Table of Contents

Advertisement

Quick Links

TABLE OF CONTENTS
Before driving
1
When driving
2
Interior features
3
Maintenance
4
and care
When trouble
5
arises
Vehicle
6
specifications
For US owners
7
Index
Adjusting and operating features such as door locks, mir-
rors, and steering column.
Driving, stopping and safe-driving information.
Air conditioning and audio systems, as well as other interior
features for a comfortable driving experience.
Cleaning and protecting your vehicle, performing do-it-your-
self maintenance, and maintenance information.
What to do if the vehicle needs to be towed, gets a flat tire,
or is involved in an accident.
Detailed vehicle information.
Reporting safety defects for US owners.
Alphabetical listing of information contained in this manual.
i

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Lx470 and is the answer not in the manual?

Questions and answers

Related Manuals for Lexus Lx470

Summary of Contents for Lexus Lx470

  • Page 1 TABLE OF CONTENTS Adjusting and operating features such as door locks, mir- Before driving rors, and steering column. When driving Driving, stopping and safe-driving information. Air conditioning and audio systems, as well as other interior Interior features features for a comfortable driving experience. Maintenance Cleaning and protecting your vehicle, performing do-it-your- and care...

  • Page 2: Table Of Contents

    TABLE OF CONTENTS Index 1-6. Anti-theft system ......47 Before driving Engine immobilizer system..47 Alarm............ 49 1-1. Key information ......2 Theft prevention labels (U.S.A.)..........51 Keys ............2 1-7. Safety information....... 52 1-2. Opening, closing and locking Correct driving posture ....52 the doors.........
  • Page 3 ..... 182 Cruise control ........ 120 Rear view monitor system ..123 3-2. Using the audio system.... 183 Lexus night view system..... 126 Audio system type (without AHC (Active Height Control navigation system)..... 183 Suspension) ........130 Using the radio.......
  • Page 4 235 Air conditioning filter....308 Garage door opener....237 Wireless remote control Compass........... 242 battery........... 309 Lexus Link System ....... 246 Checking and replacing fuses ........... 311 Maintenance and care Light bulbs........320 When trouble arises 4-1. Maintenance and care.... 260 Cleaning and protecting the vehicle exterior ......
  • Page 5 5-2. Steps to take in an Index emergency ......337 If a warning light turns on or a warning buzzer sounds....337 Alphabetical index....398 If you have a flat tire..... 346 If the engine will not start ..357 What to do if.......
  • Page 6 Pictorial index Exterior Headlights (low beam) Windshield wipers P. 115 P. 112 Moon roof P. 41 Headlights (high beam) P. 112 Outside rear view mirrors P. 32 Hood P. 275 Parking and front side marker lights P. 112 Front turn signal lights P.
  • Page 7 Tail lights P. 112 Rear window defogger P. 182  Roof luggage carrier P. 34 Rear window wiper Side door P. 5 P. 118 Tires Back door P. 9 ●Rotation P. 292 ●Replacement P. 346 License plate lights ●Inflation pressure P.
  • Page 8 Pictorial index Interior Ashtray P. 225 Front passenger airbag Seat belt P. 54 P. 24 Head restraint P. 23 Driver airbag P. 54 Floor mat P. 234 Front seat P. 12 Power window switch P. 37 SRS side airbag P. 54 Rear seat P.
  • Page 9 Inside rear view mirror P. 31  Lexus link system P. 246 Front personal lights P. 212 Rear personal switches P. 212 SRS curtain shield airbag P. 54 Front interior light P. 212 Rear air conditioning controls P. 180 Rear interior light P.
  • Page 10 Pictorial index Interior Driving position memory switches P. 21 Door lock switch P. 5,9 Window lock switch P. 38 Power window switches P. 37...
  • Page 11 Four wheel drive control lever P. 139 Shift lever P. 98 Active height control switch P. 130 Damping pattern selector switch P. 138 Shift lock override button P. 358 Driving mode selector switch P. 100 Seat heater switches P. 230...
  • Page 12 Pictorial index Instrument panel Headlight switch P. 112 Turn signal lever P. 102 For light switch P. 114 Gauges and meters P. 104 Windshield wipers and washer switch P. 115 Rear window wiper and washer switch P. 118 Glove box P.
  • Page 13 Without navigation system Clock P. 223 Trip information display Outside temperature display P. 110 P. 224 Security indicator light Emergency flashers P. 47,49 Audio system P. 183 Antenna switch Front passenger's seat belt reminder P. 193 switch P. 67,340 Center differential lock/ AIRBAG ON and OFF unlock switch indicator...
  • Page 14 Pictorial index Instrument panel With navigation system Navigation system Clock Outside temperature P. 223 display P. 224 Security indicator light P. 47,49 Emergency flashers Front passenger's seat belt reminder Antenna switch switch P. 67,340 P. 193 AIRBAG ON and OFF Center differential lock/ indicator unlock switch...
  • Page 15 Power quarter window switches P. 40 Roll sensing of curtain shield airbags off switch P. 65  Lexus night view system on-off knob P. 126 Power rear view mirror control switches P. 32 Tire pressure warning reset switch P. 294 ...
  • Page 16 SRS airbag system and seat belt pretensioner sys- tem, be sure to check with your Lexus dealer for precautionary measures or special instructions regarding installation.
  • Page 17 Scrapping of your Lexus The SRS airbag and seat belt pretensioner devices in your Lexus contain explosive chemicals. If the vehicle is scrapped with the airbags and seat belt pretensioners left as they are, this may cause an accident such as fire. Be sure to have the systems of the SRS airbag and seat belt pretensioner removed and disposed of by a qualified service shop or by your Lexus dealer before you scrap your vehicle.
  • Page 18 This is a warning against anything which may cause damage to the vehicle or its equipment if the warning is ignored. You are informed about what you must or must not do in order to avoid or reduce the risk of damage to your Lexus and its equipment. Safety symbol Throughout this manual, you will also see the symbol of a circle with a slash through it.

  • Page 19: Before Driving

    Before driving 1-1. Key information......2 1-4. Opening and closing the windows and moon roof ..37 Keys............2 Power windows......37 Power quarter windows .... 40 1-2. Opening, closing and locking the doors ........3 Moon roof......... 41 Wireless remote control....3 Side doors ..........

  • Page 20: Key Information

    ■ Keep the plate in a safe place such as your wallet, not in the vehicle. In the event that a key is lost, a new key can be made at your Lexus dealer using the key number plate. NOTICE To prevent key damage ■...

  • Page 21: Opening, Closing And Locking The Doors

    1-2. Opening, closing and locking the doors Wireless remote control The wireless remote control can be used to lock/unlock the vehicle and the back door from outside the vehicle. Locks all doors Unlocks all doors Opens the windows and moon roof (push and hold) Sounds alarm (push and hold) (P.
  • Page 22 1-2. Opening, closing and locking the doors Low battery ■ If the wireless remote control does not function or if it only operates very close to the vehicle, the battery may be low. (P. 309) Customization ■ Settings (e.g. 2-step unlocking function) can be changed. (P. 389) Certification for wireless remote control (for vehicles sold in the U.S.A.) ■...

  • Page 23: Side Doors

    1-2. Opening, closing and locking the doors Side doors The vehicle can be locked/unlocked using a key, wireless remote control or door lock switch. ■ Locks all doors Closes the windows and moon roof (turn and hold) Unlock all doors Turning the key unlocks the driver’...
  • Page 24 1-2. Opening, closing and locking the doors ■ Inside lock button Locks the door Unlocks the door The front doors can be opened by pulling the inside handles even if the lock buttons are in the lock position. Locking the front doors from the outside without a key The door cannot be locked if either of the front doors is open and the key is in the ignition switch.
  • Page 25 1-2. Opening, closing and locking the doors Automatic door locking and unlocking systems The following functions can be set or canceled: Function Operation Shift position linked door Shifting the shift lever out of “P” locks all doors. locking function Shift position linked door Shifting the shift lever to “P”...
  • Page 26 1-2. Opening, closing and locking the doors Function Shift lever position Switch position Shift position linked door locking function “P” Shift position linked door unlock- ing function Speed linked door locking function “N” Driver's door linked door unlocking function When the setting or canceling operation is complete, all doors are locked and then unlocked.

  • Page 27: Back Door

    1-2. Opening, closing and locking the doors Back door The back door can be locked/unlocked using a key, wireless remote con- trol or door lock switch. ■ Unlocks the door Locks the door Open the door ■ Wireless remote control P.
  • Page 28 1-2. Opening, closing and locking the doors ■ Inside lock button Unlocks the door Locks the door Open the door Back door child-protector lock The door cannot be opened from inside the vehicle when the lock is set. This lock can be set to prevent chil- dren from opening the back door.
  • Page 29 1-2. Opening, closing and locking the doors Rear step bumper The rear step bumper is for rear end protection and easier step-up loading. CAUTION Observe the following precautions. Falling to do so may result in death or serious injury. While driving ■...

  • Page 30: Adjustable Components

    1-3. Adjustable components Front seats Seat position fore/aft control switch Seatback angle control switch Seat cushion (front) angle control switch Vertical height control switch Lumbar support control switch...
  • Page 31 1-3. Adjustable components CAUTION Reclining adjustment ■ Do not recline the seat more than necessary when the vehicle is in motion, to reduce the risk of sliding under the lap belt. If the seat is too reclined during an accident, the lap belt may slide past the hips and apply restraint forces directly to the abdomen or your neck may contact the shoul- der belt, increasing the risk of death or serious injury.

  • Page 32: Rear Seats

    1-3. Adjustable components Rear seats To adjust the seatback angle, pull the seatback angle lever Second seat Seatback angle lever Third seat...
  • Page 33 1-3. Adjustable components Tumbling second seats and third seat entry For easy access to the third seat, perform in “Tum- STEP STEP bling second seats”. (P. 15) ■ Before tumbling second seats Stow the seat belt buckles and lower the head restraints to the lowest position.
  • Page 34 1-3. Adjustable components Hook the holding strap to the STEP assist grip and secure the seat by pulling its free end. When returning the second seats to their original position, put the holding strap into the pocket. Remove the seat hook covers from STEP the back of the seat cushion, and install them on the seat hooks.
  • Page 35 1-3. Adjustable components Tumbling third seats ■ Before tumbling third seats Stow the seat belts and buckles, and lower the head restraints to the lowest position. Use the seat belt hangers to pre- vent the belts from being tangled. ■ Tumbling third seats Pull the seatback angle levers and STEP...
  • Page 36 1-3. Adjustable components While turning the lever, lift and STEP slide the whole seat backward. When returning the third seats to their original position, slide them forward to their locked position while lifting down with the lever, and then completely lift them down.
  • Page 37 1-3. Adjustable components Removing third seats ■ Before removing third seats Perform in “Tumbling third seats”. (P. 17) STEP STEP ■ Removing third seats Remove the lever cover and pull STEP the lock release lever. Lift up the rear side of the seat and pull the whole seat backward.
  • Page 38 1-3. Adjustable components CAUTION Seat adjustment ■ Do not recline the seat more than necessary when the vehicle is in motion, to reduce the risk of sliding under the lap belt. If the seat is too reclined during an accident, the lap belt may slide past the hips and apply restraint forces directly to the abdomen or your neck may contact the shoul- der belt, increasing the risk of death or serious injury.

  • Page 39: Driving Position Memory System

    1-3. Adjustable components Driving position memory system Your preferred driving position (the position of the driver's seat, steering wheel and outside rear view mirrors) can be entered into the computer's memory and recalled with the touch of a button. Two different driving positions can be entered into memory. ■...
  • Page 40 1-3. Adjustable components Retained accessory power ■ Each memorized position (except for the steering wheel position) can be activated within 30 seconds after the corresponding driver’ s door is opened, even if the key is removed from ignition switch. If any position memory button is pushed while the adjustments are being made ■...

  • Page 41: Head Restraints

    1-3. Adjustable components Head restraints Vertical adjustment Push and hold the lock release button when lowering the head restraint. Lock Angle adjustment * release button Removal Pull the head restraint up while pushing the lock release button. *: Front seats only Adjusting the height of the head restraints ■...

  • Page 42: Seat Belts

    1-3. Adjustable components Seat belts Make sure that all occupants are wearing their seat belts before driving the vehicle. ■ Correct use of the seat belts Extend the shoulder belt so that it comes fully over the shoulder, but does not come into contact with the neck or slide off the shoulder.
  • Page 43 1-3. Adjustable components Third (center seat) seat belt Fastening the belt Release button Push the tab into the buckle until a clicking sound is heard. Releasing the belt Press the release button. ■ Adjusting the height of the belt (front, second and third outboard seat) Move the height adjuster up and Release button...
  • Page 44 1-3. Adjustable components Seat belt pretensioners (front seats) The pretensioner helps the seat belt to quickly restrain the occu- pant by retracting the seat belt when the vehicle is subjected to certain types of severe frontal colli- sion. The pretensioner may not activate in the event of a minor frontal impact, a side impact or a rear impact.
  • Page 45 P. 24 regarding seat belt usage. Replacing the belt after the pretensioner has been activated ■ The seat belts cannot be used if a pretensioner has activated. After an accident, have your Lexus dealer inspect the pretensioners and replace them, if necessary.
  • Page 46 ■ If your seat belts cannot be fastened securely because they are not long enough, a person- alized seat belt extender is available from your Lexus dealer free of charge. CAUTION Wearing a seat belt ■ Observe the following precautions to reduce the risk of injury in the event of sud- den braking or an accident.
  • Page 47 Do not attempt to install, remove, modify, disassemble or dispose of a seat belt. ● Have any necessary repairs carried out by your Lexus dealer. Inappropriate han- dling of the pretensioner may cause it to activate or operate improperly and may cause death or serious injury.

  • Page 48: Steering Wheel

    1-3. Adjustable components Steering wheel The steering wheel can be adjusted to a comfortable position while the key is inserted in the ignition switch. Down Toward the driver Away from the driver Auto tilt away and auto return When the ignition key is removed, the steering wheel returns to its stowed position by moving up and away to enable easier driver entry...

  • Page 49: Inside Rear View Mirror

    1-3. Adjustable components Inside rear view mirror In the “AUTO” mode, sensors are used to detect the headlights of vehicles behind and automatically reduces the reflected light. Turns “AUTO” mode on/off The indicator comes on when “AUTO” mode is turned ON. The anti-glare mirror default mode is “AUTO”.

