■ If you choose to push the vehicle back and forth to free it, make sure the surrounding area is clear, to avoid striking other vehicles, objects or people. The vehicle may also lunge forward or lunge back suddenly as it becomes free.
  • Page 561: Fuel Information

    Vehicle specifications 8-1. Specifications Maintenance data (fuel, oil level, etc.)....562 Fuel information......571 Tire information......574 8-2. Customization Customizable features ... 585 8-3. Initialization Items to initialize......598 LX570_OM_OM60N01U_(U)
  • Page 562 8-1. Specifications Maintenance data (fuel, oil level, etc.) Dimensions and weights Overall length 200.0 in. (5080 mm) Overall width 78.0 in. (1980 mm) 74.4 in. (1890 mm) Overall height 76.0 in. (1930 mm) Wheelbase 112.2 in. (2850 mm) 64.8 in. (1645 mm) Front 65.0 in.
  • Page 563 ■ The vehicle identification number (VIN) is the legal identifier for your vehicle. This is the primary identification number for your Lexus. It is used in register- ing the ownership of your vehicle. This number is stamped on the top left of the instrument panel.
  • Page 564 8-1. Specifications Engine Model 5.7L V8 (3UR-FE) Type 8-cylinder V type, 4-cycle, gasoline 3.70  4.02 in. (94.0  102.0 mm) Bore and stroke Displacement 345.6 cu.in. (5663 cm Valve clearance Automatic adjustment Drive belt tension Fuel Fuel type Unleaded gasoline only Octane rating 91 (Research Octane Number 96) or higher Fuel tank capacity...
  • Page 565 8-1. Specifications Engine oil selection ■ “Toyota Genuine Motor Oil” is used in your Lexus vehicle. Use Lexus approved “Toyota Genuine Motor Oil” or equivalent to satisfy the following grade and viscosity. Oil grade: ILSAC GF-5 multigrade engine oil Recommended viscosity: SAE 0W-20...
  • Page 566 8-1. Specifications Cooling system Capacity (Reference) 17.1 qt. (16.2 L, 14.3 Imp.qt.) Use either of the following. • “Toyota Super Long Life Coolant” • Similar high-quality ethylene glycol-based Coolant type non-silicate, non-amine, non-nitrite, and non- borate coolant with long-life hybrid organic acid technology Do not use plain water alone.
  • Page 567 Toyota Genuine Differential Gear Oil LT 75W-85 Oil type and viscosity GL-5 or equivalent Your Lexus vehicle is filled with “Toyota Genuine Differential Gear Oil” at the factory. Use Lexus approved “Toyota Genuine Differential Gear Oil” or an equivalent of matching quality to satisfy the above specification.
  • Page 568 Recommended oil viscosity SAE 75W : Your Lexus vehicle is filled with “Toyota Genuine Transfer Gear oil LF” at the factory. Use Lexus approved “Toyota Genuine Transfer Gear oil LF” or an equivalent of matching quality to satisfy the above specification. Please contact your Lexus dealer for further details.
  • Page 569 8-1. Specifications Suspension Fluid type Suspension fluid AHC Tires and wheels 20-inch tires  Tire size 285/50R20 112V Normal driving Front: 33 psi (230 kPa, 2.3 kgf/cm or bar) Rear: Tire inflation pressure 33 psi (230 kPa, 2.3 kgf/cm or bar) (Recommended cold tire Spare: inflation pressure)
  • Page 570 8-1. Specifications Light bulbs Light bulbs Bulb No. Type Exterior Back-up lights  Interior Vanity lights A: Wedge base bulbs B: Double end bulbs LX570_OM_OM60N01U_(U)
  • Page 571 Recommendation of the use of gasoline containing detergent additives ■ Lexus recommends the use of gasoline that contains detergent additives to avoid the ● build-up of engine deposits. All gasoline sold in the U.S.A. contains minimum detergent additives to clean and/or ●...
