DISPLAY PROTECTION

POWER SAVE
All inputs except for TV*
STANDBY MODE
HEAT STATUS
FAN CONTROL
SCREEN SAVER
GAMMA
BRIGHTNESS
MOTION
SIDE BORDER COLOR
AUTO BRIGHTNESS
DVI, VGA, RGB/HV inputs only
CHANGE SECURITY
PASSWORD
SECURITY LOCK
DDC/CI
DISPLAY PROTECTION
RESET

ADVANCED OPTION

INPUT DETECT
All inputs except for TV*
NONE
FIRST DETECT
LAST DETECT
VIDEO DETECT
CUSTOM DETECT
INPUT CHANGE
LONG CABLE COMP
EQUALIZE
VGA, RGB/HV inputs only
POLE
PEAK
*: The product you purchased may not have this feature.
Sets how long the monitor waits to go into power save mode after a lost signal.
Note: When connecting DVI, video card might not stop sending digital data even if image has
disappeared. In this case the monitor does not get to power management mode.
Lowers power consumption.
Note: RS-232C and LAN Function are lost when in Eco Standby mode.
Displays status of the FAN, BRIGHTNESS and TEMPERATURE.
Cooling fan reduces the temperature of the display to protect from overheating.
If "AUTO" is selected, you can adjust the start temperature of the cooling fan and fan speed.
Use the SCREEN SAVER function to reduce the risk of Image Persistence.
The display gamma is changed and fixed when "ON" is selected.
The brightness is decreased when "ON" is selected.
NOTE: Do not select this function when picture model is AMBIENT1 or AMBIENT2.
The screen image is slightly expanded and moves in 4 directions (UP, DOWN, RIGHT, LEFT)
at user determined intervals. You can set interval time and zooming ratio.
Adjusts the color of the side borders when a 4:3 image is displayed.
Press + button, the bar will become lighter.
Press - button, the bar will become darker.
Adjusts the brightness level according to the input signal.
NOTE: Do not select this function when picture model is AMBIENT1 or AMBIENT2.
Allows the security password to be changed.
The factory preset password is 0000.
Locks the security password.
ENABLE/DISABLE: Turns On or OFF the two way communication and control of the monitor.
Resets the following settings within the DISPLAY PROTECTION menu back to factory setting:
POWER SAVE, STANDBY MODE, FAN CONTROL, SCREEN SAVER, SIDE BORDER COLOR,
AUTO BRIGHTNESS, DDC/CI.
Selects the method of input detection the monitor uses when more than two input devices
are connected.
The Monitor will not search the other video input ports.
When the current video input signal is not present, then the monitor searches for a video signal
from the other video input port. If the video signal is present in the other port, then the monitor
switches the video source input port to the new found video source automatically.
The monitor will not look for other video signals while the current video source is present.
When the monitor is displaying a signal from the current source and a new secondary source
is supplied to the monitor, the monitor will automatically switch to the new video source.
When current video input signal is not present, the monitor searches for a video signal from
the other video input port. If the video signal is present in the other port, then the monitor
switches the video source input port to the new found video source automatically.
DVD/HD1, DVD/HD2, SCART, VIDEO1, VIDEO2 or S-VIDEO inputs will have priority over
DVI, VGA, RGB/HV. When DVD/HD1, DVD/HD2, SCART, VIDEO1, VIDEO2 or S-VIDEO
input signal is present the monitor will change and keep to the DVD/HD1, DVD/HD2, SCART,
VIDEO1, VIDEO2 or S-VIDEO input.
Set the priority of input signals.
When CUSTOM DETECT is selected, monitor searches listed inputs only.
Sets input change speed.
NOTE: When "QUICK" is selected, picture may be distorted when signal input is changed.
Manually compensates for image degradation caused from using a long cable.
Adjusts frequency.
Adjusts equalizing value.
English-24
ON
STANDBY
-
AUTO
OFF
OFF
OFF
15
OFF
-
OFF
ENABLE
-
FIRST DETECT
NORMAL
OFF
0
0