  • Page 50: Outside Rear View Mirrors

    1-3. Adjustable components Outside rear view mirrors Mirror angle can be adjusted using the switch when the ignition key is in “ACC” or “ON” position. Select the mirror to adjust (“L”: left or “R”: right) Adjust the mirror up, down, in, or out using the switch Folding the mirrors Press the switch.
  • Page 51 1-3. Adjustable components Linked mirror function when reversing ■ The outside rear view mirrors will automatically angle downwards when the vehicle is reversing in order to give a better view of the ground. However, this function will not operate when the mirror select switch is in the neutral position (neither “L” nor “R”...

  • Page 52: Roof Luggage Carrier

    1-3. Adjustable components Roof luggage carrier (if equipped) Cross rails Roof rails Adjusting the position of cross rails Side knobs STEP Upper knob Turn the knobs counterclockwise to release the cross rails. Slide the cross rails to the appro- STEP priate position for loading luggage and turn the side knobs clockwise to tighten the cross rails securely.
  • Page 53 1-3. Adjustable components Turn the upper knobs clockwise to STEP fix the cross rails to the appropri- ate length. CAUTION Cross rail adjustment ■ Make sure the cross rails are locked securely by pushing forward and rearward them. Failure to do so may cause an unexpected accident or severe injury in the event of emergency braking or a collision.
  • Page 54 1-3. Adjustable components NOTICE Cross rail adjustment ■ Do not remove the cross rail stoppers, or the moon roof may be damage when it is tilted. When loading the luggage ■ Be careful not to scratch the surface of the moon roof.

  • Page 55: Opening And Closing The Windows And Moon Roof

    1-4. Opening and closing the windows and moon roof Power windows The power windows can be opened and closed using the following switches. Closing One-touch closing Opening One-touch opening : Pushing the switch in the opposite direction will stop window travel partway.
  • Page 56 1-4. Opening and closing the windows and moon roof Lock switch Press the switch down to lock pas- senger window switches. Use this switch to prevent children from accidentally opening or clos- ing a passenger window. The power windows can be operated when ■...
  • Page 57 1-4. Opening and closing the windows and moon roof CAUTION Closing the windows ■ Observe the following precautions. Failing to do so may result in death or serious injury. Check to make sure that all passengers do not have any part of their body in a ●...

  • Page 58: Power Quarter Windows

    1-4. Opening and closing the windows and moon roof Power quarter windows The power quarter windows can be opened and closed using the following switches. For the left quarter window Close Open For the right quarter window The power quarter windows can be operated when ■...

  • Page 59: Moon Roof

    1-4. Opening and closing the windows and moon roof Moon roof Use the overhead switches to open, close, and tilt the moon roof up and down. ■ Opening and closing Open Stops just before it is opened fully. Press the switch again to fully open.
  • Page 60 1-4. Opening and closing the windows and moon roof The moon roof can be operated when ■ The ignition key must be in the “ON” position. Linked door lock moon roof operation ■ The moon roof can be opened and closed using the key. (P. 5) ●...
  • Page 61 1-4. Opening and closing the windows and moon roof CAUTION Opening the moon roof ■ Observe the following precautions. Failing to do so may cause death or serious injury. Do not allow any passengers to put their hands or heads outside the vehicle while ●...

  • Page 62: Refueling

    1-5. Refueling Opening the fuel tank cap Perform the following steps to open the fuel tank cap. ■ Before refueling the vehicle Stop the engine and ensure that all the doors and windows are closed. ■ Opening the fuel tank cap Pull the lever.
  • Page 63 1-5. Refueling Closing the fuel tank cap After refueling, turn the fuel tank cap clockwise until you hear a click. The cap will revolve slightly in opposite direction once released. Fuel types ■ Use premium unleaded gasoline. (91 Octane Rating [Research Octane Number 96] or higher) Fuel tank capacity ■...
  • Page 64 When replacing the fuel tank cap ■ Do not use anything but a genuine Lexus fuel tank cap designed for your vehicle. Failure to do so may cause a fire or other incident which may result in death or seri- ous injury.

  • Page 65: Anti-Theft System

    1-6. Anti-theft system Engine immobilizer system The vehicle's keys have built-in transponder chips that prevent the engine from starting if the key has not been previously registered in the vehicle's on-board computer. The indicator light flashes after the key has been removed from the ignition switch to indicate that the system is operating.
  • Page 66 1-6. Anti-theft system CAUTION Certifications for the engine immobilizer system ■ Changes or modifications not expressly approved by the party responsible for compliance could void the user’ s authority to operate the equipment. NOTICE For proper system operation ■ Do not modify, remove or disable the engine immobilizer system. If any unautho- rized changes or modifications are made, the proper operation of the system can- not be guaranteed.

  • Page 67: Alarm

    1-6. Anti-theft system Alarm The system sounds the alarm and flashes the vehicle lights when an attempt to steal the vehicle is detected. ■ Triggering of the alarm The alarm is triggered in the following situations. ● A locked door is unlocked or opened in any way other than using the wireless remote door lock function or key.
  • Page 68 1-6. Anti-theft system Items to check before locking the vehicle ■ To prevent unexpected triggering of the alarm and vehicle theft, make sure of the following. Nobody is in the vehicle. ● The windows and moon roof are closed before the alarm is set. ●...

  • Page 69: Theft Prevention Labels (U.s.a.)

    1-6. Anti-theft system Theft prevention labels (U.S.A.) These labels are attached to the vehicle to reduce vehicle theft by facilitating the tracing and recovery of parts from stolen vehicles. Do not remove under penalty of law.

  • Page 70: Safety Information

    1-7. Safety information Correct driving posture Drive with a good posture as follows: Sit upright and well back in the seat. Adjust the position of the seat forward or backward to ensure the pedals can be reached easily depressed to the extent required.
  • Page 71 1-7. Safety information CAUTION While driving ■ Do not adjust the position of the driver’ s seat. ● Doing so could cause the driver to lose control of the vehicle. Do not place a cushion between the driver or passenger and the seatback. ●...

  • Page 72: Srs Airbags

    1-7. Safety information SRS airbags The SRS airbags inflate when the vehicle is subjected to certain types of severe impacts that may cause significant injury to the occupants. They work together with the seat belts to help reduce the risk of death or serious injury.
  • Page 73 1-7. Safety information Airbag system components Front passenger airbag Driver's seat belt buckle switch Airbag sensor assembly Driver's seat position sensor Front passenger occupant Front airbag sensor classification indicator light Curtain shield airbag Occupant detection sensor Side airbag SRS warning light Curtain shield airbag sensor Driver airbag Side and curtain shield airbag...
  • Page 74 1-7. Safety information In certain types of severe frontal or side impacts, the SRS airbag system triggers the airbag inflators. A chemical reaction in the inflators quickly fills the airbags with non-toxic gas to help restrain the motion of the occu- pants.
  • Page 75 1-7. Safety information Operating conditions (side airbags) ■ The SRS side airbags are designed to inflate when the passenger compartment ● is subjected to a severe impact from the side. The SRS side airbag on the passenger seat will not activate if there is no passen- ●...
  • Page 76 1-7. Safety information Types of collisions that may not deploy the SRS airbag (front airbags) ■ The SRS front airbags are generally not designed to inflate if the vehicle is involved in a side or rear collision, if it rolls over, or if it is involved in a low-speed frontal colli- sion.
  • Page 77 1-7. Safety information The SRS curtain shield airbags are not generally designed to inflate if the vehicle is involved in a frontal or rear collision, if it pitches end over end, or if it is involved in a low-speed side collision. Collision from the front ●...
  • Page 78 1-7. Safety information When to contact your Lexus dealer ■ In the following cases, contact your Lexus dealer as soon as possible. Do not dis- connect the battery cables before contacting your Lexus dealer. Any of the SRS airbags have been inflated.
  • Page 79 1-7. Safety information CAUTION SRS airbag precautions ■ Observe the following precautions regarding the airbags. Failure to do so may cause death or serious injury. The driver and all passengers in the vehicle must wear their seat belts properly. ● The SRS airbags are supplemental devices to be used with the seat belts.
  • Page 80 An infant or child who is too small to use a seat belt should be properly secured using a child restraint system. Lexus strongly recommends that all infants and children be placed in the rear seats of the vehicle and properly restrained.
  • Page 81 1-7. Safety information CAUTION SRS airbag precautions ■ Do not sit on the edge of the seat or lean ● against the dashboard. Do not allow a child to sit on the knees of a ● front passenger while the vehicle is moving. Do not drive the vehicle while the driver or ●...
  • Page 82 If the areas where the SRS airbags are stored, such as the steering wheel pad and ● front pillar garnish, are damaged or cracked, have them replaced by your Lexus dealer.
  • Page 83 ■ Do not dispose of your vehicle or perform any of the following modifications with- out consulting your Lexus dealer. The SRS airbag may malfunction or deploy (inflate) accidentally, causing death or serious injury. Installation, removal, disassembly and repair of the SRS airbags ●...
  • Page 84 1-7. Safety information This switch only should be used ■ In a situation where the inflation is not desired (such as during extreme off road driv- ing). Operating conditions when the RSCA OFF indicator turns on ■ The curtain shield airbag and seat belt pretensioner will not activate in a vehicle ●...

  • Page 85: Front Passenger Occupant Classification System

    1-7. Safety information Front passenger occupant classification system Your vehicle is equipped with a front passenger occupant classification sys- tem. This system detects the conditions of the front passenger seat and activates or deactivates the devices for front passenger. SRS warning light AIRBAG OFF indicator light AIRBAG ON indicator light Front passenger’...
  • Page 86 1-7. Safety information ■ Child or child restraint system AIRBAG ON and AIRBAG OFF OFF* indicator lights Indicator/ SRS warning light warning light Front passenger’ s seat belt reminder light Flashing Front passenger airbag Deactivated Side airbag on the front passenger seat Devices Curtain shield airbag in the front passenger side...
  • Page 87 1-7. Safety information ■ There is a malfunction in the system AIRBAG ON and AIRBAG OFF indicator lights Indicator/ warning light SRS warning light Front passenger’ s seat belt reminder light Front passenger airbag Deactivated Side airbag on the front passenger seat Devices Curtain shield airbag in the front passenger side...
  • Page 88 1-7. Safety information CAUTION Front passenger occupant classification system precautions ■ Observe the following precautions regarding front passenger occupant classifica- tion system. Failure to do so may cause death or serious injury. Wear the seat belt properly. ● Make sure the front passenger’ s seat belt tab has not been left inserted into the ●...
  • Page 89 Do not kick the front passenger seat or subject it to severe impact. Otherwise, ● the SRS warning light may come on to indicate a malfunction on the detection system. In this case, contact your Lexus dealer immediately. Child restraint systems installed on the second seat should not contact the front ●...

  • Page 90: Child Restraint Systems

    1-7. Safety information Child restraint systems A child restraint system for a small child or baby must itself be properly restrained on the seat with the lap portion of the lap/shoulder belt. The laws of all 50 states of the U.S.A. and Canada now require the use of child restraint systems.
  • Page 91 1-7. Safety information Convertible seat Booster seat When the child restraint system is not in use ■ Leave the child restraint system properly secured on the seat. Do not store the restraint loosely on a passenger seat or in the luggage compartment. Selecting an appropriate child restraint system ■...
  • Page 92 In an accident, the child can be crushed against the wind- shield, or between you and the vehicle's interior. Lexus strongly urges the use of a proper child restraint system that conforms to ● the size of the child, installed on the rear seat. According to accident statistics, the child is safer when properly restrained in the rear seat than in the front seat.

  • Page 93: Installing Child Restraints

    1-7. Safety information Installing child restraints Follow the child restraint system manufacturer's instructions. Firmly secure the child restraints using the seat belt. If using the lower anchor- ages, use the top strap as well, and be sure to secure both firmly. Seat belts equipped with a child restraint locking mecha- nism (ALR/ELR belts except...
  • Page 94 1-7. Safety information Installing child restraints using a seat belt (child restraint lock function belt) Rear facing child seat Infant/convertible ■ Place the child seat on the second STEP or third outboard seat facing the rear of the vehicle. Run the seat belt through the child STEP seat and insert the plate into the buckle.
  • Page 95 1-7. Safety information While pushing the child seat down STEP into the seat, allow the shoulder belt to retract until the child seat is securely in place. After the shoulder belt has retracted to a point where there is no slack in the belt, pull the belt to check that it cannot be extended.
  • Page 96 1-7. Safety information While pushing the child seat into STEP the seat, allow the shoulder belt to retract until the child seat is securely in place. After the shoulder belt has retracted to a point where there is no slack in the belt, pull the belt to check that it cannot be extended.
  • Page 97 1-7. Safety information Installing child restraints using a seat belt (2-point type seat belt) Rear facing child seat Infant/convertible ■ Place the child seat on the third STEP center seat facing the rear of the vehicle. Run the seat belt through the child STEP seat and insert the plate into the buckle.
  • Page 98 1-7. Safety information Removing a child restraint installed with a seat belt Push the buckle release button and fully retract the seat belt. Installation with child restraint lower anchorages Fold the seatback forward and STEP then back to the 1st lock position (most upright position) until it locks into place.
  • Page 99 1-7. Safety information Type A Latch the hooks of the lower straps STEP onto the anchorages. If the child restraint has a top strap, the top strap should be latched onto the anchorage. For owners in Canada: The symbol on a child restraint sys- tem indicates the presence of a lower anchorage system.
  • Page 100 1-7. Safety information Child restraint systems with a top strap Secure the child restraint using a STEP seat belt or lower anchors, and remove the head restraint. Take off the carpet, latch the hook STEP onto the anchor bracket and tighten the top strap.
  • Page 101 1-7. Safety information Laws and regulations pertaining to anchorages ■ Anchorages conform to FMVSS225 or CMVSS210.2. Child restraint systems conforming to FMVSS213 or CMVSS213 specifications can be used. This vehicle is designed to conform to the SAE J1819. CAUTION When installing a booster seat ■...
  • Page 102 1-7. Safety information CAUTION When installing a child restraint system ■ Follow the directions given in the child restraint system installation manual and fix the child restraint system securely in place. If the child restraint system is not correctly fixed in place, the child may be seriously injured or even killed in the event of sudden braking or an accident.
  • Page 103 1-7. Safety information CAUTION Do not use a seat belt extender ■ If a seat belt extender is used when installing a child restraint system, the seat belt will not securely hold the child restraint system, which could cause death or serious injury to the child or other passengers in the event of a collision.
  • Page 104 1-7. Safety information...

  • Page 105: When Driving

    Driving the vehicle...... 88 Cruise control ......120 Starting the engine ...... 95 Rear view monitor system ..123 Automatic transmission..... 98 Lexus night view system... 126 Turn signal lever ......102 AHC (Active Height Control Parking brake....... 103 Suspension)....... 130 AVS (Adaptive Variable 2-2.