  • Page 572 Some gasoline contains on octane enhancing additive called MMT (Methylcy clopenta- dienyl Manganese Tricarbonyl). Lexus does not recommend the use of gasoline that contains MMT. If fuel containing MMT is used, your emission control system may be adversely affected. The malfunction indicator lamp on the instrument cluster may come on. If this happens, contact your Lexus dealer for service.
  • Page 573 8-1. Specifications NOTICE Notice on fuel quality ■ Do not use improper fuels. If improper fuels are used the engine will be damaged. ● Do not use leaded gasoline. ● Leaded gasoline can cause damage to your vehicle’ s three-way catalytic converters causing the emission control system to malfunction.
  • Page 574: Tire Information

    8-1. Specifications Tire information Typical tire symbols Tire size (P. 576) DOT and Tire Identification Number (TIN) (P. 575) Location of treadwear indicators (P. 486) Tire ply composition and materials Plies are layers of rubber-coated parallel cords. Cords are the strands which form the plies in a tire.
  • Page 575 8-1. Specifications Typical DOT and Tire Identification Number (TIN) DOT symbol Tire Identification Number (TIN) Tire manufacturer’ s identification mark Tire size code Manufacturer’ s optional tire type code (3 or 4 letters) Manufacturing week Manufacturing year : The DOT symbol certifies that the tire conforms to applicable Federal Motor Vehicle Safety Standards.
  • Page 576 8-1. Specifications Tire size Typical tire size information ■ The illustration indicates typical tire size. Tire use (P = Passenger car, T = Temporary use) Section width (millimeters) Aspect ratio (tire height to section width) Tire construction code (R = Radial, D = Diagonal) Wheel diameter (inches) Load index (2 digits or 3 digits)
  • Page 577 8-1. Specifications Tire section names Bead Sidewall Shoulder Tread Belt Inner liner Reinforcing rubber Carcass Rim lines Bead wires Chafer LX570_OM_OM60N01U_(U)
  • Page 578 National Highway Traffic Safety Administration of the U.S. Department of Trans- portation. It provides the purchasers and/or prospective purchasers of Lexus vehicles with information on uniform tire quality grading. Your Lexus dealer will help answer any questions you may have as you read this infor- mation. DOT quality grades ■...
  • Page 579 8-1. Specifications Temperature A, B, C ■ The temperature grades are A (the highest), B, and C, representing the tire’ s resistance to the generation of heat and its ability to dissipate heat when tested under controlled conditions on a specified indoor laboratory test wheel.
  • Page 580 8-1. Specifications Glossary of tire terminology Tire related term Meaning Tire pressure when the vehicle has been parked for Cold tire inflation pressure three hours or more, or has not been driven more than 1 mile or 1.5 km under that condition Maximum inflation pres- The maximum cold inflated pressure to which a tire may sure...
  • Page 581 8-1. Specifications Tire related term Meaning Rim diameter Nominal diameter of the bead seat (Wheel diameter) Rim size designation Rim diameter and width The industry manufacturer’ s designation for a rim by Rim type designation style or code Rim width Nominal distance between rim flanges Vehicle capacity weight The rated cargo and luggage load plus 150 lb.
  • Page 582 8-1. Specifications Tire related term Meaning A pneumatic tire with an inverted flange tire and rim system in which the rim is designed with rim flanges pointed radially inward and the tire is designed to fit on the underside of the rim in a manner that encloses the rim flanges inside the air cavity of the tire A tire designed to operate at higher loads and at higher Extra load tire...
  • Page 583 8-1. Specifications Tire related term Meaning The linear distance between the exteriors of the side- Overall width walls of an inflated tire, including elevations due to label- ing, decorations, or protective bands or ribs A tire intended for use on passenger cars, multipurpose Passenger car tire passenger vehicles, and trucks, that have a gross vehicle weight rating (GVWR) of 10,000 lb.
