DVD DECK EXPLODED VIEW (TOP VIEW)
600
AB
703
CLASS
PART NO.
GREASE
Y315061000
Y315121000
625
620
616
AB
704
612
623
619
621
611
604
703
PART NAME
MARK
AA
G-555G
SF-112
AB
603
622
605
AB
AB
617
NOTE:
Applying positions AA and AB for the grease are
displayed for this section.
Check if the correct grease is applied for each p
osition.