  • Page 106: Driving Procedures

    2-1. Driving procedures Driving the vehicle The following procedures should be observed to ensure safe driving. ■ Starting the engine (P. 95) ■ Driving With the brake pedal depressed, shift the shift lever to “D”. STEP (P. 98) Release the parking brake. (P.
  • Page 107 2-1. Driving procedures Breaking in your new Lexus ■ To extend the life of the vehicle, the following precautions are recommended to observe: For the first 200 miles (300 km): ● Avoid sudden stops. For the first 500 miles (800 km): ●...
  • Page 108 2-1. Driving procedures CAUTION When starting the vehicle ■ Always keep your foot on the brake pedal while stopped with the engine running. This prevents the vehicle from creeping. When driving the vehicle ■ Do not drive if you are unfamiliar with the location of the brake and accelerator ●...
  • Page 109 2-1. Driving procedures CAUTION When driving the vehicle ■ Use engine braking (downshift) to maintain a safe speed when driving down a ● steep hill. Using the brakes continuously may cause the brakes to overheat and lose effec- tiveness. (P. 99) When stopped on an inclined surface, use the brake pedal and parking brake to ●...
  • Page 110 2-1. Driving procedures CAUTION When shifting the shift lever ■ Be careful not to shift the shift lever with the accelerator pedal depressed. This may lead to unexpected rapid acceleration of the vehicle that may cause an accident and result in death or serious injury. When the vehicle is stopped ■...
  • Page 111 2-1. Driving procedures CAUTION When taking a nap in the vehicle ■ Always turn the engine off. Otherwise, you may accidentally move the shift lever or press the accelerator pedal, which could cause an accident or fire due to abnormal engine overheating. Additionally, if the vehicle is parked in a poorly ventilated area, exhaust fumes may enter the vehicle and cause gas poisoning.
  • Page 112 If you hear a squealing or scraping noise (brake pad wear limit indicators) ■ Have your Lexus dealer check and replace the brake pads as soon as possible. The rotor damage can result if the pads are not replaced when needed.

  • Page 113: Starting The Engine

    2-1. Driving procedures Starting the engine ■ Ignition switch LOCK: The steering wheel is locked and the key can be removed. ACC: Some electrical components such as the audio system can be used. All electrical components can be used. START ■...
  • Page 114 2-1. Driving procedures Steering lock release ■ When starting the engine, the ignition switch may seem stuck in the “LOCK” position. To free it, turn the ignition key while turning the steering wheel sightly in either direction. If the engine does not start ■...
  • Page 115 2-1. Driving procedures Cranking hold function ■ Once you turn the ignition key to “START” position and release it, the function con- tinues to crank the engine in “ON” position until it starts. If the engine has not started, the function stops after about 25 seconds. Wait a few seconds and restart Leak detection pump ■...

  • Page 116: Automatic Transmission

    2-1. Driving procedures Automatic transmission Select a shift position appropriate for the driving conditions. ■ Shifting the shift lever While the ignition key is in the “ON” position, depress the brake pedal and move the shift lever.
  • Page 117 2-1. Driving procedures ■ Shift position uses Shift position Function Parking the vehicle or starting the engine Reversing Neutral Normal driving Position for engine braking Position for more powerful engine braking Position for maximum engine braking : To improve fuel consumption and reduce noises, set the shift lever in the “D”...
  • Page 118 2-1. Driving procedures ■ Selecting a driving mode The following patterns can be selected to suit current driving and operating conditions. Normal mode Power mode For powerful acceleration and driving in mountainous regions. “2nd STRT” (second start) For starting on slippery road surfaces, such as on snow.
  • Page 119 2-1. Driving procedures Downshifting restrictions ■ Keep the engine rpm from going into red zone. The maximum allowable speed is as follows: Maximum speed mph (km/h) Downshifting Transfer “L” “H” 43 32 (51) 80 (129) 32 21 (35) 54 (88) 21 9 (14) 22 (37)

  • Page 120: Turn Signal Lever

    2-1. Driving procedures Turn signal lever Left turn Right turn Move and hold the lever part- way to signal a lane change The left hand signal will flash until you release the lever. Move and hold the lever part- way to signal a lane change The right hand signal will flash until you release the lever.

  • Page 121: Parking Brake

    2-1. Driving procedures Parking brake Sets the parking brake Fully set the parking brake while depressing the brake pedal. Releases the parking brake U.S.A. Canada NOTICE Before driving ■ Fully release the parking brake. Driving the vehicle with the parking brake set will lead to brake components over- heating, which may affect braking performance and increase brake wear.

  • Page 122: Instrument Cluster

    2-2. Instrument cluster Gauges and meters The units used on the speedometer may differ depending on the target region. The following gauges, meters and display illuminate when the ignition key is turned to the “ON” position. Voltmeter Displays the charge state. Speedometer Displays the vehicle speed.
  • Page 123 2-2. Instrument cluster Odometer Displays the total distance the vehicle has been driven. Trip meter Displays the distance the vehicle has been driven since the meter was last reset. Trip meters A and B can be used to record and display different dis- tances independently.
  • Page 124 When the voltmeter indicates more than 19 V or less than 9 V, the battery may be ● malfunctioning. Have your vehicle checked at your Lexus dealer. When the engine oil pressure gauge does not work properly, immediately stop ●...

  • Page 125: Indicators And Warning Lights

    2-2. Instrument cluster Indicators and warning lights The indicator and warning lights on the instrument cluster and center panel inform the driver of the status of the vehicle’s various systems. Instrument cluster The units used on the speedometer and some indicators may differ depend- ing on the target region.
  • Page 126 2-2. Instrument cluster ■ Indicators The indicators inform the driver of the operating state of the vehi- cle’ s various systems. Turn signal indicator Active height control indi- (P. 102) cator (P. 130) Vehicle stability control Headlight high beam indi- system OFF indicator cator (P.
  • Page 127 “ON” position, this could mean that these systems are not available to help protect you in an accident, which could result in death or serious injury. Have the vehicle inspected by your Lexus dealer immediately if this occurs.

  • Page 128: Trip Information Display

    2-2. Instrument cluster Trip information display The trip information display presents the driver with a variety of driving- related data. Display items can be switched by pushing the “MODE” switch. Trip information ■ Average vehicle speed Displays the average vehicle speed since the engine was started or the function was reset.
  • Page 129 2-2. Instrument cluster ■ Driving range Displays the estimated maximum distance that can be driven with the quantity of fuel remaining. This distance is computed based on your average fuel consumption. As a result, the actual distance that can be driven may differ from that displayed.

  • Page 130: Operating The Lights And Windshield Wipers

    2-3. Operating the lights and windshield wipers Headlight switch The headlights can be operated manually or automatically. The side marker, parking, tail, license plate and instrument panel lights U.S.A. turn on. The headlights and all Canada lights listed above turn The headlights and all the lights listed above turn on and off automatically.
  • Page 131 2-3. Operating the lights and windshield wipers Daytime running light system ■ To make your vehicle more visible to other drivers, the headlights turn on automati- cally (at a reduced intensity) whenever the engine is started and the parking brake is released.

  • Page 132: Fog Light Switch

    2-3. Operating the lights and windshield wipers Fog light switch The fog lights improve visibility in difficult driving conditions, such as in rain or fog. They can be turned on only when the headlights are on low beam.

  • Page 133: Windshield Wipers And Washer

    2-3. Operating the lights and windshield wipers Windshield wipers and washer With “AUTO” selected, the wipers will operate automatically when the sensor detects falling rain. The system automatically adjusts wiper timing in accordance with rain volume and vehicle speed. Sensor sensitivity (low) Sensor sensitivity (high) Rain-sensing wiper operation Low speed wiper operation...
  • Page 134 2-3. Operating the lights and windshield wipers Rain drop sensor ■ The sensor judges the amount of raindrops. If no windshield washer fluid sprays ■ Check that the washer nozzles are not blocked if there is washer fluid in the wind- shield washer fluid reservoir.
  • Page 135 2-3. Operating the lights and windshield wipers NOTICE When the windshield is dry ■ Do not use the wipers, as they may damage the windshield. When there is no washer fluid spray from the nozzle ■ Damage to the washer fluid pump may be caused if the lever is pulled toward you and held continually.

  • Page 136: Rear Window Wiper And Washer

    2-3. Operating the lights and windshield wipers Rear window wiper and washer Intermittent window wiper operation Normal window wiper oper- ation Washer operation Washer/wiper operation The rear window wiper and washer can be operated when ■ The ignition key is in the “ON” position. Dripping prevention wiper sweep ■...

  • Page 137: Headlight Cleaner Switch

    2-3. Operating the lights and windshield wipers Headlight cleaner switch (if equipped) Washer fluid can be sprayed on the headlights. Press the switch to clean the headlights. The headlight cleaner can be operated when ■ When the ignition key is in the “ON” position and the headlight switch is turned NOTICE When the washer fluid tank is empty ■...

  • Page 138: Using Other Driving Systems

    2-4. Using other driving systems Cruise control Use the cruise control to maintain a set speed without using the accelera- tor. ■ Set the vehicle speed Turn the “ON-OFF” button ON. STEP Push the button once more to deactivate the cruise control. Accelerate or decelerate to the STEP desired speed and press the...
  • Page 139 Turn the “ON-OFF” button off once, and then reactivate the system. If the cruise control speed cannot be set or if the cruise control cancels immediately after being activated, there may be a malfunction in the cruise control system. Have the vehicle inspected by your Lexus dealer.
  • Page 140 2-4. Using other driving systems CAUTION To avoid operating the cruise control by mistake ■ Keep the “ON-OFF” button off when not in use. Situations unsuitable for cruise control ■ Do not use cruise control in any of the following situations. Doing so may result in control of the vehicle being lost and could cause serious or fatal accident.

  • Page 141: Rear View Monitor System

    2-4. Using other driving systems Rear view monitor system (if equipped) The rear view monitor system assists the driver by displaying an image of the view behind the vehicle while reversing. The image is displayed in reverse on the screen. This allows the image to appear in the same manner as that of the rear view mirror.
  • Page 142 2-4. Using other driving systems Rear view monitor system camera ■ In the following cases, it may be difficult to see the images on the screen, even when the system is functioning correctly. • In the dark (e.g. at night). •...
  • Page 143 ■ If the back of the vehicle is hit, the camera's position and mounting angle may ● change. Contact your Lexus dealer. Rapid temperature changes, such as when hot water is poured on the vehicle in ● cold weather, may cause the system to function abnormally.

  • Page 144: Lexus Night View System

    2-4. Using other driving systems Lexus night view system (if equipped) The Lexus night view system assists the driver by displaying a monochrome image of the view in front of the vehicle while driving at night. Near-infrared rays are irradi-...
  • Page 145 2-4. Using other driving systems The Lexus night view system can be operated when ■ The ignition key is in the “ON” position. ● It is dark outside. ● The headlights are on. ● When all the above conditions are met, the head-up display shutter opens automat- ically and the image sent from the head-up display is shown on the windshield.
  • Page 146 If the front bumper is deformed in a collision, etc., the performance of the near- ● infrared floodlight will be affected. Have it repaired or replaced by your Lexus dealer. If you notice the inner lens of the near-infrared camera is dirty, have it inspected ●...
  • Page 147 2-4. Using other driving systems NOTICE To avoid damaging the head-up display ■ Do not put anything in front of the head-up display shutter. It may hinder the open- ● ing or closing of the shutter. Do not let drinks spill on the head-up display. ●...

  • Page 148: Ahc (Active Height Control Suspension)

    2-4. Using other driving systems AHC (Active Height Control Suspension) AHC adjusts the vehicle height in accordance with driving conditions. There are 3 selectable modes, “HI” (high), “N” (normal), and “LO” (low). ■ Height control switch “▲” (Up) switch “▼” (Down) switch “OFF”...
  • Page 149 2-4. Using other driving systems Vehicle height modes Press “▲” to step up one height mode, and “▼” to step down one height mode. (Ex. When in the low height mode, press “▲” once to switch to the normal height mode, and twice to switch to the high height mode.) ■...
  • Page 150 2-4. Using other driving systems AHC indicator lights If you change the vehicle height mode, the indicator lights change as fol- lows: • The current mode indicator light will turn off, and the selected mode indicator light will begin flashing. •...
  • Page 151 2-4. Using other driving systems Extra high mode ■ If the vehicle becomes stuck, extra high mode may be automatically selected when the vehicle height is in high mode with the four-wheel drive control lever in the “L” position. The vehicle height is raised to 2.8 in. (70 mm) higher than the normal mode height, or slightly higher.
  • Page 152 2-4. Using other driving systems If the vehicle height does not change ■ If the vehicle is loaded too heavily, or the undercarriage has come into contact with the road surface, the vehicle height cannot be raised/lowered. In this case, the indi- cator lights will change as follows: The current mode indicator light will turn off, and the target mode indicator light ●...
  • Page 153 If the indicator light continues to blink, have the vehicle checked at your Lexus dealer as soon as possible. If the height control “OFF” indicator light does not come on when the ignition ●...
  • Page 154 2-4. Using other driving systems CAUTION Using the high and extra high modes ■ These modes should only be used for rough off-road conditions. Because the vehi- cle's center of gravity is higher when in these modes, the vehicle may become unstable when turning abruptly, resulting in an accident.
  • Page 155 2-4. Using other driving systems NOTICE To avoid damage to the vehicle ■ If in the low mode, the vehicle automatically shifts to the normal mode when the ● vehicle is started. Take care when overhead height is limited. After unloading, the vehicle height may be slightly higher than normal. Take care ●...

  • Page 156: Avs (Adaptive Variable Suspension)

    2-4. Using other driving systems AVS (Adaptive Variable Suspension) AVS controls the suspension according to the road and driving conditions. Selecting an optimum driving mode allows good riding comfort and stabil- ity. For driving on a bumpy road For ordinary driving such as in the city traffic For moderate high speed driving...

  • Page 157: Four-Wheel Drive System

    2-4. Using other driving systems Four-wheel drive system Use the four-wheel drive control lever and center differential lock/unlock switch to select following transfer and center differential modes. Four-wheel drive control lever “H” (high speed position) Normal driving on all types of roads.
  • Page 158 2-4. Using other driving systems Advice for driving on slippery roads in “L” (low speed position) ■ If you shift the four-wheel drive control lever to “L” and the shift lever to “2” while ● driving in steep off-road areas, the output of the brake can be controlled effec- tively by the active traction control system, which assists the driver to control the driving power of 4 wheels.
  • Page 159 2-4. Using other driving systems CAUTION While driving ■ Never move the four-wheel drive control lever if the wheels are slipping. Doing so may cause an accident resulting in death or serious injury. NOTICE To prevent damage to the center differential ■...