  • Page 584 8-1. Specifications Tire related term Meaning The rim on which a tire is fitted for testing, and may be Test rim any rim listed as appropriate for use with that tire That portion of a tire that comes into contact with the Tread road Tread rib...
  • Page 585: Customizable Features

    Your vehicle includes a variety of electronic features that can be personalized to suit your preferences. The settings of these features can be changed by using the multi-information display, by using the Remote Touch screen or at your Lexus dealer. Customizing vehicle features Changing by using the Remote Touch screen ■...
  • Page 586 Settings that can be changed using the Remote Touch screen Settings that can be changed using the multi-information display Settings that can be changed by your Lexus dealer Definition of symbols: O = Available, – =Not available Smart access system with push-button start (P. 132) ■...
  • Page 587 8-2. Customization Smart access system with push-button start (P. 132) and wireless remote ■ control (P. 110) Customized Function Default setting setting Operation signal (Emer- — gency flashers) Adjust the volume of confir- mation buzzer sounds — when the vehicle is locked or unlocked 1 to 7 Open door warning func-...
  • Page 588 8-2. Customization Power back door (P. 122) ■ Customized Function Default setting setting Switch operation Push and hold One short push — — Operation signal — — Wireless remote control linked operation (one — — motion) : In this case, the power back door operation will be made only by push and hold. : The back door can be opened using the wireless remote control after unlocking the back door.
  • Page 589 8-2. Customization Moon roof (P. 168) ■ Customized Function Default setting setting Mechanical linked — — operation Linked operation of com- ponents when mechanical Slide only Tilt only — — key is used Wireless remote control — — linked operation (open) Linked operation of com- ponents when...
  • Page 590 8-2. Customization Illumination (P. 419) ■ Customized Function Default setting setting Interior lights illumination — — control Time period before the inte- 15 seconds 7.5 seconds — rior lights turn off 30 seconds Operation after the engine — — switch is turned off Operation when the doors —...
  • Page 591 8-2. Customization Customized Function Default setting setting Operation of the running board lights when a door is — — opened Sensitivity of the ambient light sensor used for dim- Standard -2 to 2 — — ming the meter lights etc. Sensitivity of the ambient light sensor used for bright- Standard...
  • Page 592 8-2. Customization Rear window wiper and washer (P. 235) ■ Customized Function Default setting setting Drip prevention function — — Rear window wiper opera- — — tion linked with washer Linked operation when the — — shift lever in R position Times of the linked opera- tion when the shift lever in R Once...
  • Page 593 8-2. Customization Front seat heaters and ventilators (P. 415) ■ Customized Function Default setting setting Adjustment of the front seat heater temperature or the ventilator fan speed during Level 1 (low) to Level 3 (standard) — automatic operation (indi- level 5 (high) vidual seat adjustment...
  • Page 594 8-2. Customization Drive mode customization (P. 286) ■ Customized Function Default setting setting Powertrain Normal — — Power Sport Chassis Normal — — Comfort Automatic air conditioning Normal — — system Turn signal lever (P. 216) ■ Customized Function Default setting setting The number of times the turn signal lights flash auto-...
  • Page 595 8-2. Customization Multi-information display (P. 91) ■ Default Customized Function setting setting French Language English – Spanish miles (MPG Imperial) Units miles (MPG US) – km (L/100 km) km (km/L) Eco Driving Indicator Light – – Drive Desired status switch settings –...
  • Page 596 8-2. Customization LDA (Lane Departure Alert) (P. 263) ■ Default Customized Function setting setting — — Alert method (Steering (Buzzer) vibration) Alert sensitivity Standard High — — Vehicle sway warning — — Vehicle sway warning sensi- Standard — — tivity High : If equipped BSM (Blind Spot Monitor)
  • Page 597 8-2. Customization HUD (Head-up Display) (P. 100) ■ Default Customized Function setting setting Driving support display — — (Navigation system Driving support display — — (Driving assist Driving support display — — (compass Driving support display — — (audio : If equipped Vehicle customization ■...
