- Page 1 Ceramic LAM1701 LAM1702 Side Control Hob User & Installation Guide...
- Page 2 LAMONA Appliances Dear Customer, Congratulations on your choice of hob which has been designed to give you excellent service. The user manual will help you use your product quickly and safely. Please read this user manual before installing and using the hob.
- Page 3 User manual LAM1701 / LAM1702 This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved.
- Page 4 LAMONA Appliances Unattended cooking on a hob with fat or oil can be dangerous and may result in fire. NEVER try to extinguish a fire with water, but switch off the appliance and then cover flame e.g. with a lid or a fire blanket.
-
Page 5: Table Of Contents
User manual LAM1701 / LAM1702 Index 01 - Before Using the hob 02 - Safety General Fire safety advice Deep fat frying If you have an Electrical Fire 03 - Using your hob Controls Hot hob Indicator lights Heat Settings... -
Page 6: Before Using The Hob
LAMONA Appliances 01 - Before using the hob Make sure that you have removed all packaging, wrappings, stickers and from the hob surface. It is recommended that you clean and wash the hob surface before using for the time. Apply a thin coat of ceramic hob cleaner to the hob to help maintain and protect it. -
Page 7: Fire Safety Advice
User manual LAM1701 / LAM1702 Deep-fat frying presents more Never use the hob surface as a chopping board or food preparation area, as this may dangers in your kitchen lead to it becoming damaged. Never put metal cooking utensils, cutlery, knives or other metal objects on the hob. -
Page 8: Using Your Hob
LAMONA Appliances 03 - Using the hob - Side Control Ceramic Hob Do not use the ceramic hob if the glass surface is cracked, as electrical parts are directly beneath. Switch off the appliance at the supply to prevent electric shock and contact your supplier. -
Page 9: Hob Layout
User manual LAM1701 / LAM1702 Hob layout Rear Left Zone (140mm 1200w) Power on Indicator Suitable for 6” or 15cm diameter saucepan Rear right Control Knob Rear Right Zone (180mm 1700w) Suitable for 7” or 18cm diameter saucepan Rear left Control Knob... -
Page 10: Cleaning And Maintenance
LAMONA Appliances 04 - Cleaning & maintenance Ceramic glass hobs leave a ace which t av haza t av ace. spatt 06 - Installation General information Positioning Protecting the Hob cut-out tectiv ve a w heat t av type. tenance... -
Page 11: Clearances And Dimensions Requirements
User manual LAM1701 / LAM1702 Clearances and dimensions requirements Minimum distance between carcasses must be equal to width of hob 400mm min 55mm min 50mm min between hob and rear wall 560mm (>60mm to cut out aperture) 490mm 50mm Min... -
Page 12: Connect To The Electricity Supply
LAMONA Appliances Installation above an oven If the appliance is installed with an oven underneath, please leave atleast 25mm of Underside of hob ventilation, umless otherwise stated in your oven Typical Installation positions installation guidelines. Worktop 25mm oven or partition... -
Page 13: Technical Data
User manual LAM1701 / LAM1702 Technical Data Outer Dimentions Width 580mm Depth 510mm Height 71mm Cutout Dimentions Width 560mm Depth 490mm Cook Zones Hob Wattage-Front Left Ø180-1700w Hob Wattage-Rear Left Ø140-1200w Hob Wattage-Front Right Ø140-1200w Hob Wattage-Rear Right Ø180-1700w Total Electric Power... -
Page 14: Your Guarantee
LAMONA Appliances 07 - Your guarantee Product Guarantee Details (UK only) breakdown repairs. (Details of which are shown on your Proof of Purchase Document). Any claim during the period of the guarantee (MUST BE ACCOMPANIED BY THE PROOF OF PURCHASE) The product must be correctly installed and operated in accordance with the manufacturer’s... - Page 15 User manual LAM1701 / LAM1702 Product Informa on Commission Regula on (EU) No 66/2014 Model LAM1701/2 Type of hob Ceramic No of cooking zones Hea ng technology Ceramic FL - 180mm RL - 140mm FR - 140mm RR - 180mm FL - 206.93 Wh/kg...
- Page 16 LAMONA Appliances Notes...
- Page 17 User manual LAM1701 / LAM1702 Notes _ 17...
- Page 18 Issue 5 28/04/2015 If supplied, please stick your self adhesive product rating plate here, or make a note of the product serial number below in the box below for future reference. Serial Number : ...................
