Viewing The Ipv4 Routing Table - HP PS110 Configuration And Administration Manual

This page includes the following information:
Status
•
RIP: The current status of RIP on the router.
•
RIPng: The current status of RIPng on the router.
IPv4 routing table
Displays the IPv4 routes statically configured or dynamically learned by the router. For a
detailed description, see
IPv6 routing table
Displays the IPv6 routes statically configured or dynamically learned by the router. For a
detailed description, see

Viewing the IPv4 routing table

The routing table shows all the current IPv4 routes used by the router, including any routes
created using static routing or RIP.
This page includes the following information:
Flags
Indicates the type of route:
•
C: A network directly connected to the router.
•
S: A route manually entered on the router.
•
R: A route dynamically learned through the RIP protocol.
Route
The destination network to which packets can be routed.
Gateway
Displays the IP address of the router at the next hop to which matching frames are forwarded.
Subnet Mask
Displays the subnetwork associated with the destination.
78 Routing configuration
"Viewing the IPv4 routing table" on page
"Viewing the IPv6 routing table" on page
78.
81.
