NX7700i/5080H-64, NX7700i/5040H-32
CAUTION
Before using the product, be sure to read this manual and strictly
adhere to the instructions.
Keep this manual at hand for quick reference as required.
©NEC Corporation 2006
This manual cannot be duplicated or revised without permission from NEC Corp.
The contents of this manual may be changed without prior notice.
855-900547-200-A
Rev. １
TX7/i9610
Operation Manual
NEC Corporation