  • Page 160: Driving Assist Systems

    2-4. Using other driving systems Driving assist systems To help enhance driving safety and performance, the following systems operate automatically in response to various driving situations. Be aware, however, that these systems are supplementary and should not be relied upon too heavily when operating the vehicle. ■...
  • Page 161 2-4. Using other driving systems When the TRAC system is operating If the 4 wheels spin, the active trac- tion control system indicator light flashes to indicate that the TRAC U.S.A system have been engaged. Canada To disable VSC system If the vehicle gets stuck in fresh snow or mud, VSC system may reduce power from the engine to the wheels.
  • Page 162 2-4. Using other driving systems Sounds and vibrations caused by the ABS, BA, VSC, TRAC and VGRS systems ■ A sound may be heard from the engine compartment when the engine is ● started or just after the vehicle begins to move. This sound does not indicate that a malfunction has occurred in any of these systems.
  • Page 163 In addition, make sure that the tires are inflated to the specified tire pres- sure level. The ABS and VSC will not function correctly if different tires are fitted on the vehi- cle. Contact your Lexus dealer for further information when replacing tires or wheels.

  • Page 164: Driving Information

    2-5. Driving information Off-road precautions This vehicle belongs to the utility vehicle class, which has higher ground clearance and narrower tread in relation to the height of its center of gravity to make it capable of performing in a wide variety of off-road applications.
  • Page 165 2-5. Driving information CAUTION Off-road vehicle precautions ■ Always observe the following precautions to help minimize the risk of serious per- sonal injury or damage to your vehicle: In a rollover crash, an unbelted person is significantly more likely to die than a ●...
  • Page 166 2-5. Driving information Off-road driving When driving your vehicle off-road, please observe the following precau- tions to ensure your driving enjoyment and to help prevent the closure of areas to off-road vehicles. ● Drive your vehicle only in areas where off-road vehicles are permitted to travel.
  • Page 167 2-5. Driving information CAUTION Off-road driving precautions ■ Always observe the following precautions to help minimize the risk of serious per- sonal injury or damage to your vehicle: Drive carefully when off the road. Do not take unnecessary risks by driving in ●...
  • Page 168 2-5. Driving information NOTICE When you drive through water ■ If driving through water, such as when crossing shallow streams, first check the depth of the water and the bottom of the river bed for firmness. Drive slowly and avoid deep water. Inspection after off-road driving ■...

  • Page 169: Cargo And Luggage

    2-5. Driving information Cargo and luggage Take notice of the following information about storage precautions, cargo capacity and load. ● Stow cargo and luggage in the luggage compartment whenever possible. Be sure all items are secured in place. ● Be careful to keep the vehicle level. Placing the weight as far for- ward as possible helps maintain vehicle balance.
  • Page 170 2-5. Driving information (6) If your vehicle will be towing a trailer, load from your trailer will be transferred to your vehicle. Consult this manual to determine how this reduces the available cargo and luggage load capacity of your vehicle. (P. 155) Example on your vehicle Cargo capacity Total load capacity...
  • Page 171 2-5. Driving information Seating configuration variation Cargo capacity Weight of removed third seat When removing the third seat, it is possible to load as much cargo as the weight of the removed seat. (Cargo capacity) = (Total load capacity) - (Total weight of occupants) + (Weight of the removed third seat).
  • Page 172 2-5. Driving information CAUTION Storage precautions ■ Do not stack anything in the luggage compartment higher than the seatbacks. ● Such items may be thrown about and possibly injure people in the vehicle during sudden braking or in an accident. Do not drive with objects on top of the instrument panel.

  • Page 173: Vehicle Load Limits

    2-5. Driving information Vehicle load limits Vehicle load limits include total load capacity, seating capacity, towing capacity and cargo capacity. ■ Total load capacity: 1200 lb. (545 kg) Total load capacity means the combined weight of occupants, cargo and luggage. ■...

  • Page 174: Winter Driving Tips

    2-5. Driving information Winter driving tips Carry out the necessary preparations and inspections before driving the vehicle in winter. Always drive the vehicle in a manner appropriate to the prevailing weather conditions. ■ Pre-winter preparations ● Use fluids that are appropriate to the prevailing outside tempera- tures.
  • Page 175 2-5. Driving information ■ Before driving the vehicle Perform the following according to the driving conditions. ● Do not try to forcibly open a window or move a wiper that is fro- zen. Pour warm water over the frozen area to melt the ice. Wipe away the water immediately to prevent it from freezing.
  • Page 176 2-5. Driving information Selection tire chains Use the correct tire chain size when mounting the snow chains. Chain size is regulated for each tire size. Side chain (3.5 mm [0.14 in.] in diameter) Cross chain (4 mm [0.16 in.] in diameter) Regulations on the use of snow chains ●...
  • Page 177 NOTICE Repairing or replacing snow tires ■ Request repairs of and obtain replacement snow tires from Lexus dealers or legiti- mate tire retailers. This is because the removal and attachment of snow tires affects the operation of the tire pressure warning valves and transmitters.

  • Page 178: Trailer Towing

    Towing a trailer will have an adverse effect on handling, performance, braking, durability, and fuel consumption. For your safety and the safety of others, do not overload the vehicle or trailer. Lexus warranties do not apply to damage or malfunction caused by towing a trailer for commercial purposes. ■...
  • Page 179 Total trailer weight Tongue load Towing a trailer Contact your Lexus dealer for further information about additional requirements such as a towing kits, etc. Hitch Trailer hitch assemblies have different weight capacities established by the hitch manufacturer.
  • Page 180 2-5. Driving information Selecting trailer ball Use the correct trailer ball for your application. Trailer ball load rating Matches or exceeds the gross trailer weight rating of the trailer. Ball diameter Matches the size of the trailer cou- pler. Most couplers are stamped with the required trailer ball size.
  • Page 181 2-5. Driving information Connecting trailer lights Use the wire harness stored in the rear end under body. When connecting and disconnecting a trailer ■ Connecting Set the active height control suspension to “LO” mode. STEP STEP Turn off the ignition switch or the active height control suspension. STEP STEP Connect the trailer.
  • Page 182 Break-in schedule ■ Lexus recommends that you do not use a new vehicle or a vehicle with any new power train components (engine, transmission, differential, wheel bearings, etc.) to tow a trailer for the first 500 miles (800 km) of driving.
  • Page 183 The tow hitch receiver installed on your vehicle must never be used on another ● vehicle. Hitches ■ If you wish to install a trailer hitch, contact your Lexus dealer. ● Use only a hitch that conforms to the total trailer weight requirement. ● Follow the directions supplied by the hitch manufacturer.
  • Page 184 NOTICE When installing a trailer hitch ■ Use only the position recommended by your Lexus dealer. Do not install the ● trailer hitch on the bumper; this may cause body damage. Do not use axle-mounted hitches, as they can cause damage to the axle housing, ●...
  • Page 185 2-5. Driving information ● Reversing with a trailer attached is difficult and requires practice Grip the bottom of the steering wheel and move your hand to the left to move the trailer to the left. Move your hand to the right to move the trailer to right.
  • Page 186 2-5. Driving information ● Due to the added load of the trailer, your vehicle’ s engine may overheat on hot days (at temperatures over 85 F[30 C] when driving up a long   or steep grade. If the engine coolant temperature gauge indicates overheating, immediately turn off the air conditioning (if in use), pull your vehicle off the road and stop in a safe spot.
  • Page 187 2-5. Driving information CAUTION To avoid an accident ■ Do not exceed 45 mph (72 km/h) or the posted towing speed limit, whichever is ● lower. A instability (swaying) of the towing vehicle-trailer combination increases as speed increases, exceeding 45 mph (72 km/h) may cause loss of control. Slow down and downshift before descending steep or long downhill grades.

  • Page 188: Dinghy Towing

    2-5. Driving information Dinghy towing Your vehicle is not designed to be dinghy towed (with 4 wheels on the ground) behind a motor home. NOTICE To avoid serious damage to your vehicle ■ Do not tow your vehicle with four wheels on the ground.

  • Page 189: Interior Features

    Seat heaters ........ 230 system ......... 204 Coat hooks........232 Using the steering Armrest......... 233 switches........206 Floor mats ........234 Rear seat audio system ..209 Luggage compartment features........235 Garage door opener....237 Compass ........242 Lexus Link System ....246...

  • Page 190: Using The Air Conditioning System And Defogger

    3-1. Using the air conditioning system and defogger Automatic air conditioning system (without navigation system) Airflow and outlets are automatically selected according to the tempera- ture setting. Owners of models equipped with a navigation system should refer to the “Navigation System Owner’ s Manual”. Fan speed control Temperature display Fan speed display...
  • Page 191 3-1. Using the air conditioning system and defogger Using the automatic mode Press STEP The air conditioning system will begin to operate. Air outlets and fan speed are automatically selected according to the temperature setting. Press to switch to “AUTO” mode. STEP Automatically switches between outside air and recirculated air modes.
  • Page 192 3-1. Using the air conditioning system and defogger ■ Changing the air outlets Press The air outlets switch each time the button is pressed. Air flows to the upper body. Air flows to the upper body and feet. Air flows to the feet. Air flows to the feet and the windshield defogger operates.
  • Page 193 3-1. Using the air conditioning system and defogger ■ Switching between outside air and recirculated air modes Press The mode switches between (recycles air inside the vehicle), (automatic mode) and (introduces air from outside the vehicle) modes each time the button is pressed. When the system is switched to automatic mode, the air conditioning mode system operates automatically.
  • Page 194 3-1. Using the air conditioning system and defogger Turn to adjust the desired STEP sensitivity. From -3 (low) to 3 (high) can be set. Adjusting the position of and opening and closing the air outlets Center outlets Direct air flow to the left or right, up or down Turn the knob to open or close the vent...
  • Page 195 3-1. Using the air conditioning system and defogger Lower outlets Direct airflow to the up or down. When defogging the windshield, it is recommended that you close the lower vent.
  • Page 196 There may be a problem in the air conditioning system if the indicator light continues to flash. Turn the air conditioning system off and have it inspected by your Lexus dealer. Automatic mode for air intake control ■...
  • Page 197 3-1. Using the air conditioning system and defogger CAUTION To prevent the windshield from fogging up ■ Do not use during cool air operation in extremely humid weather. The dif- ference between the temperature of the outside air and that of the windshield can cause the outer surface of the windshield to fog up, blocking your vision.

  • Page 198: Rear Air Conditioning Controls

    3-1. Using the air conditioning system and defogger Rear air conditioning controls Automatic mode Air flow control Fan speed control Temperature control Rear air conditioning ON/ OFF switch Using the automatic mode Press STEP to adjust the desired temperature. STEP Adjusting the settings ■...
  • Page 199 3-1. Using the air conditioning system and defogger ■ Changing the air outlets Touch any switch of Air flows to the upper body. Air flows to the upper body and feet. Air flows to the feet. warm air cool air...

  • Page 200: Rear Window And Outside Rear View Mirror Defoggers

    3-1. Using the air conditioning system and defogger Rear window and outside rear view mirror defoggers These features are used to defog the rear window, and to remove rain- drops, dew and frost from the outside rear view mirrors. ■ Rear window defogger switch ON/OFF ■...

  • Page 201: Using The Audio System

    3-2. Using the audio system Audio system type (without navigation system) Owners of models equipped with a navigation system should refer to the “Navigation System Owner's Manual”. CD player with changer, cassette player and AM/FM radio. Title Page Using the radio P.
  • Page 202 3-2. Using the audio system NOTICE To prevent battery discharge ■ Do not leave the audio system on longer than necessary with the engine off. To avoid damaging the audio system ■ Take care not to spill drinks or other fluids over the audio system.

  • Page 203: Using The Radio

    3-2. Using the audio system Using the radio Press to choose either an AM or FM band. Scan for receivable stations Displaying radio Present stations text messages Adjusting the frequency (AM, FM mode) or channel (SAT mode) Power Volume · SAT/FM Seeking any traffic mode buttons...
  • Page 204 3-2. Using the audio system ® Setting station presets (excluding XM satellite radio) or pressing  or  Search for desired stations by turning STEP Press and hold one of the preset stations (1 - 6) until you hear a STEP beep.
  • Page 205 3-2. Using the audio system The type of program changes each time the button is pressed. ● ROCK ● EASYLIS (Easy listening) ● CLS/JAZZ (Classical music and Jazz) ● R & B (Rhythm and Blues) ● INFORM (Information) ● RELIGION ●...
  • Page 206 3-2. Using the audio system ■ Traffic announcement Press “TRAF SEEK” appears on the display, and the radio will start seeking any station broadcasting traffic program information. If no traffic program station is found, “NO TRAF INFO” appears on the dis- play.
  • Page 207 3-2. Using the audio system ® ■ Scanning XM satellite radio channels ● Scanning channels in the current category Press STEP “SCAN” appears on the display. When the desired channel is reached, press the button once STEP again. ● Scanning preset channels Press until you hear a beep.
  • Page 208 Ask your Lexus dealer for details. ® satellite radio ■ The optional Lexus genuine satellite radio tuner and antenna allows you to receive and play XM satellite radio broadcasts. (Subscription is required. Not available in Hawaii and Alaska.)* ®...
  • Page 209 XM antenna cable is attached securely. ANTENNA There is a short-circuit in the antenna or the surround- ing antenna cable. See a Lexus certified dealer. ® You have not subscribed to XM satellite radio. The radio is being updated with the latest encryption code.
  • Page 210 3-2. Using the audio system The channel you selected is no longer available. Wait for about 2 seconds until the radio returns to the previ- ous channel or “CH001. If it does not change auto- matically, select another channel. ® Contact the XM Listener Care Center at (800) 967-2346 during the following hours*.
  • Page 211 3-2. Using the audio system Power antenna Down Up-Max. 33.5 in. (850 mm) When you turn on the radio, the antenna will extend to its previous position. CAUTION Extending the antenna ■ Confirm that no one is close enough to get injured. NOTICE To prevent damage to the antenna ■...

  • Page 212: Using The Cassette Player

    3-2. Using the audio system Using the cassette player Insert a cassette tape or press with a tape inserted. Change playback direction Rewind Noise reduction Repeat play Fast forward Power Volume Track selection Playback Tape slot Tape eject...
  • Page 213 3-2. Using the audio system Selecting a track ■ Skip a number of tracks at a time. Press  on STEP Press  until the number you want to skip appears. STEP 9 tracks can be skipped at a time. ■...
  • Page 214 3-2. Using the audio system When the cassette player does not operate correctly due to the cassette record- ■ ing conditions Forwarding to the beginning of a track, repeat, blank tape skip and fast-forward may not be possible in the following situations: The interval between tracks is less than 3 seconds (beginning of track and ●...

