4. OPERATION
This section describes how to select a computer or video source, ad-
just the picture and sound, edit a signal and adjust all other settings
and adjustments for proper projector set-up.
General Controls
Before you turn on the projector ensure that the computer or video
source is turned on and that the lens cap is removed.
1. Turn On The Projector
Plug the supplied power cable into the AC outlet. The main power
switch is on the rear panel of the projector. By turning this switch
on, the projector will go into its standby mode and the POWER
indicator will glow amber. Only after you press the 'POWER ON'
button on the remote control or projector cabinet will the POWER
light turn to green and the projector will fully turn on.
2. Select The Computer Or Video Source
Press the INPUT button on the remote control to select the desired
source. Or press the MENU button on the remote control and use
the Source Select to select your video source: Video, S-Video, RGB,
Y/Cr/Cb, RGB Digital or SDI.
3. Adjust The Image
Press the ADJUST PICTURE button or the ADJUST WHITE BAL
on the remote control or use the [Main menu]->[Adjustments] to
adjust the picture.
4. Turn Off The Projector
First press the POWER OFF button on the remote control or the
projector cabinet. Allow the fan to cool the projector for three min-
utes. This will extend the life of the lamp. After the cooling fan
stops working, the POWER indicator will change to a steady amber
glow and the projector will be in the stand-by mode. Then turn off
the main power switch on the rear panel. The POWER indicator
will go out. If you desire to move the projector then unplug the
power cable.
IMPORTANT:
• The projector should be unplugged if it will not be used for an ex-
tended period.
• If you want to turn off the image briefly (five minutes or less), press
the MUTE PICTURE button instead of turning the projector off
and on.
• The projector will display a black, blue image or logo if no input
signal is present.
• Do not turn the projector off and then immediately back on. The
Projector needs to cool down for three minutes before it is powered
on again.
CAUTION: Do not turn off the main power while the cooling fan
is working.
Using The Menus
1. Press the MENU button on the remote control to display the Main
menu.
2. Use the
or
button on the remote control to select the sub
menu.
3. The right-oriented delta symbol indicates further choices are avail-
able. Press the
button to highlight the item you want to adjust
or set in the selected menu.
4. Press the
or
button on the remote control to select the item.
5. Press the ENTER button on the remote control to display the ad-
justment screen or dialog box.
6. Adjust the level or turn the selected item on or off by using
on the remote control. The on-screen slide bar will show you the
amount of increase or decrease.
NOTE: The change is stored automatically when any one of the
following procedures is performed:
* The on-screen dissapears.
* The projector goes into standby.
* One input is switched to another.
7. Repeat steps 2-5 to adjust an additional item, or press the CANCEL
button on your remote control to quit.
Using the Magifying Glass Icon
When the image is magnified with the MAGNIFY button on the re-
mote control, pressing CTL and any one of
play the magnifying glass icon.
At this time you can select any part of the screen and expand it.
To move the magnifying glass icon, use , ,
Press CTL and any one of
glass icon will disappear.
E – 29
,
,
, or
,
.
,
,
, or
again and the manifying
or
will dis-
