GV-LPR CAM 10A
Installation Guide V1.6
Before attempting to connect or operate this product,
please read these instructions carefully and save this manual for future use.
© 2012 Auguest GeoVision Inc. All rights reserved.
(Type B Model)
2012/08
English
LPRCAM10AV16-C
Models
The GV-LPR CAM is available in both EIA and CCIR video format. The camera gives a 570
TVL high-contrast license plate recognition video to the GV-LPR software that identifies license
plates. It features 7 high-efficient LEDs for an illumination range of 7 ~ 12 meters / 22.96 ~
39.37 feet. It also features a weather-sealed, IP66-compliant housing for outdoor use. This
installation guide will take you through the functionality and use of the GV-LPR CAM.
Note:
The GV-LPR CAM comes with a free GV-LPR Software, and you need to insert the supplied
GV-USB Dongle to the PC to run the software. The free GV-LPR Software is a Trial Edition.
It can only capture the license plate images and does not support the license plate
recognition function.

Packing List

AC Power Cable (110-125V, 10A) x 1
Power Adapter (100-240V, 12V/5A) x 1
Outdoor Mounting Bracket x 1
GV-LPR Software DVD
GV-USB Dongle
There are hardware types A, B and C for GV-LPR CAM 10A. Your current device is a type B.
You can find this information on your product box.
 GV-LPR CAM 10A PAL DC12V
 GV-LPR CAM 10A NTSC DC12V
 GV-LPR CAM 20A PAL DC12V
 GV-LPR CAM 20A NTSC DC12V
A
B
C

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GV-LPR CAM 10A and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for GeoVision GV-LPR CAM 10A

  • Page 1: Packing List

    ● GV-USB Dongle (Type B Model) There are hardware types A, B and C for GV-LPR CAM 10A. Your current device is a type B. You can find this information on your product box.  GV-LPR CAM 10A PAL DC12V  GV-LPR CAM 10A NTSC DC12V  GV-LPR CAM 20A PAL DC12V...
  • Page 2: Video Out

    Installing Camera Module Push the sun shield forward to align with Slightly lift the camera module and slide it Insert the video cable through the screw Loosen the screw cap on the left, insert cap and the inside rubber of the cap. the power cable through the screw cap the back of camera enclosure.
  • Page 3: Adjusting Camera Settings

    Adjusting Camera Settings Overview Shutter Speed See the lists below for shutter speed settings. Distance between the object and the Distance between the object and the camera is 550 cm (18.04 ft). camera is 1100 cm (36.08 ft). 165 SEC 145 SEC 182 SEC 150 SEC...
  • Page 4 OSD Menu Options and Functions Main Menu Sub Menu Options Function Default Main Menu Sub Menu Options Function Default Exposure Lens Manual (ELC Level) Manually adjusts the camera lens. Day & Night Auto Burst ON, OFF Automatically switches between color and B &...
  • Page 5 Installing Camera Enclosure After the installation of camera module and settings adjustment, you are now ready to install the Main Menu Sub Menu Options Function Default camera enclosure back. Camera ID 0 ~ 254 Adjust the lens focus. Lift the camera module. Title Edit l t i t...
  • Page 6: Specifications

    Specifications GV-LPR CAM 10A 1/3’’ B/W License Plate Recognition Camera Max. Power Consumption Dimensions (L x W x H) 315 x 109 x 110.2 mm / 12.40 x 4.29 x 4.34 in (with sun shield) Model GV-LPR CAM 10A EIA DC 12V...