  • Page 215: Using The Cd Player

    3-2. Using the audio system Using the CD player Insert a CD or press with a CD inserted. CD slot Searching playback Displaying text message CD eject CD load Power Volume Playback Track selection Fast forward Random playback Rewind Repeat play Select CD...
  • Page 216 3-2. Using the audio system Loading a CD ■ Loading a single CD Press STEP “WAIT” appears on the display. Insert a CD when the indicator on the slot turns from amber to STEP green. The display changes from “WAIT” to “LOAD”. ■...
  • Page 217 3-2. Using the audio system Ejecting CDs ■ Ejecting a CD To select the CD to be ejected, press () or (). STEP The number of the CD selected is shown on the display. Press and remove the CD. STEP ■...
  • Page 218 3-2. Using the audio system Selecting a CD ■ To select a CD to play Press () or () until the desired CD number appears on the display. ■ To scan loaded CDs Press and hold until you hear a beep. STEP The first 10 seconds of the first track on each CD will be played.
  • Page 219 The CD may be dirty, damaged, or inserted up-side down. WAIT: Operation is stopped due to a high temperature inside the player. Wait for a while and then press . Contact your Lexus dealer if the CD still cannot be played back. CD compatibility ■...
  • Page 220 3-2. Using the audio system NOTICE Discs and adapters that cannot be used ■ Do not use the following types of CDs, 3 in. (8 cm) CD adapters or dual discs. Doing so may damage the player and render the CD insert/eject function unusable. CDs that have a diameter that is not 4.7 in.
  • Page 221 3-2. Using the audio system NOTICE Player precautions ■ Failure to follow the precautions below may result in damage to the CDs or the player itself. Do not insert anything other than CDs into the CD slot. ● Do not apply oil to the player. ●...

  • Page 222: Optimal Use Of The Audio System

    3-2. Using the audio system Optimal use of the audio system Displays the current mode. Changes the following set- tings. • Sound quality and volume balance. The sound quality and balance setting can be changed to pro- duce the best sound. •...
  • Page 223 3-2. Using the audio system ■ Adjusting sound quality Turning adjusts the level. Sound quality Mode Turn to the Turn to the Level mode displayed left right Low-pitched -5 to 5 tones* Mid-pitched -5 to 5 High tones* High pitched -5 to 5 tones* Front/rear...

  • Page 224: Using The Steering Switches

    3-2. Using the audio system Using the steering switches Some audio features can be controlled using the switches on the steering wheel. Volume Radio: Select radio stations Cassette: Fast forward, rewind and selecting tracks CD: Select tracks and discs DVD*: Select tracks, discs and chapter Power on, select audio source...
  • Page 225 3-2. Using the audio system Adjusting the volume Press “+” on to increase the volume and “-” to decrease the vol- ume. Hold down the button to continue increasing or decreasing the volume. Selecting a radio station Press to select the radio mode. STEP Press ...
  • Page 226 3-2. Using the audio system Selecting a disc in the CD or DVD player Press to select the CD or DVD player. STEP Press and hold  or  on until you hear a beep. STEP CAUTION To reduce the risk of an accident ■...

  • Page 227: Rear Seat Audio System

    3-2. Using the audio system Rear seat audio system Rear seat audio system is designed for the rear passengers to enjoy a dif- ferent audio mode from the one used on the front audio system*. ® *: Vehicles with navigation system only ...
  • Page 228 3-2. Using the audio system Adjusting the volume Turn to the right to increase the volume and left to decrease the volume. Selecting a radio station Press to select the radio mode. STEP Press to select the preferred radio station. STEP is pressed and held until a beep is heard, the audio system automati- cally searches for a receivable frequency.
  • Page 229 3-2. Using the audio system Selecting a CD track or CD ■ Selecting a track Press to select the CD mode. STEP Press to select the desired track. STEP Press and hold to fast forward or rewind. ■ Selecting a CD Press to select the CD mode.

  • Page 230: Using The Interior Lights

    3-3. Using the interior lights Interior lights list Illuminated entry system: The various lights automatically turn on/off whether the doors are locked/unlocked and whether the doors are open/ closed. Running board lights Vanity lights Front personal lights (P. 213) Rear personal lights (P. 213) Front interior light (P.
  • Page 231 3-3. Using the interior lights Interior lights Front “ON” “OFF” “DOOR” Rear “DOOR” “OFF” “ON” The interior lights are turned on/off by the illuminated entry system. Personal lights Front “ON” “OFF”...
  • Page 232 3-3. Using the interior lights Rear “ON” “OFF”...

  • Page 233: Using The Storage Features

    3-4. Using the storage features List of storage features Card holder Overhead console Cup holders Console box Glove box...
  • Page 234 3-4. Using the storage features Glove box Open (pull lever) Unlock with the master key Lock with the master key Glove box light ■ The glove box light turns on when the tail lights are on. CAUTION While driving ■ Keep the glove box closed.
  • Page 235 3-4. Using the storage features CAUTION While driving ■ Keep the console box closed. Injuries may result in the event of an accident or sudden braking. Overhead console (if equipped) The overhead console is useful for temporarily storing sunglasses and similar small items.
  • Page 236 3-4. Using the storage features Cup holders ■ Front To open, press down and release the cup holder lid. You can adjust or remove the sepa- rator inside. Pull down the knob so that the cup holder swings down. Push down the cup holder with holding the console box lid.
  • Page 237 3-4. Using the storage features Left-side trim panel near the third seat To open, pull out the cup holder lid. Right-side trim panel near the third seat CAUTION Items unsuitable for the cup holder ■ Do not place anything other than cups or aluminum cans in the cup holders. Other items may be thrown out of the holders in the event of an accident or sudden braking and cause injury.
  • Page 238 3-4. Using the storage features Card holder...

  • Page 239: Other Interior Features

    3-5. Other interior features Sun visors Forward position: Flip down. Side position: Flip down, unhook, and swing to the side. Side extender: Place in side position, then slide back- wards. Forward position with the sun visor in the position Flip down...

  • Page 240: Vanity Mirror

    3-5. Other interior features Vanity mirror The light turns on when the cover is opened.

  • Page 241: Clock

    3-5. Other interior features Clock ■ Adjust clock Adjust hours. Adjust minutes. Round the nearest hour.* *: e.g. 1:00 to 1:291:00 1:30 to 1:592:00 The clock is displayed when ■ The ignition key is in the “ACC” or “ON” position. When the battery is disconnected ■...

  • Page 242: Outside Temperature Display

    Outside temperature display The displayed temperature ranges from -22°F (-30°C) up to 122°F (50°C). Operating conditions ■ The ignition key is in the “ON” position. When --- is displayed ■ The system may be malfunctioning. Take your vehicle to your Lexus dealer.

  • Page 243: Ashtrays

    3-5. Other interior features Ashtrays Front Press in and release the lid to open. Press down on the lock spring plate to remove. Push the lid to close. Rear Pull the ashtray lid to open. Pull the ashtray upwards to remove.
  • Page 244 3-5. Other interior features CAUTION When not in use ■ Keep the ashtray closed. Injuries may result in the event of an accident or sudden braking. NOTICE To prevent fire ■ Fully extinguish matches and cigarettes before putting them in the ashtray, then ●...

  • Page 245: Cigarette Lighter

    3-5. Other interior features Cigarette lighter Push the cigarette lighter in. The cigarette lighter will pop up when ready for use. The cigarette lighter can be used when ■ The ignition key is in the “ACC” position. CAUTION To avoid burns or fires ■...

  • Page 246: Power Outlet

    3-5. Other interior features Power outlet The power outlet can be used for 12V accessories that run on less than 10A. Instrument panel Console box (without Navigation System) Console box (with Navigation System)
  • Page 247 3-5. Other interior features Luggage compartment The power outlet can be used when ■ The ignition key is in the “ACC” or “ON” position. NOTICE To avoid damaging the power outlet ■ Close the power outlet lid when not in use. Foreign objects or liquids that enter the power outlet may cause a short circuit.

  • Page 248: Seat Heaters

    3-5. Other interior features Seat heaters For driver’ s seat For passenger’ s seat High heating temperature Low heating temperature To turn on the seat heater, push the switch to “HI” or “LO”. To turn off, push the switch lightly on the opposite side.
  • Page 249 3-5. Other interior features NOTICE To prevent seat heater damage ■ Do not put unevenly weighted objects on the seat and do not stick sharp objects (needles, nails, etc.) into the seat. To prevent battery discharge ■ Turn the switches off when the engine is not running.

  • Page 250: Coat Hooks

    3-5. Other interior features Coat hooks Press in and release the hook to use. CAUTION Items that must not be hung on the hook ■ Do not hang a coat hanger, other hard or sharp object on the hook. If the side cur- tain airbags deploy, there items may become projectiles that cause death or serious injury.

  • Page 251: Armrest

    3-5. Other interior features Armrest Pull the armrest down for use. NOTICE To prevent damage to the armrest ■ Do not place too much strain on the armrest.

  • Page 252: Floor Mats

    3-5. Other interior features Floor mats Securely place a mat that matches the size of the space on the carpet. Secure the floor mat using the hooks provided. CAUTION When inserting the floor mat ■ Make sure the floor mat is properly placed on the vehicle carpet. If the floor mat slips and interferes with the movement of the pedals during driving, it may cause an accident.

  • Page 253: Luggage Compartment Features

    3-5. Other interior features Luggage compartment features ■ Tie-down hooks Tie-down hooks are provided for securing loose items. ■ Cargo net hooks To hang the cargo net, use the cargo net hooks and rear tie- down hooks. The cargo net itself is not included as an original equipment.
  • Page 254 3-5. Other interior features ■ First-aid kit holder Hold the first-aid kit with a band. The first-aid kit itself is not included as an original equipment. NOTICE To prevent damage to the cargo net hooks ■ Avoid hanging things other than a cargo net on it.

  • Page 255: Garage Door Opener

    3-5. Other interior features Garage door opener The garage door opener can be programmed to operate garage doors, gates, entry doors, door locks, home lighting systems, and security systems, and other devices.  The garage door opener (HomeLink Universal Transceiver) is manufactured ...
  • Page 256 3-5. Other interior features Press and hold down one of the STEP  buttons on the HomeLink the button on the transmitter. When the indicator light on the  HomeLink changes from a slow to a rapid flash after 20 seconds, you can release both buttons.
  • Page 257 3-5. Other interior features ■ Programming a Rolling Code system (for U.S.A. owners) If your device is Rolling Code equipped, follow the steps under the  heading “Programming the HomeLink ” before proceeding with the steps listed below. Locate the training button on the ceiling mounted garage door STEP opener motor.
  • Page 258 HomeLink buttons. ■ Programming other devices To program other devices such as home security systems, home door locks or lighting, contact your authorized Lexus dealer for assistance. ■ Reprogramming a button  The individual HomeLink buttons cannot be erased but can be reprogrammed.
  • Page 259 3-5. Other interior features Before programming ■ Install a new battery in the transmitter. ●  The battery side of the transmitter must be pointed away from the HomeLink ● Certification for the garage door opener ■ This device complies with Part 15 of the FCC Rules and with RSS-210 of the IC Rules.

  • Page 260: Compass

    3-5. Other interior features Compass (if equipped) The compass on the inside rear view mirror indicates the direction in which the vehicle is heading. ■ Operation To turn the compass on or off, push “AUTO” for longer than 3 seconds. ■...
  • Page 261 3-5. Other interior features Calibrating the compass The direction display deviates from the true direction determined by the earth’ s magnetic field. The amount of deviation varies according to the geographic position of the vehicle. If you cross over a map boundary shown in illustration, the compass will devi- ate.
  • Page 262 3-5. Other interior features Wait a few seconds until the compass direction is displayed. STEP The calibration is complete. ■ Circling calibration If “C” appears on the display, drive the vehicle at 5 mph (8 km/h) or less in a circle until a direction is displayed.
  • Page 263 3-5. Other interior features CAUTION While driving ■ Do not adjust the display. Be sure to adjust the display only when the vehicle is stopped. When doing the circling calibration ■ Be sure to secure a wide space, and watch out for people and vehicles in the neigh- borhood.

  • Page 264: Lexus Link System

    3-5. Other interior features Lexus Link System (if equipped) The Lexus Link System is a communication service that uses Global Posi- tioning System (GPS) data and cellular service to provide you with safety, security and convenience. This system is only operational in GPS and cellu- lar coverage areas.
  • Page 265 ■ Exposure to radio frequency signals The Lexus Link System installed in your vehicle is a low power ratio trans- mitter and receiver. When the ignition switch is in the “ON” position, it receives and also sends radio frequency (RF) signals.
  • Page 266 When you press the button, a priority call is placed to the Lexus Link Call Center with your vehicle’ s location. At the Call Center, the Lexus Link Advisor can determine your vehicle’ s location, communicate with you, and, if appropriate, contact the nearest emergency service provider.
  • Page 267 ● In the case that you forget where you parked the vehicle, such as in a large parking lot, the Lexus Link Call Center can send a signal to flash the headlights and sound the horn to help you locate the vehicle.
  • Page 268 • “Clear” When you are entering digits, this command will erase the last digit entered. • “Cancel” This command takes you from the current function to the “Lexus Link ready” prompt. If the last response from the system was “Lexus Link...
  • Page 269 ■ There are 5 ways to make a call. Dialing a specific number Press the button. When the system responds with “Lexus STEP Link ready”, say “Dial”. When the system responds with “Phone number to dial please”, STEP say the entire number you wish to dial without pausing.
  • Page 270 ● How to store a nametag Press the button. When the system responds with “Lexus STEP Link ready”, say “Store”. When the system responds with “Phone number to store, please”, STEP say the entire number you wish to store with no pauses.
  • Page 271 When the system responds with “Lexus STEP Link ready”, say “Redial”. The system will respond with “Redialing [#]”. STEP Dialing a number a Lexus Link Advisor downloaded to your vehicle Press the button. When the system responds with “Lexus STEP Link ready”, say “Number recall”.
  • Page 272 Press the button to try again. ■ How to retrieve your phone number Press the button. When the system responds with “Lexus STEP Link ready”, say “My number”. The system responds with “Your number is [#]”.
  • Page 273 3-5. Other interior features ■ Verifying remaining units (minutes) To verify remaining minutes Press the button. When the system responds with “Lexus STEP Link ready”, say “Units”. When the system responds with “Verify or add”, say “Verify”. STEP The system responds with “You have [#] units remaining”.
  • Page 274 Speech recognition information ■ The Lexus Link speech recognition systems use speech technology that is designed to understand a wide range of speakers of American English. However, the technol- ogy may not work as well if a regional or ethnic accent is encountered. If the speech recognition system does not work properly, refer to the following.
  • Page 275 Lexus Link Advisor. Information on Advanced services ■ See the Lexus Link area of the Lexus website at www.lexus.com/lexuslink/ or call the Lexus Link Call Center at 1-800-25-LEXUS (1-800-255-3987)(toll-free) for more information. Certification for the Lexus Link System ■...
  • Page 276 When you remove the antenna, make sure the ignition is turned off. Use only the supplied or an approved antenna. Unauthorized antennas, modifi- ● cations, or attachments could damage the Lexus Link System and may violate FCC regulations. CAUTION FCC WARNING ■...
  • Page 277 Maintenance and care 4-1. Maintenance and care ..260 4-2. Maintenance......265 Cleaning and protecting the Maintenance vehicle exterior......260 requirements......265 Cleaning and protecting the General maintenance....267 vehicle interior......262 Emission inspection and maintenance (I/M) programs ........270 4-3.

