Owner's Manual
VGA Over Cat5 Extenders
and Extender/Splitters
Extender Kit Models:
B130-101A-MR and B130-101A-SR
Transmitter Unit Models:
B132-002A-2 and B132-004A-2
Receiver Unit Models:
B132-100A-MR, B132-100A-SR and B132-200A-SR
1111 W. 35th Street, Chicago, IL 60609 USA • www.tripplite.com/support
Copyright © 2015 Tripp Lite. All rights reserved.
All trademarks are the sole property of their respective owners.
1
15-04-118-9333BE.indd 1
4/8/2015 10:35:08 AM
Advertisement
Table of Contents
Related Manuals for Tripp Lite B130-101A-MR
Summary of Contents for Tripp Lite B130-101A-MR
- Page 1 Receiver Unit Models: B132-100A-MR, B132-100A-SR and B132-200A-SR 1111 W. 35th Street, Chicago, IL 60609 USA • www.tripplite.com/support Copyright © 2015 Tripp Lite. All rights reserved. All trademarks are the sole property of their respective owners. 15-04-118-9333BE.indd 1 4/8/2015 10:35:08 AM...
-
Page 2: Table Of Contents
Table of Contents Package Contents Mounting Hardware Instructions Product Features Installation EDID Copy B130-101A-MR Extender Kit Installation B130-101A-SR Non-Kit Standard Installation B132-002A-2 Non-Kit Daisy Chain Installation 13 B132-004A-2 B132-100A-MR Troubleshooting B132-100A-SR Warranty and Product B132-200A-SR Registration Optional Accessories Additional Warnings and... -
Page 3: Product Features All
• All operating systems supported. • Plug and play; no software or drivers required. • HDCP compliant. B130-101A-MR • Extends a 1920 x 1080 video signal up to 300 ft. or a 1024 x 768 video signal up to 750 ft. -
Page 4: B132-004A-2
• Includes mounting hardware that allows unit to be wall-mounted, rack mounted or pole mounted. • Up to three local units can be connected to a Tripp Lite B132-004-RB rackmount bracket and mounted in just 1U of rack space. • EDID copy feature ensures optimal display compatibility. -
Page 5: B132-100A-Sr
Product Features continued B132-100A-SR • Works with the B132-002A-2 and B132-004A-2 transmitter units to extend a VGA video and audio signal. • Extends a 1440 x 900 video signal up to 150 ft. or a 1024 x 768 video signal up to 300 ft. •... -
Page 6: Mounting Hardware
Note: The images below show a B140-101X DVI Extender, but mounting is the same for the VGA Extenders. The B132-004A-2 can also be mounted to a Tripp Lite B132-004-RB 1U rackmount bracket. Up to three B132-004A-2 local units can be connected to a B132-004-RB. -
Page 7: Installation
EDID Copy section above. If using a B132-002A-2 or B132-004A-2 model, connect the powered-on monitor to the input port of the transmitter unit. For the B130-101A-MR and B130-101A-SR, connect the built-in VGA cable on the transmitter unit to the powered-on monitor. 15-04-118-9333BE.indd 7... - Page 8 If using a B132-002A-2 or B132-004A-2 model, connect the external power supply to the unit and plug it into a Tripp Lite Surge Protector, Power Distribution Unit (PDU) or Uninterruptible Power Supply (UPS). For the B130-101A-MR and B130-101A-SR models, connect the included Micro USB cable to the unit and plug it into the USB port on a computer or a USB wall outlet.
-
Page 9: Extender Kit Installation
All Tripp Lite N202-Series cables are made with 24 AWG solid-wire cabling. Tripp Lite N022-01K-GY (Cat5e) and N222-01K-GY (Cat6) are 24 AWG solid-wire bulk cables. For optimal image quality, use Zero-Skew cable such as Tripp Lite P524-01K. Make sure the VGA and audio source is powered off. - Page 10 Installation continued Connect a 3.5 mm audio cable from the receiver unit to the monitor or external speakers. Use the included Micro USB cable to connect the receiver unit with a USB port on the monitor or USB wall outlet. Turn on the power to the computer, monitor and speakers.
-
Page 11: Non-Kit Standard Installation
All Tripp Lite N202-Series cables are made with 24 AWG solid-wire cabling. Tripp Lite N022-01K-GY (Cat5e) and N222-01K-GY (Cat6) are 24 AWG solid-wire bulk cables. For optimal image quality, use Zero-Skew cable such as Tripp Lite P524-01K. 5. To achieve maximum resolution, it is recommended that you use Tripp Lite P502-Series VGA video or P504-Series VGA video and audio cables with RGB coax. - Page 12 LOCAL port(s) on the transmitter unit. Connect the external power supply to the transmitter unit, then plug it into a Tripp Lite Surge Protector, Power Distribution Unit (PDU) or Uninterruptible Power Supply (UPS). Using Cat5e/6 cable, connect an available RJ45 OUTPUT port on the transmitter unit to the RJ45 INPUT port on a receiver unit (see Product Features section for your model’s max distance information).
-
Page 13: Non-Kit Daisy Chain Installation
All Tripp Lite N202-Series cables are made with 24 AWG solid-wire cabling. Tripp Lite N022-01K-GY (Cat5e) and N222-01K-GY (Cat6) are 24 AWG solid-wire bulk cables. For optimal image quality, use Zero-Skew cable such as Tripp Lite P524-01K. 4. To achieve maximum resolution, it is recommended that you use Tripp Lite P502-Series VGA video or P504-Series VGA video and audio cables with RGB coax. - Page 14 Connect the external power supply to the first transmitter unit in the installation, and then plug it into a Tripp Lite Surge Protector, Power Distribution Unit (PDU) or Uninterruptible Power Supply (UPS). Repeat step 6 for each additional transmitter unit in the installation.
- Page 15 USB wall outlet. (B132-200A-SR) – Connect the external power supply to the receiver unit, then plug it into a Tripp Lite Surge Protector, Power Distribution Unit (PDU), or Uninterruptible Power Supply (UPS). Repeat steps 10 and 11 for each receiver unit in the installation.
-
Page 16: Troubleshooting
Mirror the image on both displays. 4. Compatibility issues can occur when EDID information is not properly communicated between the source and the display. Tripp Lite’s VGA over Cat5 extender products include an EDID copy feature which stores a monitor’s EDID information and sends it to the source, ensuring optimal compatibility. - Page 17 Series VGA + audio cables, as they have been tested to work with Tripp Lite’s VGA over Cat5 extender products. 8. Is your Cat5e/6 cabling wired to TIA 568B? Tripp Lite’s VGA over Cat5 extender products have been tested using Cat5e/6 cabling wired to TIA 568B (all Tripp Lite Cat5e/6 cables are wired to TIA 568B).
-
Page 18: Warranty And Product
TRIPP LITE warrants its products to be free from defects in materials and workmanship for a period of one (1) year from the date of initial purchase. TRIPP LITE’s obligation under this warranty is limited to repairing or replacing (at its sole option) any such defective products. To obtain service under this warranty, you must obtain a Returned Material Authorization (RMA) number from TRIPP LITE or an authorized TRIPP LITE service center. -
Page 19: Additional Warnings And
• Consult the dealer or an experienced radio/TV technician for help. Any changes or modifications to this equipment not expressly approved by Tripp Lite could void the user’s authority to operate this equipment. WEEE Compliance Information for Tripp Lite Customers and Recyclers (European Union) - Page 20 1111 W. 35th Street, Chicago, IL 60609 USA • www.tripplite.com/support 15-04-118 93-33BE_RevB 15-04-118-9333BE.indd 20 4/8/2015 10:35:11 AM...