  • Page 598: Items To Initialize

    8-3. Initialization Items to initialize The following item must be initialized for normal system operation such cases as the battery being reconnected, or maintenance being performed on the vehicle: Item When to initialize Reference Message indicating mainte- After the maintenance is per- P.
  • Page 599: Reporting Safety Defects For U.s. Owners

    For owners Reporting safety defects for U.S. owners........600 Seat belt instructions for Canadian owners (in French) ..........601 SRS airbag instructions for Canadian owners (in French) ..........603 LX570_OM_OM60N01U_(U)
  • Page 600 However, NHTSA cannot become involved in individual problems between you, your dealer, or Lexus Division of Toyota Motor Sales, U.S.A., Inc.
  • Page 601 Seat belt instructions for Canadian owners (in French) The following is a French explanation of seat belt instructions extracted from the seat belt section in this manual. See the seat belt section for more detailed seat belt instructions in English. Utilisation adéquate des ceintures de sécurité...
  • Page 602 Entretien et soin Ceintures de sécurité ■ Avec un chiffon ou une éponge, nettoyez à l’aide d’un savon doux et de l’eau tiède. Vérifiez aussi les ceintures régulièrement pour vous assurer qu’elles ne présentent pas d’usure excessive, d’effilochage ou de coupures. WARNING Lorsque vous utilisez la ceinture du siège central de la troisième rangée de sièges ■...
  • Page 603 SRS airbag instructions for Canadian owners (in French) The following is a French explanation of SRS airbag instructions extracted from the SRS airbag section in this manual. See the SRS airbag section for more detailed SRS airbag instructions in English. ◆...
  • Page 604 ◆ Coussins gonflables SRS latéraux et en rideau Coussins gonflables SRS latéraux avant Peuvent aider à protéger le torse des occupants des sièges avant Coussins gonflables SRS latéraux arrière Peuvent aider à protéger le torse des occupants des sièges latéraux de la deuxième rangée de sièges Coussins gonflables SRS en rideau Peuvent aider à...
  • Page 605 Composants du système de coussins gonflables SRS Coussins gonflables de protection Module de capteur de coussin des genoux gonflable Coussins gonflables en rideau Capteurs d’impact avant Coussin gonflable du passager Limiteurs de force et dispositifs de avant tension des ceintures de sécurité (sièges avant) Capteurs d’impact latéral (portière avant)
  • Page 606 Votre véhicule est doté de COUSSINS GONFLABLES ÉVOLUÉS dont la conception s’appuie sur les normes de sécurité des véhicules à moteur américains (FMVSS208). Le module de capteur de coussin gonflable (ECU) contrôle le déploiement des coussins gonflables en fonction des informations obtenues des capteurs et d’autres éléments affichés dans le diagramme des composants du système ci-dessus.
  • Page 607 être correctement retenu à l’aide d’un dispositif de retenue pour enfants. Lexus recommande vivement de placer et d’attacher correctement tous les bébés et tous les enfants sur les sièges arrière du véhicule à...
  • Page 608 WARNING Précautions relatives aux coussins gonflables SRS ■ Ne vous asseyez pas sur le bord du siège et ● ne vous appuyez pas sur la planche de bord. Ne laissez pas un enfant se tenir face au cous- ● sin gonflable SRS du passager avant ni s’asseoir sur les genoux d’un passager avant.
  • Page 609 Si les emplacements de stockage des coussins gonflables SRS, tels que le tampon de ● volant et les garnitures des montants avant, latéraux et arrière, sont endommagés ou fissurés, faites-les remplacer par votre concessionnaire Lexus. Ne placez aucun objet, par exemple un coussin, sur le siège du passager avant. Cela ●...