  • Page 278: Maintenance And Care

    4-1. Maintenance and care Cleaning and protecting the vehicle exterior Perform the following to protect the vehicle and maintain it in prime condi- tion. ● Working from top to bottom, liberally apply water to the vehicle body, wheel wells and underside of the vehicle to remove any dirt and dust.
  • Page 279 4-1. Maintenance and care To prevent paint deterioration and corrosion on the body ■ Wash the vehicle immediately in the following cases: ● • After driving near the sea coast • After driving on salted roads • If you see coal tar or tree sap on the paint surface •...

  • Page 280: Cleaning And Protecting The Vehicle Interior

    4-1. Maintenance and care Cleaning and protecting the vehicle interior The following procedures will help protect your vehicle's interior and keep it in top condition: ■ Protecting the vehicle interior Remove dirt and dust using a vacuum cleaner. Wipe dirty surfaces with a cloth dampened with lukewarm water.
  • Page 281 Wipe the window in strokes running parallel to the heater wires. Caring for leather areas ■ Lexus recommends cleaning the interior of the vehicle at least twice a year to main- tain the quality of the vehicle’ s interior. Shampooing the carpets ■...
  • Page 282 4-1. Maintenance and care NOTICE Cleaning detergents ■ Do not use the following types of detergent, as they may discolor the vehicle inte- rior or cause streaks or damage to painted surfaces. Non-seat portions: Organic substances such as benzene or gasoline, alkaline or ●...

  • Page 283: Maintenance

    It is recommended that genuine Lexus parts be used for repair to ensure perfor- mance of each system. If non-Lexus parts are used in replacement or if a repair shop other than a Lexus dealer performs repairs, confirm the warranty coverage.
  • Page 284 4-2. Maintenance Allow inspection and repairs to be performed by a Lexus dealer ■ Lexus technicians are well-trained specialists and are kept up to date with the ● latest service information. They are well informed about the operations of all systems on your vehicle.

  • Page 285: General Maintenance

    Listed below are the general maintenance items that should be performed at the intervals specified in the “Warranty and Services Guide/Owner’s Manual Supplement”. It is recommended that any problem you notice should be brought to the attention of your Lexus dealer or qualified service shop for advice. Engine compartment...
  • Page 286 4-2. Maintenance Vehicle interior Items Check points • Moves smoothly (without uneven Accelerator pedal pedal effort or catching)? • Can the vehicle be hold securely Automatic transmission “Park” on an incline with the shift lever in mechanism “P”? • Moves smoothly? Brake pedal •...
  • Page 287 4-2. Maintenance Items Check points • Moves smoothly? Steering wheel • Has correct free play? • No strange noises? Vehicle exterior Items Check points Doors • Operate smoothly? Engine hood • The lock system works properly? Fluid leaks • Is there any leakage after parking? •...

  • Page 288: Emission Inspection And Maintenance (I/M) Programs

    If the malfunction indicator lamp comes on The OBD system determines that a problem exists somewhere in the emission control system. Your vehicle may not pass the I/M test and may need to be repaired. Contact your Lexus dealer to service the vehicle. ■...

  • Page 289: Do-It-Yourself Maintenance

    • FMVSS No.116 DOT 3 or SAE J1703 brake fluid Brake fluid level (P. 284) • Rag or paper towel • Funnel (used only for adding brake fluid) • Genuine Lexus fuse or equivalent Cartridge type fuses (P. 311) with same amperage rating as orig- inal...
  • Page 290 4-3. Do-it-yourself maintenance Items Parts and tools • “Toyota Super Long Life Coolant” or similar high quality ethylene gly- col based non-silicate, non-amine, non-nitrite and non-borate coolant with long-life hybrid organic acid technology. For the U.S.A.: “Toyota Super Long Life Coolant” Engine coolant level (P.
  • Page 291 4-3. Do-it-yourself maintenance Items Parts and tools • Suspension fluid AHC • Rag or paper towel Suspension fluid (P. 287) • Funnel (used only for adding sus- pension fluid AHC) • Tire pressure gauge Tire inflation pressure (P. 302) • Compressed air source •...
  • Page 292 4-3. Do-it-yourself maintenance CAUTION The engine compartment contains many mechanisms and fluids that may move sud- denly, become hot, or become electrically energized. To avoid death or serious injury. When working on the engine compartment ■ Keep hands, clothing, and tools away from the moving fan and engine drive belt. ●...

  • Page 293: Hood

    4-3. Do-it-yourself maintenance Hood Release the lock from the inside of the vehicle to open the hood. Pull the hood release lever. STEP The hood will pop up slightly. Lift the hood catch and lift the STEP hood. CAUTION Pre-driving check ■...

  • Page 294: Engine Compartment

    4-3. Do-it-yourself maintenance Engine compartment Engine oil filler cap Washer fluid tank (P. 278) (P. 291) Engine oil level dipstick Condenser (P. 283) (P. 277) Radiator (P. 283) Brake fluid reservoir Engine coolant reservoir (P. 284) (P. 282) Fuse box (P.
  • Page 295 4-3. Do-it-yourself maintenance Engine oil With the engine at operating temperature and turned off, check the oil level on the dipstick. ■ Checking the engine oil Park the vehicle on level ground. After turning off the engine, wait STEP a few minutes for the oil to drain back into the bottom of the engine.
  • Page 296 4-3. Do-it-yourself maintenance ■ Adding engine oil If the oil level is below or near the low level mark, add engine oil of the same type as already in the engine. Make sure to check the oil type and prepare the items needed before adding oil.
  • Page 297 4-3. Do-it-yourself maintenance ■ Recommended viscosity SAE 5W-30 is the best choice for good fuel economy and good starting in cold weather. *: If SAE 5W-30 is not available, SAE 10W-30 may be used. However, it should be replaced with SAE 5W-30 at the next oil Outside temperature change.
  • Page 298 Oil consumption: Max. 1.1 qt./600 miles, 0. 9 lmp.qt./600 miles (1.0 L per 1000 ● km). If the vehicle consumes more than this amount, contact your Lexus dealer. Resetting the engine oil maintenance data (U.S.A. only) ■...
  • Page 299 ● pose of used oil and filters in household trash, in sewers or onto the ground. Call your Lexus dealer, service station or auto parts store for information con- cerning recycling or disposal. Do not leave used engine oil within the reach of children.
  • Page 300 ■ Visually check the radiator, hoses, reservoir cap, radiator cap, drain cock and water pump. If you cannot find a leak, have your Lexus dealer pressure test the cap and check for leaks in the cooling system. Coolant selection ■...
  • Page 301 Check the radiator and condenser and clear any foreign objects. If either of the above parts are extremely dirty or you are not sure of their condition, have your vehicle checked by your Lexus dealer. CAUTION The radiator and condenser may be hot after driving ■...
  • Page 302 4-3. Do-it-yourself maintenance Brake fluid ■ Checking fluid level The brake fluid level should be between the “MAX” and “MIN” lines on the tank. Make sure to check the fluid type and prepare the necessary items. ■ Adding fluid Fluid type FMVSS No.116 DOT 3 or SAE J1703 brake fluid Items Clean funnel...
  • Page 303 4-3. Do-it-yourself maintenance NOTICE If the fluid level is low or high ■ It is normal for the brake fluid level to go down slightly as the brake pads wear or when the fluid level in the accumulator is high. If the reservoir needs frequent refilling, it may indicate a serious problem.
  • Page 304 4-3. Do-it-yourself maintenance Power steering fluid ■ Fluid level The fluid level should be within the appropriate range. Full (when hot) Add fluid (when hot) Full (when cold) Add fluid (when cold) Hot: Vehicle has been driven around 50 mph (80 km/h) for 20 min- utes, or slightly longer in frigid temperatures.
  • Page 305 4-3. Do-it-yourself maintenance CAUTION When checking the reservoir ■ Take care, as the reservoir may be hot. NOTICE When adding fluid ■ Avoid overfilling, or the power steering may be damaged. After replacing the reservoir cap ■ Check the steering box case, vane pump and hose connections for leaks or dam- age.
  • Page 306 Make sure the fluid level is between “MAX” and “MIN”. STEP If the fluid level is lower than “MIN”, have suspension fluid AHC filled by your Lexus dealer. Battery ■ Exterior Make sure that the battery terminals are not corroded and that there are no loose connections, cracks, or loose clamps.
  • Page 307 Checking battery condition Check the battery condition using the indicator color. Blue: Good condition White: Charging is necessary. Have the vehicle inspected by your Lexus dealer. Red: Not working properly, have the battery checked by your Lexus dealer. Before recharging ■...
  • Page 308 4-3. Do-it-yourself maintenance CAUTION Chemicals in the battery ■ A battery contains poisonous and corrosive sulfuric acid and may produce hydro- gen gas which is flammable and explosive. To reduce the risk of death or serious injury, take the following precautions while working on or near battery: Do not cause sparks by touching the battery terminals with tools.
  • Page 309 4-3. Do-it-yourself maintenance NOTICE When recharging the battery ■ Never recharge the battery while the engine is running. Also, be sure all accesso- ries are turned off. Washer fluid If any washer does not work or the low washer fluid warning light come on the washer tank may be empty.

  • Page 310: Tires

    ■ The tire pressure warning system Your Lexus is equipped with a tire pressure warning system that uses tire pressure warning valves and transmitters to detect low tire infla- tion pressure before serious problems arise. (P. 340)
  • Page 311 4-3. Do-it-yourself maintenance Installing tire pressure warning valves and transmitters When replacing tires or wheels, tire pressure warning valves and trans- mitters must also be installed. Tire pressure warning valves and transmit- ters can be installed in any of the following three ways: ●...
  • Page 312 4-3. Do-it-yourself maintenance Initializing the tire pressure warning system ■ The tire pressure warning system must be initialized in the following circumstances: ● When rotating the tires on vehicles differing with front and rear tire inflation pressures. ● When changing the tire inflation pressure by changing traveling speed or load weight, etc.
  • Page 313 “2nd” position: The code is not registered. When you replace a new set of tires, purchase tire pressure warning valves and transmitters from your Lexus dealer and have the new ID code registered by your Lexus dealer.
  • Page 314 A tire goes flat repeatedly or cannot be properly repaired due to the size or ● location of a cut or other damage If you are not sure, consult with your Lexus dealer. Replacing tires and wheels ■ If the ID code is not registered, the system will not work properly. After about 1 hour, the tire pressure warning light blinks to indicate a system malfunction.
  • Page 315 4-3. Do-it-yourself maintenance Maximum load of tire ■ Check that the maximum load of the replaced tire is greater than 1/2 of the Gross Axle Weight Ratings (GAWR) of either the front axle or the rear axle, whichever is greater. As for the maximum load of the tire, see the load limit at maximum cold tire inflation pressure mentioned on the sidewall of the tire, and as for the Gross Axle Weight ...
  • Page 316 If repeated attempts to record tire inflation pressure settings are unsuccessful, have the vehicle inspected by your Lexus dealer. When operating the tire pressure warning reset switch, the warning light does ●...
  • Page 317 4-3. Do-it-yourself maintenance Tire pressure warning system certification ■ For vehicles sold in the U.S.A. NOTE: This device complies with Part 15 of the FCC Rules. Operation is subject to the fol- lowing two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
  • Page 318 When removing or fitting the wheels, tires or the tire pressure warning valve and ● transmitter, contact your Lexus dealer as the tire pressure warning valve and transmitter may be damaged if not handled correctly. When replacing tires, make sure also to replace the tire pressure warning valve ●...
  • Page 319 4-3. Do-it-yourself maintenance NOTICE Driving on rough roads ■ Take particular care when driving on roads with loose surfaces or potholes. These conditions may cause losses in tire inflation pressure, reducing the cushion- ing ability of the tires. In addition driving on rough roads may cause damage to the tires themselves, as well as the vehicle’...

  • Page 320: Tire Inflation Pressure

    4-3. Do-it-yourself maintenance Tire inflation pressure ■ Tire inflation pressure The recommended cold tire inflation pressure and tire size is dis- played on the tire and loading information label. (P. 376)
  • Page 321 4-3. Do-it-yourself maintenance ■ Inspection and adjustment procedure Tire valve Tire pressure gauge Remove the tire valve cap. STEP Press the tip of the tire pressure gauge onto the tire valve. STEP Read the pressure using the graduations of the gauge. STEP If the tire inflation pressure is not within the recommended lev- STEP...
  • Page 322 Reduced safety ● Damage to the drive train ● If a tire needs frequent refilling, have it checked by your Lexus dealer. Instructions for checking tire inflation pressure ■ When checking tire inflation pressure, observe the following: Check only when the tires are cold.
  • Page 323 4-3. Do-it-yourself maintenance CAUTION Proper inflation is critical to save tire performance ■ Keep your tires properly inflated. Otherwise, the following conditions may occur and result in an accident causing death or serious injury. Excessive wear ● Uneven wear ● Poor handling ●...

  • Page 324: Wheels

    When replacing wheels ■ The wheels of your Lexus are equipped with tire pressure warning valves and trans- mitters that allow the tire pressure warning system to provide advanced warning in the event of a loss in tire inflation pressure. Whenever wheels are replaced, the tire pressure warning valves and transmitters must be switched over from the old wheels.
  • Page 325 Because tire repair or replacement may affect the tire pressure warning valves ● and transmitters, make sure to have tires serviced by your Lexus dealer or other qualified service shop. In addition, make sure to purchase your tire pressure warning valves and transmitters at your Lexus dealer.

