Quick Start
Tilt
Grasp both sides of the monitor screen with
your hands and adjust the tilt as desired
(Figure TS.1).

Remove Monitor Stand for Mounting

To prepare the monitor for alternate mounting
purposes:
1. Remove the connector cover and
the cable cover (Figure R.1).
2. Disconnect all cables.
3. Place monitor face down on a
non-abrasive surface
(Figure R.2).
4. Remove the 4 screws
connecting the monitor to the
stand and lift off the stand
assembly (Figure R.2).
The monitor is now ready for
mounting in an alternate
manner.
5. Connect the AC cord and signal cable to the back of the monitor (Figure
R.3).
6. Reverse this process to reattach stand.
NOTE: Use only VESA-compatible alternative mounting method.
Figure R.2
Non-abrasive surface
–continued
5
Figure TS.1
Figure R.1
Figure R.3
