Summary of Contents for Lamona LAM1742
- Page 1 Ceramic Domino LAM1742 Touch Control Hob User & Installation Guide...
- Page 2 LAMONA Appliances Dear Customer, Congratulations on your choice of hob which has been designed to give you excellent service. The user manual will help you use your product quickly and safely. • Please read this user manual before installing and using the hob.
-
Page 3: Table Of Contents
User manual LAM1742 Index 01 - Before Using the hob 02 - Safety General Fire safety advice If a pan catches fire Deep fat frying If you have an Electrical Fire 03 - Using your hob Pans Controls Heat Settings Hob Layout 04 - Cleaning and Maintenance... -
Page 4: Before Using The Hob
LAMONA Appliances 01 - Before using the hob • Make sure that you have removed all packaging, wrappings, stickers and films from the hob surface. • It is recommended that you clean and wash the hob surface before using for the first time. • Apply a thin coat of ceramic hob cleaner to the hob to help maintain and protect it. 02 - Safety This appliance is for domestic cooking •... -
Page 5: Fire Safety Advice
User manual LAM1742 Deep-fat frying presents more • Never use the hob surface as a chopping board or food preparation area, as this may dangers in your kitchen lead to it becoming damaged. • Never put metal cooking utensils, cutlery, •... -
Page 6: Using Your Hob
LAMONA Appliances 03 - Using the hob - Touch Control Ceramic Hob Turn on the appliance by selecting the start sensor Do not use the ceramic hob if the glass surface is cracked, as electrical parts are directly beneath. A (ON/OFF), ‘_’ appears on all displays for 10 seconds. -
Page 7: Heat Settings
User manual LAM1742 If the hob is turned off with the Lock function Hob Hot Function: still active, the setting remains memorised and the When a cooking zone has been used and the glass display shows the symbol upon the subsequent surface temperature is higher than 65°, it’s display... -
Page 8: Hob Layout
LAMONA Appliances Hob layout Rear Zone (180mm 1800w) Suitable for 7” or 18cm diameter saucepan Front Zone (145mm 1200w) Suitable for 6” or 15cm diameter saucepan Using the hob... -
Page 9: Cleaning And Maintenance
User manual LAM1742 04 - Cleaning & maintenance Ceramic glass hobs • The ceramic hob top can be cleaned using a • Regular cleaning will prevent any salts or clean, damp cloth or kitchen paper. Do not minerals from accumulating on your hob and use a used dishcloth or sponge as they can discolouring the glass. -
Page 10: Clearances And Dimensions Requirements
LAMONA Appliances Clearances and dimensions requirements Minimum distance between carcasses must be equal to overall width of all hobs 400mm min 150mm min between hob and rear wall (158mm min to cut out aperture) 270mm 270mm 55mm min between hob and rear wall 490mm (>60mm to cut out aperture) -
Page 11: Connect To The Electricity Supply
User manual LAM1742 Worktop 25mm Worktop oven or partition 25mm oven or partition If the installation is not above an oven and the underside of the hob is accessible, a wooden shield is required to be installed at least 15mm below the underside of the hob unit. -
Page 12: Technical Data
LAMONA Appliances Technical Data Outer Dimentions Width 290mm Depth 510mm Height 45mm Cutout Dimentions Width 270mm Depth 490mm Cook Zones Hob Wattage-Front Ø145-1200W Hob Wattage-Rear Ø180-1800W Total Electric Power 3000W Supply Voltage 230V~50Hz Fuse Protection 13 A min Cable Type HORR-F5 2.5mm ², 3 core or equivalent... -
Page 13: Your Guarantee
User manual LAM1742 06 - Your guarantee Product Guarantee Details (UK only) Your appliance has the benefit of a comprehensive manufacturer’s guarantee which covers the cost of breakdown repairs. (Details of which are shown on your Proof of Purchase Document). • Any claim during the period of the guarantee (MUST BE ACCOMPANIED BY THE PROOF OF PURCHASE) •... - Page 14 LAMONA Appliances Notes...
- Page 15 User manual LAM1742 Notes _ 15...
- Page 16 ISSUE draft 1 If supplied, please stick your self adhesive product rating plate here, or make a note of the product serial number below in the box below for future reference. Serial Number : ...................