  • Page 326: Air Conditioning Filter

    4-3. Do-it-yourself maintenance Air conditioning filter The air conditioning filter must be changed regularly to maintain air condi- tioning efficiency. ■ Information label Contact your Lexus dealer for further information when replacing air conditioning filter. Changing interval ■ Inspect and replace the air conditioning filter according to the maintenance sched- ule.

  • Page 327: Wireless Remote Control Battery

    4-3. Do-it-yourself maintenance Wireless remote control battery Replace the battery with a new one if it is discharged. ■ You will need the following items: ● Small Phillips-head screwdriver ● Lithium battery (CR2016) ■ Replacing the battery Remove the screw and cover. STEP Push the cover in the arrow direction.
  • Page 328 Use a CR2016 lithium battery ■ Batteries can be purchased at your Lexus dealer, jewelers or camera stores. ● Replace only with the same or equivalent type recommended by a Lexus dealer. ● Dispose of used batteries according to the local laws. ●...

  • Page 329: Checking And Replacing Fuses

    4-3. Do-it-yourself maintenance Checking and replacing fuses If any of the electrical components do not operate, a fuse may have blown. If this happens, check and replace the fuses as necessary. Turn the ignition key to the “LOCK” position. STEP Open the fuse box cover.
  • Page 330 4-3. Do-it-yourself maintenance Driver’ s side instrument panel Lift the lid off while pushing the tabs on either side. Passenger’ s side instrument panel Lift the lid off while pushing the tabs on either side. After a system failure, see “Fuse layout and amperage ratings” STEP (P.
  • Page 331 4-3. Do-it-yourself maintenance Check if the fuse has blown. STEP Type A (blade type fuse) Normal fuse Blown fuse Replace it with one of an appro- priate amperage rating. The amperage rating can be found on the fuse box lid. Type B (cartridge type fuse) Normal fuse Blown fuse...
  • Page 332 4-3. Do-it-yourself maintenance Fuse layout and amperage ratings ■ Engine compartment Fuse Ampere Circuit ABS NO.2 Anti-lock brake system ABS NO.1 Anti-lock brake system Active height control suspension (AHC) WIP-S No circuit TOWING Trailer lights MIR HTR Outside rear view mirror defogger RR HTR Rear air conditioning system HAZ-TRN...
  • Page 333 4-3. Do-it-yourself maintenance Fuse Ampere Circuit ALT-S Charging system NV-IR Lexus night view system FR FOG Fog lights TOWING BRK Trailer lights HEAD CLNER Headlight cleaner FR-IG Charging system PANEL Instrument panel light TOWING TAIL Trailer lights TAIL Parking lights, Tail lights All components in “ECU-B2”...
  • Page 334 4-3. Do-it-yourself maintenance Fuse Ampere Circuit Multiport fuel injection system/ AIR PUMP Sequential multiport fuel injection system Multiport fuel injection system/ A/F HTR Sequential multiport fuel injection system ■ Driver’s side instrument panel Fuse Ampere Circuit PWR OUTLET Power outlets Cigarette lighter Instrument panel light Multiport fuel injection system/...
  • Page 335 4-3. Do-it-yourself maintenance Fuse Ampere Circuit Active height control suspension AHC-IG (AHC) EFI or ECD No.2 Emission control system GAUGE 1 Gauges and meters Multiport fuel injection system/ ECU-IG 1 Sequential multiport fuel injection system ECU-B1 Navigation system DBL LOCK Double lock system Air conditioning system STOP...
  • Page 336 4-3. Do-it-yourself maintenance ■ Passenger’s side instrument panel Fuse Ampere Circuit Power door lock system, Power win- ECU-B2 DIFF Four-wheel drive system WASHER Windshield washer RADIO Audio system DOME Interior lights VGRS Variable gear ratio steering system P/W (FL) Power window P/W (RL) Power window WIPER...
  • Page 337 Never replace a fuse with a wire, even as a temporary fix. This can cause extensive damage or even fire. Do not modify fuses or the fuse box. ● NOTICE Before replacing fuses ■ Have the cause of electrical overload determined and repaired by your Lexus dealer.

  • Page 338: Light Bulbs

    4-3. Do-it-yourself maintenance Light bulbs You may replace the following bulbs yourself. For more information about replacing other light bulbs, contact your Lexus dealer. ■ Prepare a replacement light bulb. Check the wattage of the light bulb being replaced. (P. 377) ■...
  • Page 339 4-3. Do-it-yourself maintenance Replacing light bulbs ■ Headlight high beam Turn the bulb base counterclock- STEP wise. Unplug the connector while STEP depressing the lock release.
  • Page 340 4-3. Do-it-yourself maintenance ■ Headlight low beam Turn the cover counterclockwise. STEP Unplug the connector. STEP Release the wire clip and remove STEP the light bulb.
  • Page 341 Remove the light bulb. STEP ■ Bulbs other than the above If any of the bulbs listed below has burnt out, have your Lexus dealer replace it. ● Fog lights ● Front turn signal lights ● Front side marker lights...
  • Page 342 The tail, tail/stop and high mounted stoplights consist of a number of LEDs. If any LEDs burn out, take your vehicle to your Lexus dealer to have the light replaced. If two or more LEDs in a stoplight burn out, your vehicle may not conform to local...
  • Page 343 4-3. Do-it-yourself maintenance CAUTION Replacing light bulbs ■ Turn off the headlights. Do not attempt to replace the bulb immediately after turn- ● ing off the headlights. The bulbs become very hot and may cause burns. Do not touch the glass portion of the light bulb with bare hands. Hold the bulb by ●...
  • Page 344 4-3. Do-it-yourself maintenance...

  • Page 345: When Trouble Arises

    When trouble arises 5-1. Essential information.... 328 If your vehicle needs to be towed .......... 328 If you think something is wrong.......... 333 Fuel pump shut off system ..334 Event data recorder....335 5-2. Steps to take in an emergency......

  • Page 346: Essential Information

    If your vehicle needs to be towed If towing is necessary, we recommend having your vehicle towed by your Lexus dealer or a commercial towing service, using a lift-type truck or a flat bed truck. Use a safety chain system for all towing, and abide by all state/provincial and local laws.
  • Page 347 5-1. Essential information Emergency towing procedure ■ The ignition key must be in the “ACC” or the “ON” (engine running) posi- STEP tion. Put the four-wheel drive control lever in “H”. (The center differential is STEP unlocked.) Put the vehicle height in the “N” mode and push the height control switch STEP to turn off the AHC.
  • Page 348 5-1. Essential information Towing with a sling-type truck NOTICE To prevent body damage ■ Do not tow with a sling type truck, either from the front or rear.
  • Page 349 5-1. Essential information Towing with a wheel lift-type truck From front Use a towing dolly under the rear wheels. From rear NOTICE To prevent causing serious damage to the transmission ■ Never tow this vehicle wheels on the ground.
  • Page 350 5-1. Essential information Using a flat bed truck If your Lexus is transported by a flat bed truck, it should be tied down at the locations shown in the illustration. If you use chains or cables to tie down your vehicle, the angles shaded in black must be 45.

  • Page 351: If You Think Something Is Wrong

    5-1. Essential information If you think something is wrong If you notice any of the following symptoms, your vehicle probably needs adjustment or repair. Contact your Lexus dealer as soon as possible. ■ Visible symptoms ● Fluid leaks under the vehicle (Water dripping from the air conditioning after use is normal.)

  • Page 352: Fuel Pump Shut Off System

    5-1. Essential information Fuel pump shut off system To minimize the risk of fuel leakage when the engine stalls or an airbag inflates upon collision, the fuel pump shut off system stops supplying fuel to the engine. Follow the procedure below to restart the engine after the system is acti- vated.

  • Page 353: Event Data Recorder

    ● SRS airbag deployment data ● SRS airbag system diagnostic data Your Lexus’ Electronic Control Unit (ECU) may contain another EDR. There are a variety of driving situations which include activating the vehi- cle stability control (VSC) under which the VSC EDR will record certain information.
  • Page 354 Disclosure of the data Lexus will not disclose the data recorded in an EDR to a third party except when: ● An agreement from the vehicle's owner (or the leasing company for a leased vehicle) is obtained ●...

  • Page 355: Steps To Take In An Emergency

    Stop the vehicle immediately. Continuing to drive the vehicle may be dangerous. The following warning indicates a possible problem in the brake system. Immediately stop the vehicle in a safe place and contact your Lexus dealer. Warning light...

  • Page 356: If A Warning Light Turns On Or A

    Charging system warning light Malfunction in the vehicle’ s charging system. Have the vehicle inspected by your Lexus dealer immediately. Failing to investigate the cause of the following warnings may lead to the system operating abnormally and possibly cause an accident. Have the vehicle inspected by your Lexus dealer immediately.
  • Page 357 • The active traction control system. Variable gear ratio steering system warning light Malfunction in the variable gear ratio steering system. Lexus night view system warning light The bulb for the near-infrared floodlight is burned out. Automatic transmission fluid temperature warning light The automatic transmission fluid temperature is too high.
  • Page 358 Adjust the tire inflation pres- Low tire inflation pressure. sure. When the light blinks: Have the system checked by Malfunction in the tire pres- your Lexus dealer. sure warning system. Unengaged “Park” warning light Shift four-wheel drive control The transmission “Park”...
  • Page 359 5-2. Steps to take in an emergency Engine oil replacement reminder light Illuminates for about 3 sec- onds and then flashes for Check and the engine oil, and about 12 seconds: Indicates change if necessary. that the engine oil is scheduled to be changed.
  • Page 360 If it is, tighten it securely. The light will go off after taking several driving trips. If the light does not go off even after several trips, contact your Lexus dealer as soon as possible. Front passenger detection sensor and passenger seat belt reminder ■...
  • Page 361 If the tire pressure warning light blinks ■ If the tire pressure warning light blinks when the ignition key is turned to the “ON” position, have it checked by your Lexus dealer. Changing the engine oil (U.S.A. only) ■ Make sure to reset oil change system...
  • Page 362 Check the tires. If the tire is flat, change to the spare tire and have the flat tire repaired by the nearest Lexus dealer. • Avoid abrupt maneuvering and braking. If the vehicle tires deteriorate, you could lose control of the steering wheel or the brakes.
  • Page 363 5-2. Steps to take in an emergency NOTICE Precaution when installing a different tire ■ When a tire of a different specification or maker is installed, the tire pressure warn- ing system may not operate properly.

  • Page 364: If You Have A Flat Tire

    5-2. Steps to take in an emergency If you have a flat tire Remove the flat tire and replace it with the spare provided. ■ Before jacking up the vehicle ● Stop the vehicle on a hard, flat surface. ● Set the parking brake. ●...
  • Page 365 5-2. Steps to take in an emergency Taking out the jack and tools Tool bag Remove the lid and take out the tool bag. Jack Loosen Tighten Loosen and remove the jack. Jack handle (in the tool bag) Assemble the jack handle exten- sion as shown.
  • Page 366 5-2. Steps to take in an emergency Taking out the spare tire Remove the spare tire carrier lid STEP using a flathead screwdriver. Insert the jack handle extension STEP into the lowering screw. Place a rag under the jack handle extension to protect the bumper.
  • Page 367 5-2. Steps to take in an emergency Replacing a flat tire Chock the tires. STEP Flat tire Wheel chock position Left-hand side Behind the rear right-hand side tire Front Right-hand side Behind the rear left-hand side tire Left-hand side In front of the front right-hand side tire Rear Right-hand side In front of the front left-hand side tire...
  • Page 368 5-2. Steps to take in an emergency Slightly loosen the wheel nuts (one STEP turn). Position the jack at the jack points STEP as shown. Front - Under the chassis frame side rail at the No.2 body mount bracket Left rear - Under the rear axle housing Right rear - Under the bracket on the rear axle housing...
  • Page 369 5-2. Steps to take in an emergency Raise the vehicle until the tire is STEP slightly raised off the ground. Remove all the wheel nuts and the STEP tire. When resting the tire on the ground, place the tire so that the wheel design faces up to avoid scratching the wheel surface.
  • Page 370 5-2. Steps to take in an emergency Installing the spare tire Remove any dirt or foreign matter STEP from the wheel contact surface. If foreign matter is on the wheel contact surface, the wheel nuts may loosen while the vehicle is in motion, and the tire may come off the vehicle.
  • Page 371 5-2. Steps to take in an emergency Firmly tighten each nut two or STEP three times in the order shown in the illustration. Tightening torque: 97 ft•lbf (131 N•m, 13.4 kgf•m) Reinstall the wheel ornament. STEP Stowing the flat/spare tire, jack and tools Lay down the tire with the outer side facing up, and install the STEP holding bracket.
  • Page 372 5-2. Steps to take in an emergency CAUTION Using the tire jack ■ Improper use of the tire jack may lead to death or injuries due to the vehicle sud- denly falling off the jack. Do not use the tire jack for any purpose other than replacing tires or installing and ●...
  • Page 373 5-2. Steps to take in an emergency CAUTION Replacing a flat tire ■ Observe the following precautions to reduce the risk of injury. Lower the spare tire completely to the ground before removing it from under the ● vehicle. Do not try to remove the wheel ornament by hand. Take due care in handling the ●...
  • Page 374 When removing or fitting the wheels, tires or the tire pressure warning valve and ● transmitter, contact your Lexus dealer as the tire pressure warning valve and transmitter may be damaged if not handled correctly. Replace the grommets for the tire pressure warning valves and transmitters as ●...

  • Page 375: If The Engine Will Not Start

    One of the following may be the cause of the problem. ● One or both of the battery terminals may be disconnected. ● The battery may be discharged. (P. 360) Contact your Lexus dealer if the problem cannot be repaired, or if repair procedures are unknown.

  • Page 376: If The Shift Lever Cannot Be Shifted From P

    If the shift lever cannot be shifted with your foot on the brake, there may be a problem with the shift lock system (a system to prevent accidental opera- tion of the shift lever). Have the vehicle inspected by your Lexus dealer immediately.

  • Page 377: If You Lose Your Keys

    5-2. Steps to take in an emergency If you lose your keys New genuine Lexus keys can be made by your Lexus dealer using one of the other keys or the key number stamped on your key number plate.

