settings; time lock is active.
Medium:
Same as for "Low", however, settings can
also only be changed following entry of the
PIN code.
High:
Same as for "Medium", but an anti-theft
alarm is enabled as well as the PIN code
query.
VIKING recommends that the
"Low", "Medium" or "High" safety
levels be set.
● Select the required level and confirm
with OK; enter the 4-digit PIN code if
necessary.
Reset lock:
PIN code query prior to resetting the
machine to the factory defaults.
Connection lock:
PIN code query prior to linking of the
robotic mower and docking station.
Time lock:
PIN code query for changing a setting if no
PIN code has been entered for more than
one month.
Setting prot.:
PIN code query when settings are
changed.
Anti-th. alarm:
If the mower is lifted by the handle for
longer than 10 seconds, the PIN query
appears. If the PIN code is not entered
within one minute, an alarm sounds and
automatic operation is switched off.
3. Change PIN code:
The 4-digit PIN code can be
changed if required.
The "Change PIN code" menu item
is only displayed in the safety levels
"Low", "Medium" or "High".
● First enter the old PIN code and confirm
with OK.
0478 131 9920 C - EN
● Then enter the new 4-digit PIN code
and confirm with OK.
VIKING recommends making a
note of the changed PIN code.
If the PIN code is entered
incorrectly 5 times, a 4-digit Master
code is required, otherwise
automatic operation is switched off.
For creation of the master code,
you must provide your VIKING
specialist dealer with the 9-digit
serial number and the 4-digit date,
which are displayed in the selection
window.
4. Alarm signal:
For switching on and off the acoustic
signal that sounds when the robotic
mower hits an obstacle.
5. Menu signal:
For switching on and off the acoustic
click that sounds when a menu is
opened and a selection is confirmed with
OK.
6. Keylock:
When the keylock is switched on,
the buttons on the control panel
can only be operated if the Back
button is pressed and held and the
control pad is then pressed forwards.
The keylock is activated 2 minutes after
the last button has been pressed.
7. Link iMow and dock:
Following initial operation, the
robotic mower can only be operated
in conjunction with the docking station
supplied.
Following a replacement of the docking
station or of electronic components in the
robotic mower or for operation of the
robotic mower on an additional mowing
area using a different docking station, the
robotic mower and docking station must be
linked.
● Install the docking station and connect
the perimeter wire. ( 9.5), (
Lift the robotic mower slightly by the
carrying handle (1) and relieve the weight
on the drive wheels. Push the machine,
resting on its front wheels, into the docking
station.
● After pressing the OK button,
enter the PIN code. The robotic
mower will then search for the
wire signal and save it automatically.
This process takes several minutes.
( 9.8)
No PIN code is required in the
safety level "None".

10.16 Service

1. Blade change:
Installation of a new mowing blade is
confirmed with OK.
9.7)