  • Page 610 ■ Ne mettez pas votre véhicule au rebut et n’effectuez aucune des modifications suiva- ntes sans d’abord consulter votre concessionnaire Lexus. Les coussins gonflables SRS pourraient fonctionner de manière incorrecte ou se déployer (gonfler) accidentelle- ment, ce qui serait susceptible d’occasionner des blessures graves, voire mortelles.
  • Page 611 Index What to do if... (Troubleshooting)........612 Alphabetical index........616 For vehicles with a navigation system or a multimedia system, refer to the “NAVIGATION SYSTEM OWNER’S MANUAL” for infor- mation regarding the equipment listed below. • Navigation system • Audio/video system • Rear seat entertainment system •...
  • Page 612 What to do if... (Troubleshooting) What to do if... (Troubleshooting) If you have a problem, check the following before contacting your Lexus dealer. The doors cannot be locked, unlocked, opened or closed You lose your keys If you lose your mechanical keys, new genuine mechanical keys can be made ●...
  • Page 613 What to do if... (Troubleshooting) If you think something is wrong The engine does not start Did you press the engine switch while firmly depressing the brake pedal? ● (P. 205) Is the shift lever in P? (P. 205) ● Is the electronic key anywhere detectable inside the vehicle? (P.
  • Page 614 What to do if... (Troubleshooting) The steering wheel cannot be turned after the engine is stopped It is locked automatically to prevent theft of the vehicle. (P. 207) ● The windows do not open or close by operating the power window switches Is the window lock switch pressed? ●...
  • Page 615 What to do if... (Troubleshooting) A warning buzzer sounds when leaving the vehicle Is the electronic key left inside the vehicle or the moon roof opened? ● Check the message on the multi-information display. (P. 532) A warning light turns on or a warning message is displayed When a warning light turns on or a warning message is displayed, refer to ●...
  • Page 616 Alphabetical index Alphabetical index Airbags............38 Airbag operating conditions ..46 A/C............401, 412 Air conditioning filter......501 Airbag precautions for your Changing the rear seat child............41 settings..........406 Airbag warning light ......524 Front automatic air Correct driving posture....28 conditioning system.......
  • Page 617 Alphabetical index Anti-lock brake system (ABS)............379 Back door..........122 Function ..........379 Back door handle........124 Warning light ........524 Jam protection function....126 Approach warning Power back door ........123 Dynamic radar cruise control Wireless remote control....110 with full-speed range....278 Back-up lights Armrest ............
  • Page 618 Alphabetical index Child safety..........57 Airbag precautions........ 41 Care..........458, 461 Aluminum wheels ......458 Back door precautions..... 127 Exterior........... 458 Battery precautions.....483, 555 Interior ............461 Child-protectors........118 Radar sensor ........368 Child restraint system......58 Seat belts..........462 How your child should wear Cargo capacity........
  • Page 619 Alphabetical index Coolant............. 566 Display Capacity ..........566 Crawl Control........309 Checking..........478 Drive information........94 Preparing and checking Dynamic radar cruise control before winter ........384 with full-speed range ..... 271 Cooling system Fuel consumption information..106 Engine overheating......556 Head-up display ......... 100 Crawl Control ........309 Intuitive parking assist......290 Cruise control...
  • Page 620 Alphabetical index Drive information ........94 Emergency, in case of If a warning buzzer sounds ..524 Driver’s seat belt reminder light..526 Driver’s seat position memory... 151 If a warning light turns on ....524 Driving............174 If a warning message is Break-in tips ..........
  • Page 621 Alphabetical index Engine Engine switch (ignition switch) ..205 Accessory mode....... 206 Engine switch light Air cleaner..........471 (ignition switch light)......419 Compartment........473 Event data recorder (EDR)....10 Engine switch........205 Exhaust gas precautions .......75 Exhaust gas precautions ....75 Hood ............472 How to start the engine ....
  • Page 622 Alphabetical index Front passenger occupant Fuel consumption information..105 classification system......51 Fuel filler door........239 Front passenger’s seat belt Opener...........240 reminder light ........526 Refueling ..........239 Front seats ..........140 Fuel pump shut off system ....523 Adjustment..........140 Fuses............505 Cleaning..........