  • Page 378: If The Battery Is Discharged

    You can call your Lexus dealer, Roadside Assistance or Lexus Customer Service. If you have a set of jumper (or booster) cables and a second vehicle with a 12 volt battery, you can jump start your Lexus following the steps below. STEP Connecting the jumper cables.
  • Page 379 Once the vehicle’ s engine has started, remove the jumper STEP cables in the exact reverse order in which they were con- nected. Once the engine starts, have the vehicle checked at your Lexus dealer as soon as possible. Avoiding a discharged battery ■...
  • Page 380 5-2. Steps to take in an emergency CAUTION Battery precautions ■ The battery contains poisonous and corrosive acidic electrolyte, while related parts contain lead and lead compounds. Observe the following precautions when han- dling the battery: When working with the battery, always wear safety glasses and take care not to ●...

  • Page 381: If Your Vehicle Overheats

    If the fan is operating: Wait until the engine coolant temperature gauge begins to fall and then stop the engine. If the fan is not operating: Stop the engine immediately and call your local Lexus dealer. After the engine has cooled STEP...
  • Page 382 STEP Water can be used in an emer- gency measure if coolant is unavailable. (P. 372) Have the vehicle checked at your nearest Lexus dealer as soon as pos- sible. Overheating ■ In the following situations, your vehicle may be overheating.
  • Page 383 5-2. Steps to take in an emergency NOTICE When adding engine coolant ■ Wait until the engine has cooled down before adding engine coolant. When adding coolant, do so slowly. Adding cool coolant to a hot engine too quickly can cause damage to the engine.

  • Page 384: If The Vehicle Becomes Stuck

    5-2. Steps to take in an emergency If the vehicle becomes stuck Carry out the following procedures if the tires spin or the vehicle becomes stuck in mud, dirt, or snow. Stop the engine. Set the parking brake and shift the shift lever STEP in “P”.

  • Page 385: Vehicle Specifications

    Vehicle specification 6-1. Specifications ......368 Maintenance data..... 368 Fuel information......378 Tire information......381 6-2. Customization......389 Customizable features ... 389 6-3. Initialization......393 Items to initialize......393...

  • Page 386: Specifications

    6-1. Specifications Maintenance data Dimensions and weight Overall length 192.5 in. (4890 mm) Overall width 76.4 in. (1940 mm) Overall height 72.8 in. (1850 mm) Wheelbase 112.2 in. (2850 mm) Front 63.8 in. (1620 mm) Tread Rear 63.6 in. (1615 mm) Vehicle capacity weight 1200 lb.
  • Page 387 Vehicle identification number The vehicle identification number (VIN) is the legal identifier for your vehicle. This is the primary identification number for your Lexus. It is used in registering the ownership of your vehicle. This number is stamped on the top left of the instrument panel.
  • Page 388 6-1. Specifications Engine Model 2UZ-FE Type 8-cylinder V type, 4-cycle, gasoline 3.70  3.30 in. (94.0  84.0 mm) Bore and stroke Displacement 284.6 cu.in. (4664 cm Drive belt tension Automatic adjustment Fuel Fuel type Unleaded gasoline only Octane rating 91 (Research octane number 96) or higher Fuel tank capacity 25.4 gal.
  • Page 389 7.2 qt. (6.8 L, 6.0 lmp.qt.) without filter 6.8 qt. (6.4 L, 5.6 lmp.qt.) Oil grade ILSAC multigrade engine oil Use Lexus approved “Toyota Genuine Motor Oil” or equivalent to satisfy the above grade and viscosity. Recommended oil viscosity Outside temperature :5W-30 is an oil that provides optimal levels of fuel efficiency.
  • Page 390 6-1. Specifications Cooling system Capacity 16.3 qt. (15.4 L, 13.6 lmp.qt.) Use either of the following: • “Toyota Super Long Life Coolant” • Similar high-quality ethylene glycol-based non-sili- Coolant type cate, non-amine, non-nitrite, and non-borate cool- ant with long-life hybrid organic acid technology Do not use plain water alone.
  • Page 391 6-1. Specifications Electrical system Battery 12.6  12.8V Fully charged Open voltage at 12.2  12.4V Half charged 68F (20C): 11.8  12.0V Discharged (Voltage is checked 20 minutes after the key is removed with all lights turned off.) Charging rates 5A max.
  • Page 392 6-1. Specifications Automatic transmission Fluid capacity Drain and refill 3.2 qt. (3.0 L, 2.6 lmp.qt.) Fluid type Toyota Genuine ATF WS NOTICE Using transmission fluid other than “Toyota Genuine ATF WS” may cause deteriora- tion in shift quality, locking up of your transmission accompanied by vibration, and ulti- mately damage the transmission of your vehicle.
  • Page 393 6-1. Specifications Chassis lubrication Lithium base wheel bearing grease, NLGI Wheel bearings No.2 Molybdenum-disulfide lithium base chassis Steering knuckles grease, NLGI No.2 Propeller shafts Spider Lithium base chassis grease, NLGI No.2 Slide yoke Molybdenum-disulfide lithium base chassis grease, NLGI No.2 or lithium base chassis grease, NLGI No.2 Steering Free play...
  • Page 394 6-1. Specifications Tires and wheels Tire size P275/60R18 111H Normal driving Front tires: 29 psi (200 kPa, 2.0 kgf/cm or bar) Rear tires: 32 psi (220 kPa, 2.2 kgf/cm or bar) Spare tire: Tire inflation pressure 32 psi (220 kPa, 2.2 kgf/cm or bar) (Recommended cold tire inflation Trailer towing...
  • Page 395 6-1. Specifications Light bulbs Light Bulbs Bulb No. Type Headlights (low beam) 9006 Headlights (high beam) 9005  Front turn signal lights Parking and front side market  lights Exterior  Fog lights License plate lights Rear turn signal lights 7440 Back-up lights ...

  • Page 396: Fuel Information

    ASTM D4814 in the U.S.A. and CGSB3.5-M93 in Canada. Fuel tank opening for unleaded gasoline ■ To help prevent incorrect fueling, your Lexus has a fuel tank opening that only accommodates the special nozzle on unleaded fuel pumps. If premium gasoline is not available ■...
  • Page 397 Lexus allows the use of oxygenate blended gasoline where the oxygenate con- ● tent is up to 10% ethanol or 15% MTBE. If you use gasohol in your Lexus, be sure that it has an octane rating no lower ● than 87.
  • Page 398 6-1. Specifications NOTICE Notice on gasoline quality ■ Do not use leaded gasoline. ● Leaded gasoline can cause damage to your vehicle’ s three-way catalytic convert- ers causing the emission control system to malfunction. Do not use gasohol other than that stated here. ●...

  • Page 399: Tire Information

    6-1. Specifications Tire information Typical tire symbols Tire size (P. 383) DOT and Tire Identification Number (TIN) (P. 382) Location of tread wear indicators (P. 384) Tire ply composition and materials Plies are layers of rubber-coated parallel cords. Cords are the strands which form the plies in a tire.
  • Page 400 6-1. Specifications Uniform tire quality grading For details, see “Uniform tire quality grading” that follows. Typical DOT and tire identification number (TIN) DOT symbol Tire Identification Number (TIN) Tire manufacturer's identifica- tion mark Tire size code Manufacturer's optional tire type code (3 or 4 letters) Manufacturing week Manufacturing year : The DOT symbol certifies that...
  • Page 401 6-1. Specifications Tire size ■ Typical tire size information The illustration indicates typical tire size. Tire use (P = Passenger car, T = Temporary use) Section width (millimeters) Aspect ratio (tire height to section width) Tire construction code (R = Radial, D = Diagonal) Wheel diameter (inches) Load index (2 or 3 digits) Speed symbol...
  • Page 402 U.S.A. Department of Transportation. It provides the purchasers and/or prospective purchasers of Lexus vehi- cles with information on uniform tire quality grading. Your Lexus dealer will help answer any questions you may have as you read this information. ■ DOT quality grades All passenger vehicle tires must conform to Federal Safety Require- ments in addition to these grades.
  • Page 403 6-1. Specifications ■ Treadwear The treadwear grade is a comparative rating based on the wear rate of the tire when tested under controlled conditions on a specified gov- ernment test course. For example, a tire graded 150 would wear one and a half (1 - 1/2) times as well on the government course as a tire graded 100.
  • Page 404 6-1. Specifications Warning: The temperature grades for this tire are established for a tire that is properly inflated and not overloaded. Excessive speed, underinflation, or excessive loading, either separately or in combination, can cause heat buildup and possible tire failure. Glossary of tire terminology Tire related term Meaning...
  • Page 405 6-1. Specifications Tire related term Meaning The combined weight of installed regular production options weighing over 5 lb. (2.3 kg) in excess of the Production options standard items which they replace, not previously weight considered in curb weight or accessory weight, including heavy duty brakes, ride levelers, roof rack, heavy duty battery, and special trim Vehicle capacity weight...
  • Page 406 6-1. Specifications Tire related term Meaning The load on an individual tire that is determined by Vehicle maximum load on distributing to each axle its share of the maximum the tire loaded vehicle weight, and dividing by two The load on an individual tire that is determined by distributing to each axle its share of curb weight, Vehicle normal load on accessory weight, and normal occupant weight (dis-...

  • Page 407: Customization

    Your vehicle includes a variety of electronic features that can be personal- ized to your preferences. Programming these preferences requires spe- cialized equipment and may be performed by an authorized Lexus dealership. Some function settings are changed simultaneously with other functions being customized.
  • Page 408 6-2. Customization Customized Item Function Default setting setting Driver's door unlocked in All doors one step, all Unlocking using a key unlocked doors in 1-step unlocked in 2-steps Speed-detecting auto- Door lock matic door lock function  P. 5) Opening driver's door unlocks all doors Shift the shift lever to “P”...
  • Page 409 6-2. Customization Customized Item Function Default setting setting Linked door lock opera- tion Open only Linked door key opera- Open and close tion Close only Linked operation of com- Moon roof ponents when door key is Slide only Tilt only P.
  • Page 410 6-2. Customization Customized Item Function Default setting setting Windshield Switching operation when wipers and the vehicle is stationary washer Drip prevention function  P. 115) 7.5 seconds Time elapsed before lights 15 seconds turn off 30 seconds Illumination Operation when the ...

  • Page 411: Initialization

    6-3. Initialization Items to initialize The following items must be initialized for normal system operation in cases such as after the battery is reconnected, or maintenance is performed on the vehicle. Item When to initialize Reference Moon roof P. 42 •...
  • Page 412 6-3. Initialization...

  • Page 413: For Us Owners

    For US owners Reporting safety defects for U.S.A. owners......396...

  • Page 414: Reporting Safety Defects For U.s.a. Owners

    National Highway Traffic Safety Administration (NHTSA) in addition to notifying the Lexus Division of Toyota Motor Sales, U.S.A., Inc. (Toll- free: 1-800-25-LEXUS). If NHTSA receives similar complaints, it may open an investigation, and if it finds that a safety defect exists in a group of vehicles, it may order a recall and remedy campaign.

  • Page 415: Index

    Index Alphabetical index ......398 What to do if........406...

  • Page 416: Alphabetical Index

    Alphabetical index Alphabetical index A/C (Air conditioning system) ..172 Audio system ABS (Anti-lock brake system) ..142 Antenna..........193 Active traction control (TRAC)..142 Cassette player ........194 CD player/changer......197 AHC (Active Height Control Suspension) ..........130 Optimal use ......... 204 Air conditioning filter ......
  • Page 417 Alphabetical index Care Cleaning Exterior ...........260 Exterior........... 260 Interior............262 Interior .............262 Seat belts..........263 Seat belts ..........263 Card holder..........215 Clock ............223 Cargo capacity ........151 Coat hooks..........232 Compass ..........242 Cargo net hooks ........235 CD player/changer ......197 Condenser ..........283 Chains............158 Console box ..........
  • Page 418 Alphabetical index Preparing and checking Driver's seat belt reminder light ..340 Driving before winter........156 Break-in tips..........89 Engine coolant temperature Correct posture ........52 gauge ............104 Off-road precautions ......146 Engine immobilizer system ....47 Procedures..........88 Engine oil Winter driving tips......156 Capacity ..........
  • Page 419 Keys ..............2 Side mirror..........182 Wireless remote control ...... 3 Height control Active height control Lexus link system ........246 suspension...........130 Lexus night view system...... 126 Hood ............275 Licence plate lights Hooks Replacing light bulbs......320 Cargo hook ......... 235 Wattage..........377 Tie-down hooks......... 235 Light bulbs Replacing ..........320...
  • Page 420 Alphabetical index Lights Driving position memory ....21 Door courtesy lights......212 Outside temperature display ..224 Fog light switch........114 Overhead console.........217 Headlights switch ........112 Overheating, Engine ......363 Interior light switch......213 Personal light switch ......213 Parking brake.......... 103 Replacing light bulbs......320 Parking lights Turn signal lever........102 Switch............
  • Page 421 Alphabetical index Cleaning..........262 Replacing Fuses............311 Driving position memory....21 Light bulbs ..........320 Front seat adjustment ......12 Front seat adjustment Tires............346 Wireless remote control precautions..........13 battery..........309 Head restraint......... 23 Properly sitting in the seat ....52 Reporting safety defects for U.S.A. owners ........396 Rear seat adjustment......14 Roll sensing of curtain shield Rear seat adjustment...
  • Page 422 Alphabetical index Storage feature........215 Tires Stuck Chains............156 If your vehicle becomes stuck..366 Checking..........292 If you have a flat tire ......346 Sun visors ..........221 Sunshade Inflation pressure ....... 302 Roof ..............42 Information ..........381 Pressure warning system....292 Switch Driving mode select switch... 100 Replacing ..........
  • Page 423 Charging system.......338 Rear window defogger....182 Engine oil replacement Washer ............115 reminder ..........341 Windshield wipers........115 Lexus night view system....339 Wireless remote control Low fuel level........340 Replacing the battery...... 309 Low washer fluid........340 Wireless remote control ...... 3 Malfunction indicator lamp ..338 Open door ...........

  • Page 424: What To Do If

    What to do if... What to do if... A tire punctures If you have a flat tire P. 346 Engine immobilizer system P. 47 The engine does not start If the engine will not start P. 357 If the battery is discharged P.
  • Page 425 P. 338 P. 339 Variable gear ratio steering Open door warning light system warning light P. 339 P. 339 Charging system warning Lexus night view system light warning light P. 338 P. 339 Unengaged “Park” warning Low washer fluid warning light light P.
  • Page 426 GAS STATION INFORMATION Auxiliary catch lever Fuel filler door P. 275 P. 44 Hood lock release lever Fuel filler door opener Tire inflation pressure P. 275 P. 44 P. 376 Fuel tank capacity 25.4 gal. (96 L, 21.1 lmp.gal.) Fuel type Unleaded gasoline only P.

Table of Contents

Save PDF