  • Page 623 Alphabetical index Hill-start assist control......379 Hood............472 Jack Hooks Vehicle-equipped jack....536 Cargo hooks........429 Jack handle ..........536 Cargo net hooks........429 Jam protection function Coat hooks ...........444 Moon roof..........165 Retaining hooks (floor mat).....26 Power back door opener Horn............158 and closer ..........126 Power windows........169 I/M test .............
  • Page 624 Shift lever..........210 Meter............88 Turn signal lever ........216 Indicators ..........82 Wiper lever........ 231, 235 Instrument panel light control ..89 Lexus climate concierge ....400 Meters ............88 Climate concierge switch.....400 Multi-information display....91 Lexus parking assist monitor Warning lights........524 Lexus Safety System+......
  • Page 625 Alphabetical index Multi-information display.......91 Outside rear view mirrors....162 Crawl Control........309 Adjusting and folding ......162 Display contents ........91 Blind Spot Monitor ......365 Drive information ........94 Driving position memory....151 Dynamic radar cruise control Linked mirror function when with full-speed range......271 reversing..........163 Fuel consumption information ..106 Mirror position memory ....
  • Page 626 Alphabetical index Personal lights..........419 Rear window wiper ......235 Switch............421 Refueling..........239 Wattage..........570 Capacity..........564 Power back door........123 Fuel types..........564 Power easy access system ....151 Opening the fuel tank cap .... 239 Power outlet ........... 434 Remote touch/12.3-inch Power steering display............
  • Page 627 Alphabetical index Seat heaters ..........417 Sensor Automatic headlight system ..222 Seat position memory......151 Seat ventilators........417 Automatic High Beam Seating capacity........186 system..........224 Seats...........140, 142 Inside rear view mirror..... 160 Adjustment........140, 142 Intuitive parking assist......289 Adjustment precautions ..141, 150 LDA (Lane Departure Alert)..
  • Page 628 Alphabetical index Snow tires ..........384 Switch Audio remote control switches “SOS” button..........451 Spare tire Automatic High Beam switch..225 Inflation pressure....... 569 Center differential lock/unlock Storage location ........ 536 switch ...........306 Spark plug ..........566 Climate concierge switch .... 400 Specifications.........
  • Page 629 Alphabetical index Rear window wiper and Tire inflation pressure......569 washer switch........235 Maintenance data......569 Rear window and outside Warning light........526 rear view mirror defoggers Tire information ........574 switch............407 Glossary..........580 Seat heater switches......417 Size ............576 Seat ventilator switches ....417 Tire identification number .....575 “SOS”...
  • Page 630 Alphabetical index Towing Dinghy towing ........204 Vanity lights ..........432 Emergency towing......516 Vanity lights.......... 432 Towing eyelet........518 Wattage ..........570 Trailer Sway Control......379 Vanity mirrors.........432 Trailer towing ........187 Vehicle data recordings......9 TRAC (Traction Control) ....379 Vehicle identification number ..563 Trailer Sway Control......
  • Page 631 Alphabetical index Warning lights ........524 Warning messages......532 ABS............524 Warning reflector holder....430 Automatic headlight leveling Washer........... 231, 235 system ..........525 Checking ..........485 Brake system......524, 527 Preparing and checking Center differential lock....526 before winter........384 Charging system........524 Switch ..........231, 235 Electric power steering....526 Washing and waxing ......
  • Page 632 GAS STATION INFORMATION Fuel filler door Auxiliary catch lever P. 240 P. 472 Tire inflation pressure Fuel filler door opener Hood lock release lever P. 569 P. 240 P. 472 Fuel tank capacity 24.5 gal. (93 L, 20.4 Imp.gal.) (Reference) Unleaded gasoline only Fuel type P.

Table of Contents

Save PDF
